SPECIFIED TORQUE FOR STANDARD BOLTS
| Class | Diameter mm | Pitch mm | Specified torque | |||||
|---|---|---|---|---|---|---|---|---|
| Hexagon head bolt | Hexagon flange bolt | |||||||
| N.m | Kgf.cm | Ft.lbf | N.m | Kgf.cm | Ft.lbf | |||
| 4T | 6 | 1 | 5 | 55 | 48 in..lbf | 6 | 60 | 52 in..lbf |
| 8 | 1.25 | 12.5 | 130 | 9 | 14 | 145 | 10 | |
| 10 | 1.25 | 26 | 260 | 19 | 29 | 290 | 21 | |
| 12 | 1.25 | 47 | 480 | 35 | 53 | 540 | 39 | |
| 14 | 1.5 | 74 | 760 | 55 | 84 | 850 | 61 | |
| 16 | 1.5 | 115 | 1,150 | 83 | ||||
| 5T | 6 | 1 | 6.5 | 65 | 56 in..lbf | 7.5 | 75 | 65 in..lbf |
| 8 | 1.25 | 15.5 | 160 | 12 | 17.5 | 175 | 13 | |
| 10 | 1.25 | 32 | 330 | 24 | 36 | 360 | 26 | |
| 12 | 1.25 | 59 | 600 | 43 | 65 | 670 | 48 | |
| 14 | 1.5 | 91 | 930 | 67 | 100 | 1,050 | 76 | |
| 16 | 1.5 | 140 | 1,400 | 101 | ||||
| 6T | 6 | 1 | 8 | 80 | 69 in..lbf | 9 | 90 | 78 in..lbf |
| 8 | 1.25 | 19 | 195 | 14 | 21 | 210 | 15 | |
| 10 | 1.25 | 39 | 400 | 29 | 44 | 440 | 32 | |
| 12 | 1.25 | 71 | 730 | 53 | 80 | 810 | 59 | |
| 14 | 1.5 | 110 | 1,100 | 80 | 125 | 1,250 | 90 | |
| 16 | 1.5 | 170 | 1,750 | 127 | ||||
| 7T | 6 | 1 | 10.5 | 110 | 8 | 12 | 120 | 9 |
| 8 | 1.25 | 25 | 260 | 19 | 28 | 290 | 21 | |
| 10 | 1.25 | 52 | 530 | 38 | 58 | 590 | 43 | |
| 12 | 1.25 | 95 | 970 | 70 | 105 | 1,050 | 76 | |
| 14 | 1.5 | 145 | 1,500 | 108 | 165 | 1,700 | 123 | |
| 16 | 1.5 | 230 | 2,300 | 166 | ||||
| 8T | 8 | 1.25 | 29 | 300 | 22 | 33 | 330 | 24 |
| 10 | 1.25 | 61 | 620 | 45 | 68 | 690 | 50 | |
| 12 | 1.25 | 110 | 1,100 | 80 | 120 | 1,250 | 90 | |
| 9T | 8 | 1.25 | 34 | 340 | 25 | 37 | 380 | 27 |
| 10 | 1.25 | 70 | 710 | 51 | 78 | 790 | 57 | |
| 12 | 1.25 | 125 | 1,300 | 94 | 140 | 1,450 | 105 | |
| 10T | 8 | 1.25 | 38 | 390 | 28 | 42 | 430 | 31 |
| 10 | 1.25 | 78 | 800 | 58 | 88 | 890 | 64 | |
| 12 | 1.25 | 140 | 1,450 | 105 | 155 | 1,600 | 116 | |
| 11T | 8 | 1.25 | 42 | 430 | 31 | 47 | 480 | 35 |
| 10 | 1.25 | 87 | 890 | 64 | 97 | 990 | 72 | |
| 12 | 1.25 | 155 | 1,600 | 116 | 175 | 1,800 | 130 | |
Bolt Specified Torque Specification Chart
Scheme 1
HINT
Use the nut with the same number of the nut strength classification or the greater than the bolt strength classification number when tightening parts with a bolt and nut.
Example: Bolt = 4T
Nut = 4N or more
TORQUE SPECIFICATION
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Throttle body assy x Intake manifold | 30 | 306 | 22 |
| Knock sensor x Cylinder block sub-assy | 20 | 199 | 14 |
| Intake manifold x Cylinder head sub-assy | 30 | 306 | 22 |
| ECM x Instrument panel reinforcement | 5.5 | 56 | 49 in..lbf |
| ECM x Blower assy | 5.5 | 56 | 49 in..lbf |
| Accelerator pedal rod assy x Body | 7.5 | 76 | 66 in..lbf |
ENGINE CONTROL TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Front suspension upper brace center x Body (w/ Performance Rod) | 80 | 815 | 59 |
| V-bank cover sub-assy x Cylinder head cover sub-assy LH | 7.9 | 81 | 70 in..lbf |
| Throttle body assy x Intake air connector | 11 | 112 | 8 |
| Air cleaner cap sub-assy x Air cleaner case sub-assy | 5.0 | 51 | 44 in..lbf |
| Knock sensor x Cylinder block sub-assy 1MZ-FE | 39 | 398 | 29 |
| Knock sensor x Cylinder block sub-assy 3MZ-FE | 20 | 199 | 14 |
| Water outlet x Cylinder head sub-assy | 15 | 153 | 11 |
| Water outlet x Cylinder head LH | 15 | 153 | 11 |
| Intake manifold x Cylinder head sub-assy | 15 | 153 | 11 |
| Intake manifold x Cylinder head LH | 15 | 153 | 11 |
| Ground cable x Intake manifold | 8.4 | 86 | 74 in.lbf |
| ECM x Instrument panel reinforcement | 5.5 | 56 | 49 in.lbf |
| ECM x Blower assy | 5.5 | 56 | 49 in.lbf |
| Accelerator pedal rod assy x Body | 7.5 | 76 | 66 in.lbf |
ENGINE CONTROL TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Fuel delivery pipe x Cylinder head | 20 | 204 | 15 |
| Fuel tank bent tube set plate x Fuel tank assy | 5.9 | 60 | 52 in.lbf |
| Fuel main tube support x Fuel tank assy | 5.4 | 55 | 48 in.lbf |
| Fuel tank band sub-assy No. 1 RH x Body | 39 | 400 | 29 |
| Fuel tank band sub-assy No. 1 LH x Body | 39 | 400 | 29 |
| Fuel tank protector lower center x Fuel tank assy | 5.4 | 55 | 48 in.lbf |
| Packing brake cable assy No. 2 x Body | 5.4 | 55 | 48 in.lbf |
| Packing brake cable assy No. 3 x Body | 5.4 | 55 | 48 in.lbf |
| Exhaust pipe assy center x Exhaust pipe assy front | 56 | 571 | 41 |
| Exhaust pipe assy center x Exhaust pipe assy tail | 56 | 571 | 41 |
| Floor panel brace rear x Body | 20 | 199 | 14 |
FUEL TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Fuel delivery pipe sub-assy x Intake manifold | 10 | 102 | 7 |
| Fuel delivery pipe No. 2 x Intake manifold | 10 | 102 | 7 |
| Fuel pipe No. 2 union bolt x Fuel delivery pipe No. 2 | 33 | 331 | 24 |
| Fuel pressure pulsation damper assy x Fuel delivery pipe sub-assy | 33 | 331 | 24 |
| Fuel pipe sub-assy No. 1 x Intake manifold | 20 | 199 | 14 |
| Surge tank stay No. 2 x Intake air surge tank | 20 | 199 | 14 |
| Surge tank stay No. 2 x Cylinder head | 20 | 199 | 14 |
| Surge tank stay No. 1 x Intake air surge tank | 20 | 199 | 14 |
| Surge tank stay No. 1 x Cylinder head | 20 | 199 | 14 |
| Engine hunger No. 1 x Intake air surge tank | 20 | 199 | 14 |
| Engine hunger No. 1 x Cylinder head | 20 | 199 | 14 |
| Pressure feed tube assy x Engine hunger No. 1 | 7.8 | 80 | 69 in.lbf |
| Intake air surge tank x Intake manifold | 28 | 286 | 21 |
| Emission control valve set x Emission control valve bracket | 8.0 | 80 | 71 in.lbf |
| Fuel tank bent tube set plate x Fuel tank assy | 5.9 | 60 | 52 in.lbf |
| Fuel main tube support x Fuel tank assy | 5.4 | 55 | 48 in.lbf |
| Fuel tank band sub-assy No. 1 RH x Body | 39 | 400 | 29 |
| Fuel tank band sub-assy No. 1 LH x Body | 39 | 400 | 29 |
| Fuel tank protector lower center x Fuel tank assy | 5.4 | 55 | 48 in.lbf |
| Packing brake cable assy No. 2 x Body | 5.4 | 55 | 48 in.lbf |
| Packing brake cable assy No. 3 x Body | 5.4 | 55 | 48 in.lbf |
| Exhaust pipe assy center x Exhaust pipe assy front | 56 | 571 | 41 |
| Exhaust pipe assy center x Exhaust pipe assy tail | 56 | 571 | 41 |
| Floor panel brace rear x Body | 20 | 199 | 14 |
FUEL TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Charcoal canister assy x Body | 39.2 | 400 | 29 |
| Ventilation valve sub-assy x Cylinder head cover | 19 | 193 | 9 |
EMISSION CONTROL TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Charcoal canister assy x Body | 39.2 | 400 | 29 |
| Ventilation valve sub-assy x Cylinder head cover | 19 | 193 | 9 |
EMISSION CONTROL TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Intake manifold x Cylinder head | 30 | 306 | 22 |
| Air cleaner cap sub-assy x Air cleaner case sub-assy | 5.0 | 51 | 44 in..lbf |
| Engine cover sub-assy No. 1 x Cylinder head cover sub-assy | 7.0 | 71 | 62 in..lbf |
