WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES
Note. See appropriate SPECIFICATIONS & PROCEDURES article in WHEEL ALIGNMENT.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| ABS Wheel Speed Sensor | 17 (23) | |
| Axle Shaft Drive Flange | 37 (50) | |
| Ball Joint Stud Castle Nut | 41 (55) | |
| Caliper Bolt | 62 (84) | |
| Lower Control Arm-To-Crossmember Bolt | ||
| Front | 62 (84) | |
| Rear | 92 (127) | |
| Spindle-To-Knuckle Bolt | 37 (50) | |
| Stabilizer Bar | ||
| Ball Joint-To-Bar Nut | 37 (50) | |
| Ball Joint-To-Control Arm Nut | 21 (29) | |
| Bracket Bolt | 17 (23) | |
| Strut Assembly-To-Body Nut | 41 (55) | |
| Strut Assembly-To-Steering Knuckle Nut | 70 (95) | |
| Strut Tower Bar Bolt | 37 (50) | |
| Tie Rod End Castle Nut | 28 (38) | |
| Wheel Bearing Nut | 157 (213) | |
| Wheel Lug Nut | 73 (100) | |
| Wheel Speed Sensor Bolt | 17 (23) | |
| INCH Lbs. (N.m) | ||
| Wheel Bearing Lock Washer Screw | 13 (1.5) | |
| (1) For additional information (Scheme 1) | ||
| (1) | For additional information (Scheme 1) |
TORQUE SPECIFICATIONS (1)
