Air Conditioning: Removal & Installation Toyota Avalon XX30

REMOVAL

HINT

1. Installation is in the reverse order of removal.
2. COMPONENTS for instrument panel safety pad sub-assembly: See «COMPONENTS»(ref-245163-S41870318212006102300000) .

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

1. DISCONNECT BATTERY NEGATIVE TERMINAL Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
2. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-245153-S04475275442006102300000) )
3. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-245153-S04475275442006102300000) )
4. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-245153-S04475275442006102300000) )
5. REMOVE WINDSHIELD WIPER MOTOR AND LINK (See «REMOVAL»(ref-245153-S04475275442006102300000) )
6. REMOVE COWL TOP OUTSIDE PANEL FRONT Remove the 4 bolts, 2 nuts and cowl top outside panel front.
7. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
8. DISCONNECT SUCTION HOSE SUB-ASSEMBLY Remove the bolt, and slide the hook connector. Disconnect the suction hose sub-assembly. Remove the O-ring from the suction hose sub-assembly. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering.
9. DISCONNECT AIR CONDITIONER TUBE AND ACCESSORY Disconnect the air conditioner tube & accessory. Remove the O-ring from the air conditioner tube & accessory. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering.
10. DISCONNECT HEATER WATER OUTLET HOSE A(FROM HEATER UNIT) Slide the clip and disconnect the heater water outlet hose A. NOTE: Do not apply excessive force to the heater water outlet hose A. Prepare a drain pan or cloth in case the cooling water leaks.
11. DISCONNECT HEATER WATER INLET HOSE A Slide the clip and disconnect the heater water inlet hose A. NOTE: Do not apply excessive force to the heater water inlet hose A. Prepare a drain pan or cloth in case the cooling water leaks.
12. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY «REMOVAL»(ref-245163-S09561694362006102300000) HINT: Refer to the removal procedures for the instrument panel safety pad sub-assembly w/ front passenger airbag assembly.
13. REMOVE HEATER TO REGISTER DUCT NO.2 Remove the 3 clips and heater to register duct No.2.
14. REMOVE HEATER TO REGISTER DUCT ASSEMBLY NO.6 Disengage the 4 claws and then remove the heater to register duct No.6.
15. REMOVE CONSOLE BOX DUCT NO.1 Remove the clip and console box duct No.1.
16. REMOVE FLOOR CARPET BRACKET LH Release the 2 clamps. Turn back the floor carpet. Remove the 3 clips. Remove the floor carpet bracket LH.
17. REMOVE FLOOR CARPET BRACKET RH Release the 3 clamps. Turn back the floor carpet. Remove the 3 clips. Remove the floor carpet bracket RH.
18. REMOVE AIR DUCT REAR NO.2 Release the 2 claws and remove the air duct rear No.2.
19. REMOVE AIR DUCT REAR NO.1 Release the 2 claws and remove the air duct rear No.1.
20. REMOVE AIR DUCT SUB-ASSEMBLY NO.1 (See «REMOVAL»(ref-245144-S27063350802006102300000) )
21. SEPARATE STEERING INTERMEDIATE SHAFT ASSEMBLY (See «REMOVAL»(ref-245144-S27063350802006102300000) )
22. REMOVE STEERING COLUMN ASSEMBLY (See «REMOVAL»(ref-245144-S27063350802006102300000) )
23. REMOVE INSTRUMENT PANEL REINFORCEMENT ASSEMBLY Disconnect each connector and remove each clamp. Disconnect the wire harness. Remove the 6 nuts and 3 bolts. Remove the 3 bolts and nut. Using a "Torx" socket wrench (T40), remove the 5 "Torx" bolts. HINT: The "Torx" bolts on the passenger side can be removed with the collar or for adjustment. Using a hexagon wrench 12 mm, remove the 2 collars and instrument panel reinforcement assembly with the air conditioner unit assembly. Remove the 3 bolts, 2 screws and instrument panel reinforcement assembly.

