UNDERHOOD FUSE PANEL IDENTIFICATION
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Scheme 1
Fuse & Circuit Breaker Identification
- BATT - 80 Amp All Elecrtic Loads
- ABS - 50 Amp Anti-Lock Brake System
- IG - 60 Amp Cigarette Lighter, Radio, Ignition Coil, Gauges, Wiper/Washer, Rear Defroster, Turn Signals, Back-Up Lights & Heater
- LAMP - 30 Amp Tail/Dome, Stop/Horn Hazard
- HEAD R - 15 Amp Right Side Headlamp
- HEAD L - 15 Amp Left Side Headlamp High Beam Indicator
- FI - 15 Amp Electronic Fuel Injection System
- A/C - 25 Amp Air Conditioning
UNDERDASH FUSE PANEL IDENTIFICATION
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Scheme 2
- TAIL/DOME - 15 Amp Dome Lamp, Rear Clearance/Rear Marker, License Plate Lamp Front Clearance/Front Marker, Instrument Panel Illumination
- STOP/HORN - 15 Amp Stop Lamp, Dome
- HAZARD - 15 Amp Hazard
- DOOR LOCK - 20 Amp Door Lock Control
- CIGAR RADIO - 20 Amp Cigar Lighter, Radio
- IG COIL/METER - 15 Amp Ignition Coil, Distributor, Fuel Gage, Engine Coolant Temperature Gage, Fuel Injection Controller, Indicator lights
- TURN/BACK - 15 Amp Turn Signal Flasher, Back Up Lamp
- WIPER/WASHER - 15 Amp Front Wiper & Washer, Rear Wiper & Washer
- REAR DEFG - 15 Amp Rear Defogger
- HEATER - 25 Amp Heater Control
