Engine Mechanical (2AZ-FE): Overview Toyota Camry XV40

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. INSPECT ENGINE COOLANT Inspect the engine coolant (See «ON-VEHICLE INSPECTION»(/toyota/camry/xv40-2006-2009/remont/cooling-fan/#engine-cooling-system-2az-fe__on-vehicle-inspection) ).
2. INSPECT ENGINE OIL Inspect the engine oil (See «ON-VEHICLE INSPECTION»(ref-287562-S20894886862008061200000) ).
3. INSPECT BATTERY Inspect the battery (See «ON-VEHICLE INSPECTION»(ref-287568-S39623878562008061200000) ).
4. INSPECT SPARK PLUGS Inspect the spark plugs (See «ON-VEHICLE INSPECTION»(/toyota/camry/xv40-2006-2009/remont/ignition-system/#engine-ignition-system-2az-fe) ).
5. INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Remove the air cleaner filter element sub-assembly. Visually check that there is no dirt, blockage, and/or damage to the air cleaner filter element. HINT: If there is any dirt or a blockage in the air cleaner filter element, clean it with compressed air. If any dirt or a blockage remains even after cleaning the air cleaner filter element with compressed air, replace it.
6. INSPECT IGNITION TIMING Warm up the engine. When using the Techstream: Check the ignition timing. Connect the Techstream to the DLC3. Enter DATA LIST MODE on the Techstream. Ignition timing: 8 to 12° BTDC at idle HINT: Refer to the Techstream operator's service information for help when selecting the DATA LIST. When not using the Techstream: Check the ignition timing. Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3. SST 09843-18040 NOTE: Confirm the terminal numbers before connecting them. Connection with a wrong terminal can damage the engine. Turn off all electrical systems before connecting the terminals. Perform this inspection after the cooling fan motor is turned off. Remove the No. 1 engine cover. Pull out the wire harness as shown in the illustration. Connect the clip of the timing light to the wire harness. NOTE: Use a timing light which can detect the first signal. After checking, be sure to tape the wire harness. Check the ignition timing at idle. Ignition timing: 8 to 12° BTDC at idle NOTE: When checking the ignition timing, the transmission should be in neutral. HINT: After engine rpm is kept at 1,000 to 1,300 rpm for 5 seconds, check that it returns to idle speed. Disconnect terminals 13 (TC) and 4 (CG) of the DLC3. Check the ignition timing at idle. Ignition timing: 5 to 15° BTDC at idle Confirm that the ignition timing moves to the advanced angle side when the engine rpm is increased. Remove the timing light.
7. INSPECT ENGINE IDLE SPEED Warm up the engine. When using the Techstream: Check the idle speed. Connect the Techstream to the DLC3. HINT: Refer to the Techstream operator's service information for further details. Enter DATA LIST MODE on the Techstream. Idle speed IDLE SPEED SPECIFICATION Item Specified Condition M/T 650 to 750 rpm A/T 610 to 710 rpm NOTE: When checking the idle speed, the transmission should be in neutral. Check the idle speed with the cooling fan off. Switch off all accessories and air conditioning before connecting the Techstream. When not using the Techstream: Check the idle speed. Using SST, connect the tachometer tester probe to terminal 9 (TAC) of the DLC3. SST 09843-18030 Check the idle speed. Idle speed IDLE SPEED SPECIFICATION Item Specified Condition M/T 650 to 750 rpm A/T 610 to 710 rpm
8. INSPECT COMPRESSION Warm up and stop the engine. Disconnect the injector connectors. Remove the ignition coils. Remove the spark plugs. Check the cylinder compression pressure. Insert a compression gauge into the spark plug hole. Fully open the throttle. While cranking the engine, measure the compression pressure. Compression pressure: 1.360 MPa (13.9 kgf/ cm 2 , 198 psi) Minimum pressure: 0.98 MPa (10 kgf/ cm 2 , 142 psi) Difference between each cylinder: 100 kPa (1.0 kgf/ cm 2 , 14 psi) NOTE: Always use a fully charged battery to obtain an engine speed of 250 rpm or more. Check the other cylinders' compression pressure in the same way. This measurement must be done as quickly as possible. If the cylinder compression is low, pour a small amount of engine oil into the cylinder through the spark plug hole and inspect again. HINT: If adding oil increases the compression, the piston rings and/or cylinder bore may be worn or damaged. If pressure stays low, a valve may be stuck or seated improperly, or there may be leakage in the gasket.
9. INSPECT CO/HC Start the engine. Run the engine at 2,500 rpm for approximately 180 seconds. Insert the CO/HC meter testing probe at least 40 cm (1.3 ft) into the tailpipe during idling. Immediately check CO/HC concentration at idle and/or 2,500 rpm. HINT: Complete the measuring within 3 minutes. Check regulations and restrictions in your area when performing 2 mode CO/HC concentration testing (engine check at both idle speed and at 2,500 rpm). If the CO/HC concentration does not comply with regulations, troubleshoot in the order given below. Check A/F sensor and heated oxygen sensor operation (See «INSPECTION»(/toyota/camry/xv40-2006-2009/remont/auxiliary-emission-control-systems/#emission-control-system-2az-fe) ). See the table below for possible causes, and then inspect and repair. CO/HC PROBLEM CHART CO HC Problems Causes Normal High Rough idle Faulty ignitions: Incorrect timing Fouled, shorted or improperly gapped plugs Incorrect valve clearance Leaky intake and exhaust valves Leaky cylinders Low High Rough idle (fluctuating HC reading) Vacuum leaks: PCV hoses Intake manifold Throttle body Brake booster line Lean mixture causing misfire High High Rough idle (black smoke from exhaust) Restricted air filter Plugged PCV valve Faulty SFI system: Faulty pressure regulator Defective ECT Defective MAF meter Faulty ECM Faulty injectors Faulty throttle position sensor

Scheme 5

Scheme 6

1. REMOVE FRONT WHEEL RH
2. REMOVE ENGINE UNDER COVER RH
3. REMOVE FRONT FENDER APRON SEAL RH
4. REMOVE V-RIBBED BELT Using SST and 19 mm socket wrench, loosen the V-ribbed belt tensioner arm clockwise, then remove the V-ribbed belt. SST 09216-42010 NOTE: Be sure to connect SST and the tools so that they are in line during use. When retracting the tensioner, turn it clockwise slowly for 3 seconds or more. Do not apply force rapidly. After the tensioner is fully retracted, do not apply force any more than necessary.

Scheme 7

1. INSPECT V-RIBBED BELT Visually check the V-ribbed belt for excessive wear, frayed cords, etc. If any defect has been found, replace the V-ribbed belt. HINT: Cracks on the rib side of a belt are considered acceptable. If the belt has chunks missing from the ribs, it should be replaced. A "new belt" is a belt which has been used for less than 5 minutes with the engine running. A "used belt" is a belt which has been used for 5 minutes or more with the engine running.
