Windshield/windowglass: Removal & Installation Toyota Avalon XX30

Windows 29 illustrations ~2419 words

REMOVAL

HINT

However, only installation procedures requiring additional information are included.

Scheme 46

Scheme 46: REMOVAL
Scheme 46: REMOVAL

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See step 1 under «REMOVAL»(ref-245153-S04475275442006102300000) )
  2. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See step 2 under «REMOVAL»(ref-245153-S04475275442006102300000) )
  3. REMOVE COWL TOP VENTILATOR LOUVER RH (See step 3 under «REMOVAL»(ref-245153-S04475275442006102300000) )
  4. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  5. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  6. REMOVE FRONT PILLAR GARNISH LH (See step 43 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  7. REMOVE FRONT PILLAR GARNISH RH (See step 44 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  8. REMOVE ASSIST GRIP SUB-ASSEMBLY FRONT (See step 45 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  9. REMOVE ASSIST GRIP SUB-ASSEMBLY (See step 46 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  10. REMOVE VISOR BRACKET COVER (See step 47 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  11. REMOVE LH VISOR ASSEMBLY (See step 48 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  12. REMOVE RH VISOR ASSEMBLY (See step 49 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  13. REMOVE ROOF CONSOLE BOX ASSEMBLY (See step 50 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  14. REMOVE VISOR HOLDER (See step 52 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  15. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (See step 1 under «REMOVAL»(ref-245162-S05884820902006102300000) )
  16. REMOVE RAIN SENSOR COVER (See step 1 under «REMOVAL»(ref-245153-S13239175372006102400000) )
  17. REMOVE RAIN SENSOR (See step 2 under «REMOVAL»(ref-245153-S13239175372006102400000) )
  18. REMOVE SUN ROOF OPENING TRIM MOULDING (w/Sliding Roof) (See step 56 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  19. REMOVE ROOF HEADLINING ASSEMBLY (See step 57 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  20. REMOVE WINDSHIELD MOULDING OUTER UPPER Using a knife, cut off the moulding (Scheme 46) NOTE: Be careful not to damage the vehicle body with the knife. Remove the remaining moulding. HINT: Partially cut the moulding. Then pull and remove it by hand.
  21. REMOVE WINDSHIELD GLASS From the interior, insert piano wires between the vehicle body and glass (Scheme 47) Tie objects that can serve as handles to all wire ends. HINT: Apply protective tape to the outer surface of the vehicle body to prevent its surface from being scratched. NOTE: w/ Curtain shield airbag: When working around the curtain shield airbag, be careful not to damage the airbag. When separating the glass from the vehicle, be careful not to damage the vehicle's paint or interior/exterior ornaments. To prevent the safety pad from being scratched when removing the glass, place a plastic sheet between the piano wire and safety pad. Cut through the adhesive by pulling the piano wire around the glass. Disengage the stoppers. HINT: In some cases, both 1-piece type and 2-piece type stoppers are installed in the same vehicle. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
  22. CLEAN WINDSHIELD GLASS Using a scraper, remove the damaged stoppers, the damaged any adhesive remaining the glass. Clean the outer circumference on of the glass with white gasoline. NOTE: Do not tough the glass after cleaning it. Even if using new glass, clean the glass with white gasoline.
  23. CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure a proper fit. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a shop rag or piece of cloth saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 52

