- CHECK ENGINE OIL QUALITY Check the oil for deterioration, entry of water, discoloring or thinning. If the quality is visibly poor, replace the oil. Oil grade: API grade SL Energy-Conserving or ILSAC multigrade engine oil.
- CHECK ENGINE OIL LEVEL After warming up the engine and then 5 minutes after the engine stop, oil level should be between the "L" and "F" marks on the dipstick. If low. check for leakage and add oil up to the "F" mark. NOTE: Do not fill with engine oil above the "F" mark.
- REMOVE OIL PRESSURE SWITCH, AND INSTALL OIL PRESSURE GAUGE Using SST, remove the oil pressure switch. SST 09816-30010 Install the oil pressure gauge.
- WARM UP ENGINE Allow the engine to warm up to normal operating temperature.
- CHECK OIL PRESSURE Oil pressure: At idle speed 1ZZ-FE 29 kPa (0.3 kgf/cm 2 , 4.3 psi) or more 2ZZ-GE 39.2 kPa (0.4 kgf/cm 2 , 5.7 psi) or more At 3,000 rpm 294 - 539 kPa (3.0 - 5.5 kgf/cm 2 , 43 - 78 psi)
- REMOVE OIL PRESSURE GAUGE AND REINSTALL OIL PRESSURE SWITCH Remove the oil pressure gauge. Apply adhesive to 2 or 3 threads of the oil pressure switch. Adhesive: Part No. 08833-00080, THREE BOND 1344, LOCTITE 242 or equivalent Using SST, install the oil pressure switch. SST 09816-30010 Torque: 13 N.m (130 kgf.cm, 9 ft.lbf)
- START ENGINE AND CHECK FOR LEAKS
