Audio System & Visual System: Removal & Installation Toyota 4Runner IV рестайлинг

Antenna Systems 47 illustrations ~1957 words

INSTALLATION

  1. INSTALL RADIO NO. 2 BRACKET
  2. INSTALL RADIO NO. 1 BRACKET
  3. INSTALL RADIO RECEIVER (w/ Bracket)
  4. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY CENTER
  5. INSTALL AIR CONDITIONING CONTROL ASSEMBLY
  6. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER
  7. INSTALL CONSOLE UPPER REAR PANEL SUB-ASSEMBLY
  8. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY
  9. INSTALL INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER
  10. INSTALL INSTRUMENT PANEL FINISH PLATE

Scheme 92

Scheme 92: COMPONENTS
Scheme 92: COMPONENTS

Scheme 93

Scheme 93
Scheme 93
  1. INSTALL FRONT NO. 2 SPEAKER Align a claw with the notch of the speaker mounting bracket No. 1, and install the front No. 2 speaker with 2 bolts. Connect the connector.
  2. INSTALL FRONT NO. 1 SPEAKER Install the front No. 1 speaker with the 4 screws. NOTE: Install them in the order see scheme 121 Connect the connector.
  3. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH
  4. INSTALL FRONT ARMREST ASSEMBLY LH
  5. INSTALL FRONT DOOR INSIDE HANDLE BEZEL LH
  6. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH

Scheme 94

Scheme 94: COMPONENTS
Scheme 94: COMPONENTS

Scheme 95

Scheme 95
Scheme 95
  1. INSTALL FRONT STEREO COMPONENT SPEAKER
  2. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY HINT: Refer to the installation procedures of the instrument panel safety pad sub-assembly (See «INSTALLATION»(ref-280569-S24525045172008022200000) ).

Scheme 96

Scheme 96: COMPONENTS
Scheme 96: COMPONENTS

Scheme 97

Scheme 97: REMOVAL
Scheme 97: REMOVAL

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101
  1. REMOVE DOME LIGHT LENS LH Disengage the 4 claws and remove the dome the light lens LH. HINT: Tape the screwdriver tip before use.
  2. REMOVE DOME LIGHT LENS RH Disengage the 4 claws and remove the dome light lens RH. HINT: Tape the screw driver tip before use.
  3. REMOVE DOME LIGHT ASSEMBLY Remove the 2 screws. Disengage the 4 clips. Disconnect the connector and remove the dome light assembly.
  4. REMOVE TELEVISION DISPLAY ASSEMBLY Disconnect the connector. Remove the 4 bolts. Disengage the 2 clips and remove television display assembly.
  1. INSTALL TELEVISION DISPLAY ASSEMBLY
  2. INSTALL DOME LIGHT ASSEMBLY
  3. INSTALL DOME LIGHT LENS RH
  4. INSTALL DOME LIGHT LENS LH

Scheme 102

Scheme 102: COMPONENTS
Scheme 102: COMPONENTS

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104: REMOVAL
Scheme 104: REMOVAL
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY HINT: Refer to the instructions for removal of the instrument panel sub-assembly (See «REMOVAL»(ref-280569-S23218485322008022200000) ).
  2. REMOVE ANTENNA CORD SUB-ASSEMBLY Remove the 4 clamps and antenna cord sub-assembly.
  1. INSTALL ANTENNA CORD SUB-ASSEMBLY
  2. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSEMBLY HINT: Refer to the installation procedures of the instrument panel safety pad sub-assembly (See «INSTALLATION»(ref-280569-S24525045172008022200000) ).

Scheme 105

Scheme 105: COMPONENTS
Scheme 105: COMPONENTS

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107: REMOVAL
Scheme 107: REMOVAL
  1. REMOVE SUN ROOF OR REMOVABLE ROOF HEADLINING ASSEMBLY HINT: Refer to the instructions for removal of the sun roof or removable roof headlining assembly (See «REMOVAL»(ref-280535-S02047796042008022200000) ).
  2. REMOVE AMPLIFIER ANTENNA Disconnect the connectors and remove the 2 bolts. Remove the 17 clamps and amplifier antenna.
  1. INSTALL AMPLIFIER ANTENNA
  2. INSTALL SUN ROOF OR REMOVABLE ROOF HEADLINING ASSEMBLY HINT: Refer to the installation procedures of the roof headlining assembly (See «INSTALLATION»(ref-280535-S32180053972008022200000) ).

