PRECAUTION
Note. Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM (see INITIALIZATION ).
HINT: Initialization can not be completed by only disconnecting the battery terminal.
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor description | Description of what the ECM monitors and how it detects malfunctions (monitoring purpose and its details). |
| Related DTCs | Diagnostic code |
| Typical enabling condition | Preconditions that allow the ECM to detect malfunctions. |
| Typical enabling condition | With all preconditions satisfied, the ECM sets the DTC when the monitored value(s) exceeds the malfunction threshold(s). |
| Sequence of operation | The priority order that is applied to monitoring, if multiple sensors and components are used to detect the malfunction. |
| Sequence of operation | While another sensor is being monitored, the next sensor or component will not be monitored until the previous monitoring has concluded. |
| Required sensor/components | The sensors and components that are used by the ECM to detect malfunctions. |
| Frequency of operation | The number of times that the ECM checks for malfunctions per driving cycle. |
| Frequency of operation | "Once per driving cycle" means that the ECM detects malfunction only one time during a single driving cycle. |
| Frequency of operation | "Continuous" means that the ECM detects malfunction every time when enabling condition is met. |
| Duration | The minimum time that the ECM must sense a continuous deviation in the monitored value(s) before setting a DTC. This timing begins after the "typical enabling conditions" are met. |
| Malfunction thresholds | Beyond this value, the ECM will conclude that there is a malfunction and set a DTC. |
| MIL operation | MIL illumination timing after a defect is detected. |
| MIL operation | "Immediately" means that the ECM illuminates MIL the instant the ECM determines that there is a malfunction. |
| MIL operation | "2 driving cycle" means that the ECM illuminates MIL if the same malfunction is detected again in the 2nd driving cycle. |
| Component operating range | Normal operation range of sensors and solenoids under normal driving conditions. |
| Component operating range | Use these ranges as a reference. |
| Component operating range | They cannot be used to judge if a sensor or solenoid is defective or not. |
DEFINITION OF TERMS
PART AND SYSTEM NAME LIST
This reference list indicates the part names used in this manual along with their definitions.
| Part and system name | Definition |
|---|---|
| Toyota HCAC system, Hydrocarbon adsorptive Catalyst (HCAC) system, HC adsorptive three-way catalyst | HC adsorptive three-way catalytic converter |
| Variable Valve Timing sensor, VVT sensor | Camshaft position sensor |
| Variable valve timing system, VVT system | Camshaft timing control system |
| Camshaft timing oil control valve, Oil control valve OCV, VVT, VSV | Camshaft timing oil control valve |
| Variable timing and lift, VVTL | Camshaft timing and lift control |
| Crankshaft position sensor "A" | Crankshaft position sensor |
| Engine speed sensor | Crankshaft position sensor |
| THA | Intake air temperature |
| Knock control module | Engine knock control module |
| Knock sensor | Engine knock sensor |
| Mass or volume air flow circuit | Mass air flow sensor circuit |
| Vacuum sensor | Manifold air pressure sensor |
| Internal control module, Control module, Engine control ECU, PCM | Power train control module |
| FC idle | Deceleration fuel cut |
| Idle air control valve | Idle speed control |
| VSV for CCV, Canister close valve VSV for canister control | Evaporative emissions canister vent valve |
| VSV for EVAP, Vacuum switching valve assembly No. 1, EVAP VAV, Purge VSV | Evaporative emissions canister purge valve |
| VSV for pressure switching valve, Bypass VSV | Evaporative emission pressure switching valve |
| Vapor pressure sensor, EVAP pressure sensor, Evaporative emission control system pressure sensor | Fuel tank pressure sensor |
| Charcoal canister | Evaporative emissions canister |
| ORVR system | On-boad refueling vapor recovery system |
