Charging System - Generators & Regulators Toyota Camry Solara I

Charging System 20 illustrations ~1324 words

DESCRIPTION & OPERATION

Note. This article also applies to Lexus LX470. For Lexus LX470, refer to Land Cruiser, unless otherwise indicated.

The generator is a small, high RPM, high performance type with an internal Integrated Circuit (IC) voltage regulator which controls charging system voltage. A transistor inside IC regulator controls generator voltage output to maintain a constant voltage. Charging system voltage is maintained within an operating range of 13.2-15.1 volts.

When ignition is turned on, battery voltage flows from generator terminal "L" through IC regulator to ground, causing discharge warning light to come on. When engine starts, generator RPM increases, which increases generator output voltage. When generator output voltage is greater than battery voltage, voltage to recharge battery flows from terminal "B". At the same time, voltage at terminal "L" increases and the potential difference between battery and terminal "L" ceases, causing discharge warning light to go off.

ADJUSTMENTS

Note. New belt refers to a belt which has been used 5 minutes or less on a running engine. Used belt refers to a belt which has been used more than 5 minutes on a running engine. After installing new belt(s), run engine for at least 5 minutes and recheck tension.

4-Cylinder

Check belt tension using Burroughs Tension Gauge (BT-33-73F) at longest belt run. Adjust belt tension if necessary. See BELT TENSION SPECIFICATIONS (4-CYLINDER) table.

Note. Corolla and MR2 use an automatic belt tensioner. Adjustment is not required.

ApplicationNew Belt Lbs. (kg)Used Belt Lbs. (kg)
Camry, Camry Solara & RAV4
Generator
With A/C140-190 (64-86)100-120 (45-54)
Without A/C100-150 (45-68)75-115 (34-52)
Power Steering95-145 (43-66)60-100 (27-45)
Celica
Generator
With A/C170-180 (77-82)95-135 (43-61)
Without A/C100-150 (45-68)75-115 (34-52)
Power Steering99-121 (45-55)44-77 (20-35)
Corolla(2)(2)
ECHO121-143 (55-65)55-88 (25-40)
MR2(2)(2)
Tacoma & 4Runner
A/C135-185 (61-84)80-100 (36-45)
Generator116-169 (53-77)66-88 (30-40)
Power Steering135-180 (61-82)85-120 (39-54)
(1) Measure belt tension with Burroughs (BT-33-73F) tension gauge. (2) Automatic belt tensioner is used. Adjustment is not required.
(1)Measure belt tension with Burroughs (BT-33-73F) tension gauge.
(2)Automatic belt tensioner is used. Adjustment is not required.

BELT TENSION SPECIFICATIONS (4-CYLINDER) (1)

V6

Check belt tension using Burroughs Tension Gauge (BT-33-73F) at longest belt run. Adjust belt tension if necessary. See BELT TENSION SPECIFICATIONS (V6) table.

ApplicationNew Belt Lbs. (kg)Used Belt Lbs. (kg)
Avalon, Camry, Camry Solara & Sienna
Generator170-180 (77-82)95-135 (43-61)
Power Steering150-185 (68-84)95-135 (43-61)
Tacoma, Tundra & 4Runner
A/C135-185 (61-84)80-120 (36-54)
Generator140-180 (64-82)80-120 (36-54)
Power Steering135-180 (61-82)85-120 (39-54)
(1) Measure belt tension with Burroughs (BT-33-73F) tension gauge.
(1)Measure belt tension with Burroughs (BT-33-73F) tension gauge.

BELT TENSION SPECIFICATIONS (V6) (1)

V8

Automatic belt tensioner is used on Land Cruiser and Tundra. Adjustment is not required. If belt tension is not within "A" range of automatic belt tensioner, replace belt. (Scheme 1)

Scheme 1

Scheme 1: V8

TROUBLE SHOOTING

Note. See TROUBLE SHOOTING article in GENERAL INFORMATION.

