Avalon, Camry, Celica & Corolla
Measure front riding height from ground to center of lower control arm mounting bolt/nut. Measure rear riding height from ground to center of forward strut rod mounting bolt. Strut rod is parallel to side body panel.
Land Cruiser/LX470
On 1997 models, measure riding height at specified locations. (Scheme 1) Dimension "A" is follow spring clearance. Dimension "B" is bumper stopper clearance.
On 1998 models, front riding height specification is difference between spindle center height and lower control mounting bolt center height. Rear riding height specification is difference between rear axle shaft center height and trailing arm front mount bolt center height.
Scheme 1
Scheme 1: Land Cruiser/LX470
Paseo, Sienna & Tercel
Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of rear lower control arm forward mounting bolt.
RAV4
Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of body side No. 1 suspension arm mounting bolt.
Supra
Measure front riding height from ground to center of lower suspension arm mounting bolt. Measure rear riding height from ground to center of No. 2 lower suspension arm mounting bolt.
Tacoma, T100 & 4Runner
- Measure front riding height by subtracting height at center of lower arm adjuster cam bolt from height at center tip of spindle. (Scheme 2)
- Measure rear riding height by subtracting height at center of front leaf spring mounting bolt from height at center line of rear axle shaft. The difference between measurements is riding height.
Scheme 2
CARS
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| Avalon | 8.43 (214) | 10.47 (266) |
| Camry |
| P195/70R14 | 8.35 (212) | 10.39 (264) |
| P205/65R15 | 8.46 (215) | 10.49 (266) |
| Celica |
| P185/70R14 | 7.39 (187.6) | 10.07 (255.8) |
| P205/75R15 | 7.19 (182.6) | 9.84 (250) |
| Corolla |
| 175/65R14 | 7.28 (185) | 9.65 (245) |
| 185/65R14 (85S) | 7.48 (190) | 9.84 (250) |
| Paseo (185/60R14) | 7.40 (188) | 9.80 (249) |
| Supra |
| Non-Turbo | 7.32 (186) | 9.68 (246) |
| Turbo | 7.40 (188) | 10.00 (254) |
| Tercel |
| 155SR13 | 7.63 (194) | 9.92 (252) |
| 175/65R14 | 7.76 (197) | 9.96 (253) |
| 185/60R14 | 7.56 (192) | 9.84 (250) |
RIDING HEIGHT SPECIFICATIONS (CARS)
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 1997 | 1.42 (36) | 4.09 (104) |
| 1998 | 2.80 (71) | 2.01 (51) |
RIDING HEIGHT SPECIFICATIONS (LAND CRUISER/LX470)
PREVIA
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| P205/75R14 | 9.37 (238) | 11.06 (281) |
| P215/65R15 | 9.33 (237) | 10.98 (279) |
RIDING HEIGHT SPECIFICATIONS (PREVIA)
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 2WD (215/70R16) | 8.94 (227) | 13.90 (353) |
| 4WD |
| 215/70R16 | 9.33 (237) | 14.17 (360) |
| 235/60R16 | 8.58 (218) | 13.62 (346) |
RIDING HEIGHT SPECIFICATIONS (RAV4)
SIENNA
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 205/70R15 | 9.06 (230) | 12.76 (324) |
| 215/65R15 | 8.90 (226) | 12.60 (320) |
RIDING HEIGHT SPECIFICATIONS (SIENNA)
TACOMA 2WD
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 1997-98 |
| 2.4L Reg Cab | 1.73 (44) | 2.40 (61) |
| 2.4L Xtra Cab | 1.69 (43) | 2.68 (68) |
| 3.4L Xtra Cab | 1.69 (43) | 2.40 (61) |
RIDING HEIGHT SPECIFICATIONS (TACOMA 2WD)
TACOMA 4WD
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 1997 |
| RZN161L-TRMDKAB | 1.89 (48) | 1.50 (38) |
| RZN161L-TRPDKAB | 1.89 (48) | 1.50 (38) |
| VZN160L-TRMDKAB | 1.89 (48) | 1.50 (38) |
| RZN171L-CRMDKAB | 1.73 (44) | 1.34 (34) |
