Starting and Charging Schematics

Note. The following figures represent OEM-style wiring diagrams. For redrawn wiring diagrams, see appropriate WIRING DIAGRAM in ELECTRICAL section.

Scheme 11: Starting and Charging Schematics

Scheme 13: Battery Current Sensor

Connector Part Information

OEM: 13519047

Service

Description: 3-Way F GT 150 Sealed (BK)

Terminal Part Information

Terminal/Tray: 12191819/8

Core/Insulation Crimp: E/A

Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire Color	Circuit No.	Function
A	PK	5076	Current Sensor Supply Voltage
B	BN	5077	Current Sensor Low Reference
C	WH	5075	Seat Position Switch Low Reference

BATTERY SENSOR CONNECTOR PIN TERMINAL

Scheme 14: Generator

Connector Part Information

OEM: 12186308

Service: 89046837

Description: 2-Way F JPT, Sealed (BK)

Terminal Part Information

Terminal/Tray: 4-964286-1/16

Core/Insulation Crimp: E/1

Release Tool/Test Probe: 12093647/J-35616-4A (PU)

Pin	Wire Color	Circuit No.	Function
1	OG	225	Generator Turn On Signal
2	GY	23	Generator Field Duty Cycle Signal

GENERATOR CONNECTOR PINS

Scheme 15: Engine Electrical Component Views
