Electrical Component Locator Toyota 4Runner II

Electrical Component Locations 11 illustrations ~146 words

BUZZERS, RELAYS & TIMERS

ComponentLocation
A/C Cut-Off RelayOn evaporator case.
Anti-Lock Brake Solenoid RelayIn right rear corner of engine compartment.
Antenna RelayBehind upper left side of dash. (Scheme 1)
Back Door Power Door/Window & Wiper Relay (4Runner)Behind left rear trim panel. (Scheme 2)
Back-Up Relay (Pickup)On fuse/relay block No. 1. (Scheme 3)
Clutch/Starter RelayOn fuse/relay block No. 1.
Rear Window Defogger Relay (4Runner)In fuse/relay block No. 2. (Scheme 3)
EFI Circuit Opening RelayBehind right side of dash, above ECU. (Scheme 4)& (Scheme 5).
EFI Main RelayIn fuse/relay block No. 2. (Scheme 4)& (Scheme 5).
Headlight RelayIn fuse/relay block No. 2. (Scheme 4)
Heater Relay
Front (Pickup & 4Runner)In fuse/relay block No. 3. (Scheme 6)
Rear (4Runner)In fuse/relay block No. 3. (Scheme 6)
Integration RelayBehind left kick panel. (Scheme 7)
Light Reminder RelayUnder center of dash. (Scheme 7)
Main RelayBehind left kick panel. (Scheme 8)
Moon Roof Relay (4Runner)In fuse/relay block No. 1. (Scheme 3)
Power Door/Window Relay (Pickup)In fuse/relay block No. 1. (Scheme 3)
Starter RelayIn fuse/relay block No. 1. (Scheme 3)
Taillight Control RelayIn fuse/relay block No. 1. (Scheme 3)& (Scheme 7).
Turn Signal/Flasher RelayBehind left side of dash, near steering column.
Wiper Relay (4Runner)Under right side of dash.

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

ComponentLocation
Circuit Breakers (4Runner)
HeaterIn fuse/relay block No. 3. (Scheme 6)
Power Door/Window LockIn fuse/relay block No. 1. (Scheme 3)
Fuse/Relay Block No. 1Under left side of dash. (Scheme 3)& (Scheme 9).
Fuse/Relay Block No. 2On front right corner of engine compartment. (Scheme 9)
Fuse/Relay Block No. 3Behind glove box. (Scheme 6)& (Scheme 9).
Fuse/Relay Block No. 4Next to fuse relay block No. 2. (Scheme 9)
Fusible LinksOn fuse/relay block No. 2.
Main Fusible LinkOn positive battery cable. (Scheme 9)

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

ComponentLocation
Anti-Lock Brake Control UnitBehind dash, above glove box.
Cruise Control ComputerBehind left kick panel. (Scheme 8)
ECT Control UnitBehind right front kick panel. (Scheme 10)
Electronic Control Unit (ECU)Behind right kick panel. (Scheme 4)& (Scheme 5).
Shift Lock Control UnitUnder shift lever console. (Scheme 11)

CONTROL UNITS LOCATION

SENDING UNITS & SENSORS

ComponentLocation
A/C ThermistorIn evaporator case.
Airflow MeterIn front of air cleaner assembly.
Coolant Temperature Sensor (CTS)
4-CylinderOn right side of engine, in coolant outlet flange. (Scheme 4)
V6In coolant passage at rear of intake manifold. (Scheme 5)& (Scheme 10).
Deceleration SensorBehind center of dash.
Evaporator Temperature SensorOn top of evaporator housing.
Exhaust Gas (EGR) Temperature Sensor
4-CylinderNear EGR valve. (Scheme 4)
V6Near EGR valve. (Scheme 5)
Fuel Gauge Sending UnitIn fuel tank.
Knock SensorUnder Intake Runner.
Oil Pressure Sending UnitOn left lower front side of engine block.
Oxygen Sensor
4-CylinderIn exhaust manifold.
V6In exhaust pipe, near catalytic converter. (Scheme 5)
Speed Sensors
No. 1On back of speedometer. (Scheme 10)
No. 2On left rear of transmission. (Scheme 10)
No. 3On top of rear differential.
Throttle Position SensorOn side of throttle body. (Scheme 10)
Transmission Fluid Temperature Sensor
No. 1On right front of transmission case. (Scheme 10)
No. 2On right rear of transmission case. (Scheme 10)

