Engine Controls - System/component Tests - 4-CYL: Specifications

Engine Controls - System/component Tests - 4-CYL: Specifications Toyota Camry XV20

TP SENSOR RESISTANCE SPECIFICATIONS

Throttle Position	Terminals Tested	Ohms
Fully Closed	VTA & E2	200-5700
Fully Open	VTA & E2	2000-10,200
Fully Open	VC & E2	2500-5900
(1) Apply vacuum to throttle opener before checking TP sensor.

(1)	Apply vacuum to throttle opener before checking TP sensor.

TP SENSOR RESISTANCE SPECIFICATIONS (CAMRY & CELICA 2.2L) (1)

TP SENSOR RESISTANCE SPECIFICATIONS (COROLLA - 1.8L)

Throttle Position	Terminals Tested	Ohms
Fully Closed	VTA & E2	200-5700
Fully Open	VTA & E2	2000-10,200
Fully Open	VC & E2	2500-5900
(1) Apply vacuum to throttle opener before checking TP sensor.

(1)	Apply vacuum to throttle opener before checking TP sensor.

TP SENSOR RESISTANCE SPECIFICATIONS (RAV4 - 2.0L) (1)

Throttle Position	Terminals Tested	Ohms
Fully Closed	VTA & E2	200-5700
Fully Open	VTA & E2	2000-10,200
Fully Open	VC & E2	2500-5900
(1) Apply vacuum to throttle opener before checking TP sensor.

(1)	Apply vacuum to throttle opener before checking TP sensor.

TP SENSOR RESISTANCE SPECIFICATIONS (TACOMA - 2.4L & 2.7L) (1)

Throttle Position	Terminals Tested	Ohms
Fully Closed	VTA & E2	200-5700
Fully Open	VTA & E2	2000-10,200
Fully Open	VC & E2	2500-5900
(1) Apply vacuum to throttle opener before checking TP sensor.

(1)	Apply vacuum to throttle opener before checking TP sensor.

TP SENSOR RESISTANCE SPECIFICATIONS (T100 & 4RUNNER - 2.7L) (1)

Throttle Position	Terminals Tested	Ohms
Fully Closed	VTA & E2	200-5700
Fully Open	VTA & E2	2000-10,200
Fully Open	VC & E2	2500-5900
(1) On A/T models, disconnect throttle cable from linkage before checking TP sensor.

(1)	On A/T models, disconnect throttle cable from linkage before checking TP sensor.

TP SENSOR RESISTANCE SPECIFICATIONS (TERCEL - 1.5L) (1)