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

1. REMOVE AIR DUCT SUB-ASSEMBLY NO.2 Release the 2 claws and remove the air duct sub-assembly No.2 (Scheme 206)
2. REMOVE BLOWER ASSEMBLY (See «REMOVAL»(ref-245146-S26469688552006102400000) )
3. REMOVE AIR OUTLET CONTROL SERVO MOTOR Disconnect the 2 connectors and remove the air conditioner harness. Remove the 3 screws and then the air outlet control servo motor.
4. REMOVE AIR MIX CONTROL SERVO MOTOR Remove the 2 screws and air mix control servo motor.
5. REMOVE HEATER RADIATOR UNIT SUB-ASSEMBLY Remove the screw and clamp. Release the 4 claws and remove the clamp. Remove the heater radiator unit sub-assembly from the air conditioning radiator assembly. NOTE: Prepare a drain pan or cloth in case the cooling water leaks.
6. REMOVE COOLER AIR HOSE Remove the cooler air hose with the cooler (room temp. sensor) thermistor. Remove the cooler air hose with the cooler (room temp. sensor) thermistor.
7. REMOVE ASPIRATOR Disengage the 2 claws and then remove the aspirator.

HINT

1. Installation is in the reverse order of removal.
2. COMPONENTS for instrument panel safety pad sub-assembly: See «COMPONENTS»(ref-245163-S41870318212006102300000) .

Scheme 219

Scheme 220

1. DISCONNECT BATTERY NEGATIVE TERMINAL Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
2. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-245153-S04475275442006102300000) )
3. REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-245153-S04475275442006102300000) )
4. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-245153-S04475275442006102300000) )
5. REMOVE WINDSHIELD WIPER MOTOR AND LINK (See «REMOVAL»(ref-245153-S04475275442006102300000) )
6. REMOVE COWL VENTILATOR PANEL SUB-ASSEMBLY HINT: See «REMOVAL»(ref-245146-S29676953412006102400000)
7. DISCHARGE FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
8. DISCONNECT SUCTION HOSE SUB-ASSEMBLY (See «REMOVAL»(ref-245146-S29676953412006102400000) )
9. DISCONNECT AIR CONDITIONER TUBE AND ACCESSORY (See «REMOVAL»(ref-245146-S29676953412006102400000) )
10. DISCONNECT HEATER WATER OUTLET HOSE A(FROM HEATER UNIT) (See «REMOVAL»(ref-245146-S29676953412006102400000) )
11. DISCONNECT HEATER WATER INLET HOSE A (See «REMOVAL»(ref-245146-S29676953412006102400000) )
12. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «REMOVAL»(ref-245163-S09561694362006102300000) )
13. REMOVE AIR DUCT SUB-ASSEMBLY NO.1 (See «REMOVAL»(ref-245144-S27063350802006102300000) )
14. SEPARATE STEERING INTERMEDIATE SHAFT ASSEMBLY (See «REMOVAL»(ref-245144-S27063350802006102300000) )
15. REMOVE STEERING COLUMN ASSEMBLY (See «REMOVAL»(ref-245144-S27063350802006102300000) )
16. REMOVE HEATER TO REGISTER DUCT NO.2 (See «REMOVAL»(ref-245146-S29676953412006102400000) )
17. REMOVE HEATER TO REGISTER DUCT ASSEMBLY NO.6 (See «REMOVAL»(ref-245146-S29676953412006102400000) )
18. REMOVE CONSOLE BOX DUCT NO.1 (See «REMOVAL»(ref-245146-S29676953412006102400000) )
19. REMOVE FLOOR CARPET BRACKET LH (See «REMOVAL»(ref-245146-S29676953412006102400000) )
20. REMOVE FLOOR CARPET BRACKET RH (See «REMOVAL»(ref-245146-S29676953412006102400000) )
21. REMOVE INSTRUMENT PANEL REINFORCEMENT ASSEMBLY (See «REMOVAL»(ref-245146-S29676953412006102400000) )
22. REMOVE AIR DUCT SUB-ASSEMBLY NO.2 (See «REMOVAL»(ref-245146-S29676953412006102400000) )
23. REMOVE BLOWER ASSEMBLY Remove the connector and clamp, and disconnect the wire harness. Remove the 6 screws and then the blower assembly with the cooler evaporator sub-assembly.

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

1. REMOVE EVAPORATOR TEMPERATURE SENSOR Remove the clamp and evaporator temperature sensor.
2. REMOVE COOLER EXPANSION VALVE Using a hexagon wrench 4 mm, remove the 2 hexagon bolts and cooler expansion valve.
3. REMOVE COOLER EVAPORATOR SUB-ASSEMBLY NO.1 Remove the cooler evaporator sub-assembly No.1. Remove the 2 O-rings from the cooler evaporator sub-assembly No.1.
4. REMOVE AIR FILTER COVER PLATE Release the 2 claws and remove the air filter cover plate.
5. REMOVE CLEAN AIR FILTER Remove the clean air filter.
6. REMOVE AIR INLET SERVO MOTOR Remove the 3 screws and air inlet servo motor.
7. REMOVE AIR DUCT SUB-ASSEMBLY NO.3 Disengage the 4 claws and then remove the air duct sub-assembly No.3.
8. REMOVE COOLING UNIT MOTOR SUB-ASSEMBLY Remove the 3 screws and cooling unit motor sub-assembly w/ fan.

