Wheel Alignment Specifications & Procedures: Other Toyota Camry XV10

Wheel Alignment 9 illustrations ~1743 words

Camry, Celica (FWD) & Corolla

Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of strut rod mounting bolt. Strut rod is parallel to side body panel.

Celica All-Trac

Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of body side No. 2 suspension arm mounting bolt.

Cressida & Supra

Measure front riding height from ground to center of lower suspension arm mounting bolt. Measure rear riding height from ground to center of No. 2 lower suspension arm mounting bolt.

Land Cruiser

Measure front riding height from ground to center of leading arm bushing bolt/nut. Measure rear riding height from ground to center of lower arm forward mounting bolt.

MR2

Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of lower arm inboard mounting nut.

Pickup (2WD)

Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of front leaf spring mounting bolt. (Scheme 1)

Scheme 1

Scheme 1: Pickup (2WD)

Pickup (4WD) & 4Runner

  1. Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of front leaf spring. (Scheme 1) To check for standard height differential, go to next step.
  2. Measure front riding height differential by comparing height at center tip of spindle to height at center of lower arm adjustment cam bolt. Difference between measurements should be 2.303" (58.50 mm).
  3. Measure rear riding height differential by comparing height at center of front leaf spring mounting bolt to height at centerline of rear axle shaft. On Pickup (4WD), difference between measurements should be 2.402" (61.00 mm). On 4Runner, difference between measurements should be 1.403" (26.50 mm).

Previa

Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of rear lower control arm forward mounting bolt.

Tercel

Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of trailing arm forward mounting bolt. Trailing arm is parallel to side body panel.

Camry, Celica & Corolla

To raise vehicle, place floor jack under center of front longitudinal engine crossmember. For rear of FWD models, place floor jack under rear suspension crossmember. For rear of All-Trac models, place floor jack under rear differential support member.

To raise vehicle, place floor jack under front suspension crossmember and under rear differential carrier.

Place floor jack under front/rear differential to raise vehicle.

To raise vehicle, place floor jack under front undercover support and under rear suspension crossmember.

Pickup, Previa & 4Runner

To raise vehicle, place floor jack under front suspension crossmember and under rear axle housing/differential.

To raise vehicle, place floor jack under front crossmember and under center of rear axle beam.

Camry, Celica, Corolla, Cressida, MR2, Supra & Tercel

Place emergency jack on reinforced support points of side body panel (between front and rear wheels). Safety stands may also be placed at these points. (Scheme 2)or (Scheme 3).

Scheme 2

Scheme 2: Camry, Celica, Corolla, Cressida, MR2, Supra & Tercel

Scheme 3

Scheme 3

To raise vehicle, place emergency jack under front/rear axle.

Pickup & 4Runner

Place emergency jack under front suspension crossmember and under rear axle housing/differential.

To raise vehicle, place emergency jack under frame support points between front and rear wheels.

Place lift blocks on reinforced support points of side body panel (between front and rear wheels). Safety stands may also be placed at these points. (Scheme 2)or (Scheme 3).

Place lift blocks under front/rear axle to raise vehicle.

On 2WD models, place lift blocks under frame side rail and under rear axle housing to raise vehicle. On 4WD models, place lift blocks under front suspension crossmember and under rear axle housing to raise vehicle.

Place lift blocks under frame side rail supports.

TURNING ANGLE

On Land Cruiser, Pickup, Previa and 4Runner, remove steering knuckle stopper bolts. On all models, turn steering wheel fully to the right and then left, and observe turning radius on both wheels. If turning radius is incorrect, inspect and replace any damaged or worn front suspension components. See WHEEL ALIGNMENT SPECIFICATIONS .

Front Suspension (Camry, Celica, Corolla, Cressida, Land Cruiser, MR2, Previa & Tercel)

  1. Check tires for wear and improper inflation. Check front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed .039" (1 mm).
  2. Check front suspension components for looseness. Ensure front shock absorbers work properly. Check vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(ref-53561-S02292973472001100400000) .
  3. Check camber of both front wheels. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) . If camber is not within specification, inspect and replace any damaged or worn front suspension components. Camber is NOT adjustable.

