RIDING HEIGHT ADJUSTMENT
Note. On Supra with electronic chassis controls, ensure all systems are functional before adjusting riding height or wheel alignment.
Before adjusting alignment, check riding height. Riding height must be checked with vehicle on level floor and tires properly inflated. Bounce vehicle several times, and allow suspension to settle.
Visually inspect vehicle for signs of abnormal height from front to rear or side to side. Check passenger and luggage compartments for extra heavy items, and remove them if present. If riding height is not within specification, check, repair or replace suspension components. See RIDING HEIGHT SPECIFICATIONS .
Camry, Celica (FWD) & Corolla
Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of strut rod mounting bolt. Strut rod is parallel to side body panel.
Celica All-Trac
Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of body side No. 2 suspension arm mounting bolt.
Cressida & Supra
Measure front riding height from ground to center of lower suspension arm mounting bolt. Measure rear riding height from ground to center of No. 2 lower suspension arm mounting bolt.
Land Cruiser
Measure front riding height from ground to center of leading arm bushing bolt/nut. Measure rear riding height from ground to center of lower arm forward mounting bolt.
MR2
Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of lower arm inboard mounting nut.
Pickup (2WD)
Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of front leaf spring mounting bolt. (Scheme 1)
Scheme 1
Pickup (4WD) & 4Runner
- Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of front leaf spring. (Scheme 1) To check for standard height differential, go to next step.
- Measure front riding height differential by comparing height at center tip of spindle to height at center of lower arm adjustment cam bolt. Difference between measurements should be 2.303" (58.50 mm).
- Measure rear riding height differential by comparing height at center of front leaf spring mounting bolt to height at centerline of rear axle shaft. On Pickup (4WD), difference between measurements should be 2.402" (61.00 mm). On 4Runner, difference between measurements should be 1.403" (26.50 mm).
Previa
Measure front riding height from ground to center of lower arm mounting bolt. Measure rear riding height from ground to center of rear lower control arm forward mounting bolt.
Tercel
Measure front riding height from ground to center of lower arm mounting bolt/nut. Measure rear riding height from ground to center of trailing arm forward mounting bolt. Trailing arm is parallel to side body panel.
RIDING HEIGHT SPECIFICATIONS
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| All-Trac | 9.09 (231) | 10.16 (258) |
| FWD |
| 4-Cylinder |
| Sedan | 9.09 (231) | 10.31 (262) |
| Wagon | 9.02 (229) | 11.50 (292) |
| V6 |
| Sedan | 8.86 (225) | 10.08 (256) |
| Wagon | 8.78 (223) | 11.26 (286) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (CAMRY)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| All-Trac | 7.39 (188) | 9.32 (237) |
| FWD | 7.28 (185) | 9.90 (251) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (CELICA)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| All-Trac | 8.31 (211) | 9.53 (242) |
| FWD |
| Coupe |
| P155/80R13 | 7.09 (180) | 9.41 (239) |
| P175/70R13 | 7.13 (181) | 9.45 (240) |
| 185/60R1482H | 6.93 (176) | 9.33 (237) |
| Except Coupe |
| P155/80R13 | 7.20 (183) | 9.57 (243) |
| P175/70R13 | 7.24 (184) | 9.61 (244) |
| 185/60R1482H | 6.93 (176) | 9.33 (237) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (COROLLA)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| Cressida | 9.25 (235) | 9.80 (249) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (CRESSIDA)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| MR2 | 8.82 (224) | 7.99 (203) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (MR2)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| Supra | 7.82 (199) | 8.72 (221) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (SUPRA)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| P145/80R13 | 7.28 (185) | 9.76 (248) |
| P155/80R13 | 7.56 (192) | 11.22 (285) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (TERCEL)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| P235/75R15 Tire | 13.19 (335) | 13.19 (335) |
