REPLACEMENT Toyota 4Runner V

Differential (Service Information): Removal & Installation 5 illustrations ~400 words

REPLACEMENT

HINT

  1. Use the same procedure for the RH and LH sides.
  2. The procedure listed below is for the LH side.

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. REMOVE FRONT WHEEL
  2. REMOVE DISC BRAKE CYLINDER ASSEMBLY LH . Refer to «REMOVAL - Step 4»(ref-422108-S09201321952011092600000)
  3. REMOVE FRONT DISC . Refer to «REMOVAL - Step 5»(ref-422108-S09201321952011092600000)
  4. REMOVE FRONT AXLE HUB BOLT LH Using SST and a screwdriver or equivalent to hold the axle hub, remove the front axle hub bolt. SST: 09611-12010 TEXT IN ILLUSTRATION *1 Nut *a Turn *b Hold NOTE: Do not damage the threads of the hub bolt.
  5. INSTALL FRONT AXLE HUB BOLT LH Insert a new hub bolt. Temporarily install a washer and hub nut to the hub bolt as shown in the illustration. TEXT IN ILLUSTRATION *1 Washer *2 Nut *a Turn *b Hold NOTE: Install a hub nut to prevent damage to the hub bolt. Using a screwdriver or equivalent to hold the hub, turn the hub nut until the bottom surface of the hub bolt head touches the axle hub. Remove the hub nut and washer. NOTE: Do not damage the threads of the hub bolt.
  6. INSTALL FRONT DISC . Refer to «INSTALLATION - Step 1»(ref-422108-S26410589592011092600000)
  7. INSTALL DISC BRAKE CYLINDER ASSEMBLY LH . Refer to «INSTALLATION - Step 2»(ref-422108-S26410589592011092600000)
  8. INSTALL FRONT WHEEL Torque: 112 N*m (1137 kgf*cm, 82 ft.*lbf)

Scheme 14

Scheme 14: ILLUSTRATION
Scheme 14: ILLUSTRATION

Scheme 15

Scheme 15: ON-VEHICLE INSPECTION
Scheme 15: ON-VEHICLE INSPECTION

Scheme 16

Scheme 16
Scheme 16
  1. REMOVE FRONT WHEEL
  2. REMOVE DISC BRAKE CYLINDER ASSEMBLY LH . Refer to «REMOVAL - Step 4»(ref-422108-S09201321952011092600000)
  3. REMOVE FRONT DISC . Refer to «REMOVAL - Step 5»(ref-422108-S09201321952011092600000)
  4. INSPECT FRONT AXLE HUB BEARING LOOSENESS Using a dial indicator, measure the looseness near the center of the axle hub. Maximum looseness 0.05 mm (0.00197 in.) NOTE: Make sure that the dial indicator is set at a right angle to the measurement surface. If the looseness is more than the maximum, replace the axle hub.
  5. INSPECT FRONT AXLE HUB RUNOUT Using a dial indicator, measure the runout on the surface of the axle hub outside the hub bolts. Maximum runout 0.08 mm (0.00315 in.) NOTE: Make sure that the dial indicator is set at a right angle to the measurement surface. If the runout is more than the maximum, replace the axle hub.
  6. INSTALL FRONT DISC . Refer to «INSTALLATION - Step 1»(ref-422108-S26410589592011092600000)
  7. INSTALL DISC BRAKE CYLINDER ASSEMBLY LH . Refer to «INSTALLATION - Step 2»(ref-422108-S26410589592011092600000)
  8. INSTALL FRONT WHEEL Torque: 112 N*m (1137 kgf*cm, 82 ft.*lbf)