Check all fuses, fusible links, ignition switch and appropriate relays (if equipped). Check generator output. See NO-LOAD TEST under ON-VEHICLE TESTING.

NO-LOAD TEST

  1. Disconnect battery-to-generator terminal "B" wire. (Scheme 2) Using an ammeter and voltmeter, connect negative ammeter lead to disconnected generator terminal "B" wire end, and connect positive ammeter lead to generator terminal "B".
  2. Connect voltmeter positive lead to generator terminal "B" and negative lead to ground. (Scheme 2) Start engine and increase engine speed to 2000 RPM. Both meters should read within specification. See «GENERATOR REGULATED OUTPUT SPECIFICATIONS»(/toyota/camry-solara/i-1998-2003/remont/charging-system/#charging-system-generators-regulators) table. If voltage is more than specified, replace IC regulator. If voltage is less than specified, go to next step.
  3. Locate small hole in back of generator. (Scheme 3) It may be necessary to remove generator end cover to access hole in back of generator. Using a probe, ground (full field) generator terminal "F" to generator case. (Scheme 3) If voltage is more than specified range, replace IC regulator. If voltage is less than specified range, repair or replace generator.
ApplicationAmpsVolts
Avalon10 Or Less13.2-14.8
Camry, Camry Solara, Corolla & ECHO10 Or Less13.5-15.1
Celica & RAV4
With Temperature At 77°F (25°C)10 Or Less14.0-15.1
With Temperature At 239°F (115°C)10 Or Less13.5-14.3
Land Cruiser & Sienna10 Or Less13.2-14.8
MR210 Or Less13.2-14.0
Tacoma
With Temperature At 77°F (25°C)10 Or Less13.7-14.7
With Temperature At 239°F (115°C)10 Or Less13.2-14.0
Tundra
V610 Or Less13.2-14.8
V8
With Temperature At 77°F (25°C)10 Or Less13.7-14.7
With Temperature At 239°F (115°C)10 Or Less13.2-14.0
4Runner
With Temperature At 77°F (25°C)10 Or Less13.7-14.7
With Temperature At 239°F (115°C)10 Or Less13.2-14.0
(1) Specification given is with engine speed at 2000 RPM.
(1)Specification given is with engine speed at 2000 RPM.

GENERATOR REGULATED OUTPUT SPECIFICATIONS (1)

Scheme 2

Scheme 2

Scheme 3

Scheme 3

LOAD TEST

Note. If battery is fully charged, disable ignition system. Crank engine for about 15 seconds to partially discharge battery.

  1. Connect an ammeter as described in «NO-LOAD TEST»(/toyota/camry-solara/i-1998-2003/remont/charging-system/#charging-system-generators-regulators__no-load-test), step 1). (Scheme 2) Start engine. Turn on high beam headlights and place heater blower control on HI. Increase engine speed to 2000 RPM.
  2. Check ammeter reading. Ammeter should read 30 amps or more. If amperage is less than specified, repair or replace generator.

Note. If battery is fully charged, generator load test results may be less than 30 amps.

BRUSHES

  1. Brushes should slide smoothly in holders. Replace brushes if damaged or worn. On ECHO, MR2, Tundra and 4Runner, new brush exposed length should be .374-.453" (9.5-11.5 mm). On all other models, new brush exposed length should be .413" (10.5 mm).
  2. On all models, minimum exposed length should be more than .059" (1.5 mm). There are 2 different brush holders used. One brush holder is replaced as an assembly, and the other has replaceable brushes. If exposed brush length is less than minimum, replace brushes or brush holder assembly. Install new brush springs when replacing brushes.