| 10.50R15 LT Tire | 14.19 (360) | 14.19 (360) |
| (1) Riding height will vary depending on tire size used. |
| (1) | Riding height will vary depending on tire size used. |
RIDING HEIGHT SPECIFICATIONS (LAND CRUISER)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| 4-Cylinder |
| Standard Reg. Cab, Short Chassis | 10.23 (260) | 10.55 (268) |
| DLX (Deluxe) |
| Regular Cab |
| Short Chassis | 10.12 (257) | 10.35 (263) |
| Long Chassis |
| 5-Speed M/T | 10.35 (263) | 10.28 (261) |
| 4-Speed A/T | 10.31 (262) | 10.28 (261) |
| Xtra Cab, Xtra Long Chassis | 10.94 (278) | 10.39 (264) |
| V6 |
| Standard C x C DRW (2) |
| Long Chassis |
| 5-Speed M/T | 10.20 (259) | 9.21 (234) |
| 4-Speed A/T | 10.24 (260) | 9.25 (235) |
| Super Long Chassis | 10.20 (259) | 9.13 (232) |
| DLX (Deluxe) |
| Reg. Cab, Long Chassis |
| 5-Speed M/T | 10.24 (260) | 11.18 (284) |
| 4-Speed A/T | 10.16 (258) | 11.14 (283) |
| Xtra Cab, Xtra Long Chassis |
| 5-Speed M/T | 10.91 (277) | 10.47 (266) |
| 4-Speed A/T | 10.91 (277) | 10.43 (265) |
| SR5 |
| Xtra Cab, Xtra Long Chassis |
| P205/75R14 | 10.75 (273) | 10.31 (262) |
| P215/65R15 | 10.79 (274) | 10.31 (262) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. (2) C & C DRW is Cab and Chassis with Dual Rear Wheels. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (2) | C & C DRW is Cab and Chassis with Dual Rear Wheels. |
RIDING HEIGHT SPECIFICATIONS (PICKUP 2WD)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| 4-Cylinder |
| DLX (Deluxe) Reg. Cab |
| Standard Chassis |
| A/T | 11.08 (281) | 16.73 (425) |
| M/T | 11.09 (282) | 16.81 (427) |
| Long Chassis |
| M/T Type "W" | 11.26 (286) | 16.83 (427) |
| M/T Type "G" | 11.24 (285) | 16.83 (427) |
| DLX Xtra Cab |
| Xtra Long Chassis |
| A/T | 11.47 (291) | 16.54 (420) |
| M/T Type "W" | 11.50 (292) | 16.66 (423) |
| M/T Type "G" | 11.47 (291) | 16.66 (423) |
| V6 |
| DLX Reg. Cab |
| Standard Chassis |
| P225/75R15 | 11.00 (279) | 16.63 (422) |
| 31 X 10.5R15LT | 12.24 (311) | 17.88 (454) |
| Long Chassis |
| P225/75R15 | 11.17 (284) | 16.63 (422) |
| 31 X 10.5R15LT | 12.41 (315) | 17.88 (454) |
| DLX Xtra Cab |
| Xtra Long Chassis (A/T) |
| P225/75R15 | 11.39 (289) | 16.43 (417) |
| 31 X 10.5R15LT | 12.64 (321) | 17.68 (449) |
| Xtra Long Chassis (M/T) |
| P225/75R15 | 11.41 (290) | 16.45 (418) |
| 31 X 10.5R15LT | 12.65 (321) | 17.73 (450) |
| SR5 Xtra Cab |
| Xtra Long Chassis (A/T) |
| P225/75R15 | 11.13 (282) | 16.30 (414) |
| 31 X 10.5R15LT | 12.37 (314) | 17.54 (446) |
| Xtra Long Chassis (M/T) |
| P225/75R15 | 11.15 (283) | 16.36 (416) |
| 31 X 10.5R15LT | 12.39 (314) | 17.61 (447) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (PICKUP 4WD)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| 2WD |
| P205/75R14 | 9.53 (242) | 11.06 (281) |
| P215/65R15 | 9.45 (240) | 10.98 (279) |
| 4WD |
| P205/75R14 | 9.92 (252) | 11.46 (291) |
| P215/65R15 | 9.84 (250) | 11.38 (289) |
| (1) Riding height will vary depending on tire size used. |
| (1) | Riding height will vary depending on tire size used. |
RIDING HEIGHT SPECIFICATIONS (PREVIA)
| Application (1) | Front In. (mm) | Rear In. (mm) |
|---|
| 2WD |
| SR5 4-Door A/T |
| 4-Cylinder | 11.17 (284) | 13.04 (331) |
| V6 | 11.14 (283) | 12.94 (329) |
| 4WD |
| SR5 4-Cylinder |
| 2-Door |
| A/T | 11.15 (283) | 12.83 (326) |
| M/T | 11.18 (284) | 12.87 (327) |
| 4-Door |
| A/T | 11.15 (283) | 12.78 (325) |
| M/T | 11.17 (284) | 12.81 (325) |
| SR5 V6 |
| 2-Door |
| A/T |
| P225/75R15 | 10.98 (279) | 12.96 (329) |
| 31 X 10.5R15LT | 12.19 (310) | 14.15 (359) |
| M/T |
| P225/75R15 | 11.00 (280) | 13.01 (330) |
| 31 X 10.5R15LT | 12.21 (310) | 14.19 (360) |
| 4-Door |
| A/T |
| P225/75R15 | 10.95 (278) | 13.12 (333) |
| 31 X 10.5R15LT | 12.16 (309) | 14.29 (363) |
| M/T |
| P225/75R15 | 10.98 (279) | 13.14 (334) |
| 31 X 10.5R15LT | 12.19 (310) | 14.03 (356) |
| (1) Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
| (1) | Riding height will vary depending on tire size used. Recommended tire size are available for some models. |
RIDING HEIGHT SPECIFICATIONS (4RUNNER)
Camry, Celica & Corolla
To raise vehicle, place floor jack under center of front longitudinal engine crossmember. For rear of FWD models, place floor jack under rear suspension crossmember. For rear of All-Trac models, place floor jack under rear differential support member.
