Interior: Removal & Installation Toyota 4Runner IV рестайлинг

Exterior/interior Trim 31 illustrations ~2328 words

INSTALLATION

  1. INSTALL FRONT FLOOR FOOTREST Install the footrest clips by engaging the claws with the footrest. HINT: Before the installation, check that the part of footrest to be engaged with the clips is not damaged. NOTE: If it is damaged, replace it with a new one.

Scheme 2

Scheme 2: COMPONENTS
Scheme 2: COMPONENTS

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

REMOVAL

HINT

A bolt without torque specification is a standard bolt (See SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. REMOVE TONNEAU COVER RETRACTOR SUB-ASSEMBLY
  2. REMOVE REAR NO. 2 SEAT ASSEMBLY (for 50/50 Split Seat Type) HINT: See «REMOVAL»(ref-280582-S35876473642008022200000)
  3. REMOVE NO. 3 SEAT LEG COVER NO. 2 (for 50/50 Split Seat Type)
  4. REMOVE REAR NO. 2 SEAT LOCK ASSEMBLY LH (for 50/50 Split Seat Type) Remove the 2 bolts and seat lock.
  5. REMOVE REAR NO. 2 SEAT LOCK ASSEMBLY RH (for 50/50 Split Seat Type) Remove the 2 bolts and seat lock.
  6. REMOVE SEAT ANCHOR RAIL NO. 4 (for 50/50 Split Seat Type) Using a screwdriver, remove the 2 covers, 2 bolts and anchor rail. HINT: Tape the screwdriver tip before use.
  7. REMOVE BACK DOOR WEATHERSTRIP
  8. REMOVE DECK BOARD SUB-ASSEMBLY Remove the 2 bolts and the deck board sub-assembly.
  9. REMOVE DECK BOARD ASSEMBLY Remove the 2 bolts and the deck board assembly.
  10. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR Remove the 5 bolts and mat support plate.
  11. REMOVE DECK FLOOR BOX LH Using a screwdriver, disengage the claws and remove the cover. HINT: Tape the screwdriver tip before use. Remove the bolt, deck floor box and luggage hold belt striker.
  12. REMOVE DECK FLOOR BOX RH HINT: Use the same procedures described for the LH side.
  13. REMOVE DECK TRIM COVER REAR Using a screwdriver, pry out the trim cover. HINT: Tape the screwdriver tip before use.
  14. REMOVE DECK TRIM SIDE BOARD UPR LH Remove the screw and side board.
  15. REMOVE DECK TRIM SIDE BOARD UPR RH Remove the screw and side board.
  16. REMOVE SIDE TRIM BOX ASSEMBLY LH Remove the screw and side trim box.
  17. REMOVE SIDE TRIM BOX ASSEMBLY RH Remove the screw and side trim box.
  18. REMOVE QUARTER SCUFF PLATE INSIDE LH (for 50/50 Split Seat Type) Using a screwdriver, disengage the 4 claws and covers. HINT: Tape the screwdriver tip before use. Remove the 2 bolts and scuff plate.
  19. REMOVE QUARTER SCUFF PLATE INSIDE RH (for 50/50 Split Seat Type) HINT: Use the same procedure described for the LH side.
  20. REMOVE REAR DOOR SCUFF PLATE LH Using a screwdriver, disengage the claw labeled A, claw labeled B, 2 claws labeled C and claw labeled D. Remove the scuff plate. HINT: Tape the screwdriver tip before use.
  21. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
  22. REMOVE FRONT DOOR SCUFF PLATE LH Using a screwdriver, disengage the claw labeled A, claw labeled B, 4 claws labeled C, claw labeled D and claw labeled E. Remove the scuff plate. HINT: Tape the screwdriver tip before use.
  23. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
  24. REMOVE COWL SIDE TRIM BOARD LH Remove the cap nut. Using a screwdriver, disengage the 2 claws and remove the trim board. HINT: Tape the screwdriver tip before use.
  25. REMOVE COWL SIDE TRIM BOARD RH HINT: Use the same procedure described for the LH side.
  26. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
  27. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  28. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  29. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  30. REMOVE DECK TRIM COVER REAR
  31. REMOVE REAR FLOOR CARPET ASSEMBLY
  32. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH Remove the screw and deck trim cover. Remove the 3 screws and clips. Using a screwdriver, disengage the 6 clips and remove the side panel. HINT: Tape the screwdriver tip before use.
