Steering Wheel and Column: Specifications Suzuki XL7 I

Ignition Switch/steering Lock 1 illustration

Fastener Tightening Specifications - Wiring Systems and Power Management

ApplicationSpecification
MetricEnglish
Ignition/Start Switch Bolt2 N.m18 lb in

FASTENER TIGHTENING SPECIFICATIONS - WIRING SYSTEMS AND POWER MANAGEMENT

ApplicationSpecification
MetricEnglish
Anti-Rotation Bracket Bolt5 N.m44 lb in
Intermediate Steering Shaft Bolt34 N.m25 lb ft
Intermediate Steering Shaft Lower Bolt34 N.m25 lb ft
Steering Column Lower Trim Cover Screw2.5 N.m22 lb in
Steering Column Lower Support Bracket Bolt25 N.m18 lb ft
Steering Column Upper Support Bracket Bolt25 N.m18 lb ft
Steering Wheel Nut37 N.m27 lb ft

FASTENER TIGHTENING SPECIFICATIONS - STEERING WHEEL AND COLUMN (TILT)

SPECIAL TOOLS - STEERING WHEEL AND COLUMN (TILT) Illustration Tool Number/Description J 1859A Steering Wheel Puller J 42578 Steering Wheel Puller Legs

Scheme 1

Scheme 1: Special Tools - Steering Wheel and Column - Tilt
Scheme 1: Special Tools - Steering Wheel and Column - Tilt