Front Suspension (Pickup & 4Runner)

  1. Check tires for wear and improper inflation. Check front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed.047" (1.2 mm).
  2. Check front suspension components for looseness. Ensure front shock absorbers work properly. Check vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(ref-53561-S02292973472001100400000).
  3. Check camber of both front wheels. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If camber is not within specification, add or remove shims on upper control arms on 2WD models. On 4WD models, loosen and turn adjustment cams. (Scheme 4)

Scheme 4

Scheme 4

Front Suspension (Supra)

  1. Check tires for wear and improper inflation. Check front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed.047" (1.2 mm).
  2. Check front suspension components for looseness. Ensure front shock absorbers work properly. Check vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(ref-53561-S02292973472001100400000).
  3. Check camber of both front wheels. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If camber is not within specification, loosen and turn adjustment cams. (Scheme 5)

Scheme 5

Scheme 5

Rear Suspension (Camry, Celica, Corolla FWD & MR2)

Check tires for wear and improper inflation. Check camber of both rear wheels. See WHEEL ALIGNMENT SPECIFICATIONS . If camber is not within specification, inspect and replace any damaged or worn rear suspension components. Camber is NOT adjustable.

Rear Suspension (Cressida & Supra)

Check tires for wear and improper inflation. Ensure left and right lengths of No. 1 and No. 2 lower suspension arms are equal. (Scheme 6) Check camber of both rear wheels. See WHEEL ALIGNMENT SPECIFICATIONS. If camber is not within specification, adjust camber by turning adjustment cams. (Scheme 6)

Scheme 6

Scheme 6: Rear Suspension (Cressida & Supra)

Except Supra

Ensure riding height and camber are correctly set. See WHEEL ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Check steering axis inclination of both front wheels. If steering axis inclination is not within specification, inspect and replace any damaged or worn front suspension components. See WHEEL ALIGNMENT SPECIFICATIONS . Steering axis/king pin inclination is NOT adjustable.

Supra

Ensure riding height, camber and caster are correctly set. See WHEEL ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Check steering axis inclination of both front wheels. If steering axis inclination is not within specification, inspect wheel bearing for looseness, or replace steering knuckle. See WHEEL ALIGNMENT SPECIFICATIONS .

Front Suspension (Camry & Cressida)

  1. Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) . If adjustment is necessary, see appropriate adjustment procedure.
  2. Check caster of both front wheels. If caster is not within specification, add or remove spacers on stabilizer bar (strut rod on Cressida). DO NOT use more than 2 spacers to adjust caster.

Front Suspension (Celica, Corolla, Land Cruiser, Previa & Tercel)

  1. Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) . If adjustment is necessary, see appropriate adjustment procedure.
  2. Check caster of both front wheels. If caster is not within specification, inspect and replace any damaged or worn front suspension components. Caster is NOT adjustable.

Front Suspension (MR2)

  1. Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If adjustment is necessary, see appropriate adjustment procedure.
  2. Check caster of both front wheels. If caster is not within specification, loosen strut bar front nut, and adjust camber adjusting nut. (Scheme 7) Tighten strut bar front nut after adjustment.

Scheme 7

Scheme 7
  1. Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If adjustment is necessary, see appropriate adjustment procedure.
  2. Check caster of both front wheels. If caster is not within specification, add or remove shims on upper control arms on 2WD models. DO NOT use more than 2 shims to adjust caster. On 4WD models, loosen and turn adjustment cams. (Scheme 4)
  1. Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If adjustment is necessary, see appropriate adjustment procedure.
  2. Check caster of both front wheels. If caster is not within specification, loosen and turn adjustment cams. (Scheme 5)

Front Suspension (All Models)

  1. Ensure riding height, camber, steering axis inclination and caster are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) . Ensure steering wheel is in straight-ahead position. Bounce both ends of vehicle several times to settle suspension.
  2. Measure toe-in. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) for specification. If necessary, adjust toe-in by varying length of tie rods.

Rear Suspension (Camry, Celica & Corolla FWD)

  1. Ensure rear camber is correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If adjustment is necessary, see appropriate adjustment procedure.
  2. Bounce both ends of vehicle several times to settle suspension. Measure distance between each wheel rim and corner of cam bracket to ensure both distances are the same. (Scheme 8)or (Scheme 9).
  3. Ensure toe-in is within specification. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). If necessary, adjust toe-in by turning adjustment cams.

