SHIFT LOCK SYSTEM
With ignition on, when brake pedal is depressed, an input signal is sent from brakelight switch to ECU. With shift lever in Park, an input signal from shift control switch is input to ECU, indicating shift lever is in Park. ECU then operates shift lock solenoid, so shift lever can be moved from Park.
KEY LOCK SYSTEM
With ignition in ON or ACC position and shift lever in Park, shift lock control switch opens and voltage from ECU to key interlock solenoid is turned off. When key interlock solenoid is turned off, ignition key can be turned from ACC to LOCK position on ignition switch.
COMPONENT TESTS
Note. If ignition is left in ACC or ON position with shift lever in any gear range except Park for about one hour, ECU then operates to release lock mechanism.
ELECTRONIC CONTROL UNIT (ECU)
Access ECU. see scheme 1 ECU is under center console, in front or back of shifter. Turn ignition on. Backprobing ECU harness connector with DVOM, check voltage between designated terminals. Voltage should be as specified. See appropriate SHIFT LOCK SYSTEM PIN VOLTAGES table. For circuit identification, see appropriate wiring diagram in WIRING DIAGRAMS.
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| IG - GND | Ignition Switch In ON Position | 10-14 | |
| STP - GND | Depress Brake Pedal | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| KLS - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 7.5-11.5 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 6-9 | |
| Shift Lock Solenoid | |||
| SLS+ - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| SLS+ - GND | Depress Brake Pedal | 8-13.5 | |
| SLS+ - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| Shift Lock Control Switch | |||
| P1 - P | Ignition Switch ON, Shifter In "P" Position, Depress Brake Pedal | 0 | |
| P1 - P | Ignition Switch In ON, Shifter Not In "P" Position | 9-13.5 | |
| P2 - P | Ignition Switch In ACC, Shifter In "P" Position | 9-13.5 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (AVALON, CAMRY, CAMRY SOLARA, COROLLA, ES300 & RX300)
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| IG - GND | Ignition Switch In ON Position | 10-14 | |
| STP - GND | Depress Brake Pedal | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| KLS - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 10-14 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 6-9 | |
| Shift Lock Solenoid | |||
| SLS+ - SLS | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| SLS+ - SLS | Depress Brake Pedal | 8-13.5 | |
| SLS+ - SLS | Depress Brake Pedal, (After 20 Seconds) | 5.5-9.5 | |
| SLS+ - SLS | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| Shift Lock Control Switch | |||
| P1 - P | Ignition Switch In ON Position, Shifter In "P" Position, Depress Brake Pedal | 0 | |
| P1 - P | Ignition Switch In ON, Shifter Not In "P" Position | 9-13.5 | |
| P2 - P | Ignition Switch In ACC, Shifter In "P" Position | 9-13.5 | |
| P2 - P | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (CELICA, LAND CRUISER, LX470 & TACOMA)
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| ACC - GND | Ignition Switch In ON Position | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 6-9 | |
| SLS+ - GND | Ignition Switch In ON, Shifter In "P" Position | 0 | |
| SLS+ - GND | Ignition Switch In ON, Depress Brake Pedal | 3-6 | |
| SLS+ - GND | Ignition Switch In ON, Release Brake Pedal | 0 | |
| SLS+ - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 3-6 | |
| P1 - GND | Shifter In "P" Position | 0 | |
| P1 - GND | Shifter Not In "P" Position | 10-14 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (GS300 & GS400)
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| IG - GND | Ignition Switch In ON Position | 10-14 | |
| STP - GND | Depress Brake Pedal | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 1.5 Or Less | |
| KLS - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 8.5-10.5 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 7-8.5 | |
| Shift Lock Solenoid | |||
| SLS+ - SLS | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| SLS+ - SLS | Depress Brake Pedal | 8.8-12.5 | |
| SLS+ - SLS | Depress Brake Pedal, (After 20 Seconds) | 6.5-9.2 | |
| SLS+ - SLS | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| Shift Lock Control Switch | |||
| P1 - P | Ignition Switch In ON Position, Shifter In "P" Position, Depress Brake Pedal | 0 | |
| P1 - P | Ignition Switch In ON, Shifter Not In "P" Position | 10-14 | |
| P2 - P | Ignition Switch In ACC, Shifter In "P" Position | 10-14 | |
| P2 - P | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (LS400)
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| IG - GND | Ignition Switch In ON Position | 10-14 | |
| STP - GND | Depress Brake Pedal | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| KLS - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 8-13.5 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 6-8.5 | |
| Shift Lock Solenoid | |||
| SLS+ - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| SLS+ - GND | Depress Brake Pedal | 8-14 | |
| SLS+ - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| Shift Lock Control Switch | |||
| P1 - P | Ignition Switch In ON Position, Shifter In "P" Position, Depress Brake Pedal | 0 | |
| P1 - P | Ignition Switch In ON, Shifter Not In "P" Position | 10-14 | |
| P2 - P | Ignition Switch In ACC, Shifter In "P" Position | 10-14 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (RAV4)
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| IG - GND | Ignition Switch In ON Position | 10-14 | |
| STP - GND | Depress Brake Pedal | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 1.5 Or Less | |
| KLS - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 8.5-10.5 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 6.5-8.5 | |
| Shift Lock Solenoid | |||
| SLS+ - SLS | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| SLS+ - SLS | Depress Brake Pedal | 8.0-12.5 | |
| SLS+ - SLS | Depress Brake Pedal, (After 20 Seconds) | 6.5-9.2 | |
| SLS+ - SLS | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| Shift Lock Control Switch | |||
| P1 - P | Ignition Switch In ON Position, Shifter In "P" Position, Depress Brake Pedal | 0 | |
| P1 - P | Ignition Switch In ON, Shifter Not In "P" Position | 10-14 | |
| P2 - P | Ignition Switch In ACC, Shifter In "P" Position | 10-14 | |
| P2 - P | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (SC300 & SC400)
Note. Ground (GND) terminal is also referred to as "E" terminal.