To raise vehicle, place floor jack under front suspension crossmember and under rear differential carrier.
Place floor jack under front/rear differential to raise vehicle.
To raise vehicle, place floor jack under front undercover support and under rear suspension crossmember.
Pickup, Previa & 4Runner
To raise vehicle, place floor jack under front suspension crossmember and under rear axle housing/differential.
To raise vehicle, place floor jack under front crossmember and under center of rear axle beam.
Camry, Celica, Corolla, Cressida, MR2, Supra & Tercel
Place emergency jack on reinforced support points of side body panel (between front and rear wheels). Safety stands may also be placed at these points. (Scheme 2)or (Scheme 3).
Scheme 2
Scheme 2: Camry, Celica, Corolla, Cressida, MR2, Supra & Tercel
Scheme 3
To raise vehicle, place emergency jack under front/rear axle.
Pickup & 4Runner
Place emergency jack under front suspension crossmember and under rear axle housing/differential.
To raise vehicle, place emergency jack under frame support points between front and rear wheels.
Place lift blocks on reinforced support points of side body panel (between front and rear wheels). Safety stands may also be placed at these points. (Scheme 2)or (Scheme 3).
Place lift blocks under front/rear axle to raise vehicle.
On 2WD models, place lift blocks under frame side rail and under rear axle housing to raise vehicle. On 4WD models, place lift blocks under front suspension crossmember and under rear axle housing to raise vehicle.
Place lift blocks under frame side rail supports.
TURNING ANGLE
On Land Cruiser, Pickup, Previa and 4Runner, remove steering knuckle stopper bolts. On all models, turn steering wheel fully to the right and then left, and observe turning radius on both wheels. If turning radius is incorrect, inspect and replace any damaged or worn front suspension components. See WHEEL ALIGNMENT SPECIFICATIONS .
Front Suspension (Camry, Celica, Corolla, Cressida, Land Cruiser, MR2, Previa & Tercel)
- Check tires for wear and improper inflation. Check front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed .039" (1 mm).
- Check front suspension components for looseness. Ensure front shock absorbers work properly. Check vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures__riding-height-adjustment) .
- Check camber of both front wheels. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) . If camber is not within specification, inspect and replace any damaged or worn front suspension components. Camber is NOT adjustable.
Front Suspension (Pickup & 4Runner)
- Check tires for wear and improper inflation. Check front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed.047" (1.2 mm).
- Check front suspension components for looseness. Ensure front shock absorbers work properly. Check vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures__riding-height-adjustment).
- Check camber of both front wheels. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If camber is not within specification, add or remove shims on upper control arms on 2WD models. On 4WD models, loosen and turn adjustment cams. (Scheme 4)
Scheme 4
Front Suspension (Supra)
- Check tires for wear and improper inflation. Check front wheel bearings for looseness. Check wheel runout. Wheel runout should not exceed.047" (1.2 mm).
- Check front suspension components for looseness. Ensure front shock absorbers work properly. Check vehicle riding height. See «RIDING HEIGHT ADJUSTMENT»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures__riding-height-adjustment).
- Check camber of both front wheels. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If camber is not within specification, loosen and turn adjustment cams. (Scheme 5)
Scheme 5
Rear Suspension (Camry, Celica, Corolla FWD & MR2)
Check tires for wear and improper inflation. Check camber of both rear wheels. See WHEEL ALIGNMENT SPECIFICATIONS . If camber is not within specification, inspect and replace any damaged or worn rear suspension components. Camber is NOT adjustable.