| RZN171L-CRPDKAB | 1.73 (44) | 1.34 (34) |
| VZN170L-CRMDKAB | 1.73 (44) | 1.38 (35) |
| VZN170L-CRPDKAB | 1.73 (44) | 1.38 (35) |
| VZN170L-CRMGKAB | 1.73 (44) | 1.34 (34) |
| VZN170L-CRPGKAB | 1.73 (44) | 1.34 (34) |
| 1998 |
| 2.7L Reg Cab | 1.90 (49) | 1.38 (35) |
| 2.7L Xtra Cab | 1.89 (48) | 1.89 (48) |
| 3.4L Xtra Cab | 1.89 (48) | 1.97 (50) |
RIDING HEIGHT SPECIFICATIONS (TACOMA 4WD)
T100 2WD
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 1997-98 |
| RCK10L-TRMRKA |
| P215/75R15 | 1.79 (45.4) | 2.40 (60.9) |
| P235/75R15 | 1.79 (45.4) | 2.36 (59.9) |
| RCK10L-TRSRKA |
| P215/75R15 | 1.79 (45.4) | 2.43 (61.8) |
| P235/75R15 | 1.79 (45.4) | 2.40 (60.9) |
| VCK11L-TRMDKA |
| P215/75R15 | 1.89 (48.0) | 2.43 (61.8) |
| P235/75R15 | 1.89 (48.0) | 2.39 (60.7) |
| VCK11L-THMDKA |
| 1-Ton | 1.94 (49.3) | 1.37 (34.9) |
| VCK11L-TRSDKA |
| P215/75R15 | 1.97 (49.9) | 2.48 (62.9) |
| P235/75R15 | 1.97 (49.9) | 2.44 (62.0) |
| VCK11L-THSDKA |
| 1-Ton | 1.97 (49.9) | 1.41 (35.7) |
| VCK11L-CRMDKA |
| P215/75R15 | 1.53 (38.8) | 1.78 (45.3) |
| P235/75R15 | 1.53 (38.8) | 1.77 (44.3) |
| VCK11L-CRMSKA |
| P235/75R15 | 1.53 (38.8) | 1.80 (45.6) |
| VCK11L-CRSDKA |
| P215/75R15 | 1.53 (38.8) | 1.82 (46.2) |
| P235/75R15 | 1.53 (38.8) | 1.78 (45.3) |
| VCK11L-CRSSKA |
| P235/75R15 | 1.53 (38.8) | 1.83 (46.5) |
RIDING HEIGHT SPECIFICATIONS (T100 2WD)
T100 4WD
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 1997-98 |
| VCK21L-TRMDKA |
| P235/75R15 | 1.52 (38.5) | 2.85 (72.3) |
| P265/75R16 | 1.52 (38.5) | 2.91 (74.0) |
| VCK21L-TRSDKA |
| P235/75R15 | 1.58 (40.2) | 2.80 (71.1) |
| P265/75R16 | 1.58 (40.2) | 2.87 (72.8) |
| VCK21L-CRMKA |
| P235/75R15 | 1.28 (32.5) | 3.13 (79.4) |
| P265/75R16 | 1.28 (32.5) | 3.21 (81.6) |
| VCK21L-CRSKA |
| P235/75R15 | 1.28 (32.5) | 3.08 (78.3) |
| P265/75R16 | 1.28 (32.5) | 3.17 (80.6) |
RIDING HEIGHT SPECIFICATIONS (T100 4WD)
4RUNNER
| Application | Front: In. (mm) | Rear: In. (mm) |
|---|
| 1997-98 |
| P225/75R15 | 2.74 (69.6) | 1.95 (49.6) |
| P265/70R16 | 1.87 (47.5) | 1.16 (29.4) |
RIDING HEIGHT SPECIFICATIONS (4RUNNER)
To raise vehicle front, place floor jack under center of front longitudinal engine crossmember. For vehicle rear, place floor jack under rear suspension crossmember.
Place floor jack under front and/or rear differential to raise vehicle.
To raise vehicle, place floor jack under front undercover support and/or rear suspension crossmember.
Paseo & Tercel
To raise vehicle, place floor jack under front crossmember and/or center of rear axle beam.
Previa, Sienna, Tacoma, T100 & 4Runner
To raise vehicle, place floor jack under front crossmember and/or rear axle housing/differential.
To raise vehicle, place floor jack under front suspension crossmember and/or rear differential carrier.
Avalon, Camry, Celica, Corolla, Paseo, RAV4, Supra & Tercel
Place emergency jack on reinforced support points of side body panel (between front and rear wheels). Safety stands may also be placed at these points. (Scheme 3)
To raise vehicle, place emergency jack under front and/or rear axle.
Place emergency jack under front suspension crossmember and/or rear axle housing/differential.
To raise vehicle, place emergency jack under frame support points between front and/or rear wheels.
Scheme 3
Place lift blocks on reinforced support points of side body panel (between front and rear wheels). Safety stands may also be placed at these points. (Scheme 3)
Place lift blocks under front and rear axles to raise vehicle.
