Tightening Torque Specifications
| Fastening parts | Tightening torque | ||
|---|---|---|---|
| N.m | Kg-m | Lb-ft | |
| Tie-rod end nut | 48 | 4.8 | 35.0 |
| Wheel nut | 100 | 10.0 | 72.0 |
| Tie-rod end lock nut | 65 | 6.5 | 47.0 |
| Steering lower shaft bolt | 25 | 2.5 | 18.5 |
| Gear box high pressure pipe flare nut | 25 | 2.5 | 18.0 |
| Gear box cylinder pipe flare nut | 25 | 2.5 | 18.0 |
| Gear box mounting bolt | 55 | 5.5 | 40.0 |
| Gear box low pressure pipe union bolt | 40 | 4.0 | 29.0 |
| Tie-rod ball nut (for canvas top LH model) | 85 | 8.5 | 61.5 |
| Pump union bolt | 60 | 6.0 | 43.5 |
| Pump bracket bolt | 25 | 2.5 | 18.5 |
| Pump mounting bolt | 25 | 2.5 | 18.5 |
| Pipe clamp bolt / reservoir bracket bolt | 11 | 1.1 | 8.0 |
| Gear box high pressure pipe union bolt | 35 | 3.5 | 25.5 |
| High pressure flare nut | 40 | 4.0 | 29.0 |
| Gear box low pressure pipe union bolt | 40 | 4.0 | 29.0 |
| P/S pump cover bolt | 23 | 2.3 | 17.0 |
| Pressure switch | 28 | 2.8 | 20.5 |
| Plug | 60 | 6.0 | 43.5 |
| Suction connector bolt | 10 | 1.0 | 7.5 |
Torque Specifications
Scheme 1
Scheme 2