Rear Suspension (Cressida & Supra)
Check tires for wear and improper inflation. Ensure left and right lengths of No. 1 and No. 2 lower suspension arms are equal. (Scheme 6) Check camber of both rear wheels. See WHEEL ALIGNMENT SPECIFICATIONS. If camber is not within specification, adjust camber by turning adjustment cams. (Scheme 6)
Scheme 6
Scheme 6: Rear Suspension (Cressida & Supra)
Except Supra
Ensure riding height and camber are correctly set. See WHEEL ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Check steering axis inclination of both front wheels. If steering axis inclination is not within specification, inspect and replace any damaged or worn front suspension components. See WHEEL ALIGNMENT SPECIFICATIONS . Steering axis/king pin inclination is NOT adjustable.
Supra
Ensure riding height, camber and caster are correctly set. See WHEEL ALIGNMENT SPECIFICATIONS . If adjustment is necessary, see appropriate adjustment procedure. Check steering axis inclination of both front wheels. If steering axis inclination is not within specification, inspect wheel bearing for looseness, or replace steering knuckle. See WHEEL ALIGNMENT SPECIFICATIONS .
Front Suspension (Camry & Cressida)
- Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) . If adjustment is necessary, see appropriate adjustment procedure.
- Check caster of both front wheels. If caster is not within specification, add or remove spacers on stabilizer bar (strut rod on Cressida). DO NOT use more than 2 spacers to adjust caster.
Front Suspension (Celica, Corolla, Land Cruiser, Previa & Tercel)
- Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) . If adjustment is necessary, see appropriate adjustment procedure.
- Check caster of both front wheels. If caster is not within specification, inspect and replace any damaged or worn front suspension components. Caster is NOT adjustable.
Front Suspension (MR2)
- Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If adjustment is necessary, see appropriate adjustment procedure.
- Check caster of both front wheels. If caster is not within specification, loosen strut bar front nut, and adjust camber adjusting nut. (Scheme 7) Tighten strut bar front nut after adjustment.
Scheme 7
- Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If adjustment is necessary, see appropriate adjustment procedure.
- Check caster of both front wheels. If caster is not within specification, add or remove shims on upper control arms on 2WD models. DO NOT use more than 2 shims to adjust caster. On 4WD models, loosen and turn adjustment cams. (Scheme 4)
- Ensure riding height, camber and steering axis inclination are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If adjustment is necessary, see appropriate adjustment procedure.
- Check caster of both front wheels. If caster is not within specification, loosen and turn adjustment cams. (Scheme 5)
Front Suspension (All Models)
- Ensure riding height, camber, steering axis inclination and caster are correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) . Ensure steering wheel is in straight-ahead position. Bounce both ends of vehicle several times to settle suspension.
- Measure toe-in. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) for specification. If necessary, adjust toe-in by varying length of tie rods.
Rear Suspension (Camry, Celica & Corolla FWD)
- Ensure rear camber is correctly set. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If adjustment is necessary, see appropriate adjustment procedure.
- Bounce both ends of vehicle several times to settle suspension. Measure distance between each wheel rim and corner of cam bracket to ensure both distances are the same. (Scheme 8)or (Scheme 9).
- Ensure toe-in is within specification. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). If necessary, adjust toe-in by turning adjustment cams.
Scheme 8
Scheme 9
- Ensure rear camber is correctly set. See «CAMBER ADJUSTMENT»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) under WHEEL ALIGNMENT PROCEDURES. Bounce both ends of vehicle several times to settle suspension.
- Measure toe-in. If toe-in is not within specification, adjust by turning adjustment cam. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). (Scheme 6)
Rear Suspension (MR2)
- Ensure rear camber is correct. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) . If adjustment is necessary, see appropriate adjustment procedure.
- Bounce both ends of vehicle several times to settle suspension. Measure rear wheel toe-in. See «WHEEL ALIGNMENT SPECIFICATIONS»(/toyota/4runner/ii-1987-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) . If necessary, adjust rear toe-in by rotating rear tie rod sleeves.
