Engine Controls - System/component Tests - 2.2L: Overview Toyota Camry V40

Testing & Diagnostics 1 illustration ~177 words

Fuel Pump Resistance & Operation

  1. Disconnect electrical connector for fuel pump. See «FUEL PUMP ELECTRICAL CONNECTOR LOCATION»(ref-21981-S30332060092001010300000) table. FUEL PUMP ELECTRICAL CONNECTOR LOCATION Application Connector Location Camry Under Cover Plate, Below Rear Seat
  2. To test fuel pump resistance, using ohmmeter, check resistance between specified terminals on fuel pump electrical connector or fuel pump. (Scheme 32) Replace fuel pump if resistance is not.20-3.0 ohms at 68°F (20°C). CAUTION: When testing fuel pump operation, DO NOT apply battery voltage to fuel pump for more than 10 seconds or fuel pump may be damaged. When testing fuel pump operation, keep fuel pump away from battery as far as possible.
  3. To test fuel pump operation, apply battery voltage and ground to (+) and (-) terminals on electrical connector or fuel pump. (Scheme 32) DO NOT apply battery voltage to fuel pump for more than 10 seconds. Keep fuel pump away from battery as far as possible. Replace fuel pump if fuel pump fails to operate.

Scheme 32

Scheme 32
Scheme 32