Scheme 52: INSTALLATION
Scheme 52: INSTALLATION

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60
  1. INSTALL WINDSHIELD GLASS STOPPER NO. 2 Coat the installation part of the stopper with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much Primer G. Install 2 new stoppers onto the glass (Scheme 52) Specification WINDSHIELD GLASS AREA MEASUREMENT Area Measurement A 7.7 mm (0.303 in.) B 40.0 mm (1.575 in.)
  2. INSTALL WINDSHIELD GLASS STOPPER NO. 1 Install 2 new stoppers to the vehicle body (Scheme 53)
  3. INSTALL WINDSHIELD GLASS RETAINER Install 2 new retainers onto the glass (Scheme 54)
  4. INSTALL WINDOW GLASS ADHESIVE DAM Coat the installation part of the windshield glass adhesive dam with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much primer. Install a new dam (Scheme 55) Specification WINDOW GLASS AREA MEASUREMENT Area Measurement a 7.0 mm (0.276 in.) b 48.4 mm (1.905 in.)
  5. INSTALL WINDSHIELD GLASS Position the glass. Using the suction cup, place the glass in the correct position. Check that the whole contact surface of the glass rim is perfectly even. Place reference marks on the glass and vehicle body. NOTE: Check that the stoppers are attached to the vehicle body correctly. HINT: When reusing the glass, check and correct the reference mark positions. Using a suction cup, remove the glass. Using a brush, coat the exposed areas of the vehicle body, where all adhesive has been removed with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer M. Do not apply too much Primer M. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer M. HINT: If a non-specified area is coated by accident, wipe off the primer with a clean piece of cloth before it dries. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of away any excess Primer M. Do not apply too much Primer M. Apply adhesive. Adhesive: Part No. 00850-00801 or equivalent Cut off the tip of the cartridge nozzle (Scheme 58) HINT: After cutting off the tip, use adhesive within the time described in «USAGE TIME FRAME REFERENCE»(ref-245161-S16785748752006102400000). Usage time frame USAGE TIME FRAME REFERENCE Temperature Usage time frame 35°C(95°F) 15 minutes 20°C(68°F) 1 hour 40 minutes 5°C(41°F) 8 hour Load a sealer gun with the cartridge. Coat the glass with adhesive (Scheme 58) Specification WINDSHIELD GLASS AREA MEASUREMENT Area Measurement a 8.0 mm (0.315 in.) b 12.0 mm (0.472 in.) Install the glass. Using a suction cup, position the glass so that the reference marks are aligned. Press it in gently along the rim. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the stoppers are attached to the vehicle body correctly. Check that there is a small gap between the vehicle body and glass. Lightly press the front surface of the glass to ensure that the glass is securely fit to the vehicle body. Using a scraper, remove any excess or protruding adhesive (Procedure A). HINT: Make sure that adhesive is applied up to the glass rim. NOTE: The vehicle should not be driven until the time indicated in «TEMPERATURE AND MINIMUM TIME DESCRIPTION»(ref-245161-S42559956982006102400000) has elapsed after procedure A. Minimum time TEMPERATURE AND MINIMUM TIME DESCRIPTION Temperature Minimum time prior to driving vehicle 35°C(95°F) 1 hour 30 minutes 20°C(68°F) 5 hours 5°C(41°F) 24 hours
  6. INSTALL WINDSHIELD MOULDING OUTER UPPER Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of away any excess Primer G. Do not apply too much Primer G. Install the moulding.
  7. INSPECT FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with out glass sealer.
  8. INSTALL ROOF HEADLINING ASSEMBLY
  9. INSTALL SUN ROOF OPENING TRIM MOULDING
  10. INSTALL RAIN SENSOR
  11. INSTALL RAIN SENSOR COVER
  12. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER
  13. INSTALL VISOR HOLDER
  14. INSTALL ROOF CONSOLE BOX ASSEMBLY
  15. INSTALL RH VISOR ASSEMBLY
  16. INSTALL LH VISOR ASSEMBLY
  17. INSTALL VISOR BRACKET COVER
  18. INSTALL ASSIST GRIP SUB-ASSEMBLY
  19. INSTALL ASSIST GRIP SUB-ASSEMBLY FRONT
  20. INSTALL FRONT PILLAR GARNISH RH (See step 2 under «INSTALLATION»(ref-245167-S31265216022006102300000) )
  21. INSTALL FRONT PILLAR GARNISH LH (See step 1 under «INSTALLATION»(ref-245167-S31265216022006102300000) )
  22. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  23. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  24. INSTALL COWL TOP VENTILATOR LOUVER RH
  25. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH
  26. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH

Scheme 61

Scheme 61: COMPONENTS
Scheme 61: COMPONENTS

HINT

However, only installation procedures requiring additional information are included.