On 2WD models, place lift blocks under frame side rail and rear axle housing to raise vehicle. On 4WD models, place lift blocks under front suspension crossmember and rear axle housing to raise vehicle.
Previa & Sienna
Place lift blocks under frame side rail supports.
TURNING ANGLE
On Land Cruiser/LX470, Previa, T100 and 4Runner, remove steering knuckle stopper bolt caps. On all models, turn steering wheel fully right and then left, and observe turning radius on both wheels. If turning radius is incorrect, inspect and replace any damaged or worn front suspension components. See ALIGNMENT SPECIFICATIONS .
Front Suspension (Avalon, Camry, Celica, Corolla, Land Cruiser
Cruiser, Paseo, Previa, RAV4, Sienna & Tercel)
1) Check tires for wear and improper inflation. Inspect front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed .039" (1.0 mm) on Avalon, Camry, Celica, Corolla and RAV4, .055" (1.4 mm) on Paseo, Previa and Tercel, or .118" (3.0 mm) on Land Cruiser/LX470.
2) Inspect front suspension components for looseness. Ensure front shock absorbers work properly. Measure vehicle riding height. See RIDING HEIGHT ADJUSTMENT .
3) Measure camber of both front wheels. See ALIGNMENT SPECIFICATIONS . If camber is not within specification, inspect and replace any damaged or worn front suspension components. Camber is not adjustable on all models listed except Sienna. On Sienna, loosen lower strut mounting bolts and move steering knuckle until camber is within specification. Tighten bolts to specification. See TORQUE SPECIFICATIONS .
Front Suspension (Tacoma, T100 & 4Runner)
- Check tires for wear and improper inflation. Inspect front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed.118" (3.0 mm).
- Inspect front suspension components for looseness. Ensure front shock absorbers work properly. Measure vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(ref-62274-S29475865862001100400000).
- Measure camber of both front wheels. If camber is not within specification, add or remove shims on upper suspension arms on 2WD models. On 4WD models, loosen and rotate adjuster cams. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). (Scheme 4)
Scheme 4
Front Suspension (Supra)
- Check tires for wear and improper inflation. Inspect front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed.055" (1.4 mm).
- Inspect front suspension components for looseness. Ensure front shock absorbers work properly. Measure vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(ref-62274-S29475865862001100400000).
- Measure camber of both front wheels. If camber is not within specification, remove engine undercover. Remove front lower arm bracket strut. Loosen adjuster cam lock nuts. Rotate adjuster cams as necessary. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). (Scheme 5) Tighten lock nuts to specification. See «TORQUE SPECIFICATIONS»(ref-62274-S39868646722001100400000).
Scheme 5
Rear Suspension (Avalon, Camry, Celica & Corolla)
Check tires for wear and improper inflation. Measure camber of both rear wheels. See ALIGNMENT SPECIFICATIONS . If camber is not within specification, inspect and replace any damaged or worn rear suspension components. Camber is not adjustable.
Rear Suspension (RAV4)
Check tires for wear and improper inflation. Check camber of both rear wheels. See ALIGNMENT SPECIFICATIONS . If camber is not within specification, adjust camber by rotating adjuster cams.
Rear Suspension (Supra)
Check tires for wear and improper inflation. Ensure lengths of left and right No. 1 and No. 2 lower suspension arms are equal. (Scheme 6) Check camber of both rear wheels. See ALIGNMENT SPECIFICATIONS. If camber is not within specification, adjust camber by rotating adjuster cams.
Scheme 6
Scheme 6: Rear Suspension (Supra)
Front Suspension (Avalon, Camry, Celica, Corolla, Land
Cruiser, Paseo, Previa, RAV4, Sienna & Tercel)
Measure caster of both front wheels. If caster is not within specification, inspect and replace any damaged or worn front suspension components. Caster is not adjustable.
- Measure riding height, camber, and steering axis inclination. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). If adjustment is necessary, see appropriate adjustment procedure.
- Measure caster of both front wheels. If caster is not within specification, add or remove shims on upper control arms on 2WD models. On T100 2WD, adjust shim thickness between front and rear locations to within.16" (4 mm). If measurement cannot be met, adjust strut rod length by adjusting strut rod nuts. (Scheme 7) On 4WD models, loosen and rotate adjuster cams. (Scheme 4)
Scheme 7
- Measure riding height, camber, and steering axis inclination. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). If adjustment is necessary, see appropriate adjustment procedure.
- Measure caster of both front wheels. If caster is not within specification, remove engine undercover. Remove front lower arm bracket strut. Loosen adjuster cam lock nuts. Rotate adjuster cams as necessary. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). (Scheme 5) Tighten lock nuts to specification. See «TORQUE SPECIFICATIONS»(ref-62274-S39868646722001100400000).