| Intake manifold runner control | Intake manifold tuning system |
| Intake manifold runner valve, IMRV, IACV (runner valve) | Intake manifold tuning valve |
| Intake control VSV | Intake manifold tuning solenoid valve |
| AFS | Air fuel ratio sensor |
| O2 sensor | Heater oxygen sensor |
| Oxygen sensor pumping current circuit | Oxygen sensor output signal |
| Oxygen sensor reference ground circuit | Oxygen sensor signal ground |
| Accel position sensor | Accelerator pedal position sensor |
| Throttle actuator control motor, Actuator control motor, Electronic throttle motor, Throttle control motor | Electronic throttle actuator |
| Electronic throttle control system, Throttle actuator control system | Electronic throttle control system |
| Throttle/pedal position sensor, Throttle/pedal position switch, Throttle position sensor/switch | Throttle position sensor |
| Turbo press sensor | Turbocharger pressure sensor |
| Turbo VSV | Turbocharger pressure control solenoid valve |
| P/S pressure switch | Power-steering pressure switch |
| VSV for ACM | Active control engine mount |
| Speed sensor, Vehicle speed sensor "A", Speed sensor for skid control ECU | Vehicle speed sensor |
| ATF temperature sensor, Trans, fluid temp, sensor, ATF temperature sensor "A" | Transmission fluid temperature sensor |
| Electronic controlled automatic transmission, ECT | Electronically controlled automatic |
| Intermediate shaft speed sensor "A" | Counter gear speed sensor |
| Output speed sensor | Output shaft speed sensor |
| Input speed sensor, Input turbine speed sensor "A", Speed sensor (NT), Turbine speed sensor | Input turbine speed sensor |
| PNP switch, NSW | Park/neutral position switch |
| Pressure control solenoid | Transmission pressure control solenoid |
| Shift solenoid | Transmission shift solenoid valve |
| Transmission control switch, Shift lock control unit | Shift lock control module |
| Engine immobilizer system, Immobilizer system | Vehicle anti-theft system |
PART AND SYSTEM NAME LIST
Scheme 124
SYSTEM DIAGRAM
The configuration of the electronic control system in the A245E automatic transaxles is (Scheme 125)
Scheme 125
LIST OF DISABLE A MONITOR
HINT: This table indicates ECM monitoring status for the items in the upper columns if the DTCs in each line on the left are being set.
As for the "X" mark, when the DTC on the left is stored, detection of the DTC in the upper column is not performed.
Scheme 126
Scheme 127
Scheme 128
Scheme 129
Scheme 130
Scheme 131
Scheme 132
- MONITOR DRIVE PATTERN FOR ECT TEST Perform this drive pattern as one method to simulate the detection conditions of the ECT malfunctions. (The DTCs may not be detected due the actual driving conditions. And some codes may not be detected through this drive pattern). HINT: Preparation for driving Warm up the engine sufficiently. (Engine coolant temperature is 60°C (140°F) or higher) Drive the vehicle when the atmospheric temperature is -10°C (14°F) or higher. (Malfunction is not detected when the atmospheric temperature is -10°C (14°F) or less) Driving note Drive the vehicle through all gears. Stop -> 1st -> 2nd -> 3rd -> O/D -> O/D (lock-up ON). Repeat the above driving pattern three times or more. NOTE: The monitor status can be checked using the OBDII scan tool. When using the hand-held tester, monitor status can be found in the "ENHANCED OBD II/DATA LIST" or under "CARB OBD II". In the event that the drive pattern must be interrupted (possibly due to traffic conditions or other factors) the drive pattern can be resumed and, in most cases, the monitor can be completed. CAUTION: Perform this drive pattern on a level road as much as possible and strictly observe the posted speed limits and traffic laws while driving. HINT: *1: Drive at such a speed in the uppermost gear, to engage lock-up. The vehicle can be driven at a speed lower than that in the above diagram under the lock-up condition.
MONITOR STRATEGY
| Related DTCs | P0724: Stop light switch/Range check/Rationality |
|---|---|
| Requiredsensors/Components | Stop light switch |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
The stop light switch remains on during GO and STOP 5 times.