Scheme 108

Scheme 108: COMPONENTS
Scheme 108: COMPONENTS

Scheme 109

Scheme 109
Scheme 109

Scheme 110

Scheme 110: REMOVAL
Scheme 110: REMOVAL
  1. REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL»(ref-280569-S23218485322008022200000) )
  2. REMOVE VIDEO TERMINAL Disconnect the connector. Disengage the wire harness clamp. Disengage the 4 claws and remove the video (video adapter) terminal.
  1. INSTALL VIDEO TERMINAL
  2. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER

Scheme 111

Scheme 111: COMPONENTS
Scheme 111: COMPONENTS

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113: REMOVAL
Scheme 113: REMOVAL
  1. REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER (See «REMOVAL»(ref-280569-S23218485322008022200000) )
  2. REMOVE STEREO JACK ADAPTER Disconnect the connector. Disengage the wire harness clamp. Disengage the 2 claws remove the stereo jack adapter assembly.
  1. INSTALL STEREO JACK ADAPTER
  2. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER

Scheme 114

Scheme 114: COMPONENTS
Scheme 114: COMPONENTS

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116: REMOVAL
Scheme 116: REMOVAL

Scheme 117

Scheme 117
Scheme 117
  1. SEPARATE BATTERY NEGATIVE TERMINAL (See «REMOVAL»(ref-280584-S34604174652008022200000) )
  2. REMOVE STEERING WHEEL COVER LOWER NO. 2 (See «REMOVAL»(ref-280584-S34604174652008022200000) )
  3. REMOVE STEERING WHEEL COVER LOWER NO. 3 (See «REMOVAL»(ref-280584-S34604174652008022200000) )
  4. REMOVE STEERING PAD ASSEMBLY (See «REMOVAL»(ref-280584-S34604174652008022200000) )
  5. REMOVE STEERING PAD SWITCH Disconnect the connector. Disconnect the connector of cruise control main switch. Remove the screw. Disengage the meshing of 2 pins remove the steering pad switch LH.