Except Supra
Measure riding height and camber. See ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Measure steering axis inclination of both front wheels. If steering axis inclination is not within specification, inspect and replace any damaged or worn front suspension components. See ALIGNMENT SPECIFICATIONS . Steering axis/king pin inclination is not adjustable.
Measure riding height, camber, and caster. See ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Measure steering axis inclination of both front wheels. If steering axis inclination is not within specification, inspect wheel bearing for looseness, or replace steering knuckle. See ALIGNMENT SPECIFICATIONS . Steering axis/king pin inclination is not adjustable.
Front Suspension
Measure riding height, camber, steering axis inclination, and caster. See ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Set front wheels to straight-ahead position. Bounce both ends of vehicle several times to settle suspension. Measure toe-in. If necessary, adjust toe-in by changing length of tie rods.
- Measure rear camber. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). If adjustment is necessary, see appropriate adjustment procedure.
- Bounce both ends of vehicle several times to settle suspension. Measure length of left and right No. 2 suspension arms. (Scheme 8) Ensure lengths of both arms are equal within.039" (1.0 mm).
- If toe-in is not within specification, adjust toe-in by rotating rear toe adjuster sleeves, located on No. 2 suspension arms. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). Tighten lock nuts to specification after adjustment. See «TORQUE SPECIFICATIONS»(ref-62274-S39868646722001100400000).
Scheme 8
Rear Suspension (Land Cruiser/LX470, Paseo, Previa, Sienna
Measure rear wheel toe-in. If toe-in is not within specification, inspect and replace any damaged or worn suspension components. See ALIGNMENT SPECIFICATIONS . Rear toe-in is not adjustable.
- Measure rear camber. See «CAMBER ADJUSTMENT»(ref-62274-S18873510912001100400000) under ADJUSTMENTS. Bounce both ends of vehicle several times to settle suspension.
- Measure toe-in. If toe-in is not within specification, adjust by rotating adjuster cams. See «ALIGNMENT SPECIFICATIONS»(ref-62274-S35426282502001100400000). (Scheme 6)
AVALON
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.62 | 1.37 To 0.13 |
| Rear | 0.77 | 1.52 To -0.02 |
| Caster (1) |
| Front | 2.18 | 1.43 To 2.93 |
| Rear | N/A | N/A |
| Steering Axis Inclination (1) | 13.07 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.16 (4) | 0.08 To 0.24 (2 To 6) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.4 | 0.2 To 0.6 |
| Toe-Out On Turns (1) |
| Inner | 35.78 | N/A |
| Outer | 31.42 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (AVALON)
CAMRY
| Application | Preferred | Range |
|---|
| 4-Cylinder |
| Camber (1) |
| Front | 0.6 | 1.35 To 0.15 |
| Rear | 0.7 | 1.45 To 0.05 |
| Caster (1) |
| Front | 2.17 | 1.42 To 2.92 |
| Rear | N/A | N/A |
| Steering Axis Inclination (1) | 13.02 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.16 (4) | 0.08 To 0.24 (2 To 6) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.4 | 0.2 To 0.6 |
| Toe-Out On Turns (1) (3) |
| Inner | 37.20 | N/A |
| Outer | 32.35 | N/A |
| V6 |
| Camber (1) |
| Front | 0.62 | 1.37 To 0.13 |
| Rear | 0.75 | 1.5 To 0 |
| Caster (1) |
| Front | 2.18 | 1.43 To 2.93 |
| Rear | N/A | N/A |
| Steering Axis Inclination (1) | 13.7 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.16 (4) | 0.08 To 0.24 (2 To 6) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.4 | 0.2 To 0.6 |