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front |
| Sedan FWD | 9/16 | 3/16 To 1 5/16 |
| Wagon FWD | 1/2 | 1/4 To 1 1/4 |
| Rear |
| Sedan FWD | 9/16 | 1 1/16 To -1/16 |
| Wagon FWD | 1/16 | 9/16 To 7/16 |
| All-Trac | 1/2 | 1 To 0 |
| Caster (1) |
| Sedan | 1 11/16 | 1 3/16 To 2 3/16 |
| Wagon | 1 | 1/2 To 1 1/2 |
| Steering Axis Inclination (1) |
| Sedan | 12 3/4 | 12 To 13 1/2 |
| Wagon | 12 27/32 | 12 3/32 To 13 19/32 |
| Toe-In (2) |
| Front | 1/32 (1) | 0 To 3/32 (0 To 2) |
| Rear | 5/32 (4) | 1/8 To 3/16 (3 To 5) |
| Toe-In (1) |
| Front | 1/16 | 0 To 3/16 |
| Rear | 5/16 | 1/4 To 3/8 |
| Toe-Out On Turns (1) |
| 4-Cylinder |
| Inner | 37 1/2 | N/A |
| Outer | 30 3/4 | N/A |
| V6 |
| Inner | 35 3/4 | N/A |
| Outer | 29 3/4 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (CAMRY)
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 5/32 | 29/32 To 19/32 |
| Rear | 3/4 | 1 1/4 To -1/4 |
| Caster (1) |
| All-Trac | 27/32 | 3/32 To 1 19/32 |
| Except All-Trac | 29/32 | 5/32 To 1 21/32 |
| Steering Axis Inclination (1) | 14 5/32 | 13 13/32 To 14 29/32 |
| Toe-In (2) |
| Front | 0 (0) | 3/32 To 3/32 (-2 To 2) |
| Rear | 3/16 (5) | 3/32 To 9/32 (3 To 7) |
| Toe-In (1) |
| Front | 0 | 3/16 To 3/16 |
| Rear | 3/8 | 3/16 To 9/16 |
| Toe-Out On Turns (1) |
| Inner | 33 1/2 | N/A |
| Outer | 29 1/2 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (CELICA)
| Application | Preferred | Range |
|---|
| Camber (1) |
| All-Trac | 3/16 | 5/16 To 11/16 |
| Except All-Trac |
| Front | 3/16 | 7/8 To 1/2 |
| Rear | 11/16 | 1 3/8 To 0 |
| Caster (1) |
| All-Trac | 1 1/4 | 3/4 To 1 3/4 |
| Except All-Trac | 1 7/16 | 3/4 To 2 1/8 |
| Steering Axis Inclination (1) |
| 2WD (4A-FE) | 12 21/32 | 11 29/32 To 13 13/32 |
| 2WD (4A-GE) | 12 27/32 | 12 3/32 To 13 19/32 |
| 4WD | 12 3/32 | 11 19/32 To 12 19/32 |
| Toe-In (2) |
| Front | 1/32 (1) | 0 To 1/16 (0 To 2) |
| Rear | 5/32 (4) | 1/8 To 3/16 (3 To 5) |
| Toe-In (1) |
| Front | 1/16 | 0 To 1/8 |
| Rear | 5/16 | 1/4 To 3/8 |
| Toe-Out On Turns (1) |
| All-Trac |
| Inner | 38 | N/A |
| Outer | 32 | N/A |
| Except All-Trac |
| Inner | 37 | N/A |
| Outer | 32 1/2 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (COROLLA)
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 1/2 | 1/4 To 1 1/4 |
| Rear | 0 | 3/4 To 3/4 |
| Caster (1) | 7 5/16 | 6 13/16 To 7 13/16 |
| Steering Axis Inclination (1) | 13 5/32 | 12 13/32 To 13 29/32 |
| Toe-In (2) |
| Front | 1/16 (2) | 1/32 To 3/32 (1 To 3) |
| Rear | 1/16 (2) | 0 To 5/32 (0 To 4) |
| Toe-In (1) |
| Front | 1/8 | 1/16 To 3/16 |
| Rear | 1/8 | 0 To 5/16 |
| Toe-Out On Turns (1) |
| Inner | 41 7/16 | N/A |
| Outer | 34 1/4 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (CRESSIDA)
| Application | Preferred | Range |
|---|
| Camber (1) (Front) | 1 | 1/4 To 1 1/4 |
| Caster (1) |
| P235/75R | 3 | 2 To 4 |
| 31 x 10.50R LT | 1 21/32 | 21/32 To 2 21/32 |
| Steering Axis Inclination (1) | 13 1/2 | 12 3/4 To 14 1/4 |
| Toe-In (2) | 1/32 (1) | 1/32 To 1/8 (-1 To 3) |
| Toe-In (1) | 1/16 | 1/16 To 7/32 |
| Toe-Out On Turns (1) |
| Inner | 35 | N/A |
| Outer | 30 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (LAND CRUISER)
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 15/16 | 1 7/16 To -7/16 |
