Instrument cluster — Instrument cluster circuit Suzuki X-90 I
All systems — 22 systems
- Air conditioning 3
- Anti-lock brakes
- Computer data lines
- Cruise control
- Defoggers
- Engine performance 1.6l 4
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights
- Power distribution
- Power door locks
- Power windows
- Radio
- Shift interlocks 2
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Warning systems
- Wiper/washer
Components on these wiring diagrams 20
Click a component to highlight it on every diagram it appears on.