  33. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  34. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (for 50/50 Split Seat Type) Remove the bolt and 3 screws. Using a screwdriver, remove the 5 clips and side panel. HINT: Tape the screwdriver tip before use.
  35. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (for 50/50 Split Seat Type) HINT: Use the same procedure described for the LH side.
  36. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH Remove the screw and tonneau cover hook. Remove the 3 bolts and clip. Using a screwdriver, disengage the 9 clips and remove the side garnish. HINT: Tape the screwdriver tip before use.
  37. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH HINT: Use the same procedure described for the LH side.
  38. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH (for 50/50 Split Seat Type) Remove the rear No. 2 shoulder anchor bolt. Remove the 3 screws, disengage the 4 clips labeled A and 5 clips labeled B. Using a screwdriver, disengage the 4 claws and remove the side garnish. HINT: Tape the screwdriver tip before use.
  39. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH (for 50/50 Split Seat Type) HINT: Use the same procedure described for the LH side.
  40. REMOVE CENTER PILLAR GARNISH LOWER LH Using a screwdriver, disengage the 6 claws labeled A and 2 claws labeled B. Remove the 2 clips and pillar garnish. HINT: Tape the screwdriver tip before use.
  41. REMOVE CENTER PILLAR GARNISH LOWER RH HINT: Use the same procedure described for the LH side.
  42. REMOVE CENTER PILLAR GARNISH UPPER LH Remove the bolt and disconnect the front seat outer belt (floor anchor side). Remove the 2 bolts. Using a screwdriver, disengage the 6 claws and clip, and remove the pillar garnish. HINT: Tape the screwdriver tip before use.
  43. REMOVE CENTER PILLAR GARNISH UPPER RH HINT: Use the same procedure described for the LH side.
  44. REMOVE FRONT PILLAR GARNISH LH Using a screwdriver, remove the 2 assist grip plugs. HINT: Tape the screwdriver tip before use. Remove the 2 bolts. Using a screwdriver, disengage the claw. Remove the clip labeled A, clip labeled B and pillar garnish. HINT: Tape the screwdriver tip before use. Pull the garnish upward, and remove the pillar garnish from the instrument panel. w/ Curtain shield airbag: Protect the curtain shield airbag LH. Thoroughly cover the airbag with cloth or nylon of 700 mm (27.56 in.) x 120 mm (4.72 in.) and fix the ends of the cover with adhesive tape, as shown in the illustration. NOTE: Cover the curtain shield airbag with the protection cover as soon as the front pillar garnish is removed.
  45. REMOVE FRONT PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
  46. REMOVE INNER REAR VIEW MIRROR ASSEMBLY
  47. REMOVE ROOF CONSOLE BOX ASSEMBLY Using a molding remover, disengage the 3 claws and 2 clips. HINT: Tape the screwdriver tip before use. Disconnect the map light switch connector and sliding roof switch connector, and remove the console box.
  48. REMOVE INTERIOR LIGHT ASSEMBLY NO. 1 Using a screwdriver, disengage the 4 claws and remove the interior light lens. HINT: Tape the screwdriver tip before use. Using a screwdriver, disengage the 4 claws and remove the 2 covers. HINT: Tape the screwdriver tip before use. Using a screwdriver, disengage the 4 claws. HINT: Tape the screwdriver tip before use. Remove the No. 1 roof wire from the claw of the interior light. Using a screwdriver, disengage the 4 claws and remove the interior light switch base and the interior light.
  49. REMOVE DOME LIGHT ASSEMBLY (w/ RSE) HINT: See «REMOVAL»(ref-280593-S13089746922008022200000)
  50. REMOVE TELEVISION DISPLAY ASSEMBLY (w/ RSE) HINT: See «REMOVAL»(ref-280593-S13089746922008022200000)
  51. REMOVE VISOR ASSEMBLY LH Remove the 2 screws and visor assembly. Remove the 2 screws and visor sub-assembly.
  52. REMOVE VISOR ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  53. REMOVE VISOR HOLDER Remove the screw and visor holder.
  54. REMOVE ROOF HEADLINING ASSEMBLY Disengage the 4 clips and remove the headlining.

