LEFT OR RIGHT POWER MIRROR INOPERATIVE
Check power mirror switch. See POWER MIRROR SWITCH under COMPONENT TESTS. Check power mirror motor(s). See POWER MIRROR MOTOR under COMPONENT TESTS. Check ground circuit and wiring harness. See WIRING DIAGRAMS .
UP/DOWN OR LEFT/RIGHT FUNCTION INOPERATIVE
Check power mirror motor(s). See POWER MIRROR MOTOR under COMPONENT TESTS. Check power mirror switch. See POWER MIRROR SWITCH under COMPONENT TESTS. Check ground circuit and wiring harness. See WIRING DIAGRAMS .
POWER MIRROR SWITCH
Note. Mirror motor connectors may vary in configuration from vehicle to vehicle of the same model.
Remove power mirror switch. Using ohmmeter, check continuity between appropriate mirror switch terminals. Continuity should exist between specified terminals. See appropriate POWER MIRROR SWITCH CONTINUITY TEST table. (Scheme 1)- see scheme 21. If switch fails any test, replace switch.
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 2 & 6; 1, 3 & 8 |
| Down | 3 & 6; 1, 2 & 8 |
| Left | 1, 3 & 6; 2 & 8 |
| Right | 1, 2 & 6; 3 & 8 |
| Switch In Right Position |
| Up | 2 & 5; 1, 3 & 7 |
| Down | 3 & 5; 1, 2 & 7 |
| Left | 1, 3 & 5; 2 & 7 |
| Right | 3 & 7; 1, 2 & 5 |
| (1) Continuity should exist between specified terminals. (Scheme 1)- (Scheme 2). |
POWER MIRROR SWITCH CONTINUITY TEST (AVALON)
Identifying Power Mirror Switch Connector Terminals (Avalon). Scheme 1
Scheme 1: Identifying Power Mirror Switch Connector Terminals (Avalon)
Identifying Power Mirror Motor Connector Terminals (Avalon). Scheme 2
Scheme 2: Identifying Power Mirror Motor Connector Terminals (Avalon)
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 3)- (Scheme 7). |
POWER MIRROR SWITCH CONTINUITY TEST (CAMRY & CAMRY SOLARA)
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 10; 3 & 4 |
| Down | 1 & 3; 4 & 10 |
| Left | 1 & 6; 3 & 4 |
| Right | 1 & 3; 4 & 6 |
| Switch In Right Position |
| Up | 1 & 6; 3 & 4 |
| Down | 1 & 3; 4 & 6 |
| Left | 1 & 2; 3 & 4 |
| Right | 1 & 3; 2 & 4 |
| (1) Continuity should exist between specified terminals. see scheme 8- see scheme 9. |
| (1) | Continuity should exist between specified terminals. see scheme 8- see scheme 9. |
POWER MIRROR SWITCH CONTINUITY TEST (CELICA W/POWER WINDOWS)
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 2 & 3; 7 & 8 |
| Down | 2 & 7; 3 & 8 |
| Left | 1 & 3; 7 & 8 |
| Right | 1 & 7; 3 & 8 |
| Switch In Right Position |
| Up | 3 & 10; 7 & 8 |
| Down | 3 & 8; 7 & 10 |
| Left | 3 & 5; 7 & 8 |
| Right | 3 & 8; 5 & 7 |
| (1) Continuity should exist between specified terminals. see scheme 8- see scheme 9. |
| (1) | Continuity should exist between specified terminals. see scheme 8- see scheme 9. |
POWER MIRROR SWITCH CONTINUITY TEST (CELICA W/O POWER WINDOWS)
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. see scheme 8- see scheme 9. |
| (1) | Continuity should exist between specified terminals. see scheme 8- see scheme 9. |
POWER MIRROR SWITCH CONTINUITY TEST (COROLLA)
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 3 & 4; 7 & 8 |
| Down | 3 & 8; 4 & 7 |
| Left | 4 & 9; 7 & 8 |
| Right | 4 & 7; 8 & 9 |
| Switch In Right Position |
| Up | 2 & 4; 1, 7 & 8 |
| Down | 4 & 7; 1, 2 & 8 |
| Left | 4 & 10; 1, 7 & 8 |
| Right | 4 & 7; 1, 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 8)- (Scheme 9). |
POWER MIRROR SWITCH CONTINUITY TEST (LAND CRUISER)
Scheme 8
Scheme 9
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 10)- (Scheme 11). |
POWER MIRROR SWITCH CONTINUITY TEST (RAV4)
Scheme 10
Scheme 11
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. see scheme 14- (Scheme 12). |
| (1) | Continuity should exist between specified terminals. see scheme 14- (Scheme 12). |
POWER MIRROR SWITCH CONTINUITY TEST (SIENNA)
Scheme 12
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 2 & 3; 1 & 7 |
| Down | 1 & 2; 3 & 7 |
| Left | 2 & 3; 1 & 8 |
| Right | 1 & 2; 3 & 8 |
| Switch In Right Position |
| Up | 2 & 3; 1 & 5 |
| Down | 1 & 2; 3 & 5 |
| Left | 2 & 3; 1 & 6 |
| Right | 1 & 2; 3 & 6 |
| (1) Continuity should exist between specified terminals. (Scheme 13)- (Scheme 14). |
POWER MIRROR SWITCH CONTINUITY TEST (TACOMA)
Scheme 13
Scheme 14
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 4 & 8; 6 & 7 |
| Down | 4 & 7; 6 & 8 |
| Left | 5 & 8; 6 & 7 |
| Right | 5 & 7; 6 & 8 |
| Switch In Right Position |
| Up | 3 & 8; 6 & 7 |
| Down | 3 & 7; 6 & 8 |
| Left | 5 & 8; 6 & 7 |
| Right | 5 & 7; 6 & 8 |
| (1) Continuity should exist between specified terminals. (Scheme 15)- (Scheme 16). |
POWER MIRROR SWITCH CONTINUITY TEST (TUNDRA)
Scheme 15
Scheme 16
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. see scheme 21- (Scheme 17). |
| (1) | Continuity should exist between specified terminals. see scheme 21- (Scheme 17). |
POWER MIRROR SWITCH CONTINUITY TEST (4RUNNER)
Scheme 17
POWER MIRROR MOTOR
Note. Mirror motor connectors may vary in configuration from vehicle to vehicle of the same model.