SENDING UNITS & SENSORS LOCATION

MOTORS

ComponentLocation
Cruise Control Vacuum PumpUnder cruise control actuator.
Fuel Pump MotorIn fuel tank.
Power Window MotorIn left side of tailgate. (Scheme 2)

MOTORS LOCATION

SOLENOIDS & SOLENOID VALVES

ComponentLocation
Cold Start InjectorOn intake chamber.
Ignition Key Interlock SolenoidBehind ignition switch. (Scheme 11)
Lock-Up Solenoid (A/T)In transmission valve body. (Scheme 10)
Shift Solenoids (A/T) No. 1, 2 & 4In transmission valve body. (Scheme 10)
Shift Lock Solenoids (A/T)Under center console, by shift lever. (Scheme 11)

SOLENOIDS & SOLENOID VALVES LOCATION

SWITCHES

ComponentLocation
A/C Dual Pressure SwitchOn evaporator case.
Back Door (4Runner)
Control SwitchIn tailgate. (Scheme 2)
Lock Detection Switches (2)In tailgate. (Scheme 2)
Power Door Window SwitchIn center console. (Scheme 2)
Rear Window Limit SwitchIn left side of tailgate. (Scheme 2)
Rear Window Lock SwitchIn center console. (Scheme 2)
Unlock Warning SwitchIn tailgate. (Scheme 2)
Back-Up Light SwitchOn right side of transmission.
Brake Fluid Level Warning SwitchInside brake master cylinder.
Clutch SwitchOn bracket, above clutch pedal. (Scheme 8)
Cold Start Injector Time Switch
4-Cyl.On right side of engine block, in coolant passage. (Scheme 4)
V6In coolant passage, at rear of intake manifold. (Scheme 5)
Hazard Warning SwitchIn upper right side of instrument panel. (Scheme 7)
Neutral Start Switch (A/T)On right side of transmission. (Scheme 8)& (Scheme 10).
Oil Pressure SwitchOn left front side of engine block.
Overdrive (O/D) Main SwitchOn shifter assembly. (Scheme 10)
Parking Brake SwitchAt rear of brake lever mounting bracket. (Scheme 8)
Seat Belt SwitchOn driver's side buckle.
Stoplight SwitchOn bracket, above brake pedal. (Scheme 8), (Scheme 10) & (Scheme 11).
Transmission Shift Position SwitchUnder shift selector console.
Transfer Case Shift Position SwitchOn right side of transfer case. (Scheme 5)

SWITCHES LOCATION

MISCELLANEOUS

ComponentLocation
A/C AmplifierOn evaporator housing.
A/C-Heater Blower Motor ResistorOn left side of blower housing.
Diagnostic ConnectorBehind fuse/relay block No. 2. (Scheme 5)

MISCELLANEOUS LOCATION

COMPONENT LOCATION GRAPHICS

Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.

Component Locations (1 Of 11). Scheme 1

Scheme 1: Component Locations (1 Of 11)

Component Locations (2 Of 11). Scheme 2

Scheme 2: Component Locations (2 Of 11)

Component Locations (3 Of 11). Scheme 3

Scheme 3: Component Locations (3 Of 11)

Component Locations (4 Of 11). Scheme 4

Scheme 4: Component Locations (4 Of 11)

Component Locations (5 Of 11). Scheme 5

Scheme 5: Component Locations (5 Of 11)

Component Locations (6 Of 11). Scheme 6

Scheme 6: Component Locations (6 Of 11)

Component Locations (7 Of 11). Scheme 7

Scheme 7: Component Locations (7 Of 11)

Component Locations (8 Of 11). Scheme 8

Scheme 8: Component Locations (8 Of 11)

Component Locations (9 Of 11). Scheme 9

Scheme 9: Component Locations (9 Of 11)

Component Locations (10 Of 11). Scheme 10

Scheme 10: Component Locations (10 Of 11)

Component Locations (11 Of 11). Scheme 11

Scheme 11: Component Locations (11 Of 11)