GO and STOP is defined as follows
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| GO: Vehicle speed | 30 km/h (18.63 mph) or more |
| STOP: Vehicle speed | Less than 3km/h(1.86mph) |
TYPICAL ENABLING CONDITIONS
TYPICAL MALFUNCTION THRESHOLDS
| Brake switch status | ON stuck |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 133
| Related DTCs | P0741: Shift solenoid valve SL/OFF malfunction |
|---|---|
| P0741: Shift solenoid valve SL/ON malfunction | |
| Requiredsensors/Components | Shift solenoid valve SL |
| Frequency of operation | Continuous |
| Duration | 3.6 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
TYPICAL ENABLING CONDITIONS
The following items are common to all conditions below.
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Transmission shift position" | "D" |
| ECT | 55°C(131°F) or more and Less than 105°C (221°F) |
| IAT(only for malfunction) | 10°C(14°F) or more and Less than 70°C(158°F) |
| Shift solenoid "A" (S1) circuit Shift solenoid "B" (S2) circuit Torque converter clutch solenoid (SL) circuit | There is no malfunction in the circuits shown on the left. |
| Battery voltage | 10 V or more |
| Spark retard by KCS control | 0° CA or more |
TYPICAL ENABLING CONDITIONS (ALL)
OFF malfunction
| ECM selected gear | 4th with lock up |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION)
ON malfunction
| ECM selected gear | 4th |
|---|---|
| Throttle valve opening angle | 7% or more |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION)
Either of the following conditions is met: OFF malfunction or ON malfunction
| Engine Speed | 4th gear ratio x NO + 100 rpm or more and Less than 3rd gear ratio x NO - 100 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION)
| Engine speed It is necessary 2 judgments/driving cycle 1 st judgment: temporary flag ON 2nd judgment: pending fault code ON | 4th gear ratio x NO - 50 rpm or more and Less than 4th gear ratio x NO + 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION)
| Related DTCs | P0751: Shift solenoid valve S1/OFF malfunction, Shift solenoid valve S1/ON malfunction |
|---|---|
| Requiredsensors/Components | Shift solenoid valve S1 |
| Frequency of operation | Continuous |
| Duration | 0.065 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
The following items are common to all conditions below.
| The monitor will run whenever the following DTCs are not present | See LIST OF DISABLE A MONITOR |
|---|---|
| Transmission shift position | "D" |
| ECT | 55°C(131°F) or more and Less than 105°C (221°F) |
| IAT (only for malfunction) | 10°C (14°F) or more and Less than 70°C (158°F) |
| Shift solenoid "A" (S1) circuit | There is no malfunction in the sensor circuits shown on the left |
| Shift solenoid "B" (S2) circuit | There is no malfunction in the sensor circuits shown on the left |
| Torque converter clutch solenoid (SL) circuit | There is no malfunction in the sensor circuits shown on the left |
| Battery voltage | 10 V or more |
| Spark retard by KCS control | 0° CA or more |
TYPICAL ENABLING CONDITIONS (ALL)
OFF malfunction (A)
| ECM selected gear | 1st |
|---|---|
| Throttle valve opening angle | 30% or more |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (A))
OFF malfunction (B)
| Current ECM selected gear | 2nd |
|---|---|
| Last ECM selected gear | 1st |
| Throttle valve opening angle | 7% or more |
| Closing change of throttle valve opening angle | 5% or more and Less than 5% |
| THIast-TH current THIast: Throttle valve opening angle at last ECM selected gear THcurrent: Throttle valve opening angle at current ECM selected gear | 20% or more and Less than 20% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (B))
OFF malfunction (C), (D) and (E)
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 2nd |
| Throttle valve opening angle | 7% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (C, D, E))
OFF malfunction (F) and (G)
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 3rd |
| Throttle valve opening angle | 5 % or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (F AND G))
OFF malfunction (H) and (I)
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 4th |
| Throttle valve opening angle | 5% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (H AND I))
OFF malfunction (J)
| Engine idling | ON |
|---|---|
| Braking | ON |
| Throttle valve opening angle (ECM selected gear 2nd) | 65% or more or Less than 5% |
| Throttle valve opening angle (ECM selected gear 3rd) | 65% or more or Less than 3% |
| Throttle valve opening angle (ECM selected gear 4th) | 65% or more or Less than 3% |
| THcurrent-TH2ndstep | Less than -10% or 10% or more |
| THcurrent: Throttle valve opening angle at current ECM selected gear | Less than -10% or 10% or more |
| TH2ndstep: Throttle valve opening angle at 2nd judgment step | Less than -10% or 10% or more |
| Closing change of throttle valve opening angle | Less than -10% or 10% or more |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (J))
| ECM selected gear | 4th |
|---|---|
| Throttle valve opening angle | 12% or more and Less than 35% |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION)
[OFF malfunction]
There are 2 judgment steps/driving cycle
1st judgment step: when following conditions met, temporary flag becomes ON.