| Rear | 1 11/32 | 1 27/32 To -27/32 |
| Caster (1) | 2 3/4 | 2 3/4 To 3 1/4 |
| Steering Axis Inclination (1) | 13 1/2 | 13 To 14 |
| Toe-In (2) |
| Front | 1/32 (1) | 0 To 3/32 (0 To 2) |
| Rear | 3/16 (5) | 5/32 To 1/4 (4 To 6) |
| Toe-In (1) |
| Front | 1/16 | 0 To 3/16 |
| Rear | 3/8 | 5/16 To 1/2 |
| Toe-Out On Turns (1) |
| Inner | 37 1/2 | N/A |
| Outer | 32 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (MR2)
| Application | Preferred | Range |
|---|
| 4-Cylinder |
| STD, Reg. Cab |
| Short Chassis |
| Camber (1) | 1/2 | 1/4 To 1 1/4 |
| Caster (1) | 21/32 | 0 To 1 1/2 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 1/16 (1.5) | 1/32 To 1/8 (-1 To 3) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| DLX, Reg. Cab |
| Short Chassis |
| Camber (1) | 1/2 | 1/4 To 1 1/4 |
| Caster (1) | 23/32 | 0 To 1 1/2 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 1/16 (1.5) | 1/32 To 1/8 (-1 To 3) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| Long Chassis |
| Camber (1) | 1/2 | 1/4 To 1 1/4 |
| Caster (1) | 1 | 1/4 To 1 3/4 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| DLX, Xtra Cab |
| Xtra Long Chassis |
| Camber (1) | 3/8 | 3/8 To 1 1/8 |
| Caster (1) | 1 1/4 | 1/2 To 2 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 1/8 (3) | 1/16 To 3/16 (1 To 5) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| V6 |
| Standard |
| C & C DRW (3) |
| Camber (1) | 1/2 | 1/4 To 1 1/4 |
| Caster (1) | 1 3/4 | 1 To 2 1/2 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 7/32 (5.5) | 1/8 To 5/16 (1 To 8) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| DLX, Reg. Cab |
| Long Chassis (A/T) |
| Camber (1) | 1/2 | 1/4 To 1 1/4 |
| Caster (1) | 9/16 | 3/16 To 1 5/16 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 3/16 (5) | 1/8 To 9/32 (3 To 7) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| Long Chassis (M/T) |
| Camber (1) | 1/2 | 1/4 To 1 1/4 |
| Caster (1) | 9/16 | 3/16 To 1 5/16 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 7/32 (5.5) | 1/8 To 5/16 (3 To 8) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| DLX, Xtra Cab |
| Xtra Long Chassis |
| Camber (1) | 3/8 | 3/8 To 1 1/8 |
| Caster (1) | 1 1/4 | 1/2 To 2 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 1/8 (3) | 1/16 To 3/16 (1 To 5) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| SR5, Xtra Cab |
| Xtra Long Chassis |
| Camber (1) | 13/32 | 11/32 To 1 5/32 |
| Caster (1) | 1 7/32 | 15/32 To 2 |
| Steering Axis Inclination (1) | 10 | 9 1/4 To 10 3/4 |
| Toe-In (2) | 1/8 (3) | 1/16 To 3/16 (1 To 5) |
| Toe-Out On Turns (1) |
| Inner | 34 | 32-35 |
| Outer | 30 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). (3) C & C DRW is Cab and Chassis with Dual Rear Wheels. |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
| (3) | C & C DRW is Cab and Chassis with Dual Rear Wheels. |
WHEEL ALIGNMENT SPECIFICATIONS (PICKUP 2WD)
| Application | Preferred | Range |
|---|
| 4-Cylinder |
| All Long Chassis |
| Camber (1) | 11/16 | 1/16 To 1 7/16 |
| Caster (1) | 1 11/16 | 15/16 To 2 7/16 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| DLX, Reg. Cab |
| Standard Chassis |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| A/T | 1 29/32 | 15/16 To 2 7/16 |
