Engine Ignition System: Removal & Installation Toyota Camry XV30

Ignition System 8 illustrations ~355 words

REPLACEMENT

HINT

A bolt without torque specification is a standard bolt (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 13

Scheme 13: REPLACEMENT
Scheme 13: REPLACEMENT
  1. REMOVE AIR CLEANER ASSY (See «REPLACEMENT»(ref-225970-S24875794802006032400000) )
  2. REMOVE CAMSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
  3. INSTALL CAMSHAFT POSITION SENSOR Apply a light coat of engine oil to the O-ring on the sensor. Install the sensor with the bolt. Torque: 9.0 N.m (92 kgf.cm, 80in.lbf)
  4. INSTALL AIR CLEANER ASSY (See «REPLACEMENT»(ref-225970-S24875794802006032400000) )
  5. CHECK CONNECTION OF VACUUM HOSE

HINT

A bolt without torque specification is a standard bolt (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 14

Scheme 14: REPLACEMENT
Scheme 14: REPLACEMENT

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. REMOVE ENGINE UNDER COVER RH Remove the 5 screws, 3 clips and the under cover.
  2. REMOVE FRONT FENDER APRON SEAL RH Remove the clip, 2 bolts and apron seal.
  3. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt, clamp and sensor.
  4. INSTALL CRANKSHAFT POSITION SENSOR Torque: 9.0 N.m (92 kgf.cm, 80 in.lbf)
  5. INSTALL FRONT FENDER APRON SEAL RH
  6. INSTALL ENGINE UNDER COVER RH

HINT

A bolt without torque specification is a standard bolt (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 17

Scheme 17: REPLACEMENT
Scheme 17: REPLACEMENT
  1. REMOVE AIR CLEANER INLET ASSY
  2. REMOVE AIR CLEANER ASSY (See «REPLACEMENT»(ref-225970-S10531405612006032400000) )
  3. REMOVE VVT SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
  4. INSTALL VVT SENSOR Apply a light coat of engine oil to the O-ring on the sensor. Install the sensor with the bolt. Torque: 8.0 N.m (82 kgf.cm, 71 in.lbf) Connect the sensor connector.
  5. INSTALL AIR CLEANER ASSY (See «REPLACEMENT»(ref-225970-S10531405612006032400000) )
  6. INSTALL AIR CLEANER INLET ASSY
  7. CHECK CONNECTION OF VACUUM HOSE

HINT

A bolt without torque specification is a standard bolt (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 18

Scheme 18: REPLACEMENT
Scheme 18: REPLACEMENT

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. REMOVE ENGINE UNDER COVER RH Remove the 5 screws, 3 clips and the under cover.
  2. REMOVE FRONT FENDER APRON SEAL RH Remove the clip, 2 bolts and apron seal.
  3. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.
  4. INSTALL CRANKSHAFT POSITION SENSOR Torque: 8.0 N.m (82 kgf.cm, 71 in.lbf)
  5. INSTALL FRONT FENDER APRON SEAL RH
  6. INSTALL ENGINE UNDER COVER RH