OFF malfunction (A) or (B)
It is necessary 2 judgments/driving cycle
2nd judgment step: when following conditions met, pending fault code becomes ON.
(OFF malfunction (E) and (G) and (H)) or (OFF malfunction (C) and (D) and (F) and (I))
| Engine speed | Less than 2 x NO + 1,100 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (A))
| NElast-NEcurrent | Less than 512.5 rpm at throttle valve opening angle 40 % (condition vary with throttle valve opening angle) |
|---|---|
| NElast: Engine speed at last ECM selected gear | |
| NEcurrent:Engine speed at current ECM selected gear |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (B))
OFF malfunction (C)
| Engine speed | Less than 1 st gear ratio x NO + 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (C))
OFF malfunction (D)
| Engine speed | 2nd gear ratio x NO + 50 rpm or more or Less than 2nd gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (D))
OFF malfunction (E) and (F)
| Engine speed | Less than 3rd gear ratio x NO + 50 rpm and 3rd gear ratio x NO - 50 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (E AND F))
OFF malfunction (G)
| Engine speed | 4th gear ratio x NO + 50 rpm or more or Less than 4th gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (G))
OFF malfunction (H)
| Engine speed | 3rd gear ratio x NO + 50 rpm or more or Less than 3rd gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (H))
OFF malfunction (I)
| Engine speed | Less than 4th gear ratio x NO + 50 rpm and 4th gear ratio x NO - 50 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (I))
| When one of following secondary parameter conditions met, 2nd judgment is stopped. | (See secondary parameters and condition) |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (J))
[ON malfunction]
| Engine speed | 2 x NO +1,100 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION)
| Related DTCs | P0756: Shift solenoid valve S2/OFF malfunction Shift solenoid valve S2/ON malfunction |
|---|---|
| Requiredsensors/Components | Shift solenoid valve S2 |
| Frequency of operation | Continuous |
| Duration | Less than 10 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
The following items are common to all conditions below.
