All Windows Inoperative & Lock-Out Is Inoperative
Check for defective fuse (ALT, AM1, DOOR, GAUGE, POWER), ignition switch, door lock control relay, driver's side power window switch or wiring circuits.
All Windows Inoperative & Lock-Out Operates Normal
Check for defective fuse (GAUGE, POWER), ignition switch, door lock control relay, driver's side power window switch or power main relay.
Lock Switch Inoperative
Check driver's side power window lock switch.
Window Lock Illumination Does Not Operate
Check driver's side power window switch.
One-Touch Feature Is Inoperative
Check driver's side power window switch.
One Window Does Not Operate
Check driver's side power window switch for appropriate window, power window switch, power window motor and wiring circuits for appropriate window.
Note. For door lock control relay testing, see DOOR LOCKS - POWER article. For ignition switch testing, see the STEERING COLUMN SWITCHES article. Both articles located in the ACCESSORIES/SAFETY EQUIPMENT section.
POWER WINDOW MAIN RELAY
- Remove power window main relay, located behind instrument panel, left of steering column on Camry, in junction block No. 2 at left side kick panel.
- Using an ohmmeter, check continuity between terminals No. 1and 2. Continuity should exist. (Scheme 4) Apply battery voltage to terminal No. 1 and ground terminal No. 2. Continuity should exist at terminals No. 3 and 5. If relay does not test as described, replace power window main relay.
Scheme 4
POWER WINDOW MOTOR
Remove door trim panel and waterproof shield. Remove glass retaining bolts and glass. Remove window regulator nuts and remove window regulator. Remove power window motor retaining screws and remove motor from window regulator. To install, reverse removal procedure.
POWER WINDOW SWITCH
Disconnect negative battery cable. Pry out power window switch from door panel using flat screwdriver. Disconnect power window switch connectors and remove switch. To install, reverse removal procedure.
