Fastener Tightening Specifications - Wheel Alignment
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Strut to Knuckle Nut and Bolt | 200 N.m | 148 lb ft |
| Tie Rod Jam Nut | 60 N.m | 44 lb ft |
FASTENER TIGHTENING SPECIFICATIONS
Wheel Alignment Specifications
| Suspension | Camber | Camber Cross Tolerance | Caster | Caster Cross Tolerance | Total Toe | Steering Wheel Angle | Thrust Angle |
|---|---|---|---|---|---|---|---|
| Front | 0.6°± 0.75° | 0.0 ± 0.75° | 3.00°± 0.75° | 0.0°± 0.75° | +0.15°± 0.20° | 0.00°± 3.0° | |
| Rear | 0.5°± 0.75° | 0.0°± 0.75° | +0.2°± 0.20° | 0.0°± 0.35° |
ALIGNMENT SPECIFICATIONS TABLE
SPECIAL TOOLS Illustration Tool Number/Description J 42188-B Ball Joint Separator J 42991 Strut Rod Nut Socket J 43631 Ball Joint Remover J 45400 Strut Spring Compressor