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Transmission shift position | "D" |
| ECT | 55°C (131°F) or more and Less than 105°C (221°F) |
| IAT (only for malfunction) | 10°C (14°F) or more and Less than 70°C (158°F) |
| Shift solenoid "A" (S1) circuit | There is no malfunction in the circuits shown on the left |
| Shift solenoid "B" (S2) circuit | There is no malfunction in the circuits shown on the left |
| Torque converter clutch solenoid (SL) circuit | There is no malfunction in the circuits shown on the left |
| Battery voltage | 10 V or more |
| Spark retard by KCS control | 0° CA or more |
TYPICAL ENABLING CONDITIONS (ALL)
| ECM selected gear | 2nd |
|---|---|
| Throttle valve opening angle | 10% or more and Less than 35% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (A))
| Current ECM selected gear | 2nd |
|---|---|
| Last ECM selected gear | 1st |
| Throttle valve opening angle | 7% or more |
| THlast - TH current | 20% or more and Less than 20% |
| THlast: Throttle valve opening angle at last ECM selected gear | 20% or more and Less than 20% |
| THcurrent: Throttle valve opening angle at current ECM selected gear | 20% or more and Less than 20% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (B))
| Engineidling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 2nd |
| Throttle valve opening angle | 7% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (C, D AND E))
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 3rd |
| Throttle valve opening angle | 5% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (F AND G))
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 4th |
| Throttle valve opening angle | 5% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (H))
| Engine idling | ON |
|---|---|
| Braking | ON |
| Throttle valve opening angle (ECM selected gear 2nd) | 65% or more or Less than 5% |
| Throttle valve opening angle (ECM selected gear 4th) | 65% or more or Less than 3% |
| THcurrent - TH2ndstep | Less than -10% or 10% or more |
| THcurrent: Throttle valve opening angle at current ECM selected gear | Less than -10% or 10% or more |
| TH2ndstep: Throttle valve opening angle at 2nd judgment step | Less than -10% or 10% or more |
| Closing change of throttle valve opening angle | Less than -10% or 10% or more |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION (I))
ON malfunction (A)
| ECM selected gear | 4th with lock up |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION (A))
ON malfunction (B)
| Current ECM selected gear | 2nd |
|---|---|
| Last ECM selected gear | 1st |
| Throttle valve opening angle | 7% or more |
| Closing change of throttle valve opening angle | 5% or more and Less than 5% |
| THlast - TH current | 20% or more and Less than 20% |
| THlast: Throttle valve opening angle at last ECM selected gear | 20% or more and Less than 20% |
| THcurrent: Throttle valve opening angle at current ECM selected gear | 20% or more and Less than 20% |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION (B))
ON malfunction (C), (D) and (E)
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 2nd |
| Throttle valve opening angle | 7% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION (C, D AND E))
ON malfunction (F)
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 3rd |
| Throttle valve opening angle | 5% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION (F))
ON malfunction (G) and (H)
| Engine idling | OFF |
|---|---|
| Braking | OFF |
| ECM selected gear | 4th |
| Throttle valve opening angle | 5% or more and Less than 60% |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION (G AND H))
ON malfunction (I)
| Engine idling | ON |
|---|---|
| Braking | ON |
| Throttle valve opening angle (ECM selected gear 2nd) | 65% or more or Less than 5% |
| Throttle valve opening angle (ECM selected gear 3rd) | 65% or more or Less than 3% |
| Throttle valve opening angle (ECM selected gear 4th) | 65% or more or Less than 3% |
| THcurrent - TH2ndstep | Less than -10% or 10% or more |
| THcurrent: Throttle valve opening angle at current ECM selected gear | Less than -10% or 10% or more |
| TH2ndstep: Throttle valve opening angle at 2nd judgment step | Less than -10% or 10% or more |
| Closing change of throttle valve opening angle | Less than -10% or 10% or more |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION (I))
Following conditions met (1) or (2)
