Mirror Toyota 4Runner IV рестайлинг

Scheme 1

POWER MIRROR CONTROL SYSTEM PROBLEM SYMPTOMS CHART

Scheme 2

Scheme 3

Scheme 4

1. SELECT COMPASS DISPLAY MODE The COMP switch allows you to select the Display or Non-display mode of the compass.
2. SET ZONE Deviation between the "magnetic north" and "actual north" differs depending on the location. Therefore, adjustment of the magnetism is required. Since the magnetic condition differs depending on the area where the vehicle is used, it is necessary for each user to set the zone (Refer to step 7 for Compass Zone Map). The zone setting can be changed using the COMP switch of the inner mirror.
3. PERFORM CALIBRATION Because each vehicle has its own magnetic field, calibration should be performed for each vehicle. This compass function is used when storing the record of the vehicle's magnetic field.
4. WHEN COMPASS IS MAGNETIZED A compass could be magnetized during shipping by vessels or freight cars. Therefore, make sure to perform calibration and ensure that calibration is performed properly before delivery. If it cannot be done (cannot be completed in spite of driving around several times), it may be caused by magnetization. Demagnetize the vehicle using a demagnetizer and perform calibration again.
5. SET COMPASS
6. ZONE SETTING MODE Pressing the COMP switch for 3 seconds in the normal mode will activate the zone setting mode. A number (1 to 15) is displayed on the compass display. NOTE: In the initial state, "8" is displayed. The displayed number increases by 1 every time the COMP switch is pressed. Referring to the map, check the number for the area where the vehicle will be used and set the zone number. Leave it untouched for several seconds after setting and check that the compass display shows an azimuthal direction (N, NE, E, SE, S, SW, W or NW) or "C".
7. CALIBRATION SETTING MODE Pressing the COMP switch for 6 seconds in the normal mode will activate the calibration setting mode. Drive the vehicle at a slow speed of 8 km/h (5 mph) or less in the circular direction. Driving around the circle 1 to 3 times will display the azimuthal direction on the display, completing the calibration. NOTE: After the calibration is completed, it is not necessary to perform the above procedures unless the magnetic field strength is drastically changed. If this happens, the azimuthal display will be changed to "C".

AUTOMATIC GLARE-RESISTANT EC MIRROR PROBLEM SYMPTOMS CHART

Scheme 5

Scheme 6

1. REMOVE INNER REAR VIEW MIRROR (w/o Electronic Mirror) Pushing portions (a) as indicated in the illustration, remove the cover. Pushing the claw in the direction (b), slide the mirror assembly in the direction (c) to remove it.
2. REMOVE INNER REAR VIEW MIRROR (w/ Electronic Mirror) Disconnect the mirror cover. Disconnect the connector. Remove the mirror assembly as shown in the illustration.

Scheme 7

1. INSPECT INNER REAR VIEW MIRROR ASSEMBLY Inspect operation of the electrochromic inner mirror. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2. Attach black colored tape to the forward sensor to prevent it from sensing. Light up the mirror with an electric light, and check that the mirror surface changes from bright to dark. Standard: Mirror surface changes from bright to dark If the result is not as specified, replace the mirror assembly.

INSTALLATION

1. INSTALL INNER REAR VIEW MIRROR (w/ Electronic Mirror)
2. INSTALL INNER REAR VIEW MIRROR (w/o Electronic Mirror)

Scheme 8

Scheme 9

Scheme 10

1. REMOVE FRONT DOOR SERVICE HOLE COVER LH Remove the front door lower frame bracket garnish LH. Remove the front door inside handle bezel LH. Remove the front armrest assembly LH. Remove the front door trim board LH. Remove the front door service cover LH.
2. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY LH Disconnect the connector. Remove the 3 nuts and mirror.

Scheme 11

Scheme 12

1. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH Disconnect the mirror connector. Apply battery voltage and check operation of the mirror face, as shown in the table and (Scheme 11). Standard OUTER REAR VIEW MIRROR ASSEMBLY LH Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (MV) Battery negative (-) --> Terminal 1 (M+) Turns upward (A) Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 3 (MV) Turns downward (B) Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 2 (MH) Turns right (C) Battery positive (+) --> Terminal 2 (MH) Battery negative (-) --> Terminal 1 (M+) Turns left (D) If the result is not as specified, replace the mirror assembly.
2. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH Inspect outer mirror motor operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard OUTER REAR VIEW MIRROR ASSEMBLY RH Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (MV) Battery negative (-) --> Terminal 1 (M+) Turns upward (A) Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 3 (MV) Turns downward (B) Battery positive (+) --> Terminal 1 (M+) Battery negative (-) --> Terminal 2 (MH) Turns right (C) Battery positive (+) --> Terminal 2 (MH) Battery negative (-) --> Terminal 1 (M+) Turns left (D) If the result is not as specified, replace the mirror assembly.

Scheme 13

1. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY LH Install the mirror with the 3 nuts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the connector.

Scheme 14

1. INSPECT OUTER MIRROR SWITCH ASSEMBLY Inspect the outer mirror switch. Measure the resistance according to the value(s) in the table below when the switch is operated. Resistance: Select "L" on the left/right adjustment switch SELECT "L" ON THE LEFT/RIGHT ADJUSTMENT SWITCH Tester Connection Switch Position Specified Condition 4 - 8 UP Below 1 ohms 6 - 7 4 - 7 DOWN 6 - 8 5 - 8 LEFT 6 - 7 5 - 7 RIGHT 6 - 8 Select "R" on the left/right adjustment switch SELECT "R" ON THE LEFT/RIGHT ADJUSTMENT SWITCH Tester Connection Switch Position Specified Condition 3 - 8 UP Below 1 ohms 6 - 7 3 - 7 DOWN 6 - 8 2 - 8 LEFT 6 - 7 2 - 7 RIGHT 6 - 8