| M/T | 1 5/8 | 7/8 To 2 3/8 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| DLX, Xtra Cab |
| Xtra Long Chassis |
| Camber (1) | 21/32 | 3/32 To 1 13/32 |
| Caster (1) |
| A/T | 1 7/8 | 1 1/8 To 2 5/8 |
| M/T | 1 13/16 | 1 1/16 To 2 9/16 |
| Steering Axis Inclination (1) | 11 29/32 | 11 5/32 To 12 21/32 |
| Toe-In (2) | 3/32 (2.5) | 0 To 3/16 (0 To 5) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| V6 |
| All Reg. Cab |
| Short Chassis |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) | 1 11/16 | 15/16 To 2 7/16 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| Long Chassis |
| Camber (1) | 11/16 | 1/16 To 1 7/16 |
| Caster (1) | 1 3/4 | 1 To 2 1/2 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| DLX, Xtra Cab |
| Xtra Long Chassis |
| Camber (1) | 21/32 | 3/32 To 1 13/32 |
| Caster (1) | 1 7/8 | 1 1/8 To 2 5/8 |
| Steering Axis Inclination (1) | 11 29/32 | 11 5/32 To 12 21/32 |
| Toe-In (2) | 3/32 (2.5) | 0 To 3/16 (0 To 5) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| SR5, Xtra Cab |
| Xtra Long Chassis |
| Camber (1) | 11/16 | 1/16 To 1 7/16 |
| Caster (1) |
| M/T | 1 29/32 | 1 5/32 To 2 21/32 |
| A/T | 1 15/16 | 1 3/16 To 2 11/16 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2.5) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (PICKUP 4WD)
| Application | Preferred | Range |
|---|
| 2WD |
| Camber (1) | 0 | 3/4 To 3/4 |
| Caster (1) | 5 1/2 | 4 3/4 To 6 1/4 |
| Steering Axis Inclination (1) | 10 19/32 | 9 27/32 To 11 11/32 |
| Toe-In (2) | 3/32 (2) | 1/32 To 1/8 (1 To 3) |
| Toe-In (1) | 3/16 | 1/16 To 1/4 |
| Toe-Out On Turns (1) |
| Inner | 36 | N/A |
| Outer | 33 | N/A |
| 4WD |
| Camber (1) | 1/4 | 1/2 To 1 |
| Caster (1) | 5 5/16 | 4 9/16 To 6 1/16 |
| Steering Axis Inclination (1) | 10 11/32 | 9 19/32 To 11 3/32 |
| Toe-In (2) | 1/8 (3) | 3/32 To 5/32 (2 To 4) |
| Toe-Out On Turns (1) |
| Inner | 36 | N/A |
| Outer | 33 1/2 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (PREVIA)
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 3/16 | 11/16 To 5/16 |
| Rear | 3/4 | 1 1/4 To -1/4 |
| Caster (1) | 7 11/16 | 7 3/16 To 8 3/16 |
| Steering Axis Inclination (1) | 10 29/32 | 10 5/32 To 11 21/32 |
| Toe-In (2) |
| Front | 0 (0) | 1/32 To 1/32 (-1 To 1) |
| Rear | 5/32 (4) | 1/8 To 3/16 (3 To 5) |
| Toe-In (1) |
| Front | 0 | 1/16 To 1/16 |
| Rear | 5/16 | 1/4 To 3/8 |
| Toe-Out On Turns (1) |
| Inner | 34 1/2 | N/A |
| Outer | 31 3/4 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (SUPRA)
| Application | Preferred | Range |
|---|
| Camber (1) |
| Front | 1/4 | 1 To 1/2 |
| Rear | 1/2 | 1 1/4 To 1/4 |
| Caster (1) | 1 1/4 | 1/2 To 2 |
| Steering Axis Inclination (1) | 12 | 11 1/4 To 12 3/4 |
| Toe-In (2) |
| Front | 1/32 (1) | 1/32 To 1/8 (-1 To 3) |
| Rear | 1/8 (3) | 0 To 1/4 (0 To 6) |
| Toe-In (1) |
| Front | 3/32 | 3/32 To 5/16 |
| Rear | 1/4 | 0 To 1/2 |
| Toe-Out On Turns (1) |
| Inner | 36 5/32 | N/A |
| Outer | 32 1/4 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (TERCEL)
| Application | Preferred | Range |
|---|
| 2WD |
| SR5 4-Door A/T |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| 4-Cylinder | 1 29/32 | 1 5/32 To 2 5/8 |
