Multiplex Communication: Overview Toyota Avalon XX30 рестайлинг

DESCRIPTION

This DTC is detected when communication between the body ECU and the gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 1

Scheme 2

Scheme 3

1. CHECK HARNESS AND CONNECTOR (BODY ECU - BATTERY AND BODY GROUND) Disconnect the IA and IF ECU connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition IA-1 (BATB) - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition IF-10 (GND1) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the D6, D13 and E2 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition IR-9 (MPX1) - E2-16 Always Below 1 ohms D6-21 (MPX2) - D13-6 (MPX1) Below 1 ohms Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE BODY ECU AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE BODY ECU

This DTC is detected when communication between the certification ECU and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 4

Scheme 5

Scheme 6

1. CHECK HARNESS AND CONNECTOR (CERTIFICATION ECU - BATTERY AND BODY GROUND) Disconnect the D39 ECU connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition D39-1 (+B1) - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D39-17 (E) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the D13, D39 and D44 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D39-27 (MPX1) - D13-7 (MPX2) Always Below 1 ohms D39-28 (MPX2) - D44-7 (MPX1) Below 1 ohms Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE CERTIFICATION ECU AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE CERTIFICATION ECU

This DTC is detected when communication between the passenger side outer mirror ECU (memory mirror ECU) and gateway ECU stops for more than 10 seconds.

DTC DETECTING CONDITION AND TROUBLE AREA

Scheme 7

Scheme 8

Scheme 9

1. CHECK HARNESS AND CONNECTOR (MEMORY MIRROR ECU - BATTERY AND BODY GROUND) Disconnect the G1 ECU connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Connection G1-4 (CPUB) - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Connection G1-1 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the G1 and E2 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Connection G1-8 (MPX1) - E2-16 Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : REPLACE MEMORY MIRROR ECU

This DTC is detected when communication between the driver side outer mirror ECU (memory mirror ECU) and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 10

Scheme 11

Scheme 12

1. CHECK HARNESS AND CONNECTOR (MEMORY MIRROR ECU - BATTERY AND BODY GROUND) Disconnect the H1 ECU connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Connection H1-4 (CPUB) - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Connection H1-1 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the H1 and E2 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Connection H1-8 (MPX1) - E2-16 Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : REPLACE MEMORY MIRROR ECU

This DTC is detected when communication between the power source control ECU and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 13

Scheme 14

Scheme 15

1. CHECK HARNESS AND CONNECTOR (POWER SOURCE CONTROL ECU - BATTERY AND BODY GROUND) Disconnect the D44 ECU connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition D44-33 (AM1) - Body ground Always 10 to 14 V D44-12 (AM2) - Body ground 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D44-6 (GND2) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the D44, D37 and D39 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D44-7 (MPX1) - D39-28 (MPX2) Always Below 1 ohms D44-24 (MPX2) - D37-30 (MPX+) Below 1 ohms Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE POWER SOURCE CONTROL ECU AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE POWER SOURCE CONTROL ECU

