Starting System: Specifications Toyota 4Runner III

Starter 13 illustrations

TORQUE SPECIFICATIONS

Application		Ft. Lbs. (N.m)
Starter Mounting Bolts
Avalon, Corolla, Land Cruiser, RAV4, Tundra & 4Runner		29 (39)
Camry, Camry Solara, Sienna & Tacoma		27 (37)
Celica		28 (38)
INCH Lbs. (N.m)
Park Neutral Position Switch
Land Cruiser, Tacoma, Tundra & 4Runner		116 (13)
All Others		48 (5.4)

TORQUE SPECIFICATIONS

Fig. 17: Starting System Wiring Diagram (Avalon)

Scheme 17: Starting System Wiring Diagram (Avalon)

Fig. 18: Starting System Wiring Diagram (Camry)

Scheme 18: Starting System Wiring Diagram (Camry)

Fig. 19: Starting System Wiring Diagram (Camry Solara)

Scheme 19: Starting System Wiring Diagram (Camry Solara)

Fig. 20: Starting System Wiring Diagram (Celica)

Scheme 20: Starting System Wiring Diagram (Celica)

Fig. 21: Starting System Wiring Diagram (Corolla)

Scheme 21: Starting System Wiring Diagram (Corolla)

Fig. 22: Starting System Wiring Diagram (Land Cruiser)

Scheme 22: Starting System Wiring Diagram (Land Cruiser)

Fig. 23: Starting System Wiring Diagram (Lexus LX470)

Scheme 23: Starting System Wiring Diagram (Lexus LX470)

Fig. 24: Starting System Wiring Diagram (RAV4)

Scheme 24: Starting System Wiring Diagram (RAV4)

Fig. 25: Starting System Wiring Diagram (Sienna)

Scheme 25: Starting System Wiring Diagram (Sienna)

Fig. 26: Starting System Wiring Diagram (Tacoma - 2.4L)

Scheme 26: Starting System Wiring Diagram (Tacoma - 2.4L)

Fig. 27: Starting System Wiring Diagram (Tacoma - 2.7L & 3.4L)

Scheme 27: Starting System Wiring Diagram (Tacoma - 2.7L & 3.4L)

Fig. 28: Starting System Wiring Diagram (2000 Tundra)

Scheme 28: Starting System Wiring Diagram (2000 Tundra)

Fig. 29: Starting System Wiring Diagram (4Runner)

Scheme 29: Starting System Wiring Diagram (4Runner)