| Toe-Out On Turns (1) (3) |
| Inner | 37.20 | N/A |
| Outer | 32.35 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). (3) If vehicle is equipped with P205/65R15 tires, inner is 35.78 degrees, outer is 31.42 degrees. |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
| (3) | If vehicle is equipped with P205/65R15 tires, inner is 35.78 degrees, outer is 31.42 degrees. |
WHEEL ALIGNMENT SPECIFICATIONS (CAMRY)
CELICA
| Application | Preferred | Range |
|---|
| 1.8L |
| Camber (1) |
| Front | 0.85 | 1.6 To -0.1 |
| Rear | 1.27 | 2.02 To 0.52 |
| Caster (1) | 2.12 | 1.37 To 2.87 |
| Steering Axis Inclination (1) | 15.1 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.14 (3.5) | 0.06 To 0.22 (1.5 To 5.5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.35 | 0.15 To 0.55 |
| Toe-Out On Turns (1) |
| Inner | 36.73 | N/A |
| Outer | 30.63 | N/A |
| 2.2L |
| Camber (1) |
| Front | 0.77 | 1.52 To -0.02 |
| Rear | 1.17 | 1.92 To 0.42 |
| Caster (1) | 2.08 | 1.33 To 2.83 |
| Steering Axis Inclination (1) | 14.97 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.14 (3.5) | 0.06 To 0.22 (1.5 To 5.5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.35 | 0.15 To 0.55 |
| Toe-Out On Turns (1) |
| Inner | 36.9 | N/A |
| Outer | 30.73 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (CELICA)
COROLLA
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.18 | 0.93 To 0.57 |
| Rear | 0.92 | 1.67 To 0.17 |
| Caster (1) | 1.32 | 0.57 To 2.07 |
| Steering Axis Inclination (1) | 12.63 | N/A |
| Toe-In (2) |
| Front | 0.04 (1) | 0.04 To 0.12 (-1 To 3) |
| Rear | 0.16 (3) | 0.08 To 0.24 (2 To 6) |
| Toe-In (1) |
| Front | 0.10 | 0.1 To 0.3 |
| Rear | 0.4 | 0.2 To 0.6 |
| Toe-Out On Turns (1) (3) |
| Inner | 39.22 | N/A |
| Outer | 33.37 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). (3) If vehicle is equipped with manual steering, inner is 39.02 degrees, outer is 33.37 degrees. |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
| (3) | If vehicle is equipped with manual steering, inner is 39.02 degrees, outer is 33.37 degrees. |
WHEEL ALIGNMENT SPECIFICATIONS (COROLLA)
| Application | Preferred | Range |
|---|
| 1997 |
| Camber (1) |
| Front | 1 | 0.25 To 1.75 |
| Caster (1) | 3 | 2 To 4 |
| Steering Axis Inclination (1) | 13 | N/A |
| Toe-In (2) | 0.08 (2) | 0.04 To 0.12 (1 To 3) |
| Toe-In (1) | 0.2 | 0.1 To 0.3 |
| Toe-Out On Turns (1) |
| Inner | 35.5 | N/A |
| Outer | 31 | N/A |
| 1998 |
| Camber (1) |
| Front | .08 | 0.67 To 0.83 |
| Caster (1) | 2.5 | 1.75 To 3.25 |
| Steering Axis Inclination (1) | 12.17 | N/A |
| Toe-In (2) | 0.04 (1) | 0.04 To 0.12 (-1 To 3) |
| Toe-In (1) | 0.1 | 0.1 To 0.3 |
| Toe-Out On Turns (1) |
| Inner | 35.2 | N/A |
| Outer | 32.6 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (LAND CRUISER/LX470)
PASEO
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.42 | 1.17 To 0.33 |
| Rear | 0.5 | 1.25 To 0.25 |
| Caster (1) | 1.5 | 0.75 To 2.25 |
| Steering Axis Inclination (1) | 12.25 | N/A |
| Toe-In (2) |
| Front | 0.04 (1) | 0.04 To 0.12 (-1 To 3) |
| Rear | 0.13 (3) | 0 To 0.26 (0 To 7) |
| Toe-In (1) |
| Front | 0.1 | 0.1 To 0.3 |
| Rear | 0.33 | 0 To 0.66 |
| Toe-Out On Turns (1) |
| Inner | 35.75 | N/A |
| Outer | 32.08 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (PASEO)
| Application | Preferred | Range |
|---|
| Camber (1) | 0.08 | 0.42 To 0.58 |
| Caster (1) | 5.5 | 5 To 6 |
| Steering Axis Inclination (1) | 10.58 | N/A |