INTAKE TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Intake air control valve assy x Intake air surge tank (see INTAKE AIR CONTROL VALVE ASSY NO.1 (1 MZ-FE) ) | |||
| Bolt A and nut A | 21 | 214 | 15 |
| Bolt B | 20 | 204 | 15 |
| Intake air control valve assy No. 2 x Intake air surge tank | 10 | 102 | 7 |
INTAKE TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Engine mounting bracket No. 2 RH x Timing chain cover | 52 | 531 | 38 |
| Engine moving control rod w/ bracket x Engine mounting bracket No. 2 RH | 64 | 653 | 47 |
| Engine moving control rod w/ bracket x Fender apron RH | 64 | 653 | 47 |
| Engine mounting stay No. 2 RH x Cylinder head | 64 | 653 | 47 |
| Engine mounting stay No. 2 RH x Engine mounting bracket No. 2 RH | 64 | 653 | 47 |
| Drain plug (A/T) | 49 | 500 | 36 |
| Drain plug (M/T) | 49 | 500 | 36 |
| Engine hanger No. 1 x Cylinder head | 38 | 387 | 28 |
| Engine hanger No. 2 x Cylinder head | 38 | 387 | 28 |
| ECT sensor x Cylinder head | 20 | 204 | 15 |
| Knock sensor x Cylinder block | 39 | 398 | 29 |
| Engine oil pressure switch assy x Cylinder head | 15 | 153 | 11 |
| Water by-pass pipe No. 1 x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Transverse engine mounting bracket x Cylinder block | 54 | 551 | 40 |
| Drive shaft bearing bracket x Cylinder block | 64 | 653 | 47 |
| V-ribbed belt tensioner assy x Timing chain cover | 59.5 | 607 | 44 |
| Ignition coil assy x Cylinder head | 9.0 | 92 | 80 in.lbf |
| Water inlet x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Exhaust manifold converter x Cylinder head | 37 | 378 | 27 |
| Exhaust manifold stay x Exhaust manifold converter | 44 | 449 | 32 |
| Manifold converter insulator No. 1 x Exhaust manifold converter | 12 | 122 | 9 |
| Oil level gage guide x Water by-pass pipe No. 1 | 9.0 | 92 | 80 in.lbf |
| Intake manifold x Cylinder head | 30 | 306 | 22 |
| Drive plate & ring gear (A/T) x Crankshaft | 98 | 1,000 | 72 |
| Flywheel sub-assy (M/T) x Crankshaft | 130 | 1,330 | 96 |
| Starter assy x Automatic transaxle assy | 39 | 398 | 29 |
| Starter assy x Manual transaxle assy | 39 | 398 | 29 |
| Engine mounting insulator LH x Automatic transaxle assy | 95 | 969 | 70 |
| Engine mounting insulator LH x Manual transaxle assy | 143 | 1,459 | 105 |
| Engine mounting insulator RH x Engine mounting bracket RH | 95 | 969 | 70 |
| Engine mounting insulator FR x Engine mounting bracket FR | 87 | 888 | 64 |
| Engine mounting bracket rear No. 2 x Engine lateral control rod (M/T) | 89 | 910 | 66 |
| Vane pump assy x Timing chain cover | 43 | 439 | 32 |
| Frame side plate x Front frame assy Bolt A | 85 | 867 | 63 |
| Frame side plate x Body Bolt B | 32 | 326 | 24 |
| Front suspension member brace rear x Front frame assy Bolt C | 85 | 867 | 63 |
| Front suspension member brace rear x Body Bolt D | 32 | 326 | 24 |
| Steering intermediate shaft | 35 | 357 | 26 |
| Drive plate & ring gear x Torque converter | 41 | 418 | 30 |
| Front suspension arm sub-assy lower No. 1 x Lower ball joint | 75 | 764 | 55 |
| Tie rod assy x Steering knuckle | 49 | 500 | 36 |
| Speed sensor front LH (w/ ABS) x Steering knuckle | 8.0 | 82 | 71 in.lbf |
| Speed sensor front RH (w/ ABS) x Steering knuckle | 8.0 | 82 | 71 in.lbf |
| Front axle hub LH nut x Front drive shaft | 294 | 3,000 | 217 |
| Front stabilizer link assy x Front suspension | 74 | 755 | 55 |
| Air cleaner assy x Body | 5.0 | 51 | 44 in.lbf |
| Balancer Shaft housing x Stiffening crankcase assy 1st | 22 | 220 | 16 |
| Balancer Shaft housing x Stiffening crankcase assy 2nd | Turn 90° | Turn 90° | Turn 90° |
| Stiffening crankcase assy x Cylinder block | 33 | 332 | 24 |
| W/ head taper screw plug No. 1 x Cylinder block | 26 | 265 | 19 |
| Oil control valve filter x Cylinder block | 30 | 306 | 22 |
| Cylinder block water drain cock x Stiffening crankcase assy | 25 | 255 | 18 |
| Cylinder head x Cylinder block 1st | 79 | 806 | 58 |
| Cylinder head x Cylinder block 2nd | Turn 90° | Turn 90° | Turn 90° |
| Camshaft timing gear assy x Camshaft | 54 | 551 | 40 |
| Camshaft timing sprocket x Camshaft | 54 | 551 | 40 |
| Camshaft bearing cap No. 1 x Cylinder head | 30 | 301 | 22 |
| Camshaft bearing cap No. 2 x Cylinder head | 30 | 301 | 22 |
| Camshaft bearing cap No. 3 x Cylinder head | 9.0 | 92 | 80 in.lbf |
| Oil pump assy x Stiffening crankcase assy | 19 | 194 | 14 |
| Chain tensioner plate x Stiffening crankcase assy | 12 | 122 | 9 |
| Oil pump drive sprocket x Oil pump | 30 | 301 | 22 |
| Chain vibration damper No. 1 x Cylinder head | 9.0 | 92 | 80 in.lbf |
| Chain vibration damper No. 1 x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Chain tensioner slipper x Cylinder block | 19 | 194 | 14 |
| Timing chain guide x Crankshaft bearing cap No. 1 | 9.0 | 92 | 80 in.lbf |
| Timing chain cover (See CHAIN (2AZ-FE)(FROM JULY, 2003) ) Bolt A | 9.0 | 92 | 80 in.lbf |
| Timing chain cover (See CHAIN (2AZ-FE)(FROM JULY, 2003) ) Bolt B | 21 | 214 | 15 |
| Timing chain cover (See CHAIN (2AZ-FE)(FROM JULY, 2003) ) Bolt C | 43 | 438 | 32 |
| Timing chain cover (See CHAIN (2AZ-FE)(FROM JULY, 2003) ) Nut | 9.0 | 92 | 80 in.lbf |
| Oil pan x Stiffening crankcase assy | 9.0 | 92 | 80 in.lbf |
| Oil pan drain plug x Oil pan | 25 | 250 | 18 |
| Water pump assy x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Water pump pulley x Water pump assy | 26 | 265 | 19 |
| Crankshaft position sensor x Timing chain cover | 9.0 | 92 | 80 in.lbf |
| Crankshaft pulley x Crankshaft | 170 | 1,733 | 125 |
| Chain tensioner assy No. 1 x Timing chain cover | 9.0 | 92 | 80 in.lbf |
| Camshaft position sensor x Cylinder head | 9.0 | 92 | 80 in.lbf |
| Cylinder head cover x Cylinder head | 11 | 110 | 8 |
| Oil filter union x Stiffening crankcase assy | 30 | 306 | 22 |
| Spark plug x Cylinder head | 19 | 194 | 14 |
| Ventilation valve x Cylinder head cover | 19 | 194 | 14 |
| Front suspension brace x Body | 80 | 816 | 59 |
| Stud bolt (See OVERHAUL ) Bolt A | 5 | 51 | 44 in.lbf |
| Stud bolt (See OVERHAUL ) Bolt B | 5 | 51 | 44 in.lbf |
| Stud bolt (See OVERHAUL ) Bolt C | 10 | 97 | 84 in.lbf |
| Stud bolt (See OVERHAUL ) Bolt D | 10 | 97 | 84 in.lbf |
| Stud bolt (See OVERHAUL ) Stud bolt A | 5.0 | 51 | 44 in.lbf |
| Stud bolt (See OVERHAUL ) Stud bolt B | 10 | 97 | 84 in.lbf |
| Stud bolt (See OVERHAUL ) Stud bolt C | 5.0 | 51 | 44 in.lbf |
| Crankshaft bearing cap x Cylinder block 1st | 20 | 204 | 15 |
| Crankshaft bearing cap x Cylinder block 2nd | 40 | 408 | 29 |
| Connecting rod cap x Connecting rod 1st | 25 | 250 | 18 |
| Connecting rod cap x Connecting rod 2nd | Turn 90° | Turn 90° | Turn 90° |
Engine Mechanical TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Engine hanger No. 2 x Cylinder head | 20 | 204 | 15 |
