Immobilizer circuit, except hybrid w/ smart key system for Toyota Camry XV50 (2011-2014)
Immobilizer circuit, except hybrid w/ smart key system
A/C CONTROL ASSEMBLY
AGND
ANTENNA
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
CERTIFICATION ECU (RIGHT SIDE OF DASH)
CODE
COIL
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECM (LEFT SIDE OF ENGINE COMPT)
EFII
EFIO
ENGINE ROOM R/B
ENGINE SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IMI
IMO
IND
INSTRUMENT PANEL J/B
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
SECURITY INDICATOR
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
TXCT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