Scheme 230

Scheme 231

Scheme 232

Scheme 233

1. INSTALL COOLER EVAPORATOR SUB-ASSEMBLY NO.1 sufficiently apply compressor oil (ND-OIL 8) to 2 new O-rings and the fitting surface. Install the 2 O-rings to the cooler evaporator No.1. Compressor oil: ND-OIL 8 or equivalent
2. INSTALL COOLER EXPANSION VALVE Using a hexagon wrench 4 mm, install the cooler expansion valve with the 2 hexagon bolts. Torque: 3.5 N*m (35 kgf*cm, 30 in.*lbf)
3. INSTALL EVAPORATOR TEMPERATURE SENSOR If using a mew evaporator: Install the sensor to the evaporator (Scheme 227) If reusing the evaporator: Install the sensor to the evaporator (Scheme 228) HINT: Completely cover the tube with the grommet.

Scheme 234

1. INSTALL BLOWER ASSEMBLY Install the blower assembly with the 6 screws.
2. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY (See «REASSEMBLY»(ref-245146-S22158343762006102400000) )
3. CONNECT STEERING INTERMEDIATE SHAFT ASSEMBLY (See «INSTALLATION»(ref-245144-S41914922932006102300000) )
4. INSTALL STEERING COLUMN ASSEMBLY (See «INSTALLATION»(ref-245144-S41914922932006102300000) )
5. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY (See «INSTALLATION»(ref-245163-S18152781032006102300000) )
6. INSTALL AIR CONDITIONER TUBE AND ACCESSORY (See «REASSEMBLY»(ref-245146-S22158343762006102400000) )
7. INSTALL SUCTION HOSE SUB-ASSEMBLY (See «REASSEMBLY»(ref-245146-S22158343762006102400000) )
8. CONNECT BATTERY NEGATIVE TERMINAL
9. PERFORM SYSTEM INITIALIZE Some systems need initialization when disconnecting the cable from the negative battery terminal. HINT: See «INITIALIZATION»(ref-245121-S10087552442006102400000)
10. ADD ENGINE COOLANT (See «COOLANT»(ref-245131-S22101083452006102300000) )
11. CHECK FOR ENGINE COOLANT LEAKS (See «REPLACEMENT»(ref-245131-S26186014672006102300000) )
12. CHARGE REFRIGERANT (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
13. WARM UP ENGINE (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
14. CHECK FOR LEAKAGE OF REFRIGERANT (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
15. INSTALL WINDSHIELD WIPER MOTOR AND LINK (See «INSTALLATION»(ref-245153-S12054365582006102300000) )
16. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See «INSTALLATION»(ref-245153-S12054365582006102300000) )
17. INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See «INSTALLATION»(ref-245153-S12054365582006102300000) )

Scheme 235

1. INSPECT BLOWER MOTOR Remove the blower motor. Disconnect the connector from the cooling unit motor sub-assembly w/ fan. Connect the positive (+) lead to terminal 2 of the blower motor connector, and the negative (-) lead to terminal 1.

Scheme 236

Scheme 237

Scheme 238

Scheme 239

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
2. REMOVE FAN AND GENERATOR V BELT (See «REMOVAL»(ref-245126-S19436532972006102300000) )
3. REMOVE GENERATOR ASSEMBLY (See «REMOVAL»(ref-245135-S34774008482006102300000) )
4. DISCONNECT COOLER REFRIGERANT DISCHARGE HOSE NO.1 Remove the bolt and disconnect the cooler refrigerant discharge hose No.1. Remove the O-ring from the cooler refrigerant discharge hose No.1. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering.
5. DISCONNECT SUCTION HOSE SUB-ASSEMBLY Remove the bolt and disconnect the suction hose sub-assembly. Remove the O-ring from the suction hose No.1. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering.
6. REMOVE COMPRESSOR AND MAGNETIC CLUTCH Disconnect the connector. Remove the 4 bolts and compressor and magnetic clutch.