Scheme 118

Scheme 118: INSPECTION
Scheme 118: INSPECTION

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121
  1. INSPECT STEERING PAD SWITCH LH Measure the resistance according to the values in the table below. Standard resistance STEERING PAD SWITCH LH Tester connection Condition Specified condition AU1 - EAU No switch Is pushed Approx. 100 kohms AU1 - EAU SEEK+ switch: push Approx. 0 ohms AU1 - EAU SEEK- switch: push Approx. 0.3 kohms AU1 - EAU VOL+ switch: push Approx. 1 kohms AU1 - EAU VOL- switch: push Approx. 3.1 kohms AU2 - EAU No switch is pushed Approx. 100 kohms AU2 - EAU MODE switch: push Approx. 0 ohms If the result is not as specified, replace the steering pad switch LH.
  2. INSPECT STEERING PAD SWITCH RH (w/ Navigation System) Inspect steering pad switch assembly. Measure the resistance according to the values in the table below. Standard resistance STEERING PAD SWITCH RH (W/ NAVIGATION SYSTEM) Tester connection Condition Specified condition AU1 - EAU No switch is pushed Approx. 100 kohms AU1 - EAU SEEK+ switch: push Approx. 0 ohms AU1 - EAU SEEK- switch: push Approx. 0.3 kohms AU1 - EAU VOL+ switch: push Approx. 1 kohms AU1 - EAU VOL-switch: push Approx. 3.1 kohms AU2 - EAU No switch is pushed Approx. 100 kohms AU2 - EAU MODE switch: push Approx. 0 ohms AU2 - EAU VOICE switch: push Approx. 3.1 kohms AU2 - EAU ON HOOK switch: push Approx. 0.3 kohms AU2 - EAU OFF HOOK switch: push Approx. 1 kohms Inspect steering pad switch cable. Measure the resistance according to the values in the table below. Standard resistance STEERING PAD SWITCH CABLE Tester connection Condition Specified condition B-1 - C-1 Always Below 1 ohms B-2 - C-2 Always Below 1 ohms B-3 - C-3 Always Below 1 ohms B-4 - C-4 Always Below 1 ohms B-5 - C-5 Always Below 1 ohms B-6 - C-6 Always Below 1 ohms B-7 - C-7 Always Below 1 ohms B-8 - C-8 Always Below ohms B-1 - Body ground Always 10 kohms or higher B-2 - Body ground Always 10 kohms or higher B-3 - Body ground Always 10 kohms or higher B-4 - Body ground Always 10 kohms or higher B-5 - Body ground Always 10 kohms or higher B-6 - Body ground Always 10 kohms or higher B-7 - Body ground Always 10 kohms or higher B-8 - Body ground Always 10 kohms or higher If the result is not as specified, replace the steering pad switch cable. Inspect steering pad switch RH. Measure the resistance according to the values in the table below. Standard resistance STEERING PAD SWITCH RH Tester connection Condition Specified condition AU2 (B-4) - EAU (B-2) No switch is pushed 10 kohms or higher AU2 (B-5) - EAU (B-3) AU2 (B-5) - EAU (B-2) AU2 (B-4) - EAU (B-3) AU2 (B-4) - EAU (B-2) VOICE switch: push Approx. 3.1 kohms AU2 (B-5) -EAU (B-3) AU2 (B-5) - EAU (B-2) AU2 (B-4) - EAU (B-3) AU2 (B-4) - EAU (B-2) ON HOOK switch: push Approx. 0.3 kohms AU2 (B-5) - EAU (B-3) AU2 (B-5) - EAU (B-2) AU2 (B-4) - EAU (B-3) AU2 (B-4) - EAU (B-2) OFF HOOK switch: push Approx. 1 kohms AU2 (B-5) - EAU (B-3) AU2 (B-5) -EAU (B-2) AU2 (B-4) - EAU (B-3) If the result is not as specified, replace the steering pad switch RH.
  1. INSTALL STEERING PAD SWITCH
  2. INSTALL STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-280584-S31038111392008022200000) )
  3. INSTALL STEERING WHEEL COVER LOWER NO. 3 (See «INSTALLATION»(ref-280584-S31038111392008022200000) )
  4. INSTALL STEERING WHEEL COVER LOWER NO. 2 (See «INSTALLATION»(ref-280584-S31038111392008022200000) )
  5. CONNECT BATTERY NEGATIVE TERMINAL
  6. INSPECT STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-280584-S31038111392008022200000) )
  7. INSPECT SRS WARNING LIGHT (See «INSTALLATION»(ref-280584-S31038111392008022200000) )

Scheme 122

Scheme 122: COMPONENTS
Scheme 122: COMPONENTS

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124: REMOVAL
Scheme 124: REMOVAL

Scheme 125

Scheme 125
Scheme 125
  1. REMOVE ROOF CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  2. REMOVE MICROPHONE AMPLIFIER Remove the 4 screws. Disconnect the connector. Disengage the 2 claws remove the amplifier microphone assembly.
  1. INSTALL MICROPHONE AMPLIFIER
  2. INSTALL ROOF CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-280535-S32180053972008022200000) )

Scheme 126

Scheme 126: COMPONENTS
Scheme 126: COMPONENTS

Scheme 127

Scheme 127: INSPECTION
Scheme 127: INSPECTION
  1. INSPECT WINDOW GLASS ANTENNA WIRE NOTE: When cleaning the glass, use a soft dry cloth and wipe the glass in the direction of the wire. Take care not to damage the wires. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the top of the foil negative probe and press the foil against the wire with your finger, as shown in the illustration. Inspect the continuity, at the center of each antenna wire, as shown in the illustration.

