SYSTEM DESCRIPTION

1. POWER MIRROR CONTROL SYSTEM DESCRIPTION This system has these functions: automatic glare-resistant electrochromic (EC) mirror, electrical remote control type mirror, memory function, foot light function, and rear window defogger-linked mirror defogger.
2. FUNCTION OF MAIN COMPONENT FUNCTION OF MAIN COMPONENT Components Function Vertical mirror motor Receives signal from memory mirror ECU and adjusts remote control mirror in the vertical direction. Horizontal mirror motor Receives signal from memory mirror ECU and adjusts remote control mirror in the horizontal direction. Mirror defogger Receives signal from defogger relay and starts mirror defogger. EC mirror cell Varies reflection rate of mirror through function of EC elements. Mirror control switch After selecting "R" or "L" switch, control switches change angle of mirror. Mirror signals are sent to memory mirror ECU through body ECU. Mirror master switch Consists of "R" and "L" switch. One must be chosen before mirror control switches can be operated. Mirror position sensor Detects remote control mirror position. This data is detested by memory mirror ECU. Set switch Memory switch When set switch and memory switches are pressed simultaneously, SET, 1 or 2 switch is input to body ECU and remote control mirror position is recorded. Then, when memory switch is pressed, 1 or 2 switch is input to memory mirror ECU and remote control mirror position changes according to memory.
3. SYSTEM OPERATION The remote control mirror has following features: REMOTE CONTROL MIRROR OPERATION CHART Function Outline Ignition switch-linked automatic electrical retractable mirror This function automatically retracts remote control mirrors when ignition switch is turned from ON to LOCK. This feature improves convenience of vehicle by eliminating need to manually operate mirror retract switch after stopping vehicle. Manual electrical retractable mirror This function retracts remote control mirrors when mirror retract switch is pressed. Electrical remote control type mirror When mirror control switch is operated, this function moves mirror surface vertically or laterally to enable driver to attain optimal mirror angle. Setting mirror master switch to "R" position operates right mirror, and to "L" position operates left mirror. Rear window defogger-linked mirror defogger This function automatically turns on mirror defogger when rear window defogger switch is turned on. After 15 minutes have elapsed from time this function has been activated, rear window defogger turns off automatically, and mirror defogger also turns off. Wiper-linked mirror defogger To improve rear visibility in the rain, this system automatically turns on mirror defogger when wiper switch is turned on. Automatic glare-resistant EC mirror This function helps to reduce glare/reflection in inner mirror during nighttime driving for safe driving conditions. Glare/reflection from vehicle headlights behind driver could blind driver and cause dangerous driving conditions. Memory function This function stores adjusted mirror position in driver and front passenger memory mirror ECU.

DESCRIPTION

When the memory mirror ECU receives the signal(s) from the certification ECU through BEAN communication, it illuminates the foot light. The foot light is installed on the bottom of the outer rear view mirror and comes on or does off according to the following conditions. The light comes on when

1. Doors are unlocked by wireless operation.
2. The key code ID (key code recognition signal) for smart key system matches.
3. The driver's door is manually unlocked with the shift lever is in the P position or the ignition off. (Both driver's and passenger's side come on.)

The light goes off when

1. Doors are locked by wireless operation.
2. Doors are locked by the smart key system.
3. The setting time has elapsed after the light come on.
4. The setting time has elapsed after the driver's or passenger's door is closed while the light is on.
5. The ignition is off and the shift lever is in any position other than P.
6. Doors are locked or unlocked by interlock operation or manual switch.

Scheme 1

Scheme 2

Scheme 3

1. READ VALUE OF TECHSTREAM Check the ACTIVE TEST for proper functioning of the seat memory switch. Mirror ACTIVE TEST - MIRROR Tester Display Test Part Control Range Diagnostic Note Side Mirror Foot Light Illumination operation On/Off - OK: Foot light comes on OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE NG: Go to next step
2. CHECK WIRE HARNESS (OUTER REAR VIEW MIRROR ASSEMBLY - MEMORY MIRROR ECU) LH: Disconnect the H2 and H8 connectors. Check the resistance of the wire harness side connectors. Standard resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition H8-12 - H2-2 (LP) Always Below 1 ohms H8-13 - Body ground H8-12 - Body ground 10 kohms or higher RH: Disconnect the G2 and G8 connectors. Check the resistance of the wire harness side connectors. Standard resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition G8-12 - G2-2 (LP) Always Below 1 ohms G8-13 - Body ground G8-12- Body ground 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

A switch signal of the outer mirror switch is transmitted to the selected outer mirror control ECU by way of the body ECU. Then, the memory mirror ECU activates the mirror motor to move the mirror UP, DOWN, RIGHT and LEFT in response to the inputs.

