Maintenance Information Toyota Celica T160

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

SEVERE & NORMAL SERVICE DEFINITIONS

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Normal Service

1. Driven More Than 10 Miles Daily
2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Driving Conditions)

1. Towing A Trailer, Using A Camper Or Car Top Carrier
2. Repeated Short Trips Less Than 5 Miles When Temperatures Are Below Freezing
3. Extensive Idling Conditions (Taxi Or Delivery Type Service)
4. Operating On Dusty, Rough, Muddy Or Salt Spread Roads

CAMSHAFT TIMING BELT

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

1. Cracks Or Tears In Belt Surface
2. Missing, Damaged, Cracked Or Rounded Teeth
3. Oil Contamination
4. Damaged Or Faulty Tensioners
5. Incorrect Tension Adjustment

For vehicles under severe service conditions, replace camshaft timing belt every 60,000 miles. For vehicles under normal service conditions, inspect the camshaft timing belt at 72 months or 60,000 miles, and then every 12 months or 10,000 miles thereafter.

Scheme 3

Scheme 4

Scheme 5

WHEEL TIGHTENING

Tighten all wheel lug nuts to 76 ft. lbs. (103 N.m).

BATTERY SPECIFICATIONS

All years and models use batteries with BCI group number 24F.

RADIATOR FAN & CAP

To avoid injury, stay clear of radiator fan when ignition switch is in ON position. Fan is thermostatically controlled and may come on suddenly. DO NOT loosen or remove radiator cap when cooling system is hot.

CATALYTIC CONVERTER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) EQUIPPED VEHICLES

When servicing vehicles equipped with Supplemental Restraint System (SRS), always allow at least 20 seconds after turning ignition switch to LOCK position and disconnecting negative terminal cable before working on SRS. System has a back-up power supply and may deploy air bag.

WARRANTY INFORMATION

NEW VEHICLE LIMITED WARRANTY

Covers any repair or replacement of parts which becomes necessary due to defects in materials or workmanship under normal use for 36 months or 36,000 miles from in-service date.

CORROSION PERFORATION

Covers any repair or replacement to body sheet metal which develops corrosion perforation (hole through panel), in normal use, due to defects in material or workmanship for a period of 5 years, regardless of mileage.

BATTERY

Covers replacement of defective original battery for first 12 months or 12,000 miles. After first 12 months or 12,000 miles, warranty covers a pro-rated amount based on months in service, up to 36 months.

AIR CONDITIONER REFRIGERANT CHARGE

Covers air conditioner refrigerant for first 12 months, regardless of mileage, unless done as a warranty repair.

ADJUSTMENTS

Service adjustments are covered for first 12 months or 12,500 miles, whichever occurs first.

EMISSION DEFECT WARRANTY (EXCEPT CALIFORNIA)

Warrants to retail purchaser and subsequent purchaser that vehicle was designed, built and equipped to conform with applicable emission regulations at time of sale and that vehicle is free of defects in materials and workmanship which may cause vehicle to fail to conform with applicable regulations for 5 years or 50,000 miles, whichever occurs first.

EMISSION PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Covers all repairs, adjustments and replacements if vehicle fails to conform to applicable emission standards and such failure results or will result in vehicle owner bearing any penalty or other sanctions under local, state or federal law for 5 years or 50,000 miles, whichever comes first. After 24 months or 24,000 miles, manufacturer will make necessary adjustments, repairs and replacements at no cost to owner when noncompliance is caused by a failure of any of following parts.

1. Cold Start Enrichment System
2. Deceleration Control
3. Air/Fuel Ratio Feedback Control System
4. HAC Valve
5. Automatic Hot Air Intake
6. Heat Control Valve
7. Mixture Control Valve
8. Cold Mixture Heater
9. Spark Control Devices
10. PCV Valve Or Orifice
11. Charcoal Canister
12. Vapor Liquid Separator
13. EGR Valve And Associated Parts
14. Air Pump
15. Airflow Control Valves
16. Air Injection Manifold
17. Catalytic Converter
18. Fuel Filler Neck Restrictor
19. Sensors, Switches, Valves And Electronic Controls Used In Above Systems
20. Hoses, Clamps, Belts, Pulleys, Tubes, Fittings And Gaskets Used In Above Systems

EMISSION DEFECT WARRANTY (CALIFORNIA)

Warrants to the retail purchaser, and subsequent purchaser that vehicle was designed, built, and equipped so as to conform at the time of sale with applicable U.S. and California emission regulations and that it is free from defects in materials or workmanship which may cause the vehicle to fail to conform with applicable regulations. The following components are covered for 24 months or 24,000 miles

1. Carburetor And Internal Parts
2. EFI Components
3. Cold Start Enrichment System
4. Distributor And Internal Parts
5. Spark Plugs
6. Ignition Wires
7. Hoses, Clamps, Fittings, Tubing, Sealing Gaskets Or Devices, And Mounting Hardware Used In Above Systems
8. Pulleys, Belts And Idlers Used In Above Systems

Following components are covered by California Emission Defect Warranty for 5 years or 50,000 miles, whichever occurs first.

