Starting System (2UZ-FE): Overview Toyota 4Runner IV рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. DISCHARGE FUEL SYSTEM PRESSURE (See «REMOVAL»(ref-280563-S04690156892008022200000) )
2. DRAIN ENGINE COOLANT (See «REPLACEMENT»(/toyota/4runner/iv-2005-2009/remont/cooling-system-mechanical/#engine-cooling-system-2uz-fe) )
3. DISCONNECT BATTERY NEGATIVE TERMINAL Disconnect the battery negative terminal.
4. REMOVE THROTTLE BODY COVER SUB-ASSEMBLY Remove the 2 nuts and throttle body cover sub-assembly.
5. REMOVE AIR CLEANER HOSE ASSEMBLY (See «REMOVAL»(/toyota/4runner/iv-2005-2009/remont/testing-diagnostics/#engine-control-system-2uz-fe) )
6. DISCONNECT FUEL HOSE (See «REMOVAL»(ref-280563-S04690156892008022200000) )
7. DISCONNECT NO. 2 FUEL HOSE (See «REMOVAL»(ref-280542-S30189161242008022200000) )
8. DISCONNECT FUEL VAPOR FEED HOSE ASSEMBLY Disconnect the fuel vapor feed hose assembly.
9. SEPARATE ENGINE WIRE Disconnect the 8 fuel injector connectors. Disconnect the throttle position sensor connector. Disconnect the water temperature sensor connector. Remove the 3 bolts and separate the engine wire harness.
10. DISCONNECT NO. 7 WATER BY-PASS HOSE Disconnect the No. 7 water by-pass hose.
11. DISCONNECT WATER BY-PASS HOSE Disconnect the water by-pass hose.
12. REMOVE INTAKE MANIFOLD ASSEMBLY Remove the 6 bolts and 4 nuts. Remove the intake manifold and 2 gaskets.
13. REMOVE WATER BY-PASS PIPE SUB-ASSEMBLY Separate the No. 2 engine wire. Remove the nut and water by-pass pipe sub-assembly.
14. REMOVE REAR WATER BY-PASS JOINT RH Remove the 4 nuts, water by-pass joint and 2 gaskets.
15. REMOVE AIR PUMP ASSEMBLY (See «REMOVAL»(ref-280553-S34869579662008022200000) )
16. REMOVE STARTER ASSEMBLY Disconnect the starter connector. Remove the nut and disconnect the starter cable. Remove the bolt and disconnect the engine wire protector. Remove the 2 bolts and starter.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. REMOVE STARTER YOKE ASSEMBLY Remove the nut and disconnect the terminal C wire. Remove the 2 through bolts. Pull out the starter yoke assembly with the armature assembly. Remove the O-ring from the starter yoke assembly.
2. REMOVE STARTER BRUSH HOLDER ASSEMBLY Remove the 2 screws with O-ring and end cover from the field frame. Remove the O-ring from the field frame. Using a screwdriver, hold the spring back and disconnect the brush from the brush holder. Disconnect the 4 brushes, and remove the brush holder.
3. REMOVE STARTER ARMATURE ASSEMBLY Remove the starter armature assembly from starter yoke assembly.
4. REMOVE STARTER CLUTCH SUB-ASSEMBLY Remove the 2 screws and starter drive housing. Remove the return spring, idler gear, bearing and starter clutch sub-assembly from the starter housing. Using a magnetic finger, remove the steel ball from the clutch shaft hole.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. INSPECT STARTER ASSEMBLY NOTE: These tests must be done within 3 to 5 seconds to avoid burning out the coil. Do pull-in test. Disconnect the field coil lead wire from terminal C. Connect the battery to the magnetic switch as shown. Check that the clutch pinion gear moves outward. Do holding test. With battery connected as above with the clutch pinion gear out, disconnect the negative (-) lead from terminal C. Check that the pinion hear remains out. Inspect clutch pinion gear return. Disconnect the negative (-) lead from the switch body. Check that the clutch pinion gear returns inward. Perform the operation test without load. Connect the field coil lead wire to terminal C. Torque: 5.9 N*m (60 kgf*cm, 52 in.*lbf) Grip the starter in a vise. Connect the battery and ammeter to the starter as shown. Check that the ammeter reads the specified current. Specified current (for standard area): 90 A or less at 11.5V Specified current (for cold area): 100 A or less at 11.5 V
2. INSPECT STARTER ARMATURE ASSEMBLY Inspect commutator for dirty and burnt surface. If the surface of the commutator is dirty or burned, polish the part with sandpaper (#400) or replace the armature. Inspect commutator for open circuit. Using an ohmmeter, check that there is continuity between the segments, replace the armature. If there is no continuity between any segments, replace the armature. Inspect commutator for ground. Using an ohmmeter, check that there is no continuity between the commutator and armature core. If there is continuity, replace the armature assembly. Inspect commutator circle runout. Place the armature on the V-blocks. Using a dial gauge, measure the circuit runout. Maximum circle runout: 0.05 mm (0.0020 in.) If the circle runout is greater than maximum, correct it on a lathe. Using vernier calipers, measure the commutator diameter. Standard diameter: 35.0 mm (1.378 in.) Minimum diameter: 34.0 mm (1.339 in.) If the diameter is less than minimum, replace the armature assembly. Measure the undercut depth of commutator. Standard undercut depth: 0.7 mm (0.028 in.) Minimum undercut depth: 0.2 mm (0.008 in.) If the undercut depth is less than the minimum, correct it with a hacksaw blade. Inspect the bearings. Check that the bearing rotates smoothly.
3. INSPECT STARTER YOKE ASSEMBLY Inspect field coil for open circuit. Using an ohmmeter, check that there is continuity between the lead wire and field coil brush lead. If there is no continuity, replace the starter yoke assembly. Inspect shunt coil for open circuit. Using an ohmmeter, measure the resistance between shunt coil terminals (A) and (B). Standard resistance: 1.5 to 1.9 ohms at 20°C (68°F) If the resistance is not as specified, replace the starter yoke assembly.
4. INSPECT BRUSH Using vernier calipers, measure the brush length. Standard length: 15.0 mm (0.591 in.) Minimum length: 9.0 mm (0.354 in.) If the length is less than the minimum, replace the brush holder and starter yoke assembly.
5. INSPECT STARTER BRUSH HOLDER ASSEMBLY Using an ohmmeter, check that there is no continuity between the positive and negative brush holders. If there is continuity, replace the brush holder. Take the pull scale reading the instant the brush spring separates from the brush. Standard spring installed load: 21.5 to 27.5 N (2.2 to 2.8 kgf, 4.8 to 6.2 lbf) Minimum spring installed load: 12.7 N (1.3 kgf, 2.9 lbf) If spring load is less than the minimum, replace the brush springs.
6. INSPECT STARTER CLUTCH SUB-ASSEMBLY Rotate the pinion gear clockwise, and check that it turns freely. Try to rotate the pinion gear counterclockwise and check that it locks. If necessary, replace the clutch sub-assembly.
7. INSPECT STARTER MAGNETIC SWITCH ASSEMBLY Check the pull-in coil continuity. Using an ohmmeter, check that there is continuity between terminal 50 and C. If there is no continuity, replace the starter magnetic switch assembly. Check the holding coil continuity. Using an ohmmeter, check that there is continuity between terminals 50 and switch body. If there is no continuity, replace the magnet starter switch assembly.

