DIAGNOSTIC TROUBLE CODE CHART
Note. When removing the part, turn the ignition switch OFF.
Note. Using SST 09843-18040, connect the terminals Tc and CG of DLC3. If any abnormality is not found when inspecting parts, inspect the ECU. If a malfunction code is displayed during the DTC check, check the circuit listed for that code.
| DTC | Description |
|---|---|
| DTC C0200/31, C0205/32, C1235/35, C1236/36 | RIGHT/LEFT FRONT SPEED SENSOR CIRCUIT & FOREIGN MATTER IS ATTACHED ON TIP OF RIGHT/LEFT FRONT SENSOR |
| DTC C0210/33, C0215/34, C1238/38, C1239/39 | RIGHT/LEFT REAR SPEED SENSOR CIRCUIT & FOREIGN MATTER IS ATTACHED ON TIP OF RIGHT/LEFT REAR SENSOR |
| DTC C0226/21, C0236/22, C0246/23, C0256/24, C1225/25, C1226/26, C1227/27, C1228/28 | SFR/SFL/SRR/SRL SOLENOID CIRCUIT & SMC/SPC/SRC/STR SOLENOID CIRCUIT (SAI/SA2/SAS) |
| DTC C0278/11, C0279/12 | OPEN/SHORT CIRCUIT IN ABS SOLENOID RELAY CIRCUIT |
| DTC C1201/51 | ENGINE CONTROL SYSTEM MALFUNCTION |
| DTC C1203/53 | ECM COMMUNICATION CIRCUIT MALFUNCTION |
| DTC C1210/36 | ZERO POINT CALIBRATION OF YAW RATE SENSOR UNDONE |
| DTC C1223/43 | ABS CONTROL SYSTEM MALFUNCTION |
| DTC C1224/44 | NE SIGNAL CIRCUIT |
| DTC C1231/31, C1335/35 | STEERING ANGLE SENSOR CIRCUIT |
| DTC C1232/32, C1243/43, C1244/44, C1245/45 | DECELERATION SENSOR DOES NOT FUNCTION & MALFUNCTION IN DECELERATION SENSOR |
| DTC C1233/33, C1234/34 | YAW RATE SENSOR CIRCUIT |
| DTC C1241/41, C1257/57 | LOW BATTERY POSITIVE VOLTAGE OR ABNORMALLY HIGH BATTERY POSITIVE VOLTAGE & POWER SUPPLY DRIVE CIRCUIT MALFUNCTION |
| DTC C1242/42 | IG2 POWER SOURCE CIRCUIT |
| DTC C1246/46 | MASTER CYLINDER PRESSURE SENSOR CIRCUIT |
| DTC C1249/49 | STOP LIGHT SWITCH CIRCUIT |
| DTC C1251/51, C1252/52, C1253/53 | PUMP MOTOR IS LOCKED/OPEN CIRCUIT IN PUMP MOTOR GROUND, BRAKE BOOSTER PUMP MOTOR ON TIME ABNORMALLY LONG & BRAKE BOOSTER PUMP MOTOR CIRCUIT |
| DTC C1254/54 | PRESSURE SWITCH CIRCUIT |
| DTC C1256/56 | ACCUMULATOR LOW PRESSURE |
| DTC C1268/68 | TRANSFER L4 POSITION SWITCH CIRCUIT |
| DTC C1306/96 | MALFUNCTION IN SPEED SENSOR POWER SUPPLY |
| DTC C1336/39 | ZERO POINT CALIBRATION OF DECELERATION SENSOR UNDONE |
| DTC C1337/37 | TIRES OF DIFFERENT SIZE |
| DTC C1340/47 | CENTER DEFERENTIAL LOCK CIRCUIT |
| DTC C1380/64 | MALFUNCTION IN STOP LIGHT OPERATION RELAY |