DTC B1214 is detected when the door system communication circuit and +B battery are shorted. DTC B1215 is detected when the communication circuit and body ground are shorted. When this condition is detected, the door system communication bus (BEAN) will be disabled and some diagnosis codes will be output.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. CHECK DIAGNOSTIC TROUBLE CODE (A ECU) Disconnect the A ECU connector and check for DTCs B1214 and B1215. OK: Neither DTC B1214 nor DTC B1215 is output. NOTE: Disconnect the connectors one by one. Reconnect the connectors before starting the next check. HINT: The A ECU represents the A/C ECU. If any of the stated DTCs are not output, the disconnected A ECU (A/C ECU) is malfunctioning. NG: Go to step 2 OK : REPLACE A ECU
2. CHECK DIAGNOSTIC TROUBLE CODE (B ECU) Disconnect the A ECU and B ECU connectors and check for DTCs B1214 and B1215. OK: Neither DTC B1214 nor DTC B1215 is output. NOTE: Disconnect the connectors one by one. Reconnect the connectors before starting the next check. HINT: Remove the B ECUs in the following order: Power source ECU Certification ECU Combination switch ECU Body ECU Option connector Front controller Rain sensor Front controller Power seat ECU Memory mirror ECU (LH) Memory mirror ECU (RH) If any of the stated DTCs are not output, the disconnected B ECU (one of the ECUs from the above list) or the wire harness between the A ECU and B ECU is malfunctioning. After the DTC is cleared, proceed to the next step. NG: Go to step 4 OK: Go to next step.
3. CHECK WIRE HARNESS BETWEEN A ECU AND B ECU Connect the A ECU connector. Disconnect the B ECU connectors and check for DTCs B1214 and B1215. OK: Neither DTC B1214 nor DTC B1215 is output. NOTE: Disconnect the connectors one by one. Reconnect the connectors before starting the next check. HINT: If any of the stated DTCs are not output, the wire harness between the A ECU and B ECU is functioning normally but the disconnected B ECU is malfunctioning. NG: REPAIR OR REPLACE WIRE HARNESS BETWEEN A ECU AND B ECU OK : REPLACE B ECU
4. CHECK DIAGNOSTIC TROUBLE CODE (C ECU) Connect the A ECU connector. Disconnect the B ECU and C ECU connectors and check for DTCs B1214 and B1215. OK: Neither DTC B1214 nor DTC B1215 is output. NOTE: Disconnect the connectors one by one. Reconnect the connectors before starting the next check. HINT: The C ECU represents the combination meter ECU. If any of the stated DTCs are not output, the disconnected C ECU (combination meter ECU) or the wire harness between the B ECU and C ECU is malfunctioning. NG: Go to step 6 OK: Go to next step.
5. CHECK WIRE HARNESS BETWEEN B ECU AND C ECU Connect the B ECU connector. Disconnect the C ECU connector and check for DTCs B1214 and B1215. OK: Neither DTC B1214 nor DTC B1215 is output. NOTE: Disconnect the connectors one by one. Reconnect the connectors before starting the next check. HINT: If any of the stated DTCs are not output, the wire harness between the B ECU and C ECU is functioning normally but the disconnected C ECU is malfunctioning. NG: REPAIR OR REPLACE WIRE HARNESS BETWEEN B ECU AND C ECU OK : REPLACE C ECU
6. CHECK WIRE HARNESS BETWEEN GATEWAY ECU AND A ECU OR C ECU Check for a short-circuit in B+ or body ground. Disconnect the A ECU, C ECU and gateway ECU connectors. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition A ECU connector / gateway ECU connector - Body ground Always 0 V C ECU connector / gateway ECU connector - Body ground 0 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition A ECU connector / gateway ECU connector - Body ground Always 10 kohms or higher C ECU connector / gateway ECU connector - Body ground 10 kohms or higher HINT: The A ECU represents the A/C ECU. The C ECU represents the combination meter ECU. NG: REPAIR OR REPLACE WIRE HARNESS BETWEEN GATEWAY ECU AND A ECU OR C ECU OK : REPLACE MULTIPLEX NETWORK GATEWAY ECU

This DTC is indicated when open or ground short of the GSW terminal is detected.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 23

This DTC is detected when communication between the AVC-LAN (radio receiver assembly or multi-display assembly) and multiplex network gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

This DTC is detected when communication between the A/C control (A/C ECU) and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 24

Scheme 25

Scheme 26

1. CHECK HARNESS AND CONNECTOR (A/C ECU - BATTERY AND BODY GROUND) Disconnect the D37 ECU connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition D37-21 (IG+) - Body ground Ignition switch off --> on (IG) 0 V --> 10 to 14 V D37-1 (B) - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D37-20 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the D37, E23, and D44 *1 or D13 *2 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D37-30 (MPX+) - D44-24 (MPX2) *1 Always Below 1 ohms D37-30 (MPX+) - D13-7 (MPX2) *2 Below 1 ohms D37-31 (MPX-) - E23-3 (MPD1) Below 1 ohms HINT: *1 : w/ Smart key system *2 : w/o Smart key system Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE A/C ECU AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE A/C ECU