ROTOR

  1. Check rotor for open field windings by using an ohmmeter across slip rings. Rotor resistance should be within specification. See «ROTOR RESISTANCE SPECIFICATIONS»(/toyota/camry-solara/i-1998-2003/remont/charging-system/#charging-system-generators-regulators) table.
  2. Check rotor for shorts to ground by connecting ohmmeter between slip ring and rotor shaft. Ohmmeter should indicate no continuity. Check slip rings for wear or pitting. Standard slip ring diameter is .559-.567" (14.2-14.4 mm). Turn slip rings on lathe if necessary. Minimum slip ring diameter is .504" (12.8 mm).
Application(1) Ohms
Avalon2.1-2.5
Camry & Camry Solara
4-Cyl.2.7-3.1
V62.1-2.5
Land Cruiser, MR2, Sienna, Tacoma, Tundra & 4Runner2.1-2.5
All Other Models2.7-3.1
(1) Specification given is with temperature at 68°F (20°C).
(1)Specification given is with temperature at 68°F (20°C).

ROTOR RESISTANCE SPECIFICATIONS

STATOR

Connect ohmmeter between 2 stator leads. Continuity should exist between all stator leads. Connect ohmmeter between each stator lead and metal core. Continuity should not exist. If stator does not test as indicated, replace stator.

DIODES

  1. With diode/rectifier assembly removed and on bench, contact positive diode plate terminal with one ohmmeter probe. Using other ohmmeter probe, contact each diode lead in same plate. Note ohmmeter reading. Reverse ohmmeter probes, and repeat tests for all diodes.
  2. All diodes should show continuity in one direction and no continuity in opposite direction. If any diode is defective, replace diode/rectifier assembly.

Removal & Installation (Land Cruiser)

  1. Disconnect negative battery cable. Drain engine coolant. Rotate belt tensioner counterclockwise to release tension on belt and remove drive belt. Remove splash shield from underneath engine. Remove radiator reservoir tank and radiator.
  2. Using Spanner Wrench (09960-10010), to keep power steering pump pulley from rotating, remove power steering pump pulley retaining nut. Remove power steering pump pulley. Remove generator mounting bolts and generator. To install, reverse removal procedure. Tighten bolts to specifications. See «TORQUE SPECIFICATIONS»(/toyota/camry-solara/i-1998-2003/remont/charging-system/#charging-system-generators-regulators__torque-specifications) .

Removal & Installation (All Others)

Disconnect negative battery cable. Removal and installation is basically an unbolt and bolt-on procedure. Tighten generator bolts to specification. See TORQUE SPECIFICATIONS .

Disassembly

  1. Remove rear end cover (if equipped). (Scheme 4) Remove brush holder and IC regulator. Remove diode assembly. Remove rubber insulators or seal plate (if equipped). Use generator Pulley Set Nut Wrench Set (SST 09820-63010) to remove generator pulley.
  2. To remove pulley, install SST "A" and "B" to rotor shaft and tighten SST "B" clockwise to 29 ft. lbs. (39 N.m). (Scheme 5) Place SST "C" securely into a vise. Verify that SST "A" is secured to rotor shaft and install SST "A" and "B" and generator into SST "C". Turn SST "A" in correct direction to loosen pulley nut. (Scheme 5) To prevent damage to rotor shaft, DO NOT loosen pulley nut more than 1/2 turn. Remove SST "A" and "B" and generator from SST "C". Remove SST "A" and "B" from rotor shaft, and remove pulley nut and pulley.
  3. Remove rectifier and frame using appropriate puller. Remove generator washer (if equipped). Remove rotor from drive end frame (stator).

Assembly

To assemble, reverse disassembly procedure. Use generator Pulley Set Nut Wrench Set (SST 09820-63010) to install generator pulley. Place SST "C" securely into a vise. Install SST "A" and "B" and generator into SST "C". (Scheme 5) Tighten pulley nut to 81 ft. lbs. (110 N.m) in the opposite direction of disassembly. After completing assembly, verify rotor turns smoothly.