1. Deceleration Control
2. Air/Fuel Ratio Feedback Control System
3. HAC Valve
4. Automatic Hot Air Intake
5. Heat Control Valve
6. Mixture Control Valve
7. Cold Mixture Heater
8. Intake Manifold
9. Spark Control Devices
10. Ignition Coil And Ignitor
11. PCV Valve Or Orifice
12. Oil Filler Cap
13. Charcoal Canister
14. Vapor Liquid Separator
15. Fuel Tank And Filler Cap
16. EGR Valve And Associated Parts
17. Air Pump
18. Airflow Control Valves
19. Air Injection Manifold
20. Catalytic Converter
21. Fuel Filler Neck Restrictor
22. Exhaust Manifold
23. Exhaust Pipe
24. Sensors, Switches, Valves And Electronic Controls Used In Above Systems
25. Hoses, Clamps, Belts, Pulleys, Tubes, Fittings And Gaskets Used In Above Systems

FUSE PANEL LOCATION

There are 3 fuse panels on this vehicle. The driver's side fuse box is located behind the driver's kick panel. The passenger's side fuse box is behind the passenger's side kick panel. The main fuse and relay block is in the engine compartment.

Scheme 6

Fuse & Circuit Breaker Identification

1. 1 - 15 Amp Gauges, Warning Lights & Buzzer, Back-Up Lights & A/T Overdrive System, Rear Window Defogger & Power Antenna
2. 2 - 7.5 Amp Clock & Open Door Warning Light (1987), Interior, Personal & Door Courtesy Lights (1987), Trunk & Ignition Switch Lights (1987)
3. 3 - 15 Amp Stoplights & Cruise Control Cancel Device
4. 4 - 15 Amp Tail, Park, License & Side Marker Lights, Glove Box Light & Instrument Illumination
5. 5 - 15 Amp Cigarette Lighter & Digital Clock
6. 6 - 7.5 Amp Radio & Cassette Player
7. 7 - 10 Amp Turn Signal Lights
8. 8 - 10 Amp Outside Mirror Defogger
9. 9 - Blank
10. 10 - 10 Amp Charging System
11. 11 - 20 Amp Wipers & Washers
12. 12 - 15 Amp Electric Sun Roof
13. 13 - Blank
14. 14 - 7.5 Amp Charging System & Discharge Warning Light, Electronic Fuel Injection & Electric Cooling Fans
15. 15 - 30 Amp (Circuit Breaker) Defogger
16. 16 - 14 Amp (Circuit Breaker 1986) 30 Amp (Circuit Breaker 1987-89) Power Door Locks
17. 17 - 30 Amp (Circuit Breaker) Power Windows
18. 18 - 15 Amp Anti-Lock Brake System & Foglights (1988-89)
19. 19 - 10 Amp Air Conditioning System
20. 20 - 30 Amp (Circuit Breaker) Heater

Relay Identification

1. A - Defogger
2. B - Taillight Control
3. C - Turn Signal Flasher
4. D - Clutch Start
5. E - Horn
6. F - Heater

Scheme 7

1. 1 - 15 Amp Headlights (Left)
2. 2 - 15 Amp Emergency Flashers & Horns
3. 3 - 15 Amp EFI System
4. 4 - 7.5 Amp Charging System & Discharge Warning Light
5. 5 - 15 Amp Headlights (Right)
6. 6 - 30 Amp Retractable Headlight System
7. 7 - 15 Amp (1986-87) 20 Amp (1988-89) Radio, Cassette Player & Power Antenna, Interior, Trunk, Personal & Courtesy Lights (1988-89), Ignition Switch & Door Warning Lights (1988-89), Clock (1988-89)
8. 8 - Blank
9. 9 - 30 Amp Fan

1. A - Engine Main
2. B - EFI Main
3. C - Headlight Control
4. D - Fan No. 1