| Knock sensor x Cylinder block 1MZ-FE | 39 | 398 | 39 |
| Knock sensor x Cylinder block 3MZ-FE | 20 | 204 | 15 |
| Oil pressure switch assy x Cylinder block | 15 | 152 | 11 |
| Compressor mounting bracket No. 1 x Cylinder block | 25 | 255 | 18 |
| Generator bracket No. 1 x Cylinder block | 58 | 591 | 43 |
| Pump bracket x Cylinder head | 32 | 326 | 24 |
| Drive shaft bearing bracket x Cylinder block | 64 | 653 | 47 |
| Exhaust manifold converter sub-assy No. 2 x Cylinder head | 49 | 500 | 36 |
| Exhaust manifold heat insulator No. 2 x Cylinder head | 8.5 | 87 | 75 in.lbf |
| Exhaust manifold converter sub-assy RH x Cylinder head | 49 | 500 | 36 |
| Intake manifold x Cylinder head | 15 | 153 | 11 |
| Ignition coil assy x Cylinder head cover | 8.0 | 82 | 71 in.lbf |
| Intake air surge tank x Intake manifold | 28 | 286 | 21 |
| Surge tank stay bolt | 20 | 204 | 15 |
| Engine hanger No. 2 x Cylinder head | 39 | 398 | 29 |
| Engine hanger No. 1 x Intake air surge tank | 39 | 398 | 29 |
| Manifold stay No. 2 x Exhaust manifold converter sub-assy | 49 | 500 | 36 |
| Manifold stay No. 2 x Automatic transaxle assy | 49 | 500 | 36 |
| Engine mounting insulator RH x Engine mounting bracket | 95 | 969 | 70 |
| Engine mounting insulator LH x Automatic transaxle assy | 95 | 969 | 70 |
| Engine mounting insulator FR x Automatic transaxle assy | 87 | 887 | 64 |
| Vane pump assy x Pump bracket | 43 | 439 | 32 |
| Vane pump assy x Engine mounting bracket | 43 | 439 | 32 |
| Frame side rail plate sub-assembly x Front frame assy (See REPLACEMENT ) Bolt A | 85 | 867 | 63 |
| Frame side rail plate sub-assembly x Front frame assy (See REPLACEMENT ) Bolt B | 32 | 326 | 24 |
| Frame side rail plate sub-assembly x Front frame assy (See REPLACEMENT ) Nut | 32 | 326 | 24 |
| Front suspension member brace rear x Front frame assy (See REPLACEMENT ) Bolt C | 85 | 867 | 63 |
| Front suspension member brace rear x Front frame assy (See REPLACEMENT ) Bolt D | 32 | 326 | 24 |
| Front suspension member brace rear x Front frame assy (See REPLACEMENT ) Nut | 32 | 326 | 24 |
| Compressor and magnetic clutch x Compressor mounting bracket No. 1 (See REPLACEMENT ) Bolt | 25 | 250 | 18 |
| Compressor and magnetic clutch x Compressor mounting bracket No. 1 (See REPLACEMENT ) Nut | 26 | 260 | 19 |
| Generator belt adjusting bar x Cylinder block (See REPLACEMENT ) Nut A | 43 | 438 | 32 |
| Generator belt adjusting bar x Cylinder block (See REPLACEMENT ) Bolt B | 18 | 184 | 13 |
| Generator belt adjusting bar x Cylinder block (See REPLACEMENT ) Bolt C | 8.0 | 82 | 71 in.lbf |
| Generator bracket No. 2 x Transverse engine mounting bracket | 28 | 286 | 21 |
| Intermediate shaft sub-assy | 35 | 357 | 26 |
| Drive plate & ring gear x Torque converter | 41 | 418 | 30 |
| Flywheel housing under cover x Automatic transaxle assy | 7.8 | 80 | 69 in.lbf |
| Front suspension arm x Lower ball joint | 75 | 764 | 55 |
| Tie rod end x Steering knuckle | 49 | 500 | 36 |
| Front axle hub nut x Front drive shaft | 294 | 2,998 | 217 |
| Front stabilizer link assy x Front suspension | 74 | 755 | 55 |
| V-bank cover x Cylinder head cover | 7.9 | 81 | 70 in.lbf |
| Engine mounting stay No. 2 RH x engine mounting bracket | 64 | 653 | 47 |
| Engine moving control rod (See REPLACEMENT ) Bolt A | 64 | 653 | 47 |
| Engine moving control rod (See REPLACEMENT ) Bolt B | 23 | 235 | 17 |
| Camshaft sub-gear x Main gear | 5.4 | 55 | 48 in.lbf |
| Engine rear oil seal retainer x Cylinder block | 8.0 | 82 | 71 in.lbf |
| Oil pump assy x Cylinder block (See OVERHAUL ) 10 mm head | 8.0 | 82 | 71 in.lbf |
| Oil pump assy x Cylinder block (See OVERHAUL ) 12 mm head | 20 | 204 | 15 |
| Oil pump assy x Cylinder block (See OVERHAUL ) 14 mm head | 43 | 439 | 32 |
| Crank position sensor x Oil pump assy | 8.0 | 82 | 71 in.lbf |
| Oil pan baffle plate x Oil pan sub-assy | 8.0 | 82 | 71 in.lbf |
| Oil pan sub-assy x Cylinder block (See OVERHAUL ) 10 mm head | 8.0 | 82 | 71 in.lbf |
| Oil pan sub-assy x Cylinder block (See OVERHAUL ) 12 mm head | 20 | 204 | 15 |
| Oil strainer sub-assy x Oil pan sub-assy | 8.0 | 82 | 71 in.lbf |
| Oil pan sub-assy No. 2 x Oil pan sub-assy | 8.0 | 82 | 71 in.lbf |
| Oil pan drain plug x Oil pan sub-assy No. 2 | 45 | 459 | 33 |
| Water inlet housing x Cylinder block | 8.0 | 82 | 71 in.lbf |
| Cylinder head x Cylinder block 12 pointed head 1st | 54 | 551 | 40 |
| Cylinder head x Cylinder block 12 pointed head 2nd | Turn 90° | Turn 90° | Turn 90° |
| Cylinder head x Cylinder block 12 pointed head Recessed head | 19 | 189 | 14 |
| Camshaft bearing cap x Cylinder head | 16 | 163 | 12 |
| Timing belt plate x Oil pump assy | 8.0 | 82 | 71 in.lbf |
| Water pump assy x Cylinder block | 8.0 | 82 | 71 in.lbf |
| Oil level gage guide x Cylinder block | 8.0 | 82 | 71 in.lbf |
| Oil filter union x Cylinder block | 30 | 306 | 22 |
| Timing belt idler bracket x Cylinder block | 28 | 286 | 21 |
| Timing belt No. 3 cover x Cylinder head | 8.5 | 87 | 76 in.lbf |
| Camshaft timing pulley x Camshaft | 125 | 1,275 | 92 |
| Timing belt idler sub-assy No. 2 x Timing belt idler bracket | 43 | 438 | 32 |
| Timing belt idler sub-assy No. 1 x Cylinder block | 34 | 347 | 25 |
| Chain tensioner assy No. 1 x Oil pump assy | 27 | 280 | 20 |
| Transverse engine mounting bracket x Cylinder block | 28 | 286 | 21 |
| Timing belt No. 2 cover x Timing belt No. 3 cover | 8.5 | 87 | 76 in.lbf |
| Timing belt No. 1 cover x Oil pump assy | 8.5 | 87 | 76 in.lbf |
| Crankshaft pulley x Crankshaft | 215 | 2,192 | 159 |
| Camshaft position sensor x Cylinder head | 8.0 | 82 | 71 in.lbf |
| Cylinder head cover x Cylinder head | 8.0 | 82 | 71 in.lbf |
| Spark plug x Cylinder head | 18 | 184 | 13 |
| Vane pump assy x Adjusting strut | 43 | 439 | 32 |
| Generator x Generator bracket | 58 | 591 | 43 |
| Generator x Adjusting bar | 18 | 184 | 13 |
| Front suspension brace upper x Body | 80 | 816 | 59 |
| Water outlet x Cylinder head | 15 | 153 | 11 |
| Exhaust manifold heat insulator No. 2 x Exhaust manifold LH | 8.5 | 87 | 55 in.lbf |
| Exhaust pipe support bracket No. 1 x Automatic transaxle assy | 21 | 214 | 15 |
| Drive plate & ring gear sub-assy x Crankshaft | 83 | 846 | 61 |
| W/ head straight screw plug No. 1 x Cylinder head | 44 | 449 | 32 |
| W/ head straight screw plug No. 2 x Cylinder head | 44 | 449 | 32 |
| Main bearing cap x Cylinder block 12 pointed head 1st | 22 | 224 | 16 |
| Main bearing cap x Cylinder block 2nd | Turn 90° | Turn 90° | Turn 90° |
| Main bearing cap x Cylinder block 6 pointed head | 27 | 275 | 20 |
| Connecting rod cap x Connecting rod 1st | 25 | 250 | 18 |
| Connecting rod cap x Connecting rod 2nd | Turn 90° | Turn 90° | Turn 90° |
| Cylinder block w/ head straight screw No. 1 plug x Cylinder block | 30 | 306 | 22 |