| V6 | 1 15/16 | 1 3/16 To 2 11/16 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| 4WD |
| SR5 4-Cylinder |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| 2-Door | 1 31/32 | 1 7/32 To 2 23/32 |
| 4-Door | 2 | 1 9/32 To 2 25/32 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| SR5 V6 |
| 2-Door (A/T) |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| P225/75R15 | 1 27/32 | 1 3/32 To 2 19/32 |
| 31 x 10.5R15 | 1 7/8 | 1 1/8 To 2 5/8 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| 2-Door (M/T) |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| P225/75R15 | 1 13/16 | 1 1/16 To 2 9/16 |
| 31 x 10.5R15 | 1 27/32 | 1 3/32 To 2 19/32 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| 4-Door (A/T) |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| P225/75R15 | 1 21/32 | 29/32 To 2 13/32 |
| 31 x 10.5R15 | 1 23/32 | 31/32 To 2 15/32 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| 4-Door (M/T) |
| Camber (1) | 23/32 | 1/32 To 1 15/32 |
| Caster (1) |
| P225/75R15 | 1 11/16 | 15/16 To 2 7/16 |
| 31 x 10.5R15 | 1 23/32 | 31/32 To 2 15/32 |
| Steering Axis Inclination (1) | 11 7/8 | 11 1/8 To 12 5/8 |
| Toe-In (2) | 3/32 (2) | 0 To 5/32 (0 To 4) |
| Toe-Out On Turns (1) |
| Inner | 32 | 30-33 |
| Outer | 31 | N/A |
| (1) Measurement in degrees. (2) Measurement in inches (mm). |
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS (4RUNNER)
TORQUE SPECIFICATIONS (PASSENGER
| Application | Ft. Lbs. (N.m) |
|---|
| Camry |
| Rear Toe Adjustment Cams | 83 (113) |
| Stabilizer Bar Bracket Nuts | 94 (127) |
| Stabilizer Bar-To-Lower Arm | 156 (212) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| Celica |
| Rear Toe Adjustment Cams | 83 (113) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| Corolla |
| Rear Toe Adjustment Cams | 80 (108) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| Cressida |
| Rear Lower Suspension Arm No. 2 Adjustment Cams | 134 (181) |
| Strut Rod-To-Bracket Nuts | 94 (127) |
| Strut Rod-To-Lower Arm Nuts | 76 (103) |
| Tie Rod Lock Nuts | 41 (56) |
| Wheel Lug Nuts | 76 (103) |
| MR2 |
| Strut Bar Front Nut | 83 (113) |
| Tie Rod (Sleeve) Lock Nuts | 35 (47) |
| Wheel Lug Nuts | 76 (103) |
| Supra |
| Front Suspension Adjustment Cams | 177 (240) |
| Rear Lower Susp. Arm No. 1 & 2 Adjustment Cams | 136 (184) |
| Tie Rod Lock Nuts | 14 (19) |
| Wheel Lug Nuts | 76 (103) |
| Tercel |
| Tie Rod Lock Nuts | 35 (57) |
| Wheel Lug Nuts | 76 (103) |
TORQUE SPECIFICATIONS (PASSENGER
TORQUE SPECIFICATIONS (LIGHT TRUCKS)
| Application | Ft. Lbs. (N.m) |
|---|
| Land Cruiser |
| Steering Knuckle Stopper Bolts | 33 (44) |
| Tie Rod Lock Nuts | 27 (37) |
| Wheel Lug Nuts | 116 (157) |
| Pickup (2WD) |
| Steering Knuckle Stopper Bolts | 25 (34) |
| Tie Rod Lock Nuts | 19 (25) |
| Upper Control Arm Bolts | 71 (96) |
| Wheel Lug Nuts |
| Dual Rear Wheel | 170 (230) |
| Single Rear Wheel | 101 (137) |
| Pickup (4WD) & 4Runner |
| Front Suspension Adjustment Cams | 145 (196) |
| Steering Knuckle Stopper Bolts | 35 (47) |
| Tie Rod Lock Nuts | 19 (25) |
| Wheel Lug Nuts | 76 (103) |
| Previa |
| Steering Knuckle Stopper Bolts | 24 (33) |
| Tie Rod Lock Nuts | 67 (91) |
| Wheel Lug Nuts | 76 (103) |
TORQUE SPECIFICATIONS (LIGHT TRUCKS)