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Ensure rear camber is correctly set. See «CAMBER ADJUSTMENT»(ref-53561-S31283273222001100400000) under WHEEL ALIGNMENT PROCEDURES. Bounce both ends of vehicle several times to settle suspension.
  2. Measure toe-in. If toe-in is not within specification, adjust by turning adjustment cam. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000). (Scheme 6)

Rear Suspension (MR2)

  1. Ensure rear camber is correct. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) . If adjustment is necessary, see appropriate adjustment procedure.
  2. Bounce both ends of vehicle several times to settle suspension. Measure rear wheel toe-in. See «WHEEL ALIGNMENT SPECIFICATIONS»(ref-53561-S41928566602001100400000) . If necessary, adjust rear toe-in by rotating rear tie rod sleeves.
ApplicationPreferredRange
Camber (1)
Front
Sedan FWD9/163/16 To 1 5/16
Wagon FWD1/21/4 To 1 1/4
Rear
Sedan FWD9/161 1/16 To -1/16
Wagon FWD1/169/16 To 7/16
All-Trac1/21 To 0
Caster (1)
Sedan1 11/161 3/16 To 2 3/16
Wagon11/2 To 1 1/2
Steering Axis Inclination (1)
Sedan12 3/412 To 13 1/2
Wagon12 27/3212 3/32 To 13 19/32
Toe-In (2)
Front1/32 (1)0 To 3/32 (0 To 2)
Rear5/32 (4)1/8 To 3/16 (3 To 5)
Toe-In (1)
Front1/160 To 3/16
Rear5/161/4 To 3/8
Toe-Out On Turns (1)
4-Cylinder
Inner37 1/2N/A
Outer30 3/4N/A
V6
Inner35 3/4N/A
Outer29 3/4N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (CAMRY)

ApplicationPreferredRange
Camber (1)
Front5/3229/32 To 19/32
Rear3/41 1/4 To -1/4
Caster (1)
All-Trac27/323/32 To 1 19/32
Except All-Trac29/325/32 To 1 21/32
Steering Axis Inclination (1)14 5/3213 13/32 To 14 29/32
Toe-In (2)
Front0 (0)3/32 To 3/32 (-2 To 2)
Rear3/16 (5)3/32 To 9/32 (3 To 7)
Toe-In (1)
Front03/16 To 3/16
Rear3/83/16 To 9/16
Toe-Out On Turns (1)
Inner33 1/2N/A
Outer29 1/2N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (CELICA)

ApplicationPreferredRange
Camber (1)
All-Trac3/165/16 To 11/16
Except All-Trac
Front3/167/8 To 1/2
Rear11/161 3/8 To 0
Caster (1)
All-Trac1 1/43/4 To 1 3/4
Except All-Trac1 7/163/4 To 2 1/8
Steering Axis Inclination (1)
2WD (4A-FE)12 21/3211 29/32 To 13 13/32
2WD (4A-GE)12 27/3212 3/32 To 13 19/32
4WD12 3/3211 19/32 To 12 19/32
Toe-In (2)
Front1/32 (1)0 To 1/16 (0 To 2)
Rear5/32 (4)1/8 To 3/16 (3 To 5)
Toe-In (1)
Front1/160 To 1/8
Rear5/161/4 To 3/8
Toe-Out On Turns (1)
All-Trac
Inner38N/A
Outer32N/A
Except All-Trac
Inner37N/A
Outer32 1/2N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (COROLLA)

ApplicationPreferredRange
Camber (1)
Front1/21/4 To 1 1/4
Rear03/4 To 3/4
Caster (1)7 5/166 13/16 To 7 13/16
Steering Axis Inclination (1)13 5/3212 13/32 To 13 29/32
Toe-In (2)
Front1/16 (2)1/32 To 3/32 (1 To 3)
Rear1/16 (2)0 To 5/32 (0 To 4)
Toe-In (1)
Front1/81/16 To 3/16
Rear1/80 To 5/16
Toe-Out On Turns (1)
Inner41 7/16N/A
Outer34 1/4N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (CRESSIDA)

ApplicationPreferredRange
Camber (1) (Front)11/4 To 1 1/4
Caster (1)
P235/75R32 To 4
31 x 10.50R LT1 21/3221/32 To 2 21/32
Steering Axis Inclination (1)13 1/212 3/4 To 14 1/4
Toe-In (2)1/32 (1)1/32 To 1/8 (-1 To 3)
Toe-In (1)1/161/16 To 7/32
Toe-Out On Turns (1)
Inner35N/A
Outer30N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (LAND CRUISER)