Scheme 62

Scheme 62: REMOVAL
Scheme 62: REMOVAL

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67
  1. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
  2. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  3. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH (See step 37 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  4. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH (See step 38 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  5. REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (See step 15 under «REMOVAL»(ref-245148-S35211472902006102400000) )
  6. REMOVE ASSIST GRIP SUB-ASSEMBLY
  7. REMOVE REAR ROOM LIGHT ASSEMBLY (See step 51 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  8. REMOVE ROOF HEADLINING ASSEMBLY (See step 57 under «REMOVAL»(ref-245167-S40203717262006102300000) )
  9. REMOVE BACK WINDOW MOULDING OUTSIDE UPPER Using a knife, cut off the moulding (Scheme 62) NOTE: Be careful not to damage the vehicle body with the knife. Remove the remaining moulding. HINT: Partially cut the moulding. Then pull and remove it by hand.
  10. REMOVE BACK WINDOW GLASS From the interior, insert piano wires between the vehicle body and glass (Scheme 63) Tie wooden blocks or other objects that can serve as handles to all wire ends. HINT: Apply protective tape to the outer surface of the vehicle body to prevent its surface from being scratched. NOTE: When separating the grass from the vehicle, be careful not to damage the vehicle's paint or interior/exterior ornaments. Cut through the adhesive by pulling the piano wire around the glass. Disengage the stoppers. HINT: In some cases, both 1-piece type and 2-piece type stoppers are installed in the same vehicle. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
  11. CLEAN BACK WINDOW GLASS Using a scraper, remove the damaged stoppers the dam and any adhesive remaining on the glass. Clean the outer circumference of the glass with white gasoline. NOTE: Do not tough the glass after cleaning it. Even if using new glass, clean the glass with white gasoline.
  12. CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure a proper fit. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of a shop rag or piece of cloth saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 68

Scheme 68: INSTALLATION
Scheme 68: INSTALLATION

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74
  1. INSTALL BACK WINDOW GLASS STOPPER NO. 2 Coat the installation part of the stopper with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much Primer G. Install 2 new stoppers to the glass (Scheme 68) Specification BACK WINDOW GLASS AREA MEASUREMENT Area Measurement A 12.5 mm (0.492 in.) B 50.0 mm (1.968 in.)
  2. INSTALL BACK WINDOW GLASS STOPPER NO. 1 Install 2 new stoppers to the vehicle body (Scheme 69)
  3. INSTALL BACK WINDOW MOULDING OUTSIDE UPPER Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much Primer G. Install the moulding.
  4. INSTALL BACK WINDOW GLASS Position the glass. Using a suction cup, place the glass in the correct position. Check that the whole contact surface of the glass rim perfectly even. Place reference marks on the glass and vehicle body. NOTE: Check that the stoppers are attached to the vehicle body correctly. HINT: When reusing the glass, check and correct the reference mark positions. Using a suction cup, remove the glass. Using a brush, coat the exposed areas of the vehicle body, where all adhesive has been removed with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the area adhesive is still remaining with Primer M. Dispose of any excess Primer M. Do not apply too much Primer M. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer M. HINT: If a non-specified area is coated by accident, wipe off the primer with a clean a piece of cloth before it dries out. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer M. Do not apply too much Primer M. Apply adhesive. Adhesive: Part No. 08850-00801 or equivalent Cut off the tip of the cartridge nozzle (Scheme 72) HINT: After cutting off the tip, use adhesive within the time described in «USAGE TIME FRAME REFERENCE»(ref-245161-S11972129712006102400000). Usage time frame USAGE TIME FRAME REFERENCE Temperature Usage time frame 35°C(95°F) 15 minutes 20°C(68°F) 1 hour 40 minutes 5°C(41°F) 8 hours Load a sealer gun with the cartridge. Coat the glass with adhesive (Scheme 72) Specification GLASS AREA MEASUREMENT Area Measurement a 8.0 mm (0.315 in.) b 12.0 mm (0.472 in.) c 7.0 mm (0.275 in.) Install the glass. Using a suction cup, position the glass so that the reference marks are aligned. Press it in gently along the rim. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the stoppers are attached to the vehicle body correctly. Check that there is a small gap between the vehicle body and glass. Lightly press the front surface of the glass to ensure that the glass is securely fit to the vehicle body. Using a scraper, remove any excess adhesive. HINT: Make sure that adhesive is applied up to the glass rim. NOTE: The vehicle should not be driven until the time indicated in «TEMPERATURE AND MINIMUM TIME DESCRIPTION»(ref-245161-S39545709582006102400000) has elapsed after applying adhesive. Minimum time TEMPERATURE AND MINIMUM TIME DESCRIPTION Temperature Minimum time prior to driving vehicle 35°C(95°F) 1 hour 30 minutes 20°C(68°F) 5 hours 5°C(41°F) 24 hours
  5. INSPECT FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
  6. INSTALL ROOF HEADLINING ASSY
  7. INSTALL REAR ROOM LIGHT ASSEMBLY
  8. INSTALL ASSIST GRIP SUB-ASSEMBLY
  9. INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY
  10. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH (See «INSTALLATION»(ref-245167-S31265216022006102300000) )
  11. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (See «INSTALLATION»(ref-245167-S31265216022006102300000) )
  12. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
  13. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