| Toe-In (2) | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Toe-In (1) | 0.16 | 0 To 0.32 |
| Toe-Out On Turns (1) |
| Inner | 35.58 | N/A |
| Outer | 32.75 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (PREVIA)
RAV4 - 2-DOOR 2WD
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.33 | 1.08 To 0.42 |
| Rear |
| 2-Door | 1.33 | 2.08 To -0.58 |
| 4-Door | 1.25 | 2 To -0.5 |
| Caster (1) | 1.42 | 0.67 To 2.17 |
| Steering Axis Inclination (1) | 11.0 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear |
| 2-Door | 0.16 (4) | 0.08 To 0.24 (2 To 6) |
| 4-Door | 0.12 (3) | 0.04 To 0.2 (1 To 5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear |
| 2-Door | 0.4 | 0.2 To 0.6 |
| 4-Door | 0.3 | 0.1 To 0.5 |
| Toe-Out On Turns (1) |
| Inner | 33.25 | N/A |
| Outer | 28.08 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (RAV4 - 2 DOOR 2WD)
RAV4 - 4-DOOR 2WD
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.33 | 1.08 To 0.42 |
| Rear |
| 2-Door | 1.33 | 2.08 To -0.58 |
| 4-Door | 1.25 | 2 To -0.5 |
| Caster (1) | 1.42 | 0.67 To 2.17 |
| Steering Axis Inclination (1) | 11.0 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear |
| 2-Door | 0.16 (4) | 0.08 To 0.24 (2 To 6) |
| 4-Door | 0.12 (3) | 0.04 To 0.2 (1 To 5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear |
| 2-Door | 0.4 | 0.2 To 0.6 |
| 4-Door | 0.3 | 0.1 To 0.5 |
| Toe-Out On Turns (1) |
| Inner | 33.25 | N/A |
| Outer | 28.08 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (RAV4 - 4 DOOR 2WD)
RAV4 - 2-DOOR 4WD
| Application | Preferred | Range |
|---|
| 215/70R16 |
| Camber (1) |
| Front | 0.25 | 1.0 To 0.5 |
| Rear | 1.08 | 1.83 To -0.33 |
| Caster (1) | 1.33 | 0.58 To 2.08 |
| Steering Axis Inclination (1) | 10.75 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.12 (3) | 0.04 To 0.2 (1 To 5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.3 | 0.1 To 0.5 |
| Toe-Out On Turns (1) |
| Inner | 33.25 | N/A |
| Outer | 28.08 | N/A |
| 235/60R16 |
| Camber (1) |
| Front | 0.33 | 1.08 To 0.42 |
| Rear | 1.42 | 2.17 To -0.67 |
| Caster (1) | 1.42 | 0.67 To 2.17 |
| Steering Axis Inclination (1) | 11 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.16 (4) | 0.08 To 0.24 (2 To 6) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.4 | 0.2 To 0.6 |
| Toe-Out On Turns (1) |
| Inner | 33.25 | N/A |
| Outer | 28.08 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (RAV4 - 2-DOOR 4WD)
RAV4 - 4-DOOR 4WD
| Application | Preferred | Range |
|---|
| 215/70R16 |
| Camber (1) |
| Front | 0.25 | 1.0 To 0.5 |
| Rear | 0.92 | 1.67 To -0.17 |
| Caster (1) | 1.33 | 0.58 To 2.08 |
| Steering Axis Inclination (1) | 10.75 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.12 (3) | 0.04 To 0.2 (1 To 5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.3 | 0.1 To 0.5 |
| Toe-Out On Turns (1) |
| Inner | 33.25 | N/A |
| Outer | 28.08 | N/A |
| 235/60R16 |
| Camber (1) |
| Front | 0.33 | 1.08 To 0.42 |
| Rear | 1.33 | 2.08 To -0.58 |
| Caster (1) | 1.42 | 0.67 To 2.17 |
| Steering Axis Inclination (1) | 11 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.08 To 0.08 (-2 To 2) |
| Rear | 0.12 (3) | 0.4 To 0.2 (1 To 5) |
| Toe-In (1) |
| Front | 0 | 0.2 To 0.2 |
| Rear | 0.3 | 0.1 To 0.5 |
| Toe-Out On Turns (1) |
| Inner | 33.25 | N/A |
| Outer | 28.08 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (RAV4 - 4-DOOR 4WD)
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.53 | 1.28 To 0.22 |
| Rear | 0.92 | 1.67 To -0.17 |
| Caster (1) | 1.53 | 0.78 To 2.28 |