ApplicationPreferredRange
Camber (1)
Front15/161 7/16 To -7/16
Rear1 11/321 27/32 To -27/32
Caster (1)2 3/42 3/4 To 3 1/4
Steering Axis Inclination (1)13 1/213 To 14
Toe-In (2)
Front1/32 (1)0 To 3/32 (0 To 2)
Rear3/16 (5)5/32 To 1/4 (4 To 6)
Toe-In (1)
Front1/160 To 3/16
Rear3/85/16 To 1/2
Toe-Out On Turns (1)
Inner37 1/2N/A
Outer32N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (MR2)

ApplicationPreferredRange
4-Cylinder
STD, Reg. Cab
Short Chassis
Camber (1)1/21/4 To 1 1/4
Caster (1)21/320 To 1 1/2
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)1/16 (1.5)1/32 To 1/8 (-1 To 3)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
DLX, Reg. Cab
Short Chassis
Camber (1)1/21/4 To 1 1/4
Caster (1)23/320 To 1 1/2
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)1/16 (1.5)1/32 To 1/8 (-1 To 3)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
Long Chassis
Camber (1)1/21/4 To 1 1/4
Caster (1)11/4 To 1 3/4
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
DLX, Xtra Cab
Xtra Long Chassis
Camber (1)3/83/8 To 1 1/8
Caster (1)1 1/41/2 To 2
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)1/8 (3)1/16 To 3/16 (1 To 5)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
V6
Standard
C & C DRW (3)
Camber (1)1/21/4 To 1 1/4
Caster (1)1 3/41 To 2 1/2
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)7/32 (5.5)1/8 To 5/16 (1 To 8)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
DLX, Reg. Cab
Long Chassis (A/T)
Camber (1)1/21/4 To 1 1/4
Caster (1)9/163/16 To 1 5/16
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)3/16 (5)1/8 To 9/32 (3 To 7)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
Long Chassis (M/T)
Camber (1)1/21/4 To 1 1/4
Caster (1)9/163/16 To 1 5/16
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)7/32 (5.5)1/8 To 5/16 (3 To 8)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
DLX, Xtra Cab
Xtra Long Chassis
Camber (1)3/83/8 To 1 1/8
Caster (1)1 1/41/2 To 2
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)1/8 (3)1/16 To 3/16 (1 To 5)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
SR5, Xtra Cab
Xtra Long Chassis
Camber (1)13/3211/32 To 1 5/32
Caster (1)1 7/3215/32 To 2
Steering Axis Inclination (1)109 1/4 To 10 3/4
Toe-In (2)1/8 (3)1/16 To 3/16 (1 To 5)
Toe-Out On Turns (1)
Inner3432-35
Outer30N/A
(1) Measurement in degrees. (2) Measurement in inches (mm). (3) C & C DRW is Cab and Chassis with Dual Rear Wheels.
(1)Measurement in degrees.
(2)Measurement in inches (mm).
(3)C & C DRW is Cab and Chassis with Dual Rear Wheels.

WHEEL ALIGNMENT SPECIFICATIONS (PICKUP 2WD)

ApplicationPreferredRange
4-Cylinder
All Long Chassis
Camber (1)11/161/16 To 1 7/16
Caster (1)1 11/1615/16 To 2 7/16
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
DLX, Reg. Cab
Standard Chassis
Camber (1)23/321/32 To 1 15/32
Caster (1)
A/T1 29/3215/16 To 2 7/16
M/T1 5/87/8 To 2 3/8
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
DLX, Xtra Cab
Xtra Long Chassis
Camber (1)21/323/32 To 1 13/32
Caster (1)
A/T1 7/81 1/8 To 2 5/8
M/T1 13/161 1/16 To 2 9/16
Steering Axis Inclination (1)11 29/3211 5/32 To 12 21/32
Toe-In (2)3/32 (2.5)0 To 3/16 (0 To 5)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
V6
All Reg. Cab
Short Chassis
Camber (1)23/321/32 To 1 15/32
Caster (1)1 11/1615/16 To 2 7/16
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
Long Chassis
Camber (1)11/161/16 To 1 7/16
Caster (1)1 3/41 To 2 1/2
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
DLX, Xtra Cab
Xtra Long Chassis
Camber (1)21/323/32 To 1 13/32
Caster (1)1 7/81 1/8 To 2 5/8
Steering Axis Inclination (1)11 29/3211 5/32 To 12 21/32
Toe-In (2)3/32 (2.5)0 To 3/16 (0 To 5)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
SR5, Xtra Cab
Xtra Long Chassis
Camber (1)11/161/16 To 1 7/16
Caster (1)
M/T1 29/321 5/32 To 2 21/32
A/T1 15/161 3/16 To 2 11/16
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2.5)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (PICKUP 4WD)

