POWER MIRROR SWITCH
Remove power mirror switch from instrument panel. Ensure continuity exists between appropriate power mirror switch terminals with switch in appropriate position. See appropriate POWER MIRROR SWITCH CONTINUITY TEST (LEFT) or POWER MIRROR SWITCH CONTINUITY TEST (RIGHT). (Scheme 1) If continuity does not exist, replace power mirror switch.
| Switch Position | Terminals No. |
|---|---|
| Up | 1 & 5; 2 & 3 |
| Down | 1 & 2; 3 & 5 |
| Left | 1 & 6; 2 & 3 |
| Right | 1 & 2; 3 & 6 |
POWER MIRROR SWITCH CONTINUITY TEST (LEFT)
| Switch Position | Terminals No. |
|---|---|
| Up | 1 & 4; 2 & 3 |
| Down | 1 & 2; 3 & 4 |
| Left | 1 & 7; 2 & 3 |
| Right | 1 & 2; 3 & 7 |
POWER MIRROR SWITCH CONTINUITY TEST (RIGHT)
Scheme 1
POWER MIRROR MOTOR
Disconnect power mirror harness connector. Using 12-volt power source, connect positive and negative leads to specified terminals. See appropriate POWER MIRROR MOTOR TEST (LEFT) or POWER MIRROR MOTOR TEST (RIGHT). (Scheme 2) If power mirror motor does not operate as specified, replace power mirror assembly.
| Apply 12 Volts To Terminal No. | Ground Terminal No. | Mirror Operation |
|---|---|---|
| 1 | 3 | Up |
| 3 | 1 | Down |
| 2 | 3 | Left |
| 3 | 3 | Right |
POWER MIRROR MOTOR TEST (LEFT)
| Apply 12 Volts To Terminal No. | Ground Terminal No. | Mirror Operation |
|---|---|---|
| 5 | 7 | Up |
| 7 | 5 | Down |
| 6 | 7 | Left |
| 7 | 6 | Right |
POWER MIRROR MOTOR TEST (RIGHT)
