Transfer Case -VF4AM: Removal & Installation Toyota 4Runner IV рестайлинг

INSTALLATION

1. INSTALL TRANSFER ASSEMBLY Install the transfer assembly with the 8 bolts. Torque: 24 N*m (240 kgf*cm, 17 ft.*lbf) NOTE: Take care not to damage the adaptor rear oil seal with the transfer input gear spline.
2. INSTALL AUTOMATIC TRANSMISSION WITH TRANSFER (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
3. CONFIRM FRONT DIFFERENTIAL ASSEMBLY
4. INSTALL MANIFOLD STAY NO.2 (See «INSTALLATION»(ref-280543-S17198593412008022200000) )
5. INSTALL MANIFOLD STAY (See «INSTALLATION»(ref-280543-S17198593412008022200000) )
6. INSTALL STARTER ASSEMBLY (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
7. CONNECT WIRE HARNESS
8. CONNECT CONNECTOR
9. INSTALL NO. 3 FRAME CROSSMEMBER SUB-ASSEMBLY (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
10. INSTALL TRANSFER CASE LOWER PROTECTOR Install the transfer case lower protector with the 4 bolts. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf)
11. INSTALL NO. 1 TRANSFER CONTROL CABLE BRACKET (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
12. CONNECT TRANSMISSION CONTROL CABLE ASSEMBLY (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
13. INSTALL NO. 1 OIL COOLER INLET TUBE (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
14. CONNECT NO. 1 OIL COOLER OUTLET TUBE (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
15. INSTALL TRANSMISSION OIL FILLER TUBE SUB-ASSEMBLY
16. INSTALL FRONT SUSPENSION MEMBER BRACKET LH (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
17. INSTALL FRONT SUSPENSION MEMBER BRACKET (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
18. ADD TRANSFER OIL
19. ADD AUTOMATIC TRANSMISSION FLUID (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
20. INSPECT AUTOMATIC TRANSMISSION FLUID (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
21. INSTALL PROPELLER SHAFT ASSEMBLY (See «INSTALLATION»(ref-280559-S30490901682008022200000) )
22. INSTALL PROPELLER SHAFT ASSEMBLY FRONT (See «INSTALLATION»(ref-280559-S28927078652008022200000) )
23. INSTALL EXHAUST PIPE ASSEMBLY (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
24. CONNECT OXYGEN SENSOR (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
25. INSTALL ENGINE UNDER COVER ASSEMBLY REAR (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
26. INSTALL NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
27. INSPECT AUTOMATIC TRANSMISSION FLUID (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
28. INSPECT SHIFT LEVER POSITION (See «INSTALLATION»(ref-280554-S41868190542008022200000) )
29. CHECK FOR EXHAUST GAS LEAKAGE
30. WARM UP
31. DRIVE TEST

Scheme 114
