Maintenance Information: Overview Toyota Celica T200

Procedures 8 illustrations ~881 words

Fuse & Circuit Breaker Identification

  1. 1 - 7.5 Amp - Charging System & Discharge Warning Light, Electric Cooling Fans & EFI System
  2. 2 - 15 Amp - Cigarette Lighter & Digital Clock, Radio, Cassette Player & Compact Disc Player
  3. 3 - 15 Amp - Stoplights & Cruise Control Cancel Device
  4. 4 - 15 Amp - Gauges, Warning Lights & Buzzer, Back-Up Lights & A/T Overdrive System, Rear Window Defogger & Power Antenna, Tilt Steering, Convertible Top Control
  5. 5 - 10 Amp - Turn Signal Lights
  6. 6 - 15 Amp - Electric Sun Roof
  7. 7 - 20 Amp - Wipers & Washers
  8. 8 - 15 Amp - Anti-Lock Brake System
  9. 9 - 15 Amp - Taillights, Parking Lights, Side Marker Lights, License Lights, Instrument Lights, Glove Box Light
  10. 10 - Blank
  11. 11 - 10 Amp - Rear View Mirror
  12. 12 - 30 Amp (Circuit Breaker) - Defogger
  13. 13 - Blank
  14. 14 - 20 Amp - Front Foglights
  15. 15 - 10 Amp - Air Conditioning
  16. 16 - 40 Amp (Circuit Breaker) - Heater, A/C Control System

Relay Identification

  1. A - Turn Signal Flasher
  2. B - Defogger
  3. C - Taillight Control
  4. D - Starter
  5. E - Heater Main

Scheme 1

Scheme 1: ENGINE COMPARTMENT MAIN FUSE & RELAY IDENTIFICATION (1990-93)
Scheme 1: ENGINE COMPARTMENT MAIN FUSE & RELAY IDENTIFICATION (1990-93)
  1. 1 - 15 Amp - Headlight (Left Side)
  2. 2 - 30 Amp - Retractable Headlight System
  3. 3 - 15 Amp - Headlight (Right Side)
  4. 4 - 15 Amp - EFI System
  5. 5 - 20 Amp - Radio, Cassette Player & Compact Disc Player, Power Antenna, Clock, Interior & Personal Lights, Door Courtesy Lights, Luggage Compartment Light, Trunk Light, Ignition Switch, Open Door Warning Lights
  6. 6 - 15 Amp - Hazard Flashers & Horns
  7. 7 - 30 Amp (Circuit Breaker) - Cooling Fan
  8. 8 - 30 Amp (Circuit Breaker) - Condenser Cooling Fan
  9. 9 - 100 Amp (Circuit Breaker) - Charging System
  10. 10 - 40 Amp (Circuit Breaker) - AM2 30 Amp (1992-93) - Electronic Fuel Injection, Ignition System
  11. 11 - 30 Amp (Circuit Breaker) - AM1 40 Amp (1992-93) - Charging System, Electric Underhood Cooling Fan
  12. 12 - 60 Amp (Circuit Breaker) - Anti-Lock Brake System

Relay Identification

  1. A - Fan No. 1
  2. B - Headlight Control
  3. C - EFI System
  4. D - Engine Main

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION (1994-96)
Scheme 2: FUSE PANEL IDENTIFICATION (1994-96)

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. 1 - 30 Amp - Starting System
  2. 2 - 10 Amp - Emergency Flashers
  3. 3 - 7.5 Amp - Horns
  4. 4 - 20 Amp - Car Audio System
  5. 5 - 15 Amp - Anti-Lock Brake System, Cruise Control System
  6. 6 - 10 Amp - Interior Lights, Personal Lights, Luggage Compartment Light, Trunk Light, Door Courtesy Lights, Clock
  7. 7 - 15 Amp - Left Hand Headlight
  8. 8 - 15 Amp - Right Hand Headlight
  9. 9 - Spare
  10. 10 - Spare
  11. 11 - Spare
  12. 12 - 7.5 Amp - Charging System
  13. 13 - 7.5 Amp - SRS Airbag Warning Light
  14. 14 - 15 Amp - Multiport Fuel Injection System/Sequential Multiport Fuel Injection System
  15. 15 - 15 Amp - Left Hand Headlight (Low Beam)
  16. 16 - 15 Amp - Right Hand Headlight (Low Beam)
  17. 17 - 15 Amp - Right Hand Headlight (High Beam)
  18. 18 - 15 Amp - Left Hand Headlight (High Beam)
  19. 19 - 7.5 Amp - Daytime Running Lights
  20. 20 - 15 Amp - Electronically Controlled Automatic Transmission System, Anti-Lock Brake System
  21. 21 - 20 Amp - No Circuit
  22. 22 - 7.5 Amp - Instrument Panel Lights
  23. 23 - 15 Amp - Stop Lights, High Mounted Stop Light, Multiport Fuel Injection System/Sequential Multiport Fuel Injection System, Cruise Control System Cancel Device
  24. 24 - 20 Amp - Front Fog Lights
  25. 25 - 15 Amp - Cigarette Lighter, Digital Clock Display, Car Audio System
  26. 26 - 7.5 Amp - Charging System, Discharge Warning Light, Multiport Fuel Injection System/Sequential Multiport Fuel Injection System, SRS Airbag System
  27. 27 - 20 Amp - Windshield Wipers & Washer, Rear Window Wiper & Washer
  28. 28 - 10 Amp - Multiport Fuel Injection System/Sequential Multiport Fuel Injection System
  29. 29 - 10 Amp - Turn Signal Lights, Emergency Flashers
  30. 30 - 15 Amp - Tail Lights, Parking Lights, Front Side Marker Lights, Rear Side Marker Lights, License Plate Lights
  31. 31 - 10 Amp - Air Conditioning System, Rear Window Defogger
  32. 32 - 10 Amp - Gauges & Meters, Power Door Lock System
  33. 33 - 7.5 Amp - Starting System, Multiport Fuel Injection System/Sequential Multiport Fuel Injection System
  34. 34 - 10 Amp - Air Conditioning System
  35. 35 - 7.5 Amp - On-Board Diagnosis Sytsem
  36. 36 - 30 Amp - Electric Cooling Fan
  37. 37 - 30 Amp - Electric Cooling Fan
  38. 38 - 40 Amp - Electronic Ignition System/Distributor Ignition System
  39. 39 - 30 Amp - Power Door Lock System, Convertible Top Control System
  40. 40 - 30 Amp - Rear Window Defogger
  41. 41 - 30 Amp - Power Windows, Electric Moonroof
  42. 42 - 40 Amp - Air Conditioning System
  43. 43 - 100 Amp - Charging System, Tail Lights, Parking Lights, Front Side Marker Lights, Rear Side Marker Lights, License Plate Lights, Power Door Lock System, Convertible Top Control System, Rear Window Defogger, Power Windows, Electric Moonroof
  44. 44 - 60 Amp - Starting System, Headlights, Starting System, Horns, Emergency Flashers, Interior Lights, Personal Lights, Luggage Compartment Light, Trunk Light, Door Courtesy Lights, Clock, Car Audio Sytem
  45. 45 - 50 Amp - Anti-Lock Brake System
