Radiator: Other Toyota Celica T230

ON-VEHICLE CLEANING

Using water or a steam cleaner, remove any mud or dirt from the radiator core.

Note. If using a high pressure type cleaner, be careful not to deform the fins of the radiator core. (i.e. Maintain a distance between the cleaner nozzle and radiator core.)

Scheme 28

Scheme 29

1. REMOVE RESERVOIR CAP CAUTION: To avoid the danger of being burned, do not remove the reservoir cap while the engine and radiator are still hot, as fluid and steam can be blown out under pressure.
2. INSPECT RESERVOIR CAP NOTE: If the reservoir cap has contaminations, always rinse it with water. Before using a radiator cap tester, wet the relief valve and pressure valve with engine coolant or water. When performing steps a and b below, keep the radiator cap tester at an angle of over 30° above the horizontal. Using a radiator cap tester, slowly pump the tester and check that air is coming from the vacuum valve. Pump Speed: 1 push/(3 seconds or more) NOTE: Push the pump at a constant speed. If air is not coming from the vacuum valve, replace the reservoir cap. Pump the tester and measure the relief valve opening pressure. Pump Speed: 1 push within 1 seconds NOTE: This pump speed is for the first pump only (in order to close the vacuum valve). After this, the pump speed can be reduced. Standard Opening Pressure: 93 - 123 kPa (0.95 - 1.25 kgf/cm 2 , 13.5 - 17.8 psi) Minimum Opening Pressure: 79 kPa (0.8 kgf/cm 2 , 11.5 psi) HINT: Use the tester's maximum reading as the opening pressure. If the opening pressure is less than minimum, replace the reservoir cap.
3. INSPECT COOLING SYSTEM FOR LEAKS Fill the radiator with coolant and attach a radiator cap tester. Warm up the engine. Pump it to 118 kPa (1.2 kgf/cm 2 , 17.1 psi), and check that the pressure does not drop. If the pressure drops, check the hoses, radiator or water pump for leaks. If no external leaks are found, check the heater core, cylinder block and head.
4. REINSTALL RESERVOIR CAP

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. REMOVE UPPER FRONT FENDER APRON SEAL AND UPPER RADIATOR SUPPORT SEAL
2. DRAIN ENGINE COOLANT
3. REMOVE BUMPER COVER . See «FRONT BUMPER»(ref-225252) .
4. REMOVE AIR CLEANER
5. REMOVE ENGINE COOLANT RESERVOIR Disconnect the 3 radiator reservoir hoses. Remove the bolt and engine coolant reservoir.
6. REMOVE RADIATOR ASSEMBLY Disconnect the No. 1 electric cooling fan connector. Disconnect the No. 2 electric cooling fan connector. Disconnect the upper radiator hose. Disconnect the lower radiator hose. Disconnect the 2 A/T oil cooler hoses. Remove the 3 bolts, and disconnect the hood lock. Remove the 2 bolts and center brace. Remove the 2 bolts, 2 nuts and 2 condenser upper supports. W/ cruise control system: Remove the bolt, and disconnect the cruise control actuator. Remove the 2 bolts and radiator upper support. Remove the 2 upper radiator support bushings. Remove the radiator assembly. Remove the 2 lower radiator support bushings.
7. REMOVE ELECTRIC COOLING FAN FROM RADIATOR

Remove the 2 bolts and cooling fan assembly.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. REMOVE DRAIN PLUG Remove the drain plug. Remove the O-ring.
2. DENSO Made: ASSEMBLE SST SST 09230-01010 Install the claw to the overhaul handle, inserting it in the hole in part "A" (Scheme 36) While gripping the handle, adjust the stopper bolts so that dimension "B" (Scheme 36)is 0.2 - 0.3 mm (0.008 - 0.012 in.). NOTE: If this adjustment is not done the claw may be damaged.
3. DENSO Made: UNCAULK LOCK PLATES Using SST to release the caulking, squeeze the handle until stopped by the stopper bolt. SST 09230-01010
4. DENSO Made: REMOVE TANKS AND O-RINGS Lightly tap the bracket of the radiator (or radiator inlet or outlet) with a soft-faced hammer, and remove the tank and the O-ring.
5. A/T (DENSO Made): REMOVE OIL COOLER FROM LOWER TANK Loosen the nut, and remove the cooler pipe. Remove the 2 nuts and 2 plate washers. Remove the oil cooler and 2 O-rings.
