Compass Calibration
Before calibrating the compass, drive the vehicle to an open area that is magnetically clean or free of large metallic objects such as high tension power lines or large steel buildings. Verify there are no magnetized roof antennas, magnets on or hanging from the mirror, or any other magnetized objects on the inside or outside of the vehicle close to the mirror.
- Start the engine. NOTE: Before calibrating the compass, make sure the mirror has the correct zone number. Refer to «COMPASS MAGNETIC VARIATION ADJUSTMENT»(ref-268409-S28198797502007102300000) mentioned below.
- Press and hold the switch for the compass, which may be depicted as COMP, COMPASS, or on/off (w/UE1) depending on the type of mirror on the vehicle, until the letter "C" or "CAL" is displayed.
- Drive the vehicle in circles at a speed of less than 8 km/h (5 mph) until the "C" or "CAL" is replaced by a proper vehicle heading. The calibration procedure is now complete.
Compass Magnetic Variation Adjustment
Magnetic variation adjustments are required when the compass displays a constant error in heading. Variation is the difference between magnetic north and true north due to geographical location.
Scheme 1
- Locate your current geographic location on the World Magnetic Variation Map.
- Turn ON the ignition, with the engine OFF.
- Press and hold the on/off switch for the compass until a zone number appears on the compass display.
- Depress the switch for the compass to select the desired zone number.
- Wait 5 seconds. The display will return to a compass heading. The variance procedure is now complete.
- Calibrate the compass. Refer to «COMPASS CALIBRATION»(ref-268409-S32862783262007102300000) mentioned above.
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Connector Part Information
OEM: 7123-5014-30
Service: 88988465
Description: 1-Way F (BK)
Terminal Part Information
Terminal/Tray: 7116-2951-02/27
Core/Insulation Crimp: C/B
Release Tool/Test Probe: 12094430/J-35616-42 (RD)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | PU | 293 | Rear Defog Element Supply Voltage |
REAR DEFOGGER GRID C1 - CONNECTOR TERMINAL INFORMATION
Scheme 7
Connector Part Information
OEM: 7123-5014-30
Service: 88988465
Description: 1-Way F (BK)
Terminal Part Information
Terminal/Tray: 7116-2951-02/27
Core/Insulation Crimp: C/D
Release Tool/Test Probe: 12094430/J-35616-42 (RD)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BK | 550 | Ground |
REAR DEFOGGER GRID C2 - CONNECTOR TERMINAL INFORMATION
Scheme 8
Connector Part Information
OEM: 7283-5565-40
Service
Description: 2-Way F YESC/USCAR Series (L-GY)
Terminal Part Information
Terminal/Tray: See Suzuki Terminal Repair Kit
Core/Insulation Crimp: See Suzuki Terminal Repair Kit
Release Tool/Test Probe: See Suzuki Terminal Repair Kit
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BN | 165 | Power Window Motor Left Front Down Control |
| 2 | D-BU | 164 | Power Window Motor Left Front Up Control |
WINDOW MOTOR DRIVER CONNECTOR TERMINAL INFORMATION
Scheme 9
Connector Part Information
OEM: 7283-5565-40
Service
Description: 2-Way F YESC/USCAR Series (L-GY)
Terminal Part Information
Terminal/Tray: See Suzuki Terminal Repair Kit
Core/Insulation Crimp: See Suzuki Terminal Repair Kit
Release Tool/Test Probe: See Suzuki Terminal Repair Kit
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BN | 167 | Power Window Master Switch Right Front Down Signal |
| 2 | D-BU | 166 | Power Window Master Switch Right Front Up Signal |
WINDOW MOTOR FRONT PASSENGER CONNECTOR TERMINAL INFORMATION
Scheme 10
Connector Part Information
OEM: 7283-5565-40
Service
Description: 2-Way F YESC/USCAR Series (L-GY)
Terminal Part Information
Terminal/Tray: See Suzuki Terminal Repair Kit
Core/Insulation Crimp: See Suzuki Terminal Repair Kit
Release Tool/Test Probe: See Suzuki Terminal Repair Kit
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BN | 669 | Power Window Motor Left Rear Down Control |
| 2 | D-BU | 668 | Power Window Motor Left Rear Up Control |
WINDOW MOTOR - LR CONNECTOR TERMINAL INFORMATION
Scheme 11
Connector Part Information