Scheme 4

Scheme 4: Assembly

Scheme 5

Scheme 5

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Avalon & Sienna
Generator Adjusting Bolt13 (18)
Generator Pivot Bolt41 (56)
Generator Pulley Nut81 (110)
Camry & Camry Solara
4-Cylinder
Generator Adjusting Bolt13 (18)
Generator Pivot Bolt38 (52)
Generator Pulley Nut81 (110)
V6
Generator Adjusting Bolt13 (18)
Generator Pivot Bolt41 (56)
Generator Pulley Nut81 (110)
Celica
Generator Adjusting Bolt14 (19)
Generator Pivot Bolt40 (54)
Generator Pulley Nut81 (110)
Corolla
Generator Adjusting Bolt18 (24)
Generator Pivot Bolt
1ZZ-FE Engine40 (54)
2ZZ-GE Engine43 (58)
Generator Pulley Nut81 (110)
ECHO
Generator Adjusting Bolt14 (19)
Generator Pivot Bolt40 (54)
Generator Pulley Nut81 (110)
Land Cruiser
Generator Mounting Bolts29 (39)
Generator Pulley Nut81 (110)
Power Steering Pulley Nut32 (43)
MR2
Generator Mounting Bolts18 (25)
Generator Pulley Nut40 (54)
Power Steering Pulley Nut81 (110)
RAV4
Generator Adjusting Bolt13 (18)
Generator Pivot Bolt38 (51)
Generator Pulley Nut81 (110)
Tacoma & 4Runner
4-Cylinder
Generator Adjusting Lock Bolt21 (28)
Generator Pivot Bolt43 (58)
Generator Pulley Nut81 (110)
V6
Generator Adjusting Lock Bolt25 (34)
Generator Pivot Bolt38 (51)
Generator Pulley Nut81 (110)
Tundra
V6
Generator Adjusting Lock Bolt25 (34)
Generator Pivot Bolt38 (51)
Generator Pulley Nut81 (110)
V8
Generator Mounting Bolts29 (39)
Generator Pulley Nut81 (110)
Power Steering Pulley Nut32 (43)

TORQUE SPECIFICATIONS

Charging System Wiring Diagram (Avalon). Scheme 6

Scheme 6: Charging System Wiring Diagram (Avalon)

Charging System Wiring Diagram (Camry - 2.2L & 3.0L). Scheme 7

Scheme 7: Charging System Wiring Diagram (Camry - 2.2L & 3.0L)

Charging System Wiring Diagram (Camry - 2.2L CNG). Scheme 8

Scheme 8: Charging System Wiring Diagram (Camry - 2.2L CNG)

Charging System Wiring Diagram (Camry Solara). Scheme 9

Scheme 9: Charging System Wiring Diagram (Camry Solara)

Charging System Wiring Diagram (Celica). Scheme 10

Scheme 10: Charging System Wiring Diagram (Celica)

Charging System Wiring Diagram (Corolla). Scheme 11

Scheme 11: Charging System Wiring Diagram (Corolla)

Charging System Wiring Diagram (ECHO). Scheme 12

Scheme 12: Charging System Wiring Diagram (ECHO)

Charging System Wiring Diagram (Land Cruiser). Scheme 13

Scheme 13: Charging System Wiring Diagram (Land Cruiser)

Charging System Wiring Diagram (Lexus LX470). Scheme 14

Scheme 14: Charging System Wiring Diagram (Lexus LX470)

Charging System Wiring Diagram (MR2). Scheme 15

Scheme 15: Charging System Wiring Diagram (MR2)

Charging System Wiring Diagram (RAV4). Scheme 16

Scheme 16: Charging System Wiring Diagram (RAV4)

Charging System Wiring Diagram (Sienna). Scheme 17

Scheme 17: Charging System Wiring Diagram (Sienna)

Charging System Wiring Diagram (Tacoma). Scheme 18

Scheme 18: Charging System Wiring Diagram (Tacoma)

Charging System Wiring Diagram (Tundra). Scheme 19

Scheme 19: Charging System Wiring Diagram (Tundra)

Charging System Wiring Diagram (4Runner). Scheme 20
