DESCRIPTION
This DTC is stored when a problem, such as an open in the AM2 fuse, an open or short in the wire harness between the fuse and power management control ECU, a short in the IG output circuit inside the power management control ECU, a short between the power management control ECU and relay, or a short in the relay, is detected.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2271 | The hold circuit, IG1 relay actuation circuit or IG2 relay actuation circuit inside the power management control ECU is open or shorted. | AM2 fuse Main body ECU (Driver side junction block assembly) (IG1 relays) No. 1 integration relay (IG2 relay) Power management control ECU Harness or connector |
Scheme 102
This DTC is stored when there is a problem in the ACC output circuit, which is from the ACC output terminal of the power management control ECU to the ACC relay.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2274 | The ACC relay actuation circuit inside the power management control ECU or other related circuit is malfunctioning. | AM2 fuse Main body ECU (Driver side junction block assembly) (ACC relay) Power management control ECU Harness or connector |
Scheme 103
This DTC is stored when a malfunction in the submersion monitor circuit inside the power management control ECU is detected.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2277 | A malfunction in the submersion monitor circuit inside the power management control ECU is detected. | Submerged power management control ECU Power management control ECU |
The power management control ECU and the combination meter are connected by a cable and the CAN communication lines. This DTC is stored when the vehicle speed signal information from the cable and the vehicle speed signal information from the CAN communication line are inconsistent.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2282 | The vehicle speed signal information from the cable and the vehicle speed signal information from the CAN communication line are inconsistent. | CAN communication system Power management control ECU Meter/gauge system Harness or connector |
The skid control ECU converts signals from the speed sensor into 4-pulse signals and sends them to the combination meter. After these signals are converted into a more precise rectangular waveform by the waveform shaping circuit inside the combination meter, they are then transmitted to the power management control ECU. The power management control ECU determines the vehicle speed based on the frequencies of these pulse signals.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2283 | Both conditions are met: The vehicle speed decreases significantly. The vehicle speed does not correspond with the engine speed. | Power management control ECU Meter/gauge system Skid control ECU Speed sensor Harness or connector |
Scheme 104
HINT
- A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter. The signal is changed to a pulse signal at the transistor in the combination meter. Each ECU controls its respective system based on the pulse signal.
- If a short circuit occurs in an ECU, all systems related to the components in the diagram above will not operate normally.
Scheme 105
This DTC is stored when the brake signal information from the cable and the brake signal information from the CAN communication line are inconsistent
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2284 | The brake signal information from the cable and the brake signal information from the CAN communication line are inconsistent. | STOP fuse AM2 fuse Stop light switch assembly Engine control system Power management control ECU Harness or connector |
Scheme 106
The power management control ECU and steering lock actuator (steering lock ECU) are connected by a cable and the LIN communication line. This DTC is stored when the steering lock position signal information from the cable and the steering lock position signal information from the LIN communication line are inconsistent.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2285 | The steering lock position signal information from the cable and the steering lock position signal information from the LIN communication line are inconsistent. | AM2 fuse Steering lock actuator assembly (steering lock ECU) Power management control ECU LIN communication system Harness or connector |
Scheme 107
The power management control ECU and ECM are connected by a cable and the CAN communication lines. These DTCs are stored when the crankshaft position sensor signal information from the cable and the crankshaft position sensor signal information from the CAN communication line are inconsistent.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2286 P0335 | The crankshaft position sensor signal information from the cable and the crankshaft position sensor signal information from the CAN communication line are inconsistent. | AM2 fuse Engine control system Power management control ECU Harness or connector |
Scheme 108
The power management control ECU receives information from 2 sources. It receives information via a direct line and via the CAN communication line. If the information from these 2 sources is inconsistent, this DTC is stored.
HINT
When the power management control ECU is replaced with a new one and the cable is connected to the negative (-) battery terminal, the power source mode is reset to on (IG). When the battery is removed and reinstalled, the power source mode that was selected when the battery was removed is restored.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|---|---|
| U0100 | There is no communication from the ECM. | CAN communication system ECM |
| U0142 | There is no communication from the main body ECU. | CAN communication system Main body ECU (Driver side junction block assembly) |
| U0129 | There is no communication from the skid control ECU. | CAN communication system Skid control ECU |
| U0155 | There is no communication from the combination meter. | CAN communication system Combination meter assembly |
The push-button start function uses a push-type engine switch, which the driver can operate by merely carrying the key. This system consists primarily of the power management control ECU, engine switch, ID code box, steering lock ECU, key, ACC relay, IG1 relay, IG2 relay and certification ECU. The power management control ECU controls the system. This function operates in cooperation with the smart key system.
When the engine switch is pushed with the key in the cabin, the power management control receives signals to switch the power source mode.
Scheme 109
When the engine switch is pushed with the key in the cabin, the power management control ECU receives signals to switch the power source mode.
When the engine switch is pushed with the key in the cabin, the power management control ECU receives signals to switch the power source mode.
HINT
To allow use of the Techstream to inspect the push-button start function when the engine switch is off, repeatedly open and close any of the doors. Repeatedly opening and closing a door establishes communication between the Techstream and power management control ECU (opening and closing a door can also be simulated by operating a door courtesy light switch).
