Fuses & Circuit Breakers: Other Suzuki X-90 I

Fuses & Circuit Breakers 2 illustrations

DRIVER'S UNDER-DASH FUSE BOX

Note. Driver's under-dash fuse box is located under driver's side of instrument panel..

Scheme 1

Scheme 1: DRIVER'S UNDER-DASH FUSE BOX
Scheme 1: DRIVER'S UNDER-DASH FUSE BOX
FuseSystem
TAIL/DOME15ADome Lamp, Rear Clearance/Rear Marker, License Plate Lamp, Front Clearance/Front Marker, Instrument Panel Illumination
STOP/HORN15AStop Lamp, Horn
HAZARD15AHazard
DOOR LOCK20ADoor Lock Control
CIGAR RADIO20ACigar Lighter, Radio
I.G. COIL/METER15AIgnition Coil, Distributor, Fuel Gauge, Engine Coolant Temperature gauge, Fuel Injection Controller, Indicators: Oil/Temp./Fuel/Brake/Charging/Fasten Seat Belts/Malfunction/Four Wheel Drive
TURN/BACK15ATurn Signal Flasher, Back Up Lamp
WIPER/WASHER15AFront Wiper and Washer/Rear Wiper and Washer
REAR DEFG25ARear Defogger
HEATER15AHeater Control
FOG15AFog Lights
SEAT HEATER15ASeat Heater

Under-Dash Fuse Box Fuses

UNDER-HOOD FUSE BOX

Note. Under-hood fuse box is located in right side of engine compartment.

Scheme 2

Scheme 2: UNDER-HOOD FUSE BOX
Scheme 2: UNDER-HOOD FUSE BOX
FuseSystem
BATT80AAll Electrical Loads
ABS50AAnti-Lock Brake System
IG60ACIGAR/RADIO, I.G. COIL/METER, WIPER/WASHER, REAR DEF, TURN/BACK, HEATER
LAMP30ATAIL/DOME, STOP/HORN, HAZARD
HEAD-R15ARight Side Headlamp
HEAD-L15ALeft Side Headlamp, High Beam Indicator
FI15AElectronic Fuel Injection System
A/C25AAir Conditioning

Under-Hood Fuse Box Fuses