Scheme 33

Scheme 34

1. INSTALL STARTER CLUTCH SUB-ASSEMBLY Apply grease to the steel ball, return spring, clutch rollers and starter idler pinions. Install the steel ball. Install a new O-ring to the starter housing. Insert the return spring into the magnet starter switch hole. Install the starter clutch sub-assembly, idler gear and bearing. Install the starter housing to the magnet switch assembly with the 2 screws. Torque: 9.3 N*m (95 kgf*cm, 82 in.*lbf)
2. INSTALL STARTER BRUSH HOLDER ASSEMBLY Align the claw of the brush holder with the claw groove of the starter yoke assembly. Place the brush holder on the starter yoke assembly. Using a screwdriver, hold the brush spring back. Connect the brush into the brush holder. Connect the 4 brushes. NOTE: Check that the positive (+) lead wires are not grounded. Install an O-ring to the groove of the starter yoke. Install 2 new O-rings and the end cover with the 2 screws. Torque: 3.8 N*m (39 kgf*cm, 34 in.*lbf)
3. INSTALL STARTER YOKE ASSEMBLY Install a new O-ring to the groove of the starter yoke assembly. Align the protrusion of the starter yoke assembly with the groove of the magnetic switch. Install the starter yoke assembly with the 2 through bolts. Torque: 9.3 N*m (95 kgf*cm, 82 in.*lbf) Connect the terminal C wire with the nut. Torque: 5.9 N*m (60 kgf*cm, 52 in.*lbf)