OEM: 7283-5565-40
Service
Description: 2-Way F YESC/USCAR Series (L-GY)
Terminal Part Information
Terminal/Tray: See Suzuki Terminal Repair Kit
Core/Insulation Crimp: See Suzuki Terminal Repair Kit
Release Tool/Test Probe: See Suzuki Terminal Repair Kit
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BN | 671 | Power Window Motor Right Rear Down Control |
| 2 | D-BU | 670 | Power Window Motor Right Rear Up Control |
WINDOW MOTOR - RR CONNECTOR TERMINAL INFORMATION
Scheme 12
Connector Part Information
OEM: 12191825
Service: 15306048
Description: 8-Way Metri-Pack 280 Series (BN)
Terminal Part Information
Terminal/Tray: 15304713/19
Core/Insulation Crimp: 4/4
Release Tool/Test Probe: 15315247/J-35616-4A (PU)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | D-BU | 1307 | Power Window Master Switch Lockout Signal |
| B | D-BU | 164 | Power Window Motor Left Front Up Control |
| C | BN | 165 | Power Window Motor Left Front Down Control |
| D | YE | 143 | Accessory Voltage |
| E | PU | 169 | Power Window Master Switch Left Rear Down Signal |
| F | BK | 650 | Ground |
| G | D-GN | 168 | Power Window Master Switch Left Rear Up Signal |
| H | D-BU | 1307 | Power Window Master Switch Lockout Signal |
WINDOW SWITCH CONSOLE DRIVER CONNECTOR TERMINAL INFORMATION
Scheme 13
Connector Part Information
OEM: 15326924
Service: 15306174
Description: 8-Way F GT 280 (BK)
Terminal Part Information
Terminal/Tray: 15304713/19
Core/Insulation Crimp: 4/4
Release Tool/Test Probe: 15315247/J-35616-4A (PU)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | Not Used | ||
| B | L-BU | 166 | Power Window Master Switch Right Front Up Signal |
| C | TN | 167 | Power Window Master Switch Right Front Down Signal |
| D | YE | 143 | Accessory Voltage |
| E | Not Used | ||
| F | L-GN | 170 | Power Window Master Switch Right Rear Up Signal |
| G | BK | 650 | Ground |
| H | PU | 171 | Power Window Master Switch Right Rear Down Signal |
WINDOW SWITCH CONSOLE PASSENGER CONNECTOR TERMINAL INFORMATION
Scheme 14
Connector Part Information
OEM: 6098-0245
Service
Description: 6-Way F HD Series (L-GY)
Terminal Part Information
Terminal/Tray: See Suzuki Terminal Repair Kit
Core/Insulation Crimp: See Suzuki Terminal Repair Kit
Release Tool/Test Probe: See Suzuki Terminal Repair Kit
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BN | 669 | Power Window Motor Left Rear Down Control |
| 2 | PU | 169 | Power Window Master Switch Left Rear Down Signal |
| 3 | Not Used | ||
| 4 | D-BU | 668 | Power Window Motor Left Rear Up Control |
| 5 | D-BU | 1307 | Power Window Master Switch Lockout Signal |
| 6 | D-GN | 168 | Power Window Master Switch Left Rear Up Signal |
WINDOW SWITCH LR CONNECTOR TERMINAL INFORMATION
Scheme 15
Connector Part Information
OEM: 6098-0245
Service
Description: 6-Way F HD Series (L-GY)
Terminal Part Information
Terminal/Tray: See Suzuki Terminal Repair Kit
Core/Insulation Crimp: See Suzuki Terminal Repair Kit
Release Tool/Test Probe: See Suzuki Terminal Repair Kit
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | BN | 671 | Power Window Motor Right Rear Down Control |
| 2 | PU | 171 | Power Window Master Switch Right Rear Down Signal |
| 3 | Not Used | ||
| 4 | D-BU | 670 | Power Window Motor Right Rear Up Control |
| 5 | D-BU | 1307 | Power Window Master Switch Lockout Signal |
| 6 | D-GN | 170 | Power Window Master Switch Right Rear Up Signal |
WINDOW SWITCH RR CONNECTOR TERMINAL INFORMATION
Scheme 16
Connector Part Information
OEM: 12052642
Service: 12101856
Description: 2-Way F Metri-Pack 150 Series, Sealed (L-GN)
Terminal Part Information
Terminal/Tray: 12048074/2
Core/Insulation Crimp: E/1
Release Tool/Test Probe: 12094429/J-35616-2A (GY)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | L-GN/BK | 735 | Ambient Air Temperature Sensor Signal |
| B | YE | 61 | Low Reference |
AMBIENT AIR TEMPERATURE SENSOR CONNECTOR TERMINAL INFORMATION
Compass Calibration and Variance Procedures
When the inside rearview mirror with compass is replaced, the compass must be setup utilizing the COMPASS CALIBRATION AND MAGNETIC VARIANCE .
