SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10S17 10-Cyl. |
| Compressor Belt Tension (1) |
| New Belt (2) | 143-187 lbs. (63-87 kg) |
| Used Belt | 66-110 lbs. (30-50 kg) |
| Compressor Oil Capacity (3) | 3.4-4.1 ozs. |
| Refrigerant (R-134a) Capacity | 19.4-22.9 ozs. |
| System Operating Pressures (4) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Using a belt tension gauge, measure at mid-point of longest belt run. A new belt is one that has been run less than 5 minutes. (2) A new belt is one that has been in use less than 5 minutes. (3) Use ND-OIL 8 refrigerant oil (Part No. 08885-09109). (4) With ambient temperature at 86-95°F (30-35°C) and engine at 1500 RPM. |
| (1) | Using a belt tension gauge, measure at mid-point of longest belt run. A new belt is one that has been run less than 5 minutes. |
| (2) | A new belt is one that has been in use less than 5 minutes. |
| (3) | Use ND-OIL 8 refrigerant oil (Part No. 08885-09109). |
| (4) | With ambient temperature at 86-95°F (30-35°C) and engine at 1500 RPM. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor-To-Bracket Bolt | 18 (25) |
| A/C Compressor Bracket-To-Engine Bolt | 18 (25) |
| Drive Belt Adjusting Bar Bracket Bolt/Nut | 18 (25) |
| Drive Belt Adjusting Bar Bracket-To-Adjusting Bar | 13 (18) |
| Drive Belt Adjusting Lock Bolt | 13 (18) |
| INCH Lbs. (N.m) |
| Compressor Hoses | 89 (10) |
| Condenser Lines | 89 (10) |
| Pressure Switch | 89 (10) |
| Receiver-Drier Lines | 48 (5.4) |
Automatic A/C-Heater System Wiring Diagram (2000-01 Avalon - 1 Of 2). Scheme 15
Scheme 15: Automatic A/C-Heater System Wiring Diagram (2000-01 Avalon - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000-01 Avalon - 2 Of 2). Scheme 16
Scheme 16: Automatic A/C-Heater System Wiring Diagram (2000-01 Avalon - 2 Of 2)