Scheme 128

Scheme 128: REPAIR
Scheme 128: REPAIR

Scheme 129

Scheme 129
Scheme 129
  1. REPAIR WINDOW GLASS ANTENNA WIRE Clean the broken wire tips with a grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (Dupont+. paste No. 4817). Using a fine tip brush, apply a small amount to the wire. After a few minutes, remove the masking tape. Do not repair the defogger were for at least 24 hours.

Scheme 130

Scheme 130: COMPONENTS
Scheme 130: COMPONENTS
  1. INSTALL REAR SPEAKER Install the rear speaker with the 3 screws. NOTE: Install them in the order shown in the illustration. Connect the connector.
  2. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH
  3. INSTALL REAR ARMREST ASSEMBLY LH
  4. INSTALL REAR DOOR INSIDE HANDLE BEZEL LH

Scheme 131

Scheme 131: COMPONENTS
Scheme 131: COMPONENTS

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133
  1. INSTALL REAR NO. 2 SPEAKER
  2. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  3. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  4. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
  5. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  6. INSTALL SIDE TRIM BOX ASSEMBLY LH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  7. INSTALL DECK TRIM SIDE BOARD UPR LH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  8. INSTALL DECK TRIM COVER REAR
  9. INSTALL DECK FLOOR BOX LH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  10. INSTALL REAR FLOOR MAT SUPPORT PLATE REAR (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  11. INSTALL DECK BOARD ASSEMBLY (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  12. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  13. INSTALL BACK DOOR WEATHERSTRIP
  14. INSTALL TONNEAU COVER RETRACTOR SUB-ASSEMBLY

Scheme 134

Scheme 134: COMPONENTS
Scheme 134: COMPONENTS

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137: ON-VEHICLE INSPECTION
Scheme 137: ON-VEHICLE INSPECTION
  1. INSPECT NO. 1 SPEAKER WITH BOX HINT: Remove interior parts so that the No. 1 speaker with box can be seen. Check the speaker installation. OK: The speaker is securely installed. If the result is not as specified, reinstall the No. 1 speaker with box. Visually check the speaker. OK: The cone paper of the speaker is not torn. If the result is not as specified, replace the No. 1 speaker with box. Resistance check. Measure the resistance according tot the value(s) in the table below. NOTE: The speaker should not be removed for checking. Standard resistance NO. 1 SPEAKER WITH BOX Tester connection Condition Specified condition 1 - 3 Always Approximately 1.2 ohms 2 - 4 Always Approximately 1.2 ohms If the result is not as specified, replace the No. 1 speaker with box.

Scheme 138

Scheme 138: REMOVAL
Scheme 138: REMOVAL
  1. REMOVE TONNEAU COVER RETRACTOR SUB-ASSEMBLY
  2. REMOVE BACK DOOR WEATHERSTRIP
  3. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  4. REMOVE DECK BOARD ASSEMBLY (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  5. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  6. REMOVE DECK FLOOR BOX RH (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  7. REMOVE DECK TRIM COVER REAR (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  8. REMOVE DECK TRIM SIDE BOARD UPR RH (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  9. REMOVE SIDE TRIM BOX ASSEMBLY RH (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  10. REMOVE REAR DOOR SCUFF PLATE RH (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  11. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  12. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  13. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH (See «REMOVAL»(ref-280535-S02047796042008022200000) )
  14. REMOVE WOOFER BOX SPEAKER ASSEMBLY Disconnect the connectors. Remove the 5 bolts and woofer box speaker assembly.
  1. INSTALL WOOFER BOX SPEAKER ASSEMBLY
  2. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  3. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  4. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
  5. INSTALL REAR DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  6. INSTALL SIDE TRIM BOX ASSEMBLY RH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  7. INSTALL DECK TRIM SIDE BOARD UPR RH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  8. INSTALL DECK TRIM COVER REAR (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  9. INSTALL DECK FLOOR BOX RH (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  10. INSTALL REAR FLOOR MAT SUPPORT PLATE REAR (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  11. INSTALL DECK BOARD ASSEMBLY (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  12. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-280535-S32180053972008022200000) )
  13. INSTALL BACK DOOR WEATHERSTRIP
  14. INSTALL TONNEAU COVER RETRACTOR SUB-ASSEMBLY