Scheme 240

Scheme 241

Scheme 242

1. REMOVE MAGNETIC CLUTCH ASSEMBLY Remove the bolt and bracket. Place the compressor and magnetic clutch in a vise. Using vise pliers, hold the magnet clutch hub. Remove the bolt, magnetic clutch hub and magnetic clutch washer. Using a snap ring expander, remove the snap ring and magnetic clutch rotor. Disconnect the connector. Using a snap ring expander, remove the snap ring and magnetic clutch stator.

Scheme 243

Scheme 244

1. INSPECT MAGNETIC CLUTCH CLEARANCE Set the dial indicator to the magnetic clutch hub. Connect the battery positive lead to terminal 3 of the magnetic clutch connector and the negative lead to the earth wire. Turn on and off the magnetic clutch and measure the clearance. Standard clearance: 0.26 to 0.60 mm (0.010 to 0.024 in.) If the measured value is out of the standard range, remove the magnetic clutch hub and adjust it with the magnetic clutch washers. NOTE: Adjustment shall be performed with 3 or less magnetic clutch washers. Remove the compressor and magnetic clutch from the vise.
2. INSPECT COMPRESSOR OIL Gradually discharge the refrigerant gas from the service valve when replacing the compressor and magnetic clutch with a new one. Drain the following amount of oil from the new compressor and magnetic clutch before installation. Standard: (Oil capacity inside the new compressor and magnetic clutch: 130 + 15 cc (4.6 + 0.51 fl.oz.) - (Remaining oil amount in the removed compressor and magnetic clutch) = (Oil amount to be removed before installation) NOTE: When checking the compressor oil level, observe the precautions on the cooler removal / installation. Because compressor oil remains in the pipes of the vehicle, if anew compressor and magnetic clutch is installed without removing some oil, the oil amount becomes too much, preventing heat exchange in the refrigerant cycle and causing refrigerant failure. If the remaining oil the removed compressor and magnetic clutch is too small in volume, check for oil leakage. Be sure to use ND-OIL8 for compressor oil.
3. INSPECT W/MAGNET CLUTCH COMPRESSOR ASSEMBLY Disconnect the connector from the w/ magnet clutch compressor assembly. Measure the resistance according to the value(s) in the table below. Resistance TESTER CONNECTION CONDITION AND SPECIFIED CONDITION Tester connection Condition Specified condition B8-3 - Body Ground Always Below 1 If the resistance is not as specified, replace the w/magnet clutch compressor assembly.

Scheme 245

Scheme 246

Scheme 247

Scheme 248

1. INSTALL MAGNETIC CLUTCH ASSEMBLY Matching the parts (Scheme 240), install the magnetic clutch stator. Using a snap ring expander, install a new snap ring with the chamfered side facing up. Connect the connector. Using a snap ring expander, install the magnetic clutch rotor and a new snap ring with the chamfered side facing up. Install the magnetic clutch washer and magnetic clutch hub. NOTE: Do not change the combination of the magnetic clutch washer used before disassembly. Using vise pliers, hold the magnetic clutch hub and install the bolt. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf)

Scheme 249

Scheme 250

Scheme 251

1. INSTALL COMPRESSOR AND MAGNETIC CLUTCH Install the compressor and magnetic clutch with the 4 bolts. Torque: 25 N*m (250 kgf*cm, 18 ft.*lbf) NOTE: Tighten the bolts in the order (Scheme 244)to install the compressor and magnetic clutch. Connect the connector.
2. INSTALL SUCTION HOSE SUB-ASSEMBLY Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the compressor and magnetic clutch. Compressor oil: ND-OIL 8 or equivalent Install the O-ring to the suction hose sub-assembly. Install the suction hose sub-assembly to the compressor and magnetic clutch with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
3. INSTALL COOLER REFRIGERANT DISCHARGE HOSE NO.1 Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the compressor and magnetic clutch. Compressor oil: ND-OIL 8 or equivalent Install the O-ring to the cooler refrigerant discharge hose No.1. Install the cooler refrigerant discharge hose No.1 to the compressor and magnetic clutch with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
4. INSTALL GENERATOR ASSEMBLY (See «INSTALLATION»(ref-245135-S24083978472006102300000) )
5. INSTALL FAN AND GENERATOR V BELT (See «INSTALLATION»(ref-245126-S33096852102006102300000) )
6. CHARGE REFRIGERANT (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
7. WARM UP ENGINE (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
8. CHECK FOR LEAKAGE OF REFRIGERANT (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )

Scheme 252

HINT

1. Installation is in the reverse order of removal.

Scheme 253

Scheme 254

Scheme 255

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
2. REMOVE AIR CLEANER INLET NO.2 (See «REMOVAL»(ref-245126-S19436532972006102300000) )
3. REMOVE AIR CLEANER INLET NO.1 (See «REMOVAL»(ref-245126-S19436532972006102300000) )
4. DISCONNECT HOOD LOCK ASSEMBLY
5. REMOVE RADIATOR SUPPORT UPPER (See «REMOVAL»(ref-245131-S38979007932006102400000) )
6. DISCONNECT COOLER REFRIGERANT DISCHARGE HOSE NO.1 Remove the bolt and disconnect the cooler refrigerant discharge hose No.1 from the cooler condenser assembly. Remove the O-ring from the cooler refrigerant discharge hose No.1. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering.
7. DISCONNECT AIR CONDITIONER TUBE AND ACCESSORY Remove the bolt and disconnect the air conditioner tube & accessory from the cooler condenser assembly. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering.
8. REMOVE COOLER CONDENSER ASSEMBLY Remove the 4 bolts and cooler condenser assembly.

Scheme 256

Scheme 257

Scheme 258

1. INSTALL COOLER CONDENSER ASSEMBLY Install the cooler condenser assembly with the 4 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
2. INSTALL AIR CONDITIONER TUBE AND ACCESSORY Remove the attached vinyl tape from the tube and the connecting part of the cooler condenser assembly. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the hose joint. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the air conditioning tube assembly. Install the air conditioner tube & accessory on the cooler condenser assembly with the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
3. INSTALL COOLER REFRIGERANT DISCHARGE HOSE NO.1 Remove the attached vinyl tape from the pipe and the connecting part of the cooler condenser assembly. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the pipe joint. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the cooler refrigerant discharge hose No.1. Install the cooler refrigerant discharge hose No.1. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
4. INSTALL RADIATOR SUPPORT UPPER (See «INSTALLATION»(ref-245131-S38285746822006102400000) )
5. INSTALL HOOD LOCK ASSEMBLY
6. CHARGE REFRIGERANT (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
7. WARM UP ENGINE (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )
8. CHECK FOR LEAKAGE OF REFRIGERANT (See «REPLACEMENT»(ref-245146-S42670439582006102400000) )

Scheme 259

1. INSPECT A/C ROOM TEMPERATURE SENSOR Remove the A/C room temperature sensor. Disconnect the connector from the A/C room temperature sensor. Measure the resistance according to the value(s) in the table below. Resistance TESTER CONNECTION CONDITION AND SPECIFIED CONDITION Tester connection Condition Specified condition 1 - 2 10°C (50°F) 3.00 to 3.73 k 1 - 2 15°C (59°F) 2.45 to 2.88 k 1 - 2 20°C (68°F) 1.95 to 2.30 k 1 - 2 25°C (77°F) 1.60 to 1.80 k 1 - 2 30°C (86°F) 1.28 to 1.47 k 1 - 2 35°C (95°F) 1.00 to 1.22 k 1 - 2 40°C (104°F) 0.80 to 1.00 k 1 - 2 45°C (113°F) 0.65 to 0.85 k 1 - 2 50°C (122°F) 0.50 to 0.70 k 1 - 2 55°C (131°F) 0.44 to 0.60 k 1 - 2 60°C (140°F) 0.36 to 0.50 k NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (See the graph). If the resistance value is not as specified, replace the sensor.

Scheme 260

Scheme 261

1. INSPECT A/C ROOM TEMPERATURE SENSOR Remove the A/C room temperature sensor. Disconnect the connector from the A/C room temperature sensor. Measure the resistance according to the value(s) in the table below. Resistance TESTER CONNECTION CONDITION AND SPECIFIED CONDITION Tester connection Condition Specified condition 1 - 2 10°C (50°F) 3.00 to 3.73 k 1 - 2 15°C (59°F) 2.45 to 2.88 k 1 - 2 20°C (68°F) 1.95 to 2.30 k 1 - 2 25°C (77°F) 1.60 to 1.80 k 1 - 2 30°C (86°F) 1.28 to 1.47 k 1 - 2 35°C (95°F) 1.00 to 1.22 k 1 - 2 40°C (104°F) 0.80 to 1.00 k 1 - 2 45°C (113°F) 0.65 to 0.85 k 1 - 2 50°C (122°F) 0.50 to 0.70 k 1 - 2 55°C (131°F) 0.44 to 0.60 k 1 - 2 60°C (140°F) 0.36 to 0.50 k NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (See the graph). If the resistance value is not as specified, replace the sensor.