- OFF malfunction (A)
- OFF malfunction (B), (C), (D), (E), (F), (G), (H)
(1)
It is necessary 2 judgments/driving cycle 1st judgment: temporary flag ON 2nd judgment: pending fault code ON
OFF malfunction (A)
| Engine speed | 1st gear ratio x NO + 0 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (A))
(2)
There are 2 judgment steps/driving cycle
1st judgment step: when following conditions OFF malfunction (B) met, temporary flag becomes ON. It is necessary 2 judgments/driving cycle
2nd judgment step: when following conditions met, pending fault code becomes ON. (OFF malfunction (C), (F) and (H)) or (OFF malfunction (D), (E), (G) and (H))
| NElast - NEcurrent | Less than 512.5 rpm at throttle valve opening angle 40% (Condition vary with throttle valve opening angle) |
|---|---|
| NElast: Engine speed at last ECM selected gear | Less than 512.5 rpm at throttle valve opening angle 40% (Condition vary with throttle valve opening angle) |
| NEcurrent: Engine speed at current ECM selected gear | Less than 512.5 rpm at throttle valve opening angle 40% (Condition vary with throttle valve opening angle) |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (B))
| Engine speed | 1st gear ratio x NO + 50 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (C))
| Engine speed | 2nd gear ratio x NO + 50 rpm or more or Less than 2nd gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (D))
| Engine speed | 3rd gear ratio x NO + 50 rpm or more or Less than 3rd gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (E AND F))
| Engine speed | Less than 4th gear ratio x NO + 50 rpm and 4th gear ratio x NO - 50 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (G))
| Engine speed | 3rd gear ratio x NO + 50 rpm or more or Less than 3rd gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (H))
| When one of following secondary parameter conditions met, 2nd judgment is stopped. | (See secondary parameters and condition) |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION (I))
[ON malfunction]
Following conditions met (1) or (2)
- ON malfunction (A)
- ON malfunction (B), (C), (D), (E), (F), (G), (H)
(1)
ON malfunction (A)
| Engine speed | 3rd gear ratio x NO - 50 rpm or more and Less than 3rd gear ratio x NO + 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (A))
(2)
There are 2 judgment steps/driving cycle
1st judgment step: when following conditions ON malfunction (B) met, temporary flag becomes ON. It is necessary 2 judgments/driving cycle
2nd judgment step: when following conditions met, pending fault code becomes ON. (ON malfunction (D), (F) and (H)) or (ON malfunction (C), (E), (F) and (G))
| NElast - NEcurrent | Less than 512.5 rpm at throttle valve opening angle 40% (Condition vary with throttle valve opening angle) |
|---|---|
| NElast: Engine speed at last ECM selected gear | Less than 512.5 rpm at throttle valve opening angle 40% (Condition vary with throttle valve opening angle) |
| NEcurrent: Engine speed at current ECM selected gear | Less than 512.5 rpm at throttle valve opening angle 40% (Condition vary with throttle valve opening angle) |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (B))
ON malfunction (C)
| Engine speed | Less than 1st gear ratio x NO + 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (C))
ON malfunction (D)
| Engine speed | Less than 2nd gear ratio x NO + 50 rpm and 2nd gear ratio x NO - 50 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (D))
ON malfunction (E)
| Engine speed | 3rd gear ratio x NO + 50 rpm or more or Less than 3rd gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (E))
| Engine speed | 4th gear ratio x NO + 50 rpm or more or Less than 4th gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (F))
ON malfunction (G)
| Engine speed | Less than 3rd gear ratio x NO + 50 rpm and 3rd gear ratio x NO - 50 rpm or more NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (G))
ON malfunction (H)
| Engine speed | 4th gear ratio x NO + 50 rpm or more or Less than 4th gear ratio x NO - 50 rpm NO: Transmission output speed |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (H))
| When one of following secondary parameter conditions met, 2nd judgment is stopped. | (See secondary parameters and condition) |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION (I))
| Related DTCs | P0973: Shift solenoid valve S1/Range check (Low resistance) |
