Maintenance Information: Component Locations Toyota Camry V40

Procedures 15 illustrations ~1182 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

FUSE PANEL LOCATION

Vehicle has 3 fuse panels. Instrument panel fuse box is located on dashboard, left of steering column. Passenger-side fuse box is located behind passenger-side kick panel. Main fuse and relay block is in engine compartment, near battery.

Scheme 1

Scheme 1: PASSENGER COMPARTMENT FUSE PANEL IDENTIFICATION (1983-86)
Scheme 1: PASSENGER COMPARTMENT FUSE PANEL IDENTIFICATION (1983-86)

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp - Power Antenna, Automatic Transmission System (1986)
  2. 2 - 15 Amp - Cruise Control System (1983-85), Electronically Controlled A/T System (1986)
  3. 3 - 7.5 Amp - Charging System & Discharge Warning Light, Electric Cooling Fans & Ignition Main
  4. 4 - 20 Amp - Wipers & Washers
  5. 5 - Blank
  6. 6 - 20 Amp - Stoplights, Cruise Control Cancel (1986)
  7. 7 - 7.5 Amp - Turn Signal Lights
  8. 8 - 7.5 Amp - Gauges & Warning/Indicator Lights, Rear Window Defogger & Back-Up Lights, A/T Overdrive System (1986)
  9. 9 - 15 Amp - Taillights, Parking Lights, License Lights, Side Marker Lights, Instrument Illumination
  10. 10 - 7.5 Amp - Radio, Cassette Player, Graphic Equalizer (1986)
  11. 11 - 7.5 Amp - Interior, Personal & Door Courtesy Lights, Trunk, Ignition Switch & Door Warning Lights, Radio & Cassette Player
  12. 12 - 15 Amp - Cigarette Lighter & Digital Clock, Power Rear View Mirrors
  13. 13 - 10 Amp - Air Conditioning

Scheme 2

Scheme 2: PASSENGER COMPARTMENT FUSE PANEL IDENTIFICATION (1987-91)
Scheme 2: PASSENGER COMPARTMENT FUSE PANEL IDENTIFICATION (1987-91)

Fuse Identification

  1. 1 - 7.5 Amp - Gauges, Warning Lights, Back-Up Lights & A/T Overdrive System, Rear Window Defogger & Automatic Shoulder Belt, Power Windows & Door Lock System
  2. 2 - 7.5 Amp - Interior, Personal & Door Courtesy Lights (1987-88), Trunk, Ignition Switch & Door Warning Lights (1987-88)
  3. 3 - 20 Amp - Stoplights
  4. 4 - 15 Amp - Taillights, Parking Lights, License Lights, Side Marker Lights, Glove Box Light, Instrument Illumination
  5. 5 - 15 Amp - Cigarette Lighter & Digital Clock, Shift Lock System (A/T - 1989-91)
  6. 6 - 7.5 Amp - Radio & Cassette Player, Power Rear View Mirrors
  7. 7 - 7.5 Amp - Turn Signal Lights
  8. 8 - 10 Amp - Engine Idle-Up System
  9. 9 - Blank
  10. 10 - 10 Amp - Charging & Emission Control Systems
  11. 11 - 20 Amp - Wipers & Washers
  12. 12 - 15 Amp - Cruise Control & Automatic Transmission (A/T) Systems, Shift Lock System (A/T - 1989-91)
  13. 13 - Blank
  14. 14 - 7.5 Amp - Charging & Emission Control Systems, Discharge Warning Light & Electric Cooling Fans, Electronic Fuel Injection
  15. 15 - 10 Amp - Rear Window Defogger & Anti-Lock Brake System (1989-91)
  16. 16 - 10 Amp - Environmental Cooling System (Passenger-Side Kick Panel)

Circuit Breaker Identification

  1. A - 30 Amp - Rear Window Defogger
  2. B - 30 Amp - Electric Sun Roof, Power Windows, Power Door Locks
  3. C - 30 Amp - Automatic Shoulder Belt
  4. D - 30 Amp (1987-88) - 40 Amp (1989-91) - Environmental Control System (Passenger-Side Kick Panel)

Scheme 3

Scheme 3: UNDERHOOD MAIN FUSE & RELAY PANEL IDENTIFICATION (1983-86)
Scheme 3: UNDERHOOD MAIN FUSE & RELAY PANEL IDENTIFICATION (1983-86)

Fuse & Circuit Breaker Identification

  1. 1 - 7.5 Amp - Discharge Warning Light, Choke Heater (1983-85), Charging System (1986)
  2. 2 - 15 Amp - Headlight (Left), High Beam Indicator (1983-85)
  3. 3 - 15 Amp - Headlight (Right), High Beam Indicator (1983-85)
  4. 4 - Blank
  5. 5 - Blank
  6. 6 - 15 Amp - Horns & Hazard Flashers
  7. 7 - 15 Amp - Charging & Emission Control Systems, Fuel Cut Solenoid (1983-85)
  8. 8 - 15 Amp - Electronic Fuel Injection (Gasoline) 20 Amp - Fuel Heater (Diesel)
  9. 9 - 15 Amp - Radio