HINT

The power mirror control system is part of the multiplex communication system. This system features shared communication wiring that reduces the wiring complexity of the communication lines. The first step in any repair is to confirm the proper operation of the communication system. Proceed with troubleshooting after the communication has been verified (See MULTIPLEX COMMUNICATION SYSTEM ). WIRING DIAGRAM

Scheme 4

Scheme 5

Scheme 6

1. INSPECT OUTER MIRROR SWITCH ASSEMBLY Remove the outer mirror switch assembly. Measure the resistance between the wire harness connectors. Vertical and horizontal operation RESISTANCE SPECIFICATION Tester Connection Switch Position Specified Condition 2 - 3 OFF 10 kohms or higher UP 100 ohms DOWN 250 ohms LEFT 470 ohms RIGHT 800 ohms Left or right side operation RESISTANCE SPECIFICATION Tester Connection Switch Position Specified Condition 100 ohms 1 - 2 L - R 10 ohms or less NG: REPLACE OUTER MIRROR SWITCH ASSEMBLY OK: Go to next step
2. CHECK WIRE HARNESS (OUTER MIRROR SWITCH ASSEMBLY - INSTRUMENT PANEL J/ B) Disconnect the D4 and D7 connectors. Measure the resistance between the wire harness connectors. Standard resistance RESISTANCE SPECIFICATION Tester Connection Switch Position Specified Condition D4-1 (MSW) - D7-12 (MIRS) Always Below 1 ohms D4-2 (E) - D7-3 (MIRE) D4-3 (M+) - D7-11 (MIRB) D4-1 (MSW) - Body ground 10 kohms or higher D4-2 (E) - Body ground D4-3 (M+) - Body ground NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

A mirror control switch signal and memorized mirror positions are set to the memory mirror ECU. The memory mirror ECU drive the selected mirror UP, DOWN, LEFT and RIGHT in response to the inputs.

HINT

The power mirror control system is part of the large-scale multiplex communication system. This system features shared communication wiring that reduces the wiring complexity of the communication lines. The first step in any repair is to confirm the proper operation of the communication system. Proceed with troubleshooting after the communication has been verified (See MULTIPLEX COMMUNICATION SYSTEM ).

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. PERFORM ACTIVE TEST USING TECHSTREAM Select the ACTIVE TEST, use Techstream to generate a control command, and then check that the outer rear view mirrors. Mirror: ACTIVE TEST - MIRROR Tester Display Tester Details Control Range Diagnostic Note Mirror Up / Down Mirror vertical operation Up / Down - Mirror Right / Left Mirror horizontal operation Right / Left - OK: Mirror is UP / DOWN or RIGHT / LEFT NG: Go to step 2 OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
2. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH: Disconnect the H8 connector. Apply battery voltage and check operation of the mirror face. Standard MIRROR FACE OPERATION CHART Measurement Condition Mirror Operation Battery positive (+) --> H8-3 (MV) Battery negative (-) --> H8-2 (M+) Turns upward (A) Battery positive (+) --> H8-2 (M+) Battery negative (-) --> H8-3 (MV) Turns downward (B) Battery positive (+) --> H8-2 (M+) Battery negative (-) --> H8-1 (MH) Turns left (C) Battery positive (+) --> H8-1 (MH) Battery negative (-) --> H8-2 (M+) Turns right (D) If the result is not as specified, proceed to NG-A RH: Disconnect the G8 mirror connector. Apply battery voltage and check operation of the mirror face. Standard MIRROR FACE OPERATION CHART Measurement Condition Mirror Operation Battery positive (+) --> G8-3 (MV) Battery negative (-) --> G8-2 (M+) Turns upward (A) Battery positive (+) --> G8-2 (M+) Battery negative (-) --> G8-3 (MV) Turns downward (B) Battery positive (+) --> G8-2 (M+) Battery negative (-) --> G8-1 (MH) Turns left (C) Battery positive (+) --> G8-1 (MH) Battery negative (-) --> G8-2 (M+) Turns right (D) If the result is not as specified, proceed to NG-B NG-A : REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH NG-B : REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH OK: Go to next step
3. CHECK WIRE HARNESS (OUTER REAR VIEW MIRROR ASSEMBLY - MEMORY MIRROR ECU) LH: Disconnect the H2 and H8 connectors. Check the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition H8-1 (MH) - H2-9 (DMHR) Always Below 1 ohms H8-2 (M+) - H2-10 (DM+R) Always Below 1 ohms H8-3 (MV) - H2-1 (DMVR) Always Below 1 ohms H8-1 (MH) - Body ground Always 10 kohms or higher H8-2 (M+) - Body ground Always 10 kohms or higher H8-3 (MV) - Body ground Always 10 kohms or higher RH: Disconnect the G2 and G8 connectors. Check the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition G8-1 (MH) - G2-9 (PMHR) Always Below 1 ohms G8-2 (M+) - G2-10 (PM+R) Always Below 1 ohms G8-3 (MV) - G2-1 (PMVR) Always Below 1 ohms G8-1 (MH) - Body ground Always 10 kohms or higher G8-2 (M+) - Body ground Always 10 kohms or higher G8-3 (MV) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