| Cylinder block w/ head straight screw No. 2 plug x Cylinder block | 50 | 510 | 37 |
| Cylinder block w/head straight screw No. 3 plug x Cylinder block | 30 | 306 | 22 |
| Water seal plate x Cylinder block | 18 | 184 | 13 |
| Cylinder block water drain cock sub-assy x Cylinder block | 39 | 398 | 29 |
Engine Mechanical TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Exhaust pipe damper (A/T) x Exhaust pipe assy center | 19 | 194 | 14 |
| Exhaust pipe assy center x Exhaust pipe assy tail | 56 | 571 | 41 |
| Floor panel brace rear x Body | 19.5 | 199 | 14 |
| Exhaust pipe assy front x Exhaust pipe assy center | 56 | 571 | 41 |
| Exhaust pipe assy front x Exhaust manifold converter sub assy | 62 | 633 | 46 |
| Exhaust pipe No. 1 support bracket x Exhaust pipe assy front | 33 | 337 | 24 |
| Exhaust pipe No. 1 support bracket x Exhaust pipe assy front | 33 | 337 | 24 |
| Heated oxygen sensor x Exhaust pipe assy front | 44 | 449 | 32 |
EXHAUST TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Exhaust pipe assy center x Exhaust pipe assy tail | 56 | 571 | 41 |
| Exhaust pipe assy front x Exhaust manifold RH | 62 | 633 | 47 |
| Exhaust pipe assy front x Exhaust manifold converter No. 2 | 62 | 633 | 47 |
| Exhaust pipe assy front x Exhaust pipe assy center | 56 | 571 | 41 |
| Exhaust pipe No. 1 support bracket x Body | 33 | 337 | 24 |
| Floor panel brace rear x Body | 20 | 204 | 15 |
| Exhaust pipe No. 1 support bracket x Exhaust pipe support bracket No. 1 | 33 | 337 | 24 |
| Heated oxygen sensor x Exhaust pipe assy front | 44 | 449 | 32 |
EXHAUST TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Cylinder block drain cock plug x Drain cock | 13 | 130 | 10 |
| Water pump x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Water pump pulley x Water pump | 26 | 265 | 19 |
| Water inlet x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Fan assy w/motor x Radiator assy | 5.0 | 51 | 44 in.lbf |
| Radiator support upper x Body | 14 | 142 | 10 |
| Air cleaner inlet x Body | 5.0 | 51 | 44 in.lbf |
| Oil cooler assy x Radiator tank lower | 8.3 | 85 | 73 in.lbf |
| Oil cooler pipe x Oil cooler assy | 14.7 | 150 | 11 |
COOLING TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Cylinder block drain cock plug x Drain cock | 13 | 130 | 10 |
| Water pump assy x Cylinder block | 8 | 82 | 71 in.lbf |
| Timing belt Idler sub-assy No.2 x Cylinder block | 43 | 438 | 32 |
| Engine mounting bracket RH x Cylinder block | 28 | 286 | 21 |
| Generator bracket No. 2 x Cylinder block | 28 | 286 | 21 |
| Water inlet x Cylinder block | 8 | 82 | 71 in.lbf |
| Water inlet pipe x Water inlet | 20 | 204 | 15 |
| Fan assy w/motor x Radiator assy | 5.0 | 51 | 44 in.lbf |
| Radiator support upper x body | 14 | 142 | 10 |
| Air cleaner inlet x Body | 5.0 | 51 | 44 in.lbf |
| Oil cooler assy x Radiator tank lower | 8.3 | 85 | 74 in.lbf |
| Oil cooler pipe x Oil cooler assy | 14.7 | 150 | 11 |
COOLING TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Oil pressure switch x Cylinder head | 15 | 152 | 11 |
| Oil drain plug x Oil pan sub-assy | 25 | 255 | 18 |
| Oil pump assy x Cylinder block | 19 | 194 | 14 |
| Chain tensioner plate x Stiffening crankcase assy | 12 | 122 | 9 |
| Oil pump drive sprocket x Oil pump | 30 | 301 | 22 |
| Chain vibration damper No. 1 x Cylinder block | 9.0 | 92 | 80 in.lbf |
| Chain tensioner slipper x Cylinder block | 19 | 194 | 14 |
| Timing chain cover (see REPLACEMENT ) Bolt A | 9.0 | 92 | 80 in.lbf |
| Timing chain cover (see REPLACEMENT ) Bolt B | 21 | 214 | 15 |
| Timing chain cover (see REPLACEMENT ) Bolt C | 43 | 438 | 32 |
| Timing chain cover (see REPLACEMENT ) Nut | 9.0 | 92 | 80 in.lbf |
| V-ribbed belt tensioner assy x Timing chain cover | 59.5 | 607 | 44 |
| Engine mounting bracket RH x Cylinder block | 54 | 551 | 40 |
| Engine mounting insulator RH (see REPLACEMENT ) Bolt A | 95 | 969 | 70 |
| Engine mounting insulator RH (see REPLACEMENT ) Bolt B | 87 | 888 | 64 |
| Steering gear return hose clamp | 8.0 | 80 | 69 in.lbf |
| Engine mounting insulator FR x Engine mounting bracket FR | 87 | 888 | 64 |
| Engine lateral control rod x Bracket | 89 | 910 | 66 |
| Oil pan sub-assy x Stiffening crankcase assy | 9.0 | 92 | 80 in.lbf |
| Crankshaft position sensor x Timing chain cover | 9.0 | 92 | 80 in.lbf |
| Crankshaft pulley x Crankshaft | 170 | 1,733 | 125 |
| Ignition coil assy x Cylinder head | 9.0 | 92 | 80 in.lbf |
| Engine mounting bracket No. 2 RH x Timing chain cover | 52 | 531 | 38 |
| Engine mounting stay No. 2 RH x Cylinder head | 64 | 653 | 47 |
| Engine moving control rod w/ bracket x Fender apron RH | 64 | 653 | 47 |
| Oil pump cover x Oil pump | 8.8 | 90 | 78 in.lbf |
| Oil pump strainer x Oil pump | 8.8 | 90 | 78 in.lbf |
LUBRICATION TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Oil pressure switch x Cylinder block | 15 | 152 | 11 |
| Oil drain plug x Oil pump sub-assy No. 2 | 25 | 255 | 18 |
| Oil pump assy x Cylinder block (see REPLACEMENT ) Bolt A | 8 | 82 | 71 in.lbf |
| Oil pump assy x Cylinder block (see REPLACEMENT ) Bolt B | 20 | 199 | 14 |
| Oil pump assy x Cylinder block (see REPLACEMENT ) Bolt C | 43 | 439 | 32 |
| Crankshaft position sensor x Oil pump assy | 8 | 82 | 71 in.lbf |
| Oil pan sub-assy x Cylinder block 10 mm head | 8.0 | 82 | 71 in.lbf |
| Oil pan sub-assy x Cylinder block 12 mm head | 20 | 203 | 15 |
| Oil pan sub-assy x Cylinder block 14 mm head | 37 | 379 | 27 |
| Oil strainer sub-assy x Main bearing cap | 8 | 82 | 71 in.lbf |
| Oil pan sub-assy No. 2 x Oil pan sub-assy No. 1 | 8 | 82 | 71 in.lbf |
| Engine mounting bracket RH (See REPLACEMENT ) Bolt A | 54 | 550 | 40 |
| Engine mounting bracket RH (See REPLACEMENT ) Nut B | 54 | 550 | 40 |
| Engine mounting bracket RH (See REPLACEMENT ) Bolt C | 43 | 439 | 32 |
| Engine mounting insulator RH (see REPLACEMENT ) Nut A | 95 | 969 | 70 |
| Engine mounting insulator RH (see REPLACEMENT ) Nut B | 87 | 887 | 64 |
| Engine mounting insulator FR (see REPLACEMENT ) Bolt A | 87 | 887 | 64 |
| Engine mounting insulator FR (see REPLACEMENT ) Nut B | 52 | 531 | 38 |
| Oil level gage guide x Cylinder block | 8 | 82 | 71 in.lbf |
| Compressor mounting bracket No. 1 x Cylinder block | 25 | 250 | 18 |
| Timing belt idler sub-assy No. 1 x Cylinder block | 34 | 347 | 25 |
| Compressor and magnetic clutch x Compressor mounting bracket | 25 | 250 | 18 |
| Generator bracket No. 2 x Transverse engine mounting bracket | 28 | 286 | 21 |
| Front suspension brace upper center x Body | 80 | 816 | 59 |
| Oil pump cover x Oil pump | 10 | 105 | 8 |
| Oil pump relief valve x Oil pump | 49 | 500 | 36 |
LUBRICATION TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Spark plug x Cylinder head cover | 19 | 194 | 14 |
| Ignition coil x Cylinder head cover | 9.0 | 92 | 80 in..lbf |