|---|---|
| P0974: Shift solenoid valve S1/Range check (High resistance) | |
| Requiredsensors/Components | Shift solenoid valve S1 |
| Frequency of operation | Continuous |
| Duration | 2 times or more |
| MIL operation | 1 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY
COMPONENT OPERATING RANGE
| Shift solenoid valve S1 | Resistance: 11 to 15 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 134
Scheme 135
Scheme 136
Scheme 137
- INSPECT TRANSMISSION WIRE (S1) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in «TRANSMISSION WIRE (S1) CONNECTOR TERMINAL AND BODY GROUND RESISTANCE»(ref-225480-S03952424952006031900000) . Standard: TRANSMISSION WIRE (S1) CONNECTOR TERMINAL AND BODY GROUND RESISTANCE Tester Connection Specified Condition 20°C (68°F) 3 - Body ground 11 to 15ohm NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in «ECM CONNECTOR TERMINALS RESISTANCE»(ref-225480-S25818178022006031900000) . Standard: ECM CONNECTOR TERMINALS RESISTANCE Tester Connection Specified Condition 20°C (68°F) E4 - 11 (S1) - Body ground 11 to 15ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-225473-S18636529692006031900000) ) OK: REPLACE ECM (SEE «ECM (1ZZ-FE/2ZZ-GE) REPLACEMENT»(ref-225491-S27442506802006031900000) )
- INSPECT SHIFT SOLENOID VALVE (S1) Remove the shift solenoid valve S1. Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE (S1) TERMINALS RESISTANCE»(ref-225480-S20850109352006031900000) . Standard: SHIFT SOLENOID VALVE (S1) TERMINALS RESISTANCE Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S1) - Solenoid Body (S1) 11 to 15ohm Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (S1) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (A245E)»(ref-225506-S14947891902006031900000) )
| Related DTCs | P0976: Shift solenoid valve S2/Range check (Low resistance) |
|---|---|
| P0977: Shift solenoid valve S2/Range check (High resistance) | |
| Requiredsensors/Components | Shift solenoid valve S2 |
| Frequency of operation | Continuous |
| Duration | 2 times or more |
| MIL operation | 1 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY
| Shift solenoid valve S2 | Resistance: 11 to 15 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 138
Scheme 139
Scheme 140
Scheme 141
- INSPECT TRANSMISSION WIRE (S2) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in «TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE»(ref-225480-S22868437982006031900000) . Standard: TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE Tester Connection Specified Condition 20 °C (68 °F) 6 - Body ground 11 to 15ohm NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in «ECM CONNECTOR TERMINALS AND BODY GROUND RESISTANCE»(ref-225480-S27469467062006031900000) the table below. Standard: ECM CONNECTOR TERMINALS AND BODY GROUND RESISTANCE Tester Connection Specified Condition 20°C (68°F) E4 - 9 (S2) - Body ground 11 to 15ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-225473-S18636529692006031900000) ) OK: REPLACE ECM (SEE «ECM (1ZZ-FE/2ZZ-GE) REPLACEMENT»(ref-225491-S27442506802006031900000) )
- INSPECT SHIFT SOLENOID VALVE (S2) Remove the shift solenoid valve S2. Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE (S2) TERMINALS AND BODY GROUND RESISTANCE»(ref-225480-S08544535552006031900000) . Standard: SHIFT SOLENOID VALVE (S2) TERMINALS AND BODY GROUND RESISTANCE Tester Connection Specified Condition 20 °C (68 °F) Solenoid Connector (S2) - Solenoid Body (S2) 11 to 15ohm Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (S2) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (A245E)»(ref-225506-S14947891902006031900000) )
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|---|
| Requiredsensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MILoperation | 1 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY
Range check (A)
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| Solenoid current cut status Not cut | See LIST OF DISABLE A MONITOR |
| Battery voltage | 11 V or more |
| Target current | 0.1 A or more |
TYPICAL ENABLING CONDITIONS (RANGE CHECK (A))
Range check (B)
| The monitor will run whenever the following DTCs are not present. | See LIST OF DISABLE A MONITOR |
|---|---|
| The typical enabling condition is not available. |
TYPICAL ENABLING CONDITIONS (RANGE CHECK (B))
| Solenoid status (SLT) from IC | Fail (Open or short) (Output signal duty equal to 100%) |