When SET and 1 or 2 are pressed, the position sensor detects the mirror position and sends the signal to the memory mirror ECU. Then when position 1 or 2 is pressed, the memory mirror ECU drives the mirror motor based on the memorized sensor positions.

HINT

The power mirror control system is part of the multiplex communication system. This system features shared communication wiring that reduces the wiring complexity of the communication lines. The first step in any repair is to confirm the proper operation of the communication system. Proceed with troubleshooting after the communication has been verified (See MULTIPLEX COMMUNICATION SYSTEM ).

Scheme 12

Scheme 13

Scheme 14

1. READ VALUE OF TECHSTREAM Check the DATA LIST for proper functioning of the seat memory switch. Mirror: DATA LIST - MIRROR Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mir Position Sensor V Mirror position sensor voltage (Vertical direction) Within range from 0 to 5 V - Mir Position Sensor H Mirror position Sensor voltage (Horizontal direction) Within range from 0 to 5 V - OK: 0 to 5 V is displayed NG: Go to step 2 OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
2. CHECK WIRE HARNESS (OUTER REAR VIEW MIRROR ASSEMBLY - MEMORY MIRROR ECU) LH: Disconnect the H2 and H8 connectors. Check the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection (Symbols) Condition Specified Condition H8-8 (E1) - H2-14 (DE2) Always Below 1 ohms H8-9 (VC) - H2-5 (DVC) Always Below 1 ohms H8-10 (HSRL) - H2-13 (HSSR) Always Below 1 ohms H8-11 (VSRL) - H2-6 (VSSR) Always Below 1 ohms H8-8 (E1) - Body ground Always 10 kohms or higher H8-9 (VC) - Body ground Always 10 kohms or higher H8-10 (HSRL) - Body ground Always 10 kohms or higher H8-11 (VSRL) - Body ground Always 10 kohms or higher RH: Disconnect the G2 and G8 connectors. Check the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection (Symbols) Condition Specified Condition G8-8 (E1) - G2-14 (PE2) Always r Below 1 ohms G8-9 (VC) - G2-5 (PVC) Always Below 1 ohms G8-10 (HSSR) - G2-13 (HSSR) Always Below 1 ohms G8-11 (VSSR) - G2-6 (VSSR) Always Below 1 ohms G8-8 (E1) - Body ground Always 10 kohms or higher G8-9 (VC) - Body ground Always 10 kohms or higher G8-10 (HSSR) -Body ground Always 10 kohms or higher G8-11 (VSSR) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This is the power source circuit for the memory mirror ECU.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. CHECK MEMORY MIRROR ECU (POWER SOURCE) LH: Disconnect the H1 connector. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition H1-1 (GND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition H1-3 (SIG) - Body ground Ignition switch OFF --> ON 0 V --> 10 to 14 V VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition H1-4 (CPUB) - Body ground Constant 10 to 14 V H1-6 (BDR) - Body ground Constant 10 to 14 V RH: Disconnect the G1 connector. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition G1-1 (GND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition G1-3 (SIG) - Body ground Ignition switch OFF --> ON 0 V --> 10 to 14 V G1-4 (CPUB) - Body ground Constant 10 to 14 V G1-6 (BDR) - Body ground Constant 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