Ignition TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Spark plug x Cylinder head cover | 25 | 255 | 18.5 |
| Ignition coil x Cylinder head cover | 8.0 | 82 | 71 in..lbf |
Ignition TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
2AZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Starter x Transaxle housing | 39 | 398 | 29 |
| Starter wire x Starter assy | 13 | 130 | 9 |
| Air cleaner inlet x Body | 7.0 | 71 | 62 in..lbf |
| Air cleaner bracket x Body | 12 | 122 | 9 |
| Air cleaner case sub-assy x Air cleaner bracket | 5.0 | 51 | 44 in..lbf |
| Air cleaner case sub-assy x Body | 5.0 | 51 | 44 in..lbf |
| Air cleaner cap sub-assy x Air cleaner case sub-assy | 5.0 | 51 | 44 in..lbf |
| Battery clamp sub-assy x Body | 5.5 | 56 | 49 in..lbf |
| Battery clamp sub-assy x Battery clamp bolt | 5.5 | 56 | 49 in..lbf |
| Terminal x Battery | 3.5 | 36 | 31 in..lbf |
| Commutator end frame assy x Starter drive housing assy | 6.0 | 61 | 53 in..lbf |
| Magnetic switch assy x Starter drive housing assy | 7.5 | 76 | 66 in..lbf |
| Lead wire x Terminal C | 10 | 102 | 7 |
| Generator assy x Engine M8 | 21 | 214 | 15 |
| Generator assy x Engine M10 | 52 | 530 | 38 |
| Wiring harness clamp | 9 | 92 | 80 in..lbf |
| Generator wire x Generator assy | 9.8 | 100 | 7 |
| Retainer plate x Drive end frame assy generator | 2.3 | 23 | 20 in..lbf |
| Generator rectifier end frame x Drive end frame assy generator | 5.8 | 59 | 51 in..lbf |
| Generator brush holder assy x Generator rectifier end frame | 1.8 | 18 | 16 in..lbf |
| Generator rear end cover x Generator rectifier end frame | 4.6 | 47 | 41 in..lbf |
| Generator pulley x Generator rotor assy | 110 | 1,122 | 81 |
STARTING AND CHARGING TORQUE SPECIFICATION (2AZ-FE)
1MZ-FE/3MZ-FE
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Starter assy x Transaxle housing | 37 | 380 | 26 |
| Starter wire x Starter assy | 9.8 | 100 | 7 |
| Air cleaner inlet No. 1 x Body | 7.0 | 71 | 62 in..lbf |
| Air cleaner bracket x Body | 12 | 122 | 9 |
| Air cleaner case sub-assy x Air cleaner bracket | 5.0 | 51 | 44 in..lbf |
| Air cleaner case sub-assy x Body | 5.0 | 51 | 44 in..lbf |
| Air cleaner cap sub-assy x Air cleaner case sub-assy | 5.0 | 51 | 44 in..lbf |
| Air cleaner inlet No. 2 x Body | 7.0 | 71 | 62 in..lbf |
| Battery clamp sub-assy x Body | 5.5 | 56 | 49 in..lbf |
| Battery clamp sub-assy x Battery clamp bolt | 5.5 | 56 | 49 in..lbf |
| Terminal x Battery | 3.5 | 36 | 31 in..lbf |
| Commutator end frame assy x Starter drive housing assy | 6.0 | 61 | 53 in..lbf |
| Magnetic switch assy x Starter drive housing assy | 7.5 | 76 | 66 in..lbf |
| Lead wire x Terminal C | 10 | 102 | 7 |
| Generator assy x Generator bracket No. 1 | 58 | 592 | 43 |
| Generator assy x Generator belt adjusting bar | 18 | 184 | 13 |
| Generator wire x Generator assy | 9.8 | 100 | 7 |
| Retainer plate x Drive end frame assy generator | 2.3 | 23 | 20 in..lbf |
| Generator rectifier end frame x Drive end frame assy generator | 5.8 | 59 | 51 in..lbf |
| Generator brush holder assy x Generator rectifier end frame | 1.8 | 18 | 16 in..lbf |
| Generator rear end cover x Generator rectifier end frame | 4.6 | 47 | 41 in..lbf |
| Generator pulley x Generator rotor assy | 111 | 1,127 | 82 |
STARTING AND CHARGING TORQUE SPECIFICATION (1MZ-FE/3MZ-FE)
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Tie rod end lock nut | 74 | 755 | 55 |
| Steering knuckle x Shock absorber | 210 | 2,141 | 155 |
| Hub nut | 103 | 1,050 | 76 |
| Suspension support x Body | 80 | 816 | 59 |
| Suspension support x Piston rod | 49 | 500 | 36 |
| Speed sensor wire harness bracket set bolt (w/ ABS) | 18.8 | 192 | 14 |
| Flexible hose x Shock absorber (w/o ABS) | 18.8 | 192 | 14 |
| Lower suspension arm set bolt Front side | 200 | 2,039 | 148 |
| Lower suspension arm set bolt Rear side | 206 | 2,101 | 152 |
| Transverse engine mounting insulator set nut | 87 | 887 | 64 |
| Transverse engine mounting insulator x Bracket (MT) | 64 | 653 | 47 |
| Stabilizer bar bracket x Suspension member | 19 | 194 | 14 |
| Stabilizer bar link set nut | 74 | 755 | 55 |
| Lower ball joint assy x Front suspension arm no.1 | 75 | 765 | 55 |
FRONT SUSPENSION TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Shock absorber x Body | 39 | 400 | 29 |
| Shock absorber x Rear axle carrier | 255 | 2,600 | 188 |
| Flexible hose x Shock absorber | 19 | 194 | 14 |
| ABS speed sensor wire harness x Shock absorber | 5.5 | 56 | 49 in.lbf |
| Piston rod set nut | 49 | 500 | 36 |
| Shock absorber x Stabilizer bar link | 39 | 400 | 29 |
| Rear suspension member x Rear suspension arm assy No. 1 LH | 100 | 1,020 | 74 |
| Rear suspension member x Body A, B | 55 | 561 | 41 |
| Rear suspension member x Body C | 38 | 387 | 28 |
| Rear suspension arm assy No. 1 x Rear axle carrier | 100 | 1,020 | 74 |
| Rear suspension arm assy No. 2 x Rear axle carrier | 100 | 1,020 | 74 |
| Stabilizer bar bracket | 19 | 195 | 14 |
| Stabilizer bar x Stabilizer bar link | 39 | 400 | 29 |
| Strut rod x Body | 113 | 1,150 | 83 |
| Strut rod x Rear axle carrier | 113 | 1,152 | 83 |
| Parking brake cable x Body | 5.4 | 55 | 48 in..lbf |
| Hub nut | 103 | 1,050 | 76 |
REAR SUSPENSION TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Front wheel set nut | 103 | 1,050 | 76 |
| Lower ball joint x Lower suspension arm | 75 | 765 | 55 |
| Tie rod end x Steering knuckle | 49 | 500 | 36 |
| Axle hub x Front drive shaft | 294 | 2,998 | 217 |
| Front drive shaft center bearing set bolt | 32 | 330 | 24 |
| Front speed sensor set bolt (w/ ABS) | 8.0 | 82 | 71 |
| Front flexible hose and speed sensor wire harness x Shock absorber (w/ABS) | 19 | 192 | 13 |
| Front flexible hose x Shock absorber (w/o ABS) | 19 | 192 | 13 |
| Rear wheel set nut | 103 | 1,050 | 76 |
| Rear flexible hose x Shock absorber | 19 | 192 | 14 |
| Shock absorber x Rear axle carrier | 255 | 2,600 | 188 |
| Rear axle hub set bolt | 80 | 816 | 59 |
| Rear axle carrier x Brake caliper (Rear disc brake) | 62 | 630 | 46 |
| Rear wheel brake cylinder x Brake tube (Rear drum brake) | 15 | 155 | 11 |
| Lower ball joint x Steering knuckle | 123 | 1,254 | 91 |
DRIVE SHAFT / PROPELLER SHAFT / AXLE TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Bleeder plug | 8.3 | 85 | 73 in..lbf |
| Brake booster clevis lock nut | 26 | 265 | 19 |
| Brake pedal sub-assy set bolt Normal type brake pedal | 37 | 375 | 27 |
| Stop lamp lock nut | 26 | 265 | 19 |
| Brake pedal support assy x Reinforcement | 20 | 204 | 15 |
| Brake pedal support assy x Body | 13 | 130 | 9 |
| Brake pedal support assy x Body Accelerator & brake pedal | 19.1 | 194 | 14 |
| Brake pedal support assy x Accelerator pedal assy Accelerator & brake pedal | 12 | 122 | 8.8 |