Scheme 30

Scheme 30: INSTALLATION
Scheme 30: INSTALLATION

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. INSTALL ROOF HEADLINING ASSEMBLY Align the marking, and then install the wire harness with tape. HINT: Be careful for dirt or foreign objects not to stick to the adhered part when peeling off the double-stick tape. Attach the roof wire harness along the adhered part. NOTE: Roof wire harness should be attached securely. Install the roof headlining with the 4 clips.
  2. INSTALL VISOR HOLDER Install the screw and visor holder.
  3. INSTALL VISOR ASSEMBLY LH Install the 2 screws and visor sub-assembly. Install the 2 screws and visor assembly.
  4. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  5. INSTALL INTERIOR LIGHT ASSEMBLY NO. 1 Install interior light switch base and the interior light, and engage the 4 claws. Install the No. 1 roof wire to the claw of the interior light. Engage the 4 claws. Install the 2 covers and engage the 4 claws. Install the interior light lens and engage the 4 claws.
  6. INSTALL DOME LIGHT ASSEMBLY (w/ RSE) HINT: See «INSTALLATION»(ref-280593-S15750054922008022200000)
  7. INSTALL TELEVISION DISPLAY ASSEMBLY (w/ RSE) HINT: See «INSTALLATION»(ref-280593-S15750054922008022200000)
  8. INSTALL ROOF CONSOLE BOX ASSEMBLY Install the console box and reconnect the map light switch connector and sliding roof switch connector. Engage the 3 claws and 2 clips.
  9. INSTALL INNER REAR VIEW MIRROR ASSEMBLY
  10. INSTALL FRONT PILLAR GARNISH LH Install the clip labeled A, clip labeled B and pillar garnish, and engage the claw. Install 2 bolts. Install the 2 assist grip plugs.
  11. INSTALL FRONT PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
  12. INSTALL CENTER PILLAR GARNISH UPPER LH Install the pillar garnish and engage the 6 claws. Install the 2 bolts. Install the front seat outer belt (floor anchor side) and install the bolt.
  13. INSTALL CENTER PILLAR GARNISH UPPER RH HINT: Use the same procedure described for the LH side.
  14. INSTALL CENTER PILLAR GARNISH LOWER LH Install the 2 clips and pillar garnish. And engage the 6 claws labeled A and 2 claws labeled B.
  15. INSTALL CENTER PILLAR GARNISH LOWER RH HINT: Use the same procedure described for the LH side.
  16. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH Install the side garnish and engage the 9 clips. Install the 3 bolts and clip. Install the tonneau cover hook and the screw.
  17. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH HINT: Use the same procedure described for the LH side.
  18. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (for 50/50 Split Seat Type) Install the side garnish and engage the 4 screws. Engage the 4 clips labeled A and 5 clips labeled B, and install the 3 screws. Install the rear No. 2 shoulder anchor bolt.
  19. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH (for 50/50 Split Seat Type) HINT: Use the same procedure described for the LH side.
  20. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH Install the side panel and engage the 6 clips. Install the 3 screws and clips. Install the screw and deck trim cover.
  21. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH HINT: Use the same procedure described for the LH side.
  22. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (for 50/50 Split Seat Type) Install the side panel and the 5 clips. Install the 3 screws and the bolt.
  23. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (for 50/50 Split Seat Type) HINT: Use the same procedure described for the LH side.
  24. INSTALL REAR FLOOR CARPET ASSEMBLY
  25. INSTALL DECK TRIM COVER REAR
  26. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  27. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  28. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
  29. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
  30. INSTALL COWL SIDE TRIM BOARD LH Install the trim board and engage the 2 claws. Install the cap nut.
  31. INSTALL COWL SIDE TRIM BOARD RH HINT: Use the same procedure described for the LH side.
  32. INSTALL FRONT DOOR SCUFF PLATE LH Install the scuff plate. Engage the claw labeled A, claw labeled B, 4 claws labeled C, claw labeled D and claw labeled E.
  33. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
  34. INSTALL REAR DOOR SCUFF PLATE LH Install the scuff plate. Engage the claw labeled A, claw labeled B, 2 claws labeled C and claw labeled D.
  35. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
  36. INSTALL QUARTER SCUFF PLATE INSIDE LH (for 50/50 Split Seat Type) Install the scuff plate and the 2 bolts. Engage the 4 claws and covers.
  37. INSTALL QUARTER SCUFF PLATE INSIDE RH (for 50/50 Split Seat Type) HINT: Use the same procedure described for the LH side.
  38. INSTALL SIDE TRIM BOX ASSEMBLY LH Install the side trim box and the screws.
  39. INSTALL SIDE TRIM BOX ASSEMBLY RH Install the side trim box and the screws.
  40. INSTALL DECK TRIM SIDE BOARD UPR LH Install the side board and the screw.
  41. INSTALL DECK TRIM SIDE BOARD UPR RH Install the side board and the screw.
  42. INSTALL DECK TRIM COVER REAR Install the trim cover.
  43. INSTALL DECK FLOOR BOX LH Install the deck floor box, luggage hold belt and bolt. Install the cover and the claws.
  44. INSTALL DECK FLOOR BOX RH HINT: Use the same procedure described for the LH side.
  45. INSTALL REAR FLOOR MAT SUPPORT PLATE REAR Install the mat support plate and 5 bolts.
  46. INSTALL DECK BOARD ASSEMBLY Install the deck board assembly and the 2 bolts.
  47. INSTALL DECK BOARD SUB-ASSEMBLY Install the deck board sub-assembly and the 2 bolts.
  48. INSTALL BACK DOOR WEATHERSTRIP
  49. INSTALL SEAT ANCHOR RAIL NO. 4 (for 50/50 Split Seat Type) Install the 2 covers, 2 bolts and anchor rail.
  50. INSTALL REAR NO. 2 SEAT LOCK ASSEMBLY LH Install the seat lock and 2 bolts.
  51. INSTALL REAR NO. 2 SEAT LOCK ASSEMBLY RH Install the seat lock and 2 bolts.
  52. INSTALL NO. 3 SEAT LEG COVER NO. 2 (for 50/50 Split Seat Type)
  53. INSTALL REAR NO. 2 SEAT ASSEMBLY (for 50/50 Split Seat Type) HINT: See «INSTALLATION»(ref-280582-S23600531932008022200000)
  54. INSTALL TONNEAU COVER RETRACTOR SUB-ASSEMBLY
