Automatic Transmission Shift Lock System (Floor Shift) Toyota Avalon XX20 рестайлинг

Automatic Trans 5 illustrations

Scheme 192

Scheme 192: LOCATION
Scheme 192: LOCATION

Scheme 193

Scheme 193: INSPECTION
Scheme 193: INSPECTION

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196
  1. INSPECT SHIFT LOCK CONTROL UNIT ASSEMBLY Using a voltmeter, measure the voltage at each terminal. NOTE: Do not disconnect the shift lock control unit assembly connector.
  2. INSPECT KEY INTERLOCK SOLENOID Disconnect the solenoid connector. Using an ohmmeter, measure resistance between terminals. Standard resistance: 14.+/- 1.5 ohm If resistance value is not as specified, replace the solenoid. Apply battery positive voltage between terminals. Check that an operation noise can be heard from the solenoid. If the solenoid does not operated, replace the solenoid.