| Master cylinder piston stopper bolt w/o VSC | 10 | 100 | 7 |
| Brake master cylinder x Brake booster | 13 | 130 | 9 |
| Brake line union nut | 15 | 155 | 11 |
| Vacuum hose bracket set bolt | 5.4 | 55 | 48 in..lbf |
| Wheel nut | 103 | 1,050 | 76 |
| Front brake cylinder mounting x Steering knuckle | 107 | 1,090 | 79 |
| Front brake cylinder x Front brake cylinder mounting | 34 | 350 | 25 |
| Front brake cylinder x Flexible hose | 29 | 300 | 22 |
| Rear disc brake cylinder mounting set bolt TMC made | 61.8 | 630 | 46 |
| Rear disc brake cylinder mounting set bolt TMMK made | 47 | 475 | 34 |
| Rear disc brake cylinder slide pin x Rear disc brake cylinder mounting | |||
| TMC made (Upper side) | 34.3 | 350 | 25 |
| TMC made (Lower side) | 39.2 | 400 | 29 |
| TMMK made | 43 | 440 | 32 |
| Rear disc brake cylinder x Flexible hose | 29.4 | 300 | 22 |
| Rear drum brake wheel cylinder x Backing plate | 10 | 100 | 7 |
| Brake actuator assy x Actuator bracket (w/o VSC) DENSO made | 5.4 | 55 | 48 in..lbf |
| Brake actuator assy x Actuator bracket (w/o VSC) BOSCH made | 8.0 | 82 | 71 in..lbf |
| Brake actuator bracket x Body | 19 | 194 | 14 |
| Brake actuator assy x Actuator bracket (w/VSC) | 5.4 | 55 | 48 in..lbf |
| Brake actuator bracket x Body | 19 | 194 | 14 |
| Proportioning valve assy x Body | 5.4 | 55 | 48 in..lbf |
| Proportioning valve assy x Brake line | 15.2 | 155 | 11 |
| Front speed sensor x Steering knuckle | 8.0 | 82 | 71 in..lbf |
| Front speed sensor wire harness clamp x shock absorber Bolt A | 5.0 | 51 | 44 in..lbf |
| Front speed sensor wire harness clamp x shock absorber Bolt B | 18.8 | 192 | 14 |
| Rear axle hub set bolt | 80 | 816 | 59 |
| Yawrate sensor x Body | 12.5 | 127 | 9 |
BRAKE TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Wheel nut | 103 | 1,050 | 76 |
| Parking brake cable lock nut Parking pedal type | 5.4 | 55 | 48 in..lbf |
| Parking brake cable lock nut Parking lever type | 5.0 | 51 | 44 in..lbf |
| Parking brake lever set bolt | 12.5 | 128 | 9 |
| Parking brake control pedal set bolt | 39 | 398 | 29 |
| Console box mounting set bolt | 12.5 | 128 | 9 |
| Parking brake cable No. 1 x Turn buckle | 5.4 | 55 | 48 in..lbf |
| Parking brake cable No. 3 x Backing plate | 7.8 | 80 | 69 in..lbf |
| Parking brake cable heart insulator set nut | 5.4 | 55 | 48 in..lbf |
| Parking brake cable No. 4 x Body | 12.5 | 128 | 9 |
PARKING BRAKE TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Park/neutral position switch Nut | 6.9 | 70 | 61 in.lbf |
| Park/neutral position switch Bolt | 5.4 | 55 | 48 in.lbf |
| Control shaft lever x Control shaft | 13 | 130 | 9 |
| Shift control cable x Control shaft lever | 15 | 150 | 10 |
| Transaxle housing x Engine block (U151E) | |||
| A bolt | 64 | 653 | 47 |
| B bolt | 46 | 470 | 34 |
| C bolt | 37 | 377 | 27 |
| Transaxle housing x Engine block (U250E) | |||
| A bolt | 64 | 653 | 47 |
| B bolt | 44 | 449 | 32 |
| C bolt | 46 | 470 | 34 |
| Torque converter clutch x Drive plate | 41 | 418 | 30 |
| Engine mounting bracket FR x Transaxle | 64 | 653 | 47 |
| Oil filler tube x Transaxle | 5.5 | 56 | 49 in.lbf |
| Control cable bracket x Transaxle | 12 | 122 | 9 |
| Oil cooler tube clamp x Control cable bracket | 5.4 | 55 | 48 in..lbf |
| Oil cooler inlet tube x Transaxle | 34 | 350 | 25 |
| Oil cooler outlet tube x Transaxle | 34 | 350 | 25 |
| Starter x Transaxle | 37 | 377 | 27 |
| Starter wire x starter | 9.8 | 100 | 87 in..lbf |
| Wire harness x Transaxle | 13 | 139 | 9 |
| Control cable clamp x Transaxle | 12 | 122 | 9 |
| Wire harness clamp x Transaxle | 8.4 | 86 | 74 in..lbf |
| Revolution sensor x Transaxle (U151E) | 11 | 110 | 8 |
| Revolution sensor NC sensor x Transaxle (U250E) | 8.8 | 90 | 78 in..lbf |
| Revolution sensor NT sensor x Transaxle (U250E) | 11 | 110 | 8 |
| Drain plug x Oil pan | 49 | 500 | 36 |
| Transmission wire x Transaxle | 5.4 | 55 | 48 in..lbf |
| ATF temperature sensor x Valve body | 6.6 | 67 | 58 in..lbf |
| Oil pan x Transaxle | 7.8 | 80 | 69 in..lbf |
| Solenoid valve x Valve body A, B bolt | 11 | 110 | 8 |
| Solenoid valve x Valve body C, D bolt | 6.6 | 67 | 58 in..lbf |
| Valve body x transaxle | 11 | 110 | 8 |
| Oil strainer x Valve body | 11 | 110 | 8 |
| Floor shift assy x Body | 12 | 122 | 9 |
| Control cable x Body | 4.9 | 50 | 43 in..lbf |
| Transmission case cover x Automatic transaxle | 12 | 122 | 9 |
| Flywheel housing under cover x Automatic transaxle (U151E) Bolt | 7.8 | 80 | 69 in..lbf |
| Flywheel housing under cover x Automatic transaxle (U151E) Nut | 21 | 214 | 16 |
Automatic Transmission / Transaxle TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Hub nut | 103 | 1,050 | 76 |
| Floor shift lever assembly x Body | 12 | 122 | 9 |
| Floor shift cable transmission control shift clamp x Body | 5.0 | 51 | 44 in..lbf |
| Floor shift cable transmission control shift retainer x Body | 5.0 | 51 | 44 in..lbf |
| Gear shift fork No.1 set bolt | 24 | 245 | 18 |
| Reverse shift arm bracket assy x Manual transaxle case | 17 | 173 | 13 |
| Reverse restrict pin plug | 13 | 133 | 9.6 |
| Oil receiver pipe No. 1 x Manual transmission case | 17 | 175 | 13 |
| Clutch tube bracket set bolt | 17 | 173 | 13 |
| Reverse idler gear shaft bolt | 30 | 306 | 22 |
| Gear shift fork No. 3 shift fork bolt | 24 | 244 | 17 |
| Manual transmission output shaft rear set nut | 123 | 1,250 | 90 |
| Drain plug sub-assy | 49 | 500 | 36 |
| Manual transmission filler plug | 49 | 500 | 36 |
| Back up lamp switch assy x Manual transmission case | 40 | 410 | 30 |
| Manual transmission breather plug x Manual transmission case | 49 | 500 | 36 |
| Lock ball assy No. 1 x Manual transmission case | 29 | 300 | 22 |
| Control shaft cover set bolt | 20 | 200 | 14 |
| Control shift lever x Shift & select lever shaft | 6.4 | 65 | 57 in..lbf |
| Selecting ballcrank assy x Manual transmission case | 20 | 204 | 15 |
| Release fork support x Manual transaxle case | 47 | 480 | 35 |
| Manual transaxle x Engine Bolt A | 64 | 653 | 47 |
| Manual transaxle x Engine Bolt B | 46 | 470 | 34 |
| Manual transaxle x Engine Bolt C | 44 | 449 | 32 |
| Engine mounting insulator LH x Manual transaxle | 64 | 653 | 47 |
| Exhaust pipe support bracket No. 1 set bolt | 19 | 194 | 14 |
| Manual transmission case protector x Manual transaxle | 18 | 184 | 13 |
| Engine mounting bracket FR x Manual transaxle | 64 | 653 | 47 |
| Starter assy x Manual transaxle | 39 | 398 | 29 |
| Wire harness clamp bracket x Manual transaxle | 8.4 | 86 | 74 in..lbf |
| Engine wire No. 3 x Manual transaxle | 9.6 | 98 | 85 in..lbf |
| Transmission case x Manual transaxle case | 29 | 296 | 21 |
| Manual transaxle case x Transmission case | 29 | 296 | 21 |
| Bearing retainer RR x Transmission case | 43 | 438 | 32 |