Scheme 4

Scheme 4: UNDERHOOD MAIN FUSE & RELAY PANEL IDENTIFICATION (1987-91)
Scheme 4: UNDERHOOD MAIN FUSE & RELAY PANEL IDENTIFICATION (1987-91)

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp - Headlights (Right High Beam/Canada)
  2. 2 - 15 Amp - Headlights (Left High Beam/Canada)
  3. 3 - 15 Amp (20 Amp - 1989-91) - Radio, Cassette Player, Power Antenna, Clock, Automatic Transmission System, Interior, Personal & Door Courtesy Lights, Trunk & Ignition Switch Lights, Door Warning Lights
  4. 4 - Blank
  5. 5 - 15 Amp - Headlight (Right/USA), Headlight (Right Low Beam/Canada)
  6. 6 - 7.5 Amp - Charging System & Discharge Warning Light
  7. 7 - 15 Amp - EFI System
  8. 8 - 15 Amp - Emergency Flashers & Horns
  9. 9 - 15 Amp - Headlight (Left/USA), Headlight (Left Low Beam/Canada)
  10. 10 - 30 Amp (Circuit Breaker) - A/C Condenser
  11. 11 - 15 Amp (Circuit Breaker) 30 Amp (Circuit Breaker - 1991) - Cooling Fan

Relay Identification

  1. A - A/C Fan No. 3
  2. B - A/C Magnetic Clutch (USA) Headlight Dimmer (Canada)
  3. C - A/C Fan No. 2
  4. D - Fan No. 1
  5. E - Headlights
  6. F - EFI Main Relay
  7. G - Main Engine Relay

Scheme 5

Scheme 5: FUSE PANEL IDENTIFICATION (1992-93)
Scheme 5: FUSE PANEL IDENTIFICATION (1992-93)
  1. 1 - 15 Amp - Electronically Controlled 4-Speed, Automatic Transmission System (4EAT), Cruise Control System, Anti-Lock Brake System (ABS)
  2. 2 - 10 Amp - Gauges, Meters, Back-Up Lights, Air Conditioning Control System, Rear Window Defogger, Warning Lights, Daytime Running Lights (DRL), Tilt Steering
  3. 3 - 25 Amp - Stoplights, Cruise Control System, ABS, Shift Lock System
  4. 4 - 15 Amp - Seat Heater
  5. 5 - 20 Amp - Windshield Wipers & Washer, Air Bag System
  6. 6 - 7.5 Amp - Turn Signal Lights, Emergency Flashers
  7. 7 - 7.5 Amp - Electronic Fuel Injection System (EFI), Charging System, Radiator Cooling Fan, Air Bag System
  8. 8 - 15 Amp - Audio System, DRL, Clock, Cigarette Lighter, Air Bag System, Shift Lock System
  9. 9 - 10 Amp - Outside Rear View Mirror Heater
  10. 10 - 15 Amp - Taillights, Parking Lights, License Plate Lights, Instrument Panel Lights, Rear Light Failure Warning Light
  11. 11 - 15 Amp - ABS, DRL, Air Bag System
  12. 12 - 15 Amp - Foglights
  13. 13 - 10 Amp - Air Conditioning Control System
  14. 14 - 10 Amp - Starter System, EFI
  15. 15 - 7.5 Amp - Charging System
  16. 16 - 15 Amp - EFI System
  17. 17 - 15 Amp - Right Headlight
  18. 18 - 20 Amp - Audio System, Interior Lights, Clock, Ignition Switch Light, Personal Light, Trunk Room Light, Vanity Mirror Light, Electric Moon Roof
  19. 19 - 15 Amp - Turn Signal Lights, Emergency Flasher, Horn
  20. 20 - 15 Amp - Left Headlight
  21. 21 - 7.5 Amp - 4EAT System
  22. 22 - 30 Amp - Headlights
  23. 23 - 15 Amp (Not Shown) - Right Headlight High Beam (Canada)
  24. 24 - 15 Amp (Not Shown) - Left Headlight High Beam (Canada)
  25. 25 - 15 Amp (Not Shown) - Right Headlight Low Beam (Canada)
  26. 26 - 15 Amp (Not Shown) - Left Headlight Low Beam (Canada)
  27. 27 - 15 Amp (Not Shown) - Daytime Running Light System (Canada)
  28. 28 - 40 Amp - Starting System
  29. 29 - 30 Amp - Electric Moon Roof, Power Windows, Tilt Steering, Power Door Lock Controls
  30. 30 - 40 Amp - Rear Window Defogger
  31. 31 - 40 Amp - Air Conditioning Control System
  32. 32 - 30 Amp - Condenser Cooling Fan
  33. 33 - 30 Amp - Radiator Cooling Fan
  34. 34 - 30 Amp - Starting System
  35. 35 - 100 Amp - Charging System
  36. 36 - 60 Amp - ABS

Scheme 6

Scheme 6: FUSE IDENTIFICATION (1994-96)
Scheme 6: FUSE IDENTIFICATION (1994-96)

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Fuse & Circuit Breaker Identification
