Engine Controls - Tests W/codes - 2.2L: Overview Toyota Celica T200

Testing & Diagnostics 1 illustration

TROUBLE CODE IDENTIFICATION

CodeSystem Affected(1) MIL In Normal Mode(1) MIL In Test ModeProbable Cause
DTC 12 (Except Calif.)RPM SignalONN/ADistributor, Starter Or Circuit, ECM
DTC 12 (Calif.)RPM SignalONN/ADistributor, Starter Or Circuit, ECM
DTC 13RPM Signal(2)(3)Distributor Or Circuit, ECM
DTC 14Ignition SignalONN/AIgnitor Or Circuit To ECM, ECM
DTC 16 (4)ECT Control SignalONN/AECM Or Circuit
DTC 21Oxygen Sensor SignalONONOxygen Sensor Or Circuit, ECM
DTC 22Engine Coolant Temperature Sensor SignalONONEngine Coolant Temp. Sensor Or Circuit, ECM
DTC 24Intake Air TemperatureONONIntake Air Temp. SensorOr Circuit, ECM
DTC 25Lean Air/Fuel MixtureONONInjector Or Circuit, Oxygen Sensor Or Circuit Fuel Pressure, Ignition System, Vacuum Leak, Compression Pressure, ECM
DTC 26Rich Air/Fuel MixtureONONInjector Or Circuit, Oxygen Sensor Or Circuit Fuel Pressure, Ignition System, Vacuum Leak, Compression Pressure, ECM
DTC 27Sub-Oxygen Sensor SignalONONSub-Oxygen Sensor Or Circuit, ECM
DTC 31MAP Sensor SignalONONMAP Sensor Or Circuit, ECM
DTC 41Throttle Position Sensor SignalONONThrottle Position Sensor Or Circuit, ECM
DTC 42Vehicle Speed Sensor SignalONOFFVehicle Speed Sensor Or Circuit, ECM
DTC 43Starter SignalN/AOFFStarter Signal Circuit,Starter Relay, IgnitionSwitch Or Circuit, ECM
DTC 51Switch Condition SignalN/AOFFA/C Switch Circuit, Park/Neutral Switch Or Circuit, TPS Or Circuit, ECM
DTC 52Knock Sensor SignalONN/AKnock Sensor Or Circuit, ECM
DTC 71EGR System MalfunctionONONEGR System, EGR Temp. Sensor Or Circuit, EGR-VSV, ECM
(1) ON indicates MIL on instrument panel will be illuminated. N/A indicates item is not included in malfunction diagnosis when using this mode. OFF indicates MIL on instrument panel will not be illuminated even if malfunction is detected. (2) The MIL will be illuminated only if no "NE" signal is sent to ECM with engine at approximately 1000 RPM (Calif. models) or 1500 RPM (all others). (3) The MIL will be illuminated only if no "G" signal is sent to ECM at least 4 times with engine speed between 500 and 4000 RPM. Also, on Calif. models, when in Test Mode, MIL will be illuminated if "NE" signal does not pulse 12 times to ECM during interval between "G1" and "G2" pulses. (4) Applies only to models with electronic-controlled automatic transaxle.
(1)ON indicates MIL on instrument panel will be illuminated. N/A indicates item is not included in malfunction diagnosis when using this mode. OFF indicates MIL on instrument panel will not be illuminated even if malfunction is detected.
(2)The MIL will be illuminated only if no "NE" signal is sent to ECM with engine at approximately 1000 RPM (Calif. models) or 1500 RPM (all others).
(3)The MIL will be illuminated only if no "G" signal is sent to ECM at least 4 times with engine speed between 500 and 4000 RPM. Also, on Calif. models, when in Test Mode, MIL will be illuminated if "NE" signal does not pulse 12 times to ECM during interval between "G1" and "G2" pulses.
(4)Applies only to models with electronic-controlled automatic transaxle.

TROUBLE CODE IDENTIFICATION

Scheme 119

Scheme 119: ECM TERMINAL IDENTIFICATION