This DTC is detected when communication between the combination meter (combination meter ECU) and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 27

Scheme 28

Scheme 29

1. CHECK WIRE HARNESS (COMBINATION METER ECU - BATTERY AND BODY GROUND) Disconnect the E2 meter connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition E2-1 - Body ground Always 10 to 14 V E2-2 - Body ground 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition E2-10 - Body ground Always Below 1 ohms E2-12 - Body ground Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the E2, E23 and 1G ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Condition Condition Specified Condition E2-4 - E23-12 (MPD2) Always Below 1 ohms E2-16 - IG-7 Below 1 ohms Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE COMBINATION METER ECU AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE COMBINATION METER ECU

This DTC is detected when communication between the power seat ECU and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 30

Scheme 31

Scheme 32

1. CHECK HARNESS AND CONNECTOR (POWER SEAT ECU - BATTERY AND BODY GROUND) Disconnect the P13 and P14 ECU connectors. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition P13-8 (SYSB) - Body ground Always 10 to 14 V P14-5 (+B) - Body ground 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition P14-1 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the P13 and G1 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition P13-1 (MPX1) - G1-8 (MPX1) Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : REPLACE POWER SEAT ECU

This DTC is detected when communication between the BEAN bus buffer and the gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 33

Scheme 34

1. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the D16, D7 and IR connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D16-1 (MPX+) - IR-9 Always Below 1 ohms D16-2 (GBSI) - D7-14 (GBS) Below 1 ohms Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE OPTION CONNECTOR AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE OPTION CONNECTOR

This DTC is detected when communication between the combination switch (combination switch ECU) and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 35

Scheme 36

Scheme 37

1. CHECK HARNESS AND CONNECTOR (COMBINATION SWITCH - BATTERY AND BODY GROUND) Disconnect the D13 combination switch connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition D13-1 (B) - Body ground Always 10 to 14 V D13-2 (IG) - Body ground Ignition switch off --> on (IG) 0 V --> 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D13-5 (E) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the D13, D6, and D39 *1 or D37 *2 ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition D13-6 (MPX1) - D6-21 (MPX2) Always Below 1 ohms D13-7 (MPX2) - D39-27 (MPX1) *1 Below 1 ohms D13-7 (MPX2) - D37-30 (MPX+) *2 Below 1 ohms HINT: *1 : w/ Smart key system *2 : w/o Smart key system Result RESULT REFERENCE Result Proceed to Both are OK A One is OK B Both are NG C B : REPLACE COMBINATION SWITCH AND REPAIR OR REPLACE HARNESS OR CONNECTOR C : REPAIR OR REPLACE HARNESS OR CONNECTOR A : REPLACE COMBINATION SWITCH

This DTC is detected when communication between the rain sensor and overhead J/B stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 38

Scheme 39

Scheme 40

1. CHECK WIRE HARNESS (RAIN SENSOR - BATTERY AND BODY GROUND) Disconnect the N3 sensor connector. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition N3-1 (SIG) - Body ground Ignition Switch On (IG) 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition N3-3 (ES) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the N3 and IR ECU connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition N3-2 (MPX) - IR-9 Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : REPLACE RAIN SENSOR

This DTC is detected when communication between the front controller and gateway ECU stops for more than 10 seconds.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 41

Scheme 42

Scheme 43

1. CHECK HARNESS AND CONNECTOR (FRONT CONTROLLER - BATTERY AND BODY GROUND) Disconnect the 1F and 1H front controller connectors. Measure the voltage according to the value(s) in the table below. Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition 1F-1 (+B) - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition 1H-2 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. CHECK RESISTANCE OF COMMUNICATION LINE Disconnect the 1G, IF, and E2 connectors. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition 1G-7 (MPX) - E2-16 Always Below 1 ohms 1G-8 (MPX) - IR-9 (MPX1) Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : REPLACE FRONT CONTROLLER
