Engine Lubrication System: Overview Toyota Corolla IX

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Check engine oil quality. Check the oil for deterioration, entry of water, discoloring or thinning. If the quality is visibly poor, replace the oil. Oil grade: API grade SJ, Energy-Conserving or ILSAC multi-grade engine oil. SAE 5W-30 is the best choice for your vehicle, for good fuel economy, and good starting in cold weather.
2. Check engine oil level. 5 minutes after warming up the engine, the oil level should be between the "L" and "F" marks on the dipstick. If low, check for leakage and add oil up to the "F" mark. NOTE: Do not fill with engine oil above the "F" mark.
3. Remove oil pressure switch, and install oil pressure gauge. Remove the oil pressure switch. Install the oil pressure gauge.
4. Warm up engine. Allow the engine to warm up to normal operating temperature.
5. Check oil pressure. Oil pressure
6. Remove oil pressure gauge and reinstall oil pressure switch. Remove the oil pressure gauge. Apply adhesive to 2 or 3 threads of the oil pressure switch. Adhesive: Part No. 08833-00080, THREE BOND 1344, LOCTITE 242 or equivalent Install the oil pressure switch. Torque: 13 N.m (130 kgf.cm, 9 ft.lbf)
7. Start engine and check for leaks.
