COOLING SYSTEM SPECIFICATIONS
| Application | Specification |
|---|
| Cooling System Capacity (1) |
| Esteem | 4.4 Qts. (4.2L) |
| Sidekick (1.6L) |
| Automatic Transmission | 5.5 Qts. (5.2L) |
| Manual Transmission | 5.6 Qts. (5.3L) |
| Sidekick (1.8L) | 8.4 (8.0) |
| Swift | 4.9 Qts. (4.7L) |
| X90 |
| Automatic Transmission | 5.5 Qts. (5.2L) |
| Manual Transmission | 5.6 Qts. (5.3L) |
| Pressure Cap |
| All Models | 12.5 psi (.88 kg/cm 2 ) |
| Thermostat |
| Esteem & Swift |
| Thermostat Starts To Open | 185-195°F (85.2-90.8°C) |
| Thermostat Fully Opens | 207-217°F (97.2-102.8) |
| Sidekick & X90 |
| Thermostat Starts To Open | 177-182°F (80.5-83.5°C) |
| Thermostat Fully Opens | 200.3-205.7°F (93.5-96.5) |
| (1) Includes engine, radiator, reservoir tank and heater core. |
| (1) | Includes engine, radiator, reservoir tank and heater core. |
COOLING SYSTEM SPECIFICATIONS
Electric Cooling Fan System Wiring Diagram (1997 Esteem). Scheme 1
Scheme 1: Electric Cooling Fan System Wiring Diagram (1997 Esteem)
Electric Cooling Fan System Wiring Diagram (1997 Sidekick & X90). Scheme 2
Scheme 2: Electric Cooling Fan System Wiring Diagram (1997 Sidekick & X90)
Electric Cooling Fan System Wiring Diagram (1997 Swift). Scheme 3
Scheme 3: Electric Cooling Fan System Wiring Diagram (1997 Swift)
Electric Cooling Fan System Wiring Diagram (1998 Esteem). Scheme 4
Scheme 4: Electric Cooling Fan System Wiring Diagram (1998 Esteem)
Electric Cooling Fan System Wiring Diagram (1998 Swift). Scheme 5
Scheme 5: Electric Cooling Fan System Wiring Diagram (1998 Swift)