| Steering Axis Inclination (1) | 12.58 | N/A |
| Toe-In (2) |
| Front | 0.1 (2.5) | .02 To .18 (.5 To 4.5) |
| Rear | 0.09 (2) | .03 To .21 (-1 To 5) |
| Toe-In (1) |
| Front | 27 | 0.07 To 0.47 |
| Rear | 0.22 | 0.8 To 0.52 |
| Toe-Out On Turns (1) |
| Inner | 34.32 | N/A |
| Outer | 30.32 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (SIENNA)
| Application | Preferred | Range |
|---|
| Non-Turbo |
| Camber (1) |
| Front | 0.33 | 1.08 To 0.4 |
| Rear | 1.58 | 2.08 To -1.08 |
| Caster (1) | 3.33 | 2.83 To 3.83 |
| Steering Axis Inclination (1) | 9.58 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.04 To 0.04 (-1 To 1) |
| Rear | 0.12 (3) | 0.08 To 0.16 (2 To 4) |
| Toe-In (1) |
| Front | 0 | 0.1 To 0.1 |
| Rear | 0.3 | 0.2 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 35 | N/A |
| Outer | 30.75 | N/A |
| Turbo |
| Camber (1) |
| Front | 0.5 | 1 To 0 |
| Rear | 1.5 | 2 To -1 |
| Caster (1) | 3.5 | 3 To 4 |
| Steering Axis Inclination (1) | 9.75 | N/A |
| Toe-In (2) |
| Front | 0 (0) | 0.04 To 0.04 (-1 To 1) |
| Rear | 0.12 (3) | 0.08 To 0.16 (2 To 4) |
| Toe-In (1) |
| Front | 0 | 0.1 To 0.1 |
| Rear | 0.3 | 0.2 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 34.92 | N/A |
| Outer | 30.58 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (SUPRA)
| Application | Preferred | Range |
|---|
| Camber (1) | 0.08 | 0.67 To 0.83 |
| Caster (1) |
| 2.4L Reg Cab | .58 | 0.17 To 1.33 |
| 2.4L Xtra Cab | .83 | 0.08 To 1.58 |
| 3.4L Xtra Cab | .67 | 0.08 To 1.42 |
| Steering Axis Inclination (1) | 10 | N/A |
| Toe-In (2) | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Toe-In (1) | 0.2 | 0 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 36 | N/A |
| Outer | 31 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (TACOMA - 2WD)
| Application | Preferred | Range |
|---|
| 1997 |
| Camber (1) |
| 2.7L Reg Cab | 0.25 | 0.5 To 1 |
| 3.4L Reg Cab | 0.25 | 0.5 To 1 |
| 2.7L Xtra Cab | 0.33 | 0.42 To 1.08 |
| 3.4L Xtra Cab | 0.33 | 0.42 To 1.08 |
| Caster (1) |
| 2.7L Reg Cab | 1.58 | 0.83 To 2.33 |
| 3.4L Reg Cab | 1.58 | 0.83 To 2.33 |
| 2.7L Xtra Cab | 1.75 | 1 To 2.5 |
| 3.4L Xtra Cab | 1.75 | 1 To 2.5 |
| Steering Axis Inclination (1) | 10.5 | N/A |
| Toe-In (2) | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Toe-In (1) | 0.2 | 0 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 37.5 | N/A |
| Outer | 32.5 | N/A |
| 1998 |
| Camber (1) |
| 2.7L Reg Cab | 0.17 | 0.58 To 1 |
| 2.7L Xtra Cab | 0.25 | 0.5 To 1 |
| 3.4L Xtra Cab | 0.25 | 0.5 To 1 |
| Caster (1) |
| 2.7L Reg Cab | 1.67 | 0.92 To 2.42 |
| 2.7L Xtra Cab | 1.5 | .75 To 2.25 |
| 3.4L Xtra Cab | 1.42 | 0.67 To 2.17 |
| Steering Axis Inclination (1) | 10.5 | N/A |
| Toe-In (2) | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Toe-In (1) | 0.2 | 0 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 37.33 | N/A |
| Outer | 32.64 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (TACOMA - 4WD)
TERCEL
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 0.33 | 1.08 To 0.42 |
| Rear | 0.5 | 1.25 To 0.25 |
| Caster (1) | 1.33 | 0.58 To 2.08 |
| Steering Axis Inclination (1) | 12.17 | N/A |
| Toe-In (2) |
| Front | 0.04 (1) | 0.04 To 0.12 (-1 To 3) |
| Rear | 0.12 (3) | 0 To 0.24 (0 To 6) |
| Toe-In (1) |
| Front | 0.1 | 0.1 To 0.3 |
| Rear | 0.3 | 0 To 0.6 |
| Toe-Out On Turns (1) |
| Inner | 35.92 | N/A |
| Outer | 32.17 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (TERCEL)
T100 - REGULAR CAB
| Application | Preferred | Range |
|---|
| 2WD |
| Camber (1) | 0.4 | 0.35 To 1.15 |