ApplicationPreferredRange
2WD
Camber (1)03/4 To 3/4
Caster (1)5 1/24 3/4 To 6 1/4
Steering Axis Inclination (1)10 19/329 27/32 To 11 11/32
Toe-In (2)3/32 (2)1/32 To 1/8 (1 To 3)
Toe-In (1)3/161/16 To 1/4
Toe-Out On Turns (1)
Inner36N/A
Outer33N/A
4WD
Camber (1)1/41/2 To 1
Caster (1)5 5/164 9/16 To 6 1/16
Steering Axis Inclination (1)10 11/329 19/32 To 11 3/32
Toe-In (2)1/8 (3)3/32 To 5/32 (2 To 4)
Toe-Out On Turns (1)
Inner36N/A
Outer33 1/2N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (PREVIA)

ApplicationPreferredRange
Camber (1)
Front3/1611/16 To 5/16
Rear3/41 1/4 To -1/4
Caster (1)7 11/167 3/16 To 8 3/16
Steering Axis Inclination (1)10 29/3210 5/32 To 11 21/32
Toe-In (2)
Front0 (0)1/32 To 1/32 (-1 To 1)
Rear5/32 (4)1/8 To 3/16 (3 To 5)
Toe-In (1)
Front01/16 To 1/16
Rear5/161/4 To 3/8
Toe-Out On Turns (1)
Inner34 1/2N/A
Outer31 3/4N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (SUPRA)

ApplicationPreferredRange
Camber (1)
Front1/41 To 1/2
Rear1/21 1/4 To 1/4
Caster (1)1 1/41/2 To 2
Steering Axis Inclination (1)1211 1/4 To 12 3/4
Toe-In (2)
Front1/32 (1)1/32 To 1/8 (-1 To 3)
Rear1/8 (3)0 To 1/4 (0 To 6)
Toe-In (1)
Front3/323/32 To 5/16
Rear1/40 To 1/2
Toe-Out On Turns (1)
Inner36 5/32N/A
Outer32 1/4N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (TERCEL)

ApplicationPreferredRange
2WD
SR5 4-Door A/T
Camber (1)23/321/32 To 1 15/32
Caster (1)
4-Cylinder1 29/321 5/32 To 2 5/8
V61 15/161 3/16 To 2 11/16
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
4WD
SR5 4-Cylinder
Camber (1)23/321/32 To 1 15/32
Caster (1)
2-Door1 31/321 7/32 To 2 23/32
4-Door21 9/32 To 2 25/32
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
SR5 V6
2-Door (A/T)
Camber (1)23/321/32 To 1 15/32
Caster (1)
P225/75R151 27/321 3/32 To 2 19/32
31 x 10.5R151 7/81 1/8 To 2 5/8
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
2-Door (M/T)
Camber (1)23/321/32 To 1 15/32
Caster (1)
P225/75R151 13/161 1/16 To 2 9/16
31 x 10.5R151 27/321 3/32 To 2 19/32
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
4-Door (A/T)
Camber (1)23/321/32 To 1 15/32
Caster (1)
P225/75R151 21/3229/32 To 2 13/32
31 x 10.5R151 23/3231/32 To 2 15/32
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
4-Door (M/T)
Camber (1)23/321/32 To 1 15/32
Caster (1)
P225/75R151 11/1615/16 To 2 7/16
31 x 10.5R151 23/3231/32 To 2 15/32
Steering Axis Inclination (1)11 7/811 1/8 To 12 5/8
Toe-In (2)3/32 (2)0 To 5/32 (0 To 4)
Toe-Out On Turns (1)
Inner3230-33
Outer31N/A
(1) Measurement in degrees. (2) Measurement in inches (mm).
(1)Measurement in degrees.
(2)Measurement in inches (mm).

WHEEL ALIGNMENT SPECIFICATIONS (4RUNNER)