| Manual transaxle case receiver x Manual transaxle case | 7 | 71 | 62 in..lbf |
| Gear shift head No.1 x Gear shift fork shaft No.2 | 24 | 245 | 18 |
| Gear shift fork No. 1 x Gear shift fork shaft No. 1 | 24 | 245 | 18 |
| Reverse shift arm bracket x Manual transaxle case | 17 | 173 | 13 |
| Reverse restrict pin plug x Transmission case | 13 | 133 | 9.6 |
| Oil receiver pipe No. 1 x Transmission case | 17 | 173 | 13 |
| Oil receiver pipe No.2 x Transmission case | 17 | 173 | 13 |
| Clutch tube bracket x Transmission case | 17 | 173 | 13 |
| Reverse idler gear shaft bolt x Transmission case | 30 | 306 | 22 |
| Transmission clutch hub No.3 gear shift fork shaft x input shaft | 24 | 245 | 18 |
| Manual transmission output rear set nat. x Output shaft | 123 | 1,254 | 91 |
| Drain (MTM) plug sub-assy x Transmission case | 49 | 500 | 36 |
| Manual transmission filler plug x Transmission case | 49 | 500 | 36 |
| Back up lamp switch assy x Transmission case | 40 | 408 | 30 |
| Manual transmission breather plug x Transmission case | 49 | 500 | 36 |
| Lock ball assy No.1 x Transmission case | 29 | 296 | 21 |
| Control shift cover x Transmission case | 20 | 204 | 15 |
| Control shift lever x Shift & select lever assy | 6.4 | 65 | 57 in..lbf |
| Selecting bell crank assy x Transmission case | 20 | 204 | 15 |
| Selecting bellcrank support x Selecting bellcrank No.2 plate Washer | 12 | 122 | 9 |
| Release fork support x Manual transaxle case | 47 | 480 | 35 |
| Front differential ring gear x Front differential case | 106 | 1,081 | 78 |
MANUAL TRANSMISSION / TRANSAXLE TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft:lbf |
|---|---|---|---|
| Clutch pedal sub-assy x Clutch pedal support | 39 | 398 | 29 |
| Clutch pedal support set bolt x Body | 19 | 195 | 14 |
| Cylinder push rod clevis lock nut | 26 | 260 | 19 |
| Clutch master cylinder assy x Clutch pedal support | 12 | 120 | 9 |
| Clutch master cylinder assy x Flexible hose tube | 15 | 155 | 11 |
| Master cylinder bleeder plug | 8.3 | 85 | 73 in.:lbf |
| Release cylinder bleeder plug | 8.3 | 85 | 73 in.:lbf |
| Clutch release cylinder assy x Transaxle housing | 12 | 120 | 9 |
| Clutch accumulator assy x Clutch release cylinder assy | 12 | 120 | 9 |
| Clutch release cylinder assy x flexible hose tube | 15 | 155 | 11 |
| Clutch cover assy x Flywheel | 19 | 195 | 14 |
| Release fork support x Transaxle assy | 47 | 480 | 35 |
| Clutch start switch assy set nut | 16 | 160 | 12 |
CLUTCH TORQUE SPECIFICATION
| Part tightened | N.m | Kgf.cm | Ft..lbf |
|---|---|---|---|
| Tie rod end lock nut | 74 | 750 | 54 |
| Universal joint assy x Main shaft assy | 35.3 | 360 | 26 |
| Steering column assembly set bolt and nut | 20.6 | 210 | 15 |
| Intermediate shaft sub-assy x Universal joint assembly | 35.3 | 360 | 26 |
| Intermediate shaft sub-assy x Control valve shaft | 35.3 | 360 | 26 |
| Steering wheel set nut | 50 | 510 | 37 |
| Steering wheel pad set screw (Torx screw) | 8.8 | 90 | 78 in.:lbf |
STEERING COLUMN TORQUE SPECIFICATION
| Part tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| POWER STEERING VANE PUMP (2AZ-FE) | |||
| Vane pump housing rear x Vane pump housing front | 22 | 224 | 16 |
| Pressure port union | 69 | 704 | 51 |
| Power steering suction port union set bolt | 12 | 122 | 9 |
| Power steering oil pressure switch | 21 | 214 | 15 |
| Pressure feed tube assy x Vane pump assy | 51.5 | 525 | 38 |
| Vane pump assy set bolt Bolt A | 30 (43) | 306 (440) | 22 (32) |
| Vane pump assy set bolt Bolt B | 43 | 440 | 32 |
| POWER STEERING VANE PUMP (1MZ-FE/3MZ-FE) | |||
| Vane pump housing rear x Vane pump housing front | 24 | 245 | 18 |
| Pressure port union | 83 | 846 | 61 |
| Power steering suction port union set bolt | 13 | 133 | 10 |
| Pump bracket front x Vane pump bracket rear (TYPE A VANE PUMP) | 43 | 438 | 32 |
| Pump bracket front x Vane pump bracket rear (TYPE B VANE PUMP) | 44 | 449 | 32 |
| Vane pump pulley set nut (TYPE A VANE PUMP) | 44 | 449 | 32 |
| Vane pump assy set bolt | 43 | 438 | 32 |
| Pressure feed tube assy x Vane pump assy | 51.5 | 525 | 38 |
| Power steering oil pressure switch | 21 | 214 | 15 |
| POWER STEERING GEAR | |||
| Control valve housing set bolt | 21 | 214 | 15 |
| Control valve shaft lock nut | 24.5 | 250 | 18 |
| Rack housing cap | 58.5 | 597 | 43 |
| Rack guide spring cap nut | 48 (68.5) | 489 (699) | 35 (51) |
| Power steering rack x Steering rack end sub-assy | 58.5 (83.5) | 597 (851) | 43 (62) |
| Tie rod assy lock nut | 74 | 755 | 55 |
| Turn pressure tube union nut | 11.5 (12.5) | 117 (127) | 8 (9) |
| Rack & pinion power steering gear assy set bolt and nut | 70 | 714 | 52 |
| Pressure feed and return tubes x Control valve housing | 22.5 (24.5) | 229 (250) | 17 (18) |
| Pressure feed tube clamp set bolt | 9.8 | 100 | 86 in...lbf |
| Return tube assy clamp set nut | 9.8 | 100 | 86 in...lbf |
| Front stabilizer bracket | 19 | 194 | 14 |
| Stabilizer link assy set nut | 74 | 755 | 55 |
| Tie rod assy set nut | 49 | 500 | 36 |
| Intermediate shaft sub-assy x Control valve | 35.3 | 360 | 26 |
| Hub nut | 103 | 1,050 | 76 |
POWER STEERING TORQUE SPECIFICATION
( ): For use without SST
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1 | |||
| Generator installation bolt Bolt A | 17.5 | 178 | 12 |
| Generator installation bolt Bolt C | 58 | 591 | 43 |
| AIR CONDITIONING RADIATOR ASSY | |||
| Air conditioning tube assy x Cooler evaporator sub-assy No. 1 | 3.5 | 35 | 30 in..lbf |
| Air conditioning radiator assy x Body | 1.5 | 15 | 12 in...lbf |
| Blower assy x Body | 1.5 | 15 | 12 in...lbf |
| Junction block x Instrument panel reinforcement | 8.4 | 85 | 73 in...lbf |
| Instrument panel brace sub-assy No. 1 x Instrument panel reinforcement Screw | 9.8 | 100 | 87 in...lbf |
| COOLER COMPRESSOR ASSY (3MZ-FE) | |||
| Magnet clutch hub x Cooler compressor assy | 18 | 184 | 13 |
| Compressor and magnet clutch x Engine Bolt A, B, C, F | 25 | 250 | 18 |
| Compressor and magnet clutch x Engine Nut D | 25 | 250 | 18 |
| Compressor and magnet clutch x Engine Bolt E | 18 | 184 | 13 |
| Cooler refrigerant suction hose No. 1 x Compressor and magnet clutch | 9.8 | 100 | 87 in...lbf |
| Cooler refrigerant discharge hose No. 1 x Compressor and magnet clutch | 9.8 | 100 | 87 in...lbf |
| COOLER COMPRESSOR ASSY (1MZ-FE) | |||
| Magnet clutch hub x Cooler compressor assy | 18 | 184 | 13 |
| Compressor and magnet clutch x Engine Bolt A, B, C, F | 25 | 250 | 18 |
| Compressor and magnet clutch x Engine Nut D | 25 | 250 | 18 |
| Compressor and magnet clutch x Engine Bolt E | 18 | 184 | 13 |
| Cooler refrigerant suction hose No. 1 x Compressor and magnet clutch | 9.8 | 100 | 87 in...lbf |
| Cooler refrigerant discharge hose No. 1 x Compressor and magnet clutch | 9.8 | 100 | 87 in...lbf |