| Application & Terminals | Description | Voltage | |
|---|---|---|---|
| ECU | |||
| ACC - GND | Ignition Switch In ACC Position | 10-14 | |
| IG - GND | Ignition Switch In ON Position | 10-14 | |
| STP - GND | Depress Brake Pedal | 10-14 | |
| KLS - GND | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| KLS - GND | Ignition Switch In ACC, Shifter Not In "P" Position | 7.5-11 | |
| KLS - GND | (1) Ignition Switch In ACC, Shifter Not In "P" Position | 6-9.5 | |
| Shift Lock Solenoid | |||
| SLS+ - SLS | Ignition Switch In ACC, Shifter In "P" Position | 0 | |
| SLS+ - SLS | Depress Brake Pedal | 8-13.5 | |
| SLS+ - SLS | Depress Brake Pedal (After 20 Seconds) | 6-8.5 | |
| SLS+ - SLS | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| Shift Lock Control Switch | |||
| P1 - P | Ignition Switch In ON Position, Shifter In "P" Position, Depress Brake Pedal | 0 | |
| P1 - P | Ignition Switch In ON, Shifter Not In "P" Position | 9-13.5 | |
| P2 - P | Ignition Switch In ACC, Shifter In "P" Position | 9-13.5 | |
| P2 - P | Ignition Switch In ACC, Shifter Not In "P" Position | 0 | |
| (1) Voltage measurement after one second. | |||
| (1) | Voltage measurement after one second. |
SHIFT LOCK SYSTEM PIN VOLTAGES (4RUNNER)
SHIFT LOCK SOLENOID
- Disconnect electrical connector from shift lock solenoid. Using ohmmeter, measure resistance between shift lock solenoid terminals. See «WIRING DIAGRAMS»(ref-9478-S08724358592000102700000) .
- Replace shift lock solenoid if resistance is not within specification. See «SHIFT LOCK SOLENOID RESISTANCE SPECIFICATIONS»(ref-9478-S04588750382000102700000) table. Apply battery voltage between shift lock solenoid terminals. Replace shift lock solenoid if operating sound cannot be heard.
| Application | Ohms |
|---|---|
| Avalon, Camry, Camry Solara & Tacoma (A43D) | 30-35 |
| Celica, Corolla, GS300, GS400 & 4Runner | 21-27 |
| ES300 & RX300 | 29-36 |
| Land Cruiser, LS400, LX470, SC300, SC400 & Tacoma (A-340E/F) | 20-28 |
| RAV4 | 26-33 |
SHIFT LOCK SOLENOID RESISTANCE SPECIFICATIONS
KEY INTERLOCK SOLENOID
- Disconnect electrical connector from key interlock solenoid. Using ohmmeter, measure resistance between key interlock solenoid terminals. See «WIRING DIAGRAMS»(ref-9478-S08724358592000102700000) .
- Replace key interlock solenoid if resistance is not 12-17 ohms. Apply battery voltage between of key interlock solenoid terminals. Replace key interlock solenoid if operating sound cannot be heard.
SHIFT LOCK CONTROL SWITCH
Disconnect electrical connector from shift lock control switch. Using ohmmeter, check continuity between specified terminals in relation to shift lever. See WIRING DIAGRAMS . See SHIFT LOCK CONTROL SWITCH CONTINUITY table. Replace switch if continuity is not as specified.
Note. Continuity must be checked in accordance with position of release button on shift lever and shift lever position.
| Shift Lever Position & Condition | Terminals |
|---|---|
| Any Other Gear Except Park | P & P2 |
| Park & Release Button Not Pushed | P & P1 |
| Park & Release Button Is Pushed | P & P1 Or P & P2 |
SHIFT LOCK CONTROL SWITCH CONTINUITY
Sienna
Ensure shift lock cable does not interfere with wiring harness. Ensure ignition switch turns to LOCK position when shift lever is in "P" position. Ensure brake pedal returns fully. Ensure shift lock is released when brake pedal is depressed with ignition switch at ACC, ON or START position.
Place shift lever in "P" position. Turn ignition switch to LOCK position. Loosen 2 bolts and ensure pedal button touches pedal plate cushion. Tighten 2 bolts to 97 INCH lbs. (11 N.m).