Disconnect power mirror motor harness connector. Using a 12-volt power source, connect positive and negative leads to specified pins or terminals. See appropriate POWER MIRROR MOTOR TEST table. (Scheme 1)- (Scheme 17). If power mirror motor fails any test, replace power mirror assembly.
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 2 | Up |
| 2 | 3 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
| (1) (Scheme 2)or see scheme 9. |
POWER MIRROR MOTOR TEST (AVALON, CELICA & COROLLA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 1 | 2 | Up |
| 2 | 1 | Down |
| 3 | 2 | Left |
| 2 | 3 | Right |
| (1) (Scheme 4) |
POWER MIRROR MOTOR TEST (CAMRY - WITH HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 2 | Up |
| 2 | 3 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
| (1) (Scheme 5) |
POWER MIRROR MOTOR TEST (CAMRY - WITHOUT HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 1 | 2 | Up |
| 2 | 1 | Down |
| 3 | 2 | Left |
| 2 | 3 | Right |
| (1) (Scheme 6) |
POWER MIRROR MOTOR TEST (CAMRY - WITH HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 4 | Up |
| 4 | 3 | Down |
| 3 | 4 | Left |
| 4 | 2 | Right |
| (1) (Scheme 7) |
POWER MIRROR MOTOR TEST (CAMRY SOLARA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 8 | 7 | Left |
| 7 | 8 | Right |
| 6 | 7 | Up |
| 7 | 6 | Down |
| (1) (Scheme 9) |
POWER MIRROR MOTOR TEST (LAND CRUISER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 1 | Right |
| 1 | 3 | Left |
| 3 | 5 | Down |
| 5 | 3 | Up |
| (1) (Scheme 24) |
POWER MIRROR MOTOR TEST (RAV4)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 3 | Left |
| 3 | 2 | Right |
| 2 | 1 | Up |
| 1 | 2 | Down |
| (1) see scheme 15or (Scheme 12). |
POWER MIRROR MOTOR TEST (SIENNA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 1 | Up |
| 1 | 2 | Down |
| 3 | 1 | Left |
| 1 | 3 | Right |
| (1) (Scheme 14) |
POWER MIRROR MOTOR TEST (TACOMA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 1 | Up |
| 1 | 2 | Down |
| 3 | 1 | Left |
| 1 | 3 | Right |
| (1) (Scheme 16) |
POWER MIRROR MOTOR TEST (TUNDRA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 5 | 4 | Up |
| 4 | 5 | Down |
| 1 | 4 | Left |
| 4 | 1 | Right |
| (1) (Scheme 16) |
POWER MIRROR MOTOR TEST (4RUNNER)
Note. Power mirror switch removal and installation procedures are not available from manufacturer.
Power Mirror System Wiring Diagram (Avalon). Scheme 18
Scheme 18: Power Mirror System Wiring Diagram (Avalon)
Power Mirror System Wiring Diagram (Camry). Scheme 19
Scheme 19: Power Mirror System Wiring Diagram (Camry)
Power Mirror System Wiring Diagram (Camry Solara). Scheme 20
Scheme 20: Power Mirror System Wiring Diagram (Camry Solara)
Power Mirror System Wiring Diagram (Celica). Scheme 21
Scheme 21: Power Mirror System Wiring Diagram (Celica)
Power Mirror System Wiring Diagram (Corolla). Scheme 22
Scheme 22: Power Mirror System Wiring Diagram (Corolla)
Power Mirror System Wiring Diagram (Land Cruiser). Scheme 23
Scheme 23: Power Mirror System Wiring Diagram (Land Cruiser)
Power Mirror System Wiring Diagram (RAV4). Scheme 24
Scheme 24: Power Mirror System Wiring Diagram (RAV4)
Power Mirror System Wiring Diagram (Sienna). Scheme 25
Scheme 25: Power Mirror System Wiring Diagram (Sienna)
Power Mirror System Wiring Diagram (Tacoma). Scheme 26
Scheme 26: Power Mirror System Wiring Diagram (Tacoma)
Power Mirror System Wiring Diagram (2000 Tundra). Scheme 27
Scheme 27: Power Mirror System Wiring Diagram (2000 Tundra)
Power Mirror System Wiring Diagram (4Runner - With Power Windows). Scheme 28
Scheme 28: Power Mirror System Wiring Diagram (4Runner - With Power Windows)
Power Mirror System Wiring Diagram (4Runner - Without Power Windows). Scheme 29