| COOLER COMPRESSOR ASSY (2AZ-FE) | |||
| Magnet clutch hub x Cooler compressor assy | 18 | 184 | 13 |
| Compressor and magnet clutch x Engine | 25 | 250 | 18 |
| Cooler refrigerant suction hose No. 1 x Compressor and magnet clutch | 9.8 | 100 | 87 in...lbf |
| Cooler refrigerant discharge hose No. 1 x Compressor and magnet clutch | 9.8 | 100 | 87 in...lbf |
| COOLER CONDENSER ASSY | |||
| Cap x Cooler condenser assy | 12 | 125 | 9 |
| Cooler condenser assy x Body | 9.8 | 100 | 85 in...lbf |
| Cooler refrigerant liquid pipe A x Cooler condenser assy | 5.4 | 55 | 47 in...lbf |
| Cooler refrigerant discharge hose No. 1 x Cooler condenser assy | 5.4 | 55 | 47 in...lbf |
HEATER AND AIR CONDITIONING TORQUE SPECIFICATION
| Part Tightened | N..m | Kgf..cm | Ft..lbf |
|---|---|---|---|
| Horn button assy x Steering wheel assy | 8.8 | 90 | 78 in...lbf |
| Steering wheel assy x Steering column assy | 50 | 510 | 37 |
| Front passenger airbag assy x Instrument panel reinforcement | 20 | 204 | 15 |
| Curtain shield airbag assy x Body | 14 | 143 | 10 |
| Airbag sensor assy center x Body | 17.5 | 178 | 13 |
| Airbag front sensor set bolt | 17.5 | 178 | 13 |
| Side airbag sensor assy LH x Body | 20 | 204 | 15 |
| Airbag sensor rear LH x Body Property class 8T | 20 | 204 | 15 |
| Airbag sensor rear LH x Body Property class 6T | 17.5 | 178 | 13 |
| Seat position airbag sensor x Front seat | 8.0 | 82 | 71 in..lbf |
SUPPLEMENTAL RESTRAINT SYSTEM TORQUE SPECIFICATION
| Part Tightened | N..m | Kgf..cm | Ft..lbf |
|---|---|---|---|
| FRONT SEAT BELT | |||
| Front seat outer belt assy RH (For upper bolt) x Body | 7.5 | 77 | 66 in...lbf |
| Front seat outer belt assy RH (For lower bolt) x Body | 42 | 420 | 31 |
| Front seat outer belt (floor anchor) x Body | 42 | 420 | 31 |
| Front seat outer belt (shoulder anchor) x Body | 42 | 420 | 31 |
| Front seat inner belt assy RH x Front seat | 42 | 420 | 31 |
| REAR SEAT BELT | |||
| Rear seat inner w/center belt assy RH x Body | 42 | 420 | 31 |
| Rear seat inner w/center belt assy LH x Body | 42 | 420 | 31 |
| Rear seat belt assembly outer (Retractor side) x Body | 42 | 420 | 31 |
| Rear seat belt assembly outer (Floor anchor side) x Body | 42 | 420 | 31 |
SEAT BELT TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft-lbf |
|---|---|---|---|
| Wind shield wiper motor assy x Wiper link assy | 5.4 | 55 | 48 in.-lbf |
| Wiper link assy x Body | 7.0 | 71 | 62 in.-lbf |
| FR Wiper arm RH x Wiper link | 20.1 | 205 | 15 |
| FR Wiper arm LH x Wiper link | 20.1 | 205 | 15 |
WIPER AND WASHER TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| High pitched horn Assy | |||
| High pitched horn assy x Body | 20 | 204 | 15 |
| Low Pitched Horn Assy | |||
| Low pitched horn assy x Body | 20 | 204 | 15 |
COMMUNICATION SYSTEM TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| INNER REAR VIEW MIRROR ASSY | |||
| Inner rear view mirror assy x Front door | 1.2 | 12.2 | 11 in.-lbf |
| OUTER REAR VIEW MIRROR ASSY LH | |||
| Outer rear view mirror assy x Front door | 4.5 | 46 | 40 in.-lbf |
WINDSHIELD/WINDOWGLASS/MIRROR TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| Instrument panel reinforce x Passenger airbag Bolt < F > | 20 | 204 | 15 |
| Front pillar garnish x Body | 7.5 to 20 | 77 to 204 | 67 in.-lbf to 14 |
INSTRUMENT PANEL/METER TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| FRONT SEAT ASSEMBLY | |||
| Airbag sensor x Seat adjuster assembly | 8 | 82 | 71 in.-lbf |
| Seat Inner belt assembly x Seat adjuster assembly | 42 | 428 | 31 |
| Seatback cover bracket x Seat adjuster assembly (w/Side airbag) | 5.5 | 56 | 48 in.-lbf |
| Seat assembly x Body | 37 | 375 | 27 |
| REAR SEAT ASSEMBLY | |||
| Seatback hinge sub-assy x Seatback frame | 18 | 183 | 13 |
| Seatback hinge sub-assy x Body | 18 | 183 | 13 |
| Seatback hinge sub-assy center x Seatback frame | 18 | 183 | 13 |
| Seatback hinge sub-assy center x Body | 18 | 183 | 13 |
| Seatback lock assy x Seatback frame | 20 | 204 | 15 |
SEAT TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| HOOD | |||
| Hood x Hood hinge | 26 | 265 | 19 |
| Hood lock x Body | 8.0 | 82 | 71 in.-lbf |
| FRONT DOOR | |||
| Door frame sub-assy front lower x Door panel | 7.0 | 71 | 62 in.-lbf |
| Door frame sub-assy rear lower x Door panel | 7.0 | 71 | 62 in.-lbf |
| Door glass x Window regulator | 5.5 | 56 | 49 in.-lbf |
| Door hinge x Body | 26 | 265 | 19 |
| Door hinge x Door panel | 26 | 265 | 19 |
| Door lock striker x Body | 23 | 235 | 17 |
| Door window regulator x Body | 8.0 | 82 | 71 in.-lbf |
| Door w/motor lock x Door panel | 5.0 | 51 | 44 in.-lbf |
| Outer rear view mirror x Door panel | 5.5 | 56 | 49 in.-lbf |
| Outside handle sub-assy x Door panel | 4.0 | 41 | 37 in.-lbf |
| Power window regulator motor x Window regulator | 5.4 | 55 | 48 in.-lbf |
| Window regulator x Door panel | 8.0 | 82 | 71 in.-lbf |
| REAR DOOR | |||
| Door glass x Window regulator | 5.5 | 56 | 49 in.-lbf |
| Door hinge x Body | 26 | 265 | 19 |
| Door hinge x Door panel | 26 | 265 | 19 |
| Door lock striker x Body | 23 | 235 | 17 |
| Door outside handle cover x Door panel | 4.0 | 41 | 37 in.-lbf |
| Door window division bar x Door panel | 5.5 | 56 | 49 in.-lbf |
| Door window regulator x Body | 8.0 | 82 | 71 in.-lbf |
| Door window regulator x Body | 8.0 | 82 | 71 in.-lbf |
| Door w/ motor lock x Door panel | 5.0 | 51 | 44 in.-lbf |
| Outer rear view mirror x Door panel | 5.5 | 56 | 49 in.-lbf |
| Outside handle frame x Door panel | 4.0 | 41 | 37 in.-lbf |
| Power window regulator motor x Window regulator | 5.4 | 55 | 48 in.-lbf |
| Window regulator x Door panel | 8.0 | 82 | 71 in.-lbf |
| LUGGAGE COMPARTMENT DOOR | |||
| Luggage compartment door x body | 5.5 | 56 | 49 in.-lbf |
| Luggage compartment door x luggage compartment door hinge | 8.0 | 82 | 71 in.-lbf |
ENGINE HOOD/DOOR TORQUE SPECIFICATION
| Part Tightened | N.m | Kgf.cm | Ft.lbf |
|---|---|---|---|
| FRONT BUMPER (TMC Made) | |||
| Front bumper reinforcement extension x Body | 8.5 | 87 | 75 in.-lbf |
| Front bumper reinforcement upper x Body | 8.5 | 87 | 75 in.-lbf |
| Front bumper reinforcement x Body | 34 | 347 | 25 |
| FRONT BUMPER (TMMK Made) | |||
| Part Tightened | N.m | Kgf.cm | Ft-lbf |
| Front bumper reinforcement extension x Body Bolt | 17.5 | 178 | 13 |
| Front bumper reinforcement extension x Body Nut | 6.5 | 66 | 58 in.-lbf |
| Front bumper reinforcement upper x Body Bolt | 17.5 | 178 | 13 |
| Front bumper reinforcement upper x Body Nut | 6.5 | 66 | 58 in.- lbf |
| Front bumper reinforcement x Body | 92 | 938 | 68 |
| Front bumper cover x Body | 6.5 | 66 | 58 in.-lbf |
| REAR BUMPER | |||
| Rear bumper reinforcement x Body | 34 | 347 | 25 |
EXTERIOR/INTERIOR TRIM TORQUE SPECIFICATION