| Caster (1) | 2.4 | 1.65 To 3.15 |
| Steering Axis Inclination (1) | 12.08 | N/A |
| Toe-In (2) | 0.09 (2.5) | 0.01 To 0.19 (-0.5 To 4.5) |
| Toe-In (1) | 0.18 | 0.02 To 0.38 |
| Toe-Out On Turns (1) |
| Inner | 40.67 | N/A |
| Outer | 35.1 | N/A |
| 4WD |
| Camber (1) | 0.67 | 0.08 To 1.42 |
| Caster (1) | 1.08 | 0.33 To 1.83 |
| Steering Axis Inclination (1) | 12 | N/A |
| Toe-In (2) | 0.1 (2.5) | 0 To 0.2 (0 To 5) |
| Toe-In (1) | 0.2 | 0 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 32.75 | N/A |
| Outer | 30.52 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (T100 - REGULAR CAB)
T100 - XTRA CAB
| Application | Preferred | Range |
|---|
| 2WD |
| Camber (1) | .47 | 0.28 To 1.22 |
| Caster (1) | 2.07 | 1.32 To 2.82 |
| Steering Axis Inclination (1) | 12 | N/A |
| Toe-In (2) | 0.17 (4) | 0.07 To 0.27 (1.5 To 7) |
| Toe-In (1) | 0.33 | 0.13 To 0.53 |
| Toe-Out On Turns (1) |
| Inner | 40.8 | N/A |
| Outer | 35.68 | N/A |
| 4WD |
| Camber (1) | 0.58 | 0.17 To 1.33 |
| Caster (1) | 0.92 | 0.17 To 1.67 |
| Steering Axis Inclination (1) | 12 | N/A |
| Toe-In (2) | 0.07 (2) | 0.03 To 0.17 (-1 To 4) |
| Toe-In (1) | 0.13 | 0.07 To 0.33 |
| Toe-Out On Turns (1) |
| Inner | 33.12 | N/A |
| Outer | 30.52 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (T100 - XTRA CAB)
| Application | Preferred | Range |
|---|
| 2WD |
| Camber (1) | 0.25 | 1 To 0.5 |
| Caster (1) | 3.08 | 2.33 To 3.83 |
| Steering Axis Inclination (1) | 11 | N/A |
| Toe-In (2) | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Toe-In (1) | 0.2 | 0 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 35 | N/A |
| Outer | 31 | N/A |
| 4WD |
| Camber (1) | 0.17 | 0.58 To 0.92 |
| Caster (1) | 2.42 | 1.67 To 3.17 |
| Steering Axis Inclination (1) | 10.58 | N/A |
| Toe-In (2) | 0.08 (2) | 0 To 0.16 (0 To 4) |
| Toe-In (1) | 0.2 | 0 To 0.4 |
| Toe-Out On Turns (1) |
| Inner | 36 | N/A |
| Outer | 32 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (4RUNNER)
| Application | Ft. Lbs. (N.m) |
|---|
| Avalon & Camry |
| Rear Toe Adjuster Sleeve Lock Nuts | 41 (56) |
| Tie Rod Lock Nuts | 55 (75) |
| Wheel Lug Nuts | 76 (103) |
| Celica |
| Rear Toe Adjuster Sleeve Lock Nuts | 55 (75) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| Corolla |
| Rear Toe Adjuster Sleeve Lock Nuts | 41 (56) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| Paseo & Tercel |
| Tie Rod Lock Nuts | 35 (47) |
| Wheel Lug Nuts | 76 (103) |
| Supra |
| Front Adjuster Cam Lock Nuts | 167 (226) |
| Rear Adjuster Cam Lock Nuts | 136 (184) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
TORQUE SPECIFICATIONS (CARS)
LIGHT TRUCKS
| Application | Ft. Lbs. (N.m) |
|---|
| Land Cruiser/LX470 |
| Steering Knuckle Stopper Bolts | 32 (44) |
| Tie Rod Clamp Nuts | 27 (37) |
| Wheel Lug Nuts |
| Aluminum Wheel | 76 (103) |
| Steel Wheel | 108 (147) |
| Previa & Sienna |
| Lower Strut Mounting Bolts | 155 (210) |
| Steering Knuckle Stopper Bolts | 24 (33) |
| Tie Rod Lock Nuts | 67 (91) |
| Wheel Lug Nuts | 76 (103) |
| RAV4 |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| T100 2WD |
| Tie Rod Lock Nuts | 41 (56) |
| Upper Control Arm Bolts | 71 (96) |
| Wheel Lug Nuts | 76 (103) |
| T100 4WD |
| Front Suspension Adjuster Cams | 167 (226) |
| Steering Knuckle Stopper Bolts | 35 (47) |
| Tie Rod Clamp Nuts | 16 (22) |
| Wheel Lug Nuts | 76 (103) |
| 4Runner |
| Front Suspension Adjuster Cams | 96 (130) |
| Tie Rod Clamp Nuts | 41 (55) |
| Wheel Lug Nuts | 81 (110) |
TORQUE SPECIFICATIONS (LIGHT TRUCKS)
