FRONT FOG LIGHTS SYMPTOM DIAGNOSIS

2003 model , if equipped.

Scheme 12

Scheme 12: FRONT FOG LIGHTS SYMPTOM DIAGNOSIS

Scheme 13

Scheme 13: HEADLIGHTS COMPONENTS

HAZARD SWITCH INSPECTION

Use a circuit tester to check the continuity of each switch position.

If any continuity is not obtained replace switch.

Scheme 14

Scheme 14: HAZARD SWITCH INSPECTION

HAZARD RELAY ON-VEHICLE INSPECTION

Check that relay clicks continuously when battery and tester are connected as shown in figure. Unless a continued click sound is heard, replace relay.

Scheme 15

Scheme 15: HAZARD RELAY ON-VEHICLE INSPECTION

FRONT FOG LIGHT SWITCH INSPECTION

2003 model , if equipped.

Check for continuity between terminals at each switch position as shown below. If check result is not as specified, replace.

Scheme 16

Scheme 16: FRONT FOG LIGHT SWITCH INSPECTION

Note. Front fog lights light up only when headlight switch is in HEADLIGHT position (low or high beams) or SMALL position. Front fog lights turn OFF automatically when headlight switch is turned to OFF position. If front fog light switch holds ON position, front fog lights turn ON automatically when headlight switch is turned to HEADLIGHT position (low or high beams) or SMALL position again.
