Toyota C-HR I facelift (2019-2023) Cooling fan circuit

BLK WIRE BLU WIRE BRN WIRE CANH PNK CANL WIRE COMPUTER DATA LINES SYSTEM COOLING FAN ECU COOLING FAN MOTOR E.F.I. ENGINE COOLANT TEMPERATURE SENSOR ECU-B 3 FUSE EFI 2 FUSE ENGINE ROOM R/B 1 FAN 1 FUSE FAN RELAY 1 HOT AT ALL TIMES RED WIRE RFC TOP OF ENGINE) WHT WIRE WHT/BLK WIRE YEL WIRE