TYPICAL MALFUNCTION THRESHOLDS (RANGE CHECK (A))
| Hybrid IC status | Fail (Open or short) (Output signal duty equal to 100%) |
TYPICAL MALFUNCTION THRESHOLDS (RANGE CHECK (B))
| Shift solenoid valve SLT | Resistance: 5.0 to 5.6 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 142
Scheme 143
Scheme 144
Scheme 145
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in «TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE»(ref-225480-S30449149632006031900000) . Standard: TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE Tester Connection Specified Condition 20°C (68°F) 1 (SLT+) - 4 (SLT-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in «TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE (CHECK FOR SHORT)»(ref-225480-S15019287142006031900000) . Standard (Check for short): TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE (CHECK FOR SHORT) Tester Connection Specified Condition 1 (SLT+) - Body ground 10 kohm or higher 4 (SLT-) - Body ground NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connector. Measure the resistance according to the value(s) in «ECM CONNECTOR TERMINALS RESISTANCE»(ref-225480-S36410557132006031900000) . Standard: ECM CONNECTOR TERMINALS RESISTANCE Tester Connection Specified Condition 20°C (68°F) E4 - 13 (SLT+) - E4 - 12 (SLT-) 5.0 to 5.6ohm Measure the resistance according to the value(s) in «ECM CONNECTOR TERMINALS RESISTANCE (CHECK FOR SHORT)»(ref-225480-S22337066182006031900000) . Standard (Check for short): ECM CONNECTOR TERMINALS RESISTANCE (CHECK FOR SHORT) Tester Connection Specified Condition E4 - 13 (SLT+) - Body ground 10 kohm or higher E4 - 12 (SLT-) - Body ground NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-225473-S18636529692006031900000) ) OK: REPLACE ECM (SEE «ECM (1ZZ-FE/2ZZ-GE) REPLACEMENT»(ref-225491-S27442506802006031900000) )
- INSPECT SHIFT SOLENOID VALVE (SLT) Remove the shift solenoid valve (SLT). Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE (SLT) TERMINALS RESISTANCE»(ref-225480-S13187011322006031900000) . Standard: SHIFT SOLENOID VALVE (SLT) TERMINALS RESISTANCE Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6ohm Connect the positive (+) battery lead with a 21 W bulb to the terminal 2 of the solenoid valve connector and the negative (-) battery lead to the terminal 1 of the solenoid valve connector for checking the solenoid valve operation. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE(SLT) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (A245E)»(ref-225506-S14947891902006031900000) )
| Related DTCs | P2769: Shift solenoid valve SL/Range check (Low resistance) |
|---|---|
| P2770: Shift solenoid valve SL/Range check (High resistance) | |
| Required sensors/Components | Shift solenoid valve SL |
| Frequency of operation | Continuous |
| Duration | 1 time |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Shift solenoid valve SL | Resistance: 11 to 13 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 146
Scheme 147
Scheme 148
Scheme 149
- INSPECT TRANSMISSION WIRE (SL) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in «TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE»(ref-225480-S32553395622006031900000) . Standard: TRANSMISSION WIRE CONNECTOR TERMINALS RESISTANCE Tester Connection Specified Condition 20°C(68°F) 2 - Body ground 11 to 5ohm NG: Go to step 3 OK: GO TO NEXT STEP
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in «ECM CONNECTOR TERMINALS RESISTANCE»(ref-225480-S00396729722006031900000) . Standard: ECM CONNECTOR TERMINALS RESISTANCE Tester Connection Specified Condition 20°C (68°F) E4 -10 (SL) - Body ground 11 to 15ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-225473-S18636529692006031900000) ) OK: REPLACE ECM (SEE «ECM (1ZZ-FE/2ZZ-GE) REPLACEMENT»(ref-225491-S27442506802006031900000) )
- INSPECT SHIFT SOLENOID VALVE (SL) Remove the shift solenoid valve SL. Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE SL TERMINALS RESISTANCE»(ref-225480-S30898607742006031900000) . Standard: SHIFT SOLENOID VALVE SL TERMINALS RESISTANCE Tester Connection Specified Condition 20°C(68°F) Solenoid Connector (SL) - Solenoid Body(SL) 11 to 15ohm Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK: The solenoid valve makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE(SL) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (A245E)»(ref-225506-S14947891902006031900000) )