Scheme 262

Scheme 263

1. INSPECT A/C EVAPORATOR TEMPERATURE SENSOR Remove the A/C evaporator temperature sensor (A/C thermistor). Disconnect the connector from the A/C evaporator temperature sensor (A/C thermistor). Measure the resistance according to the value(s) in the table below. Resistance TESTER CONNECTION CONDITION AND SPECIFIED CONDITION Tester connection Condition Specified condition 1 - 2 -10°C (14°F) 7.30 to 9.10 k 1 - 2 -5°C (23°F) 5.65 to 6.95 k 1 - 2 0°C (32°F) 4.40 to 5.35 k 1 - 2 5°C (41°F) 3.40 to 4.15 k 1 - 2 10°C (50°F) 2.70 to 3.25 k 1 - 2 15°C (59°F) 2.14 to 2.58 k 1 - 2 20°C (68°F) 1.71 to 2.05 k 1 - 2 25°C (77°F) 1.38 to 1.64 k 1 - 2 30°C (86°F) 1.11 to 1.32 k NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (See the graph). If the resistance value is not as specified, replace the sensor.

Scheme 264

1. INSPECT A/C PRESSURE SENSOR Start the engine. Operate the air conditioning system. Disconnect the connector from A/C pressure sensor. Install the manifold gauge set (See «ON-VEHICLE INSPECTION»(ref-245146-S21335243772006102400000) ). Connect the positive (+) lead from the three 1.5 V dry cell batteries to terminal 3 and negative (-) lead to terminal 1. Check the voltage between terminals 2 and 1 of A/C pressure sensor. Voltage: The voltage depends on the refrigerant pressure (Scheme 259) If the voltage is not as specified, replace the sensor.

Scheme 265

HINT

Installation is in the reverse order of removal.

Scheme 266

1. DISCONNECT BATTERY NEGATIVE TERMINAL Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO.2 (See «REMOVAL»(ref-245163-S09561694362006102300000) )
3. REMOVE INSTRUMENT PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-245163-S09561694362006102300000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER Release the 8 claws and 5 clips and instrument cluster finish panel sub-assembly center. Disconnect the connector and remove the instrument cluster finish panel sub-assembly center.

Scheme 267

1. REMOVE AIR CONDITIONING CONTROL ASSEMBLY Release the 4 claws and remove the air conditioning control assembly.

INSTALLATION

1. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER
2. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY
3. INSTALL INSTRUMENT CLUSTER FINISH PANEL GARNISH NO.2
4. CONNECT BATTERY NEGATIVE TERMINAL
5. PERFORM SYSTEM INITIALIZE Some systems need initialization when disconnecting the cable from the negative battery terminal. HINT: See «INITIALIZATION»(ref-245121-S10087552442006102400000) .

Scheme 268

HINT

Installation is in the reverse order of removal.

Scheme 269

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 2 (See «REMOVAL»(ref-245163-S09561694362006102300000) )
3. REMOVE INSTRUMENT PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-245163-S09561694362006102300000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER Release the 8 claws and 5 clips and instrument cluster finish panel sub-assembly center. Disconnect the connector and remove the instrument cluster finish panel sub-assembly center.

Scheme 270

1. REMOVE TEMPERATURE CONTROL SWITCH ASSEMBLY Release the 4 claws and remove the temperature control switch assembly.

1. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER
2. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY
3. INSTALL INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 2
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. PERFORM SYSTEM INITIALIZE Some systems need initialization when disconnecting the cable from the negative battery terminal.

Scheme 271

Scheme 272

HINT

Installation is in the reverse order of removal.

Scheme 273

1. DISCONNECT BATTERY NEGATIVE TERMINAL Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
2. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY NO.2 (See «REMOVAL»(ref-245163-S09561694362006102300000) )
3. REMOVE INSTRUMENT PANEL FINISH LOWER PANEL RH (See «REMOVAL»(ref-245163-S09561694362006102300000) )
4. REMOVE AIR CONDITIONING AMPLIFIER ASSEMBLY Disconnect the connector. Remove the 2 screws and air conditioning amplifier assembly.

1. CONNECT BATTERY NEGATIVE TERMINAL
2. PERFORM SYSTEM INITIALIZE Some systems need initialization when disconnecting the cable from the negative battery terminal. HINT: See «INITIALIZATION»(ref-245121-S10087552442006102400000) .
